Pi-hole smart home integration, free and open source

Pi-hole integration for Gladys Assistant

Pi-hole ad blocking: pause from the dashboard, 24 h statistics, update alerts.

View on GitHubAll external integrations

Follow and control the ad blocking of your Pi-hole from Gladys, over your local network: pause it for five minutes from the dashboard when a website breaks, see what it blocked over the last 24 hours, and know when it stops answering or when an update is out.

Developed without the hardware: feedback welcome. This integration was built and tested against the answers documented by Pi-hole (the OpenAPI specification of Pi-hole v6), not against a real server. If something does not work as described, please say so on the Gladys forum or in the issues.

What you need​

  • Gladys Assistant 5.1.0 or later (5.2.0 or later for the Pause… button of the widget).
  • Pi-hole v6 or later, reachable from Gladys. Pi-hole v5 is not supported: it is detected and reported in the Configuration screen.
  • An app password of your Pi-hole (recommended), or its web interface password, or nothing if your Pi-hole has no password.

To create an app password, open the Pi-hole web interface: Settings → Web interface / API, switch the page to Expert mode (top right), then Configure app password → Enable new app password. Copy the password shown: Pi-hole shows it only once. An app password also works when two-factor authentication is on, which the web interface password does not.

Set up​

  1. Install the integration from the Gladys catalog.
  2. In Configuration, enter the Address of your Pi-hole (for example 192.168.1.2, or https://192.168.1.2 for HTTPS), its App password, and optionally a Name. Two or three Pi-hole servers? Fill in the Second Pi-hole and Third Pi-hole sections too.
  3. Save, then click Test the connection: the message under the button says, for each server, whether it answers, its version and the state of its blocking.
  4. Open the Discover tab: one device per Pi-hole. Click Add, pick a room, save.

Options:

  • Accept self-signed certificates: Pi-hole v6 serves HTTPS with a certificate it signed itself. Tick it to use an https:// address; leave it off for http:// addresses.
  • Refresh interval: how often the servers are read, from 15 seconds to 5 minutes (1 minute by default).
  • Turning the blocking switch off: what the switch of the device does when you turn it off: pause the blocking for 5 minutes (default), 15, 30 or 60 minutes, or disable it until you turn it back on.
  • Language of the feature names: English, French, German or Spanish. The names are given when a device is added (French by default).

The device of each Pi-hole​

FeatureWhat it is
Ad blockingSwitch: on, the Pi-hole blocks; off, it lets everything through
DNS queries (24 h)Queries received over the last 24 hours
Blocked queries (24 h)Queries blocked over the last 24 hours
Share blocked (24 h)Share of the queries blocked, in %, rounded
Active clients (24 h)Devices that used the Pi-hole over the last 24 hours
Domains on blocklistsDomains on the blocklists of the Pi-hole
Updates availableNumber of Pi-hole parts with a newer version (0 when all are current)

The figures are those of the Pi-hole home page: a rolling window of the last 24 hours, not the calendar day. The badge of the device shows Local when the Pi-hole answers and Unreachable when it does not.

Dashboard​

Add the Pi-hole widget to a dashboard. By default it shows all your servers together; choose one in its settings to show only that one. Pausing a single Pi-hole out of two changes nothing: your devices then ask the other one.

The widget shows the queries, the blocked queries and the share blocked over the last 24 hours, the state of each server (blocking, paused with the minutes left, disabled, unreachable), the active clients, the domains on the blocklists and the available updates. Its buttons:

  • Pause 5 min and Pause 30 min: pause the blocking right away;
  • Pause…: opens a small form to type the duration in minutes (Gladys 5.2.0 or later; an older Gladys answers that it needs an update);
  • Resume: turns the blocking back on. It shows a check mark while the blocking is on everywhere.

Scenes​

Triggers​

  • Pi-hole blocking paused: the blocking was turned off, from Gladys or from elsewhere (the Pi-hole interface, the pihole disable command, another tool). Filter by Pi-hole and by origin (From Gladys or Outside Gladys). The actions can read the name of the Pi-hole and the length of the pause in minutes (duration_minutes, 0 when it has no end).
  • Pi-hole blocking resumed: the blocking is on again. The origin tells whether the pause ended on its own (End of the pause), from Gladys or from elsewhere; paused_minutes says how long it lasted.
  • Pi-hole update available: a new version of Pi-hole is out (core, FTL, web interface, or the Docker image when Pi-hole runs in Docker). Announced once per version, even across restarts. updates lists the new versions, for example Core v6.1.2, FTL v6.3.
  • Pi-hole no longer answers: a Pi-hole did not answer two reads in a row (the second one 15 seconds after the first). The DNS of your home may be down. error says why, in the language of the configuration.
  • Pi-hole answers again: it is back; down_minutes says after how long.

A refused password does not count as "no longer answers": the Configuration screen reports it.

Actions​

  • Pause Pi-hole blocking: pauses the blocking on one Pi-hole, or on all of them when the field is left empty, for a number of minutes (5 by default, 0 until resumed, one day at most). The following actions can read how many servers were paused.
  • Resume Pi-hole blocking: turns the blocking back on, on one Pi-hole or all of them.

The Ad blocking switch can also be used with the standard Gladys action that controls a device.

Scene ideas​

  • Safety net: a scene every evening at 20:00 with Resume Pi-hole blocking, so a switch turned off "until turned back on" never stays off all night.
  • DNS alert: Pi-hole no longer answers → send a message "Pi-hole {{triggerEvent.data.server}} does not answer: {{triggerEvent.data.error}}". And Pi-hole answers again → "back after {{triggerEvent.data.down_minutes}} min".
  • Who paused the blocking?: Pi-hole blocking paused with the origin Outside Gladys → send a message with the length of the pause.

Troubleshooting​

  • "password refused": check the app password. Creating a new app password in Pi-hole replaces the old one: copy the new one into Gladys.
  • "two-factor authentication is on": the web interface password needs a code from your phone; use an app password instead.
  • "certificate refused": you entered an https:// address; tick Accept self-signed certificates, or use the http:// address.
  • "the address redirects": your Pi-hole sends HTTP visitors to HTTPS; enter the https:// address and tick Accept self-signed certificates.
  • "no free API session": Pi-hole accepts a limited number of API sessions at once (16 by default). The integration keeps a single one per server and closes it when it stops; other tools may hold the rest. Pi-hole frees unused sessions after 30 minutes.
  • "Pi-hole v5 is not supported": update Pi-hole to version 6 (pihole -up).
  • "does not answer": check that http://<address>/admin opens from a computer on the network of Gladys. Names ending in .local usually do not work inside the integration: use the IP address.
  • Logs: on the page of the integration in Gladys, or docker logs on the host. They show the start, each server lost and back, the problems (once each, not at every reading) and your pause and resume commands. Start the container with LOG_LEVEL=debug to see every reading and every retry. Your password and the API session never appear in the logs.

Limits​

  • Pi-hole v6 only. One integration handles up to three Pi-hole servers.
  • The integration reads each server once per refresh interval (two small requests, plus the version check once an hour) and keeps one API session per server: no quota of Pi-hole is at risk.
  • The figures cover the last 24 hours as Pi-hole counts them; they are not reset at midnight.
  • The share blocked is rounded in the device (Gladys has no decimal percentage sensor); the widget shows one decimal.
  • The integration does not manage the blocklists, the allowed or denied domains, nor the clients of Pi-hole: use the Pi-hole interface for that.
  • Developed without a real Pi-hole: what was not checked on a real server is listed in the README.

This integration is not affiliated with Pi-hole LLC.

Configuration settings​

These are the settings Pi-hole asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Pi-holesectionNoPi-hole v6 or later. In Pi-hole, create an app password: Settings, Web interface / API, Expert mode, Configure app password. Up to three servers.
AddressstringYesIP address or name of the Pi-hole, with https:// for HTTPS and :port if not the default.
App passwordsecretNoAn app password (recommended) or the web interface password. Empty if the Pi-hole has none.
NamestringNoName of the device in Gladys. Empty: "Pi-hole" followed by the address.
Second Pi-hole (optional)sectionNoSame fields, for another Pi-hole of your network.
AddressstringNoIP address or name of the Pi-hole, with https:// for HTTPS and :port if not the default.
App passwordsecretNoAn app password (recommended) or the web interface password. Empty if the Pi-hole has none.
NamestringNoName of the device in Gladys. Empty: "Pi-hole" followed by the address.
Third Pi-hole (optional)sectionNoSame fields, for another Pi-hole of your network.
AddressstringNoIP address or name of the Pi-hole, with https:// for HTTPS and :port if not the default.
App passwordsecretNoAn app password (recommended) or the web interface password. Empty if the Pi-hole has none.
NamestringNoName of the device in Gladys. Empty: "Pi-hole" followed by the address.
OptionssectionNo
Accept self-signed certificatesbooleanNoFor https:// addresses: Pi-hole serves a self-signed certificate by default. Tick only for your own servers.
Refresh intervalselectNoHow often the Pi-hole servers are read.
Turning the blocking switch offselectNoPauses the blocking for this long, or until the switch is turned back on.
Language of the feature namesselectNoNames given to the features when a device is added, and texts of the scene events.

How to install Pi-hole in Gladys​

  1. In Gladys, open Integrations: Pi-hole appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-pihole:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-pihole.

Pi-hole requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Pi-hole is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
