pfSense integration for Gladys Assistant

pfSense firewalls: presence of your devices, health, gateways and outages, parental control.

View on GitHubAll integrations

Follow your pfSense firewall (CE or Plus) from Gladys, over your local network: know who is home from the devices pfSense sees, watch the health of the firewall and the state of your internet gateways, be told when a gateway drops or when an unknown device joins, and, if you allow it, cut the internet of the kids' tablet from a scene.

Developed without the hardware: feedback welcome. This integration was built and tested against the documented answers of the pfSense REST API package, not against a real firewall. If something does not work as described, please say so on the Gladys forum or in the issues.

This integration is not affiliated with Netgate. pfSense is a trademark of Electric Sheep Fencing LLC (Netgate).

What you need​

  • Gladys Assistant 5.1.0 or later.
  • A pfSense CE or pfSense Plus firewall reachable from Gladys.
  • The free REST API package (pfSense-pkg-RESTAPI, API v2, by Jared Hendrickson) installed on it. pfSense has no REST API of its own: this package adds one. It is not in the package manager of pfSense: it is installed from the command line (see below).
  • An API key, ideally for a dedicated user with read-only privileges.

Set up​

Install the REST API package​

In a shell on pfSense (Diagnostics → Command Prompt, or SSH), run the command given in the package documentation for your version, e.g. on pfSense CE:

pkg-static add https://github.com/pfrest/pfSense-pkg-RESTAPI/releases/latest/download/pfSense-2.8.1-pkg-RESTAPI.pkg

Then open System → REST API and check that the API is enabled and that API Key is among the authentication methods.

pfSense removes the packages that are not its own when it updates itself: install the package again after each pfSense update, or Gladys loses the firewall.

A read-only user and its API key​

Create a user for Gladys rather than using admin (System → User Manager → Add). Give it only the privileges of the REST API endpoints the integration reads, method GET:

  • /api/v2/status/system, /api/v2/status/gateways, /api/v2/status/interfaces: health, gateways, rates;
  • /api/v2/status/dhcp_server/leases, /api/v2/diagnostics/arp_table: presence and the "Unknown device connected" trigger;
  • /api/v2/system/version, /api/v2/system/hostname, /api/v2/routing/gateways, /api/v2/system/packages: version, name, interface of each gateway, package updates;
  • /api/v2/firewall/rules: the state of the followed rules.

A privilege missing is not an error: the matching measures are skipped, and Test the connection lists what the key may not read. The commands need two more: /api/v2/firewall/rule method PATCH and /api/v2/diagnostics/reboot method POST.

Then log in to pfSense as this user, open System → REST API → Keys → Add, and copy the key: pfSense shows it only once. A key has the privileges of the user who created it.

The configuration​

Open Integrations → pfSense → Configuration:

  • Firewall address: the address of the webConfigurator, e.g. https://192.168.1.1, with :port if it does not use 443. Without a scheme, HTTPS is used.
  • API key: the key created above.
  • Accept a self-signed certificate: pfSense serves its webConfigurator with a self-signed certificate unless you installed another one. Tick it for your own firewall.
  • Refresh interval: 10 seconds to 1 minute (30 seconds by default).
  • Gateways to follow: the names of the gateways of System → Routing (e.g. WAN_DHCP), up to four, separated by commas. Empty: every gateway pfSense monitors, four at most.
  • Departure delay (minutes): see the presence sensors.
  • Firewall rules to follow and Allow commands: see the firewall rules.
  • Language of the names: the language of the device and feature names.

Then press Test the connection: the report names the firewall, its version, the gateways and their state, the clients seen, the followed rules, and what the key may not read.

The devices​

Open the Discover tab of the integration and add what you want to follow.

The firewall​

One device for the firewall, named after its host name (or its platform when the host name is the default one). Its features:

  • CPU usage, Memory used and Disk used, in percent;
  • Temperature, when pfSense reads a sensor (most Netgate appliances; not in a virtual machine);
  • Uptime, in hours;
  • pfSense version (e.g. 2.8.1-RELEASE);
  • Package update available: 1 when an installed package has a newer version (read hourly);
  • for each followed gateway: Gateway WAN_DHCP online (1 online, 0 down), Latency WAN_DHCP in milliseconds and Packet loss WAN_DHCP in percent, as measured by dpinger, the gateway monitor of pfSense;
  • for each WAN interface of these gateways: Download WAN and Upload WAN, in Mbit/s, averaged over the refresh interval.

Presence sensors​

The Discover tab lists the devices of your network that pfSense sees (its ARP table and its DHCP leases), named after the description of their static mapping, else their host name. Each device you add becomes a presence sensor with one feature, Presence: 1 while pfSense sees it, 0 once it has not been seen for the Departure delay (minutes) (5 by default).

pfSense keeps an entry in its ARP table up to 20 minutes after the last exchange with a device: a departure shows up to 20 minutes, plus the delay, after the device left. A phone asleep stays in the table as long as it keeps its Wi-Fi connection. When the firewall cannot be read, no presence changes: an outage never sends the household away.

Firewall rules​

To control a rule from Gladys, give it a description in pfSense (Firewall → Rules → edit → Description), e.g. "Block kids tablet", and enter it in Firewall rules to follow (up to ten, separated by commas). List the firewall rules shows the rules that have a description.

Each followed rule is a device with one feature, Rule enabled: 1 when the rule is enabled (when several rules share the description, 1 as soon as one is). It is read only on purpose: a rule is never a switch a voice assistant could flip. Enabling or disabling it goes through the scene actions and the widget, and only when Allow commands is ticked.

Dashboard​

Three widgets:

  • pfSense firewall: CPU, memory, temperature, the rates of the first WAN, one row per gateway with its latency and loss (orange when degraded, red when down), the uptime, the version and the packages to update. With Allow commands, a Reboot button, with a confirmation.
  • Devices at home: the followed devices, present first, with how long each one has been away. A setting shows the present ones only.
  • Firewall rules: the followed rules and their state. With Allow commands, one button per rule (four at most), with a confirmation: the icon shows the current state, a tap switches it.

Scenes​

Triggers​

  • Gateway down: pfSense marks a gateway down (no answer, or loss or latency above its thresholds). Filter: the gateway name (empty: any). Variables: the gateway, and the reason given by pfSense (down, highloss, highdelay, force_down).
  • Gateway restored: a gateway that was down is online again. Variables: the gateway and the length of the outage in minutes.
  • Unknown device connected: a MAC address never seen before got a dynamic DHCP lease from pfSense. The first reading learns the network as it is, without firing; the addresses seen are remembered across restarts. Filter: the interface, as pfSense names it (e.g. GUESTS). Variables: the MAC address, the IP address, the host name and the interface.

Actions​

These need Allow commands.

  • Enable a firewall rule and Disable a firewall rule: every rule with the description of the chosen device, then the firewall applies the change. Output: whether the rule is now enabled.
  • Reboot the pfSense firewall: the network and the internet are cut for a few minutes.

Scene ideas​

  • At 21:00 on school days, Enable a firewall rule "Block kids tablet"; at 7:00, disable it.
  • When Gateway down fires, send a message to your phone over the mobile network (Telegram, Gladys Plus), and the length of the outage when Gateway restored fires.
  • When Unknown device connected fires on the guest interface, notify the household with the host name of the device.
  • When everybody's phone is away, turn the heating down.

How often the firewall is read​

Every refresh interval, the integration reads the system status, the gateway status, the interfaces, the DHCP leases, the ARP table and, when rules are followed, the rule list: six short HTTPS requests. The version, the host name and the gateway list are read every 10 minutes, the package list every hour (pfSense asks its package servers, with a cache). A refused key is tried again only every 5 minutes: the login protection of pfSense blocks an address after a few failures. Unchanged values are sent to Gladys again every 6 hours only, a present device every 2 minutes.

Troubleshooting​

  • "no REST API here": the package is not installed (or was removed by a pfSense update), or the address is not the webConfigurator. Install the package again.
  • "certificate refused": tick Accept a self-signed certificate.
  • "API key refused": the key was revoked or mistyped, or API Key is not among the authentication methods of System → REST API. After a few refusals, pfSense blocks the address of Gladys for a while (System → Advanced → Login Protection).
  • A measure is missing: Test the connection lists the endpoints the key may not read; add the privilege to the user.
  • A rule command is refused: the user needs the PATCH privilege of /api/v2/firewall/rule; the reboot, the POST privilege of /api/v2/diagnostics/reboot.
  • A device stays present after it left: pfSense keeps the ARP entry up to 20 minutes.
  • Logs: set the LOG_LEVEL of the integration to debug to see every request. The API key is never written.

Limits​

  • Developed without the hardware, against the documented answers of the REST API package v2: the first users are the testers.
  • The REST API package is not an official pfSense package; it must be installed again after each pfSense update. Its 32-bit builds (SG-3100) are not supported by its author.
  • The base system update ("a new pfSense version is available") is not readable through the REST API without starting the update: only the package updates are shown.
  • The DHCP lease states are texts pfSense may translate: with a webConfigurator in another language than English, the "Unknown device connected" trigger may stay silent; the presence still works through the ARP table.
  • One firewall per installation of the integration; no CARP pair, no VPN tunnels, no traffic per client.
  • The commands change nothing but the enabled state of the rules you listed, and reboot the firewall. Nothing else in pfSense is ever changed.

Configuration settings​

These are the settings pfSense asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your pfSense firewallsectionNopfSense CE or Plus with the free REST API package (pfSense-pkg-RESTAPI, API v2). Create an API key for a dedicated user with read-only privileges.
Firewall addressstringYesThe address of the webConfigurator, with :port if it does not use 443. HTTPS when no scheme is given.
API keysecretNoCreated in System > REST API > Keys, while logged in as the user Gladys reads with.
Accept a self-signed certificatebooleanNopfSense serves its webConfigurator with a self-signed certificate unless you installed another one. Tick only for your own firewall.
Refresh intervalselectNoHow often the firewall is read. The rates are averages over this interval.
Gateways to followstringNoGateway names of pfSense (System > Routing), separated by commas, up to four. Empty: every monitored gateway.
PresencesectionNoAdd the devices to follow from the Discovery tab: each one becomes a presence sensor, present while pfSense sees it in its ARP table.
Departure delay (minutes)numberNoA device no longer seen counts as away only after this delay. pfSense already keeps an ARP entry up to 20 minutes.
Firewall rules and commandssectionNoRead only by default. Commands enable or disable the rules listed below, or reboot the firewall, from a scene or a widget. Nothing else is ever changed.
Firewall rules to followstringNoThe descriptions of the rules, separated by commas (up to ten). "List the firewall rules" shows them.
Allow commandsbooleanNoLets scenes and widgets enable or disable the rules above and reboot the firewall. The user of the key needs the matching privileges.
Language of the namesselectNoLanguage of the device and feature names, set when a device is added.

How to install pfSense in Gladys​

  1. In Gladys, open Integrations: pfSense appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-pfsense:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-pfsense.

pfSense requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

pfSense is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
