Pangolin smart home integration, free and open source
Monitor your Pangolin sites and resources, and turn resources on or off from Gladys.
Published by prohand
- Devices
- Version 0.0.1
- Requires Gladys >=5.1.0
- ★ 0
This integration connects Gladys to Pangolin, the tunneled reverse proxy that exposes your services to the Internet without opening a port on your router. It works with a self-hosted Pangolin and with Pangolin Cloud.
What you get in Gladys:
- one device per site (a Newt tunnel, a WireGuard site, the Pangolin host itself), with its online state and its traffic (data in, data out);
- one device per public resource (an HTTPS site on your domain, a raw TCP/UDP port), with an enabled switch you can turn off from Gladys and its healthy state;
- scene triggers, scene actions and a dashboard widget (Gladys 5.1 or later).
Before you start
1. Enable the Integration API (self-hosted only)
Pangolin Cloud has it already. On a self-hosted Pangolin (Community Edition)
the Integration API is off by default: add this to config/config.yml, then
restart Pangolin.
flags:
enable_integration_api: true
The API then listens inside the Pangolin container on port 3003 (or
3004, depending on the version: check server.integration_port in your
configuration). See the
Pangolin documentation to
publish it on a domain such as https://api.example.com/v1.
2. Create an API key
In Pangolin, open your organization, then API Keys → Generate API Key. Give it these permissions:
| Permission | Used for |
|---|---|
| List Sites | the site devices |
| List Resources | the resource devices |
| Get Organization | the name shown by "Test the connection" (optional) |
| Update Resource | turning a resource on or off from Gladys (optional) |
Copy the key at once: Pangolin shows it only once. It looks like
abc123xyz.0123456789abcdef.
Use an organization key dedicated to Gladys, never a root key.
3. Find the organization ID
It is in the address bar when you browse your organization in Pangolin:
https://pangolin.example.com/my-org/settings → my-org.
Configuration
| Field | What to put |
|---|---|
| Local API address | Self-hosted only: the Integration API on your network, e.g. http://192.168.1.10:3004/v1. Leave empty otherwise. |
| Internet API address | Pangolin Cloud: https://api.pangolin.net/v1. Self-hosted: its public address, e.g. https://api.example.com/v1. |
| API key | The key created above. |
| Organization ID | The ID found above. |
| Refresh interval (s) | How often Pangolin is read (30 to 3600 s, 60 by default). Each read is two requests, whatever the number of devices. |
Fill in at least one of the two addresses. /v1 is added if you forget it.
Then press Test the connection: it tries every address you filled in and says, for each one, what Pangolin answered — the organization, the number of sites and resources, or the reason of the failure.
Local or Internet: the "Prefer the local connection" switch
With both addresses filled in, Gladys calls the one the Prefer the local connection switch points at, and only falls back on the other one when the first does not answer (network down, timeout, a proxy answering 502, 503 or 504). A wrong key or an unknown organization does not make it switch: both addresses lead to the same server, and the answer would be the same.
Each device shows the address in use on its badge: local, cloud, or unreachable. An orange dot means Gladys is on the fallback address: it works, but not the way you asked — check the preferred one.
With a single address, there is no fallback: the badge shows that address, or unreachable.
Devices
Open the Discover tab of the integration: every site and every public resource of the organization is listed. Create the ones you want in Gladys.
Site
| Feature | Values | Notes |
|---|---|---|
| Online | 1 = tunnel up, 0 = tunnel down | Absent on a "local" site: Pangolin reports no state |
| Data in | megabytes | Counter kept by Pangolin, until you reset it there |
| Data out | megabytes | Same |
Public resource
| Feature | Values | Notes |
|---|---|---|
| Enabled | 1 = served, 0 = disabled | Controllable: turning it off makes Pangolin stop serving the resource, without deleting it |
| Healthy | 1 = healthy, 0 = unhealthy | Result of the health checks of its targets. Empty when the resource has no health check |
Private resources (the ones reached through a Pangolin client) are not covered.
The devices keep their identity when you rename a site or a resource in Pangolin: they are tied to Pangolin's internal numbers, not to names or domains. A site or a resource deleted in Pangolin shows as unreachable: you can delete the device in Gladys.
Scenes and dashboard (Gladys 5.1)
Triggers
| Trigger | Filters | Variables |
|---|---|---|
| A Pangolin site goes online or offline | site, new status (online / offline) | site_name, status |
| The health of a Pangolin resource changes | resource, new health | resource_name, address, health, previous_health |
| Pangolin stops or starts answering | new status (answering / not answering) | status, reason, organization |
They fire once per change, at the read that sees it — so within the refresh interval. Nothing fires at startup or after a configuration change: "the site is offline" at that moment is a state, not an event. The triggers work even for sites and resources you did not create as devices.
In a scene, use the variables like any other, e.g.
{{triggerEvent.data.site_name}} is {{triggerEvent.data.status}}.
Actions
| Action | Fields | Outputs |
|---|---|---|
| Enable or disable a Pangolin resource | resource, enabled | enabled |
| Refresh Pangolin now | — | connected, sites_online, sites_offline, resources_unhealthy, resources_disabled |
Example: when everybody leaves home, enable the "Cameras" resource; when the first person comes back, disable it.
Widget "Pangolin overview"
Add it from the dashboard editor. It shows:
- three tiles: sites online, resources enabled, unhealthy resources;
- the connection (local, Internet, orange on the fallback address, red when Pangolin does not answer);
- the problems, worst first: offline sites, unhealthy resources, disabled resources — as many as the Problems listed setting says (0 to 9);
- a Refresh button.
Troubleshooting
| Message | What to do |
|---|---|
| Pangolin does not answer (…) | Check the address and the port, and that the Integration API is enabled. The reason (ECONNREFUSED, timeout…) helps. |
| Pangolin refused the API key | The key is wrong or was deleted: create a new one. |
| The API key may not read organization "…" | The key belongs to another organization, or lacks a permission: see Create an API key. |
| Pangolin knows no organization "…" | Check the organization ID, and that the address is the API one (ending in /v1), not the dashboard one. |
| A resource cannot be turned off | The key lacks Update Resource. |
The logs of the integration name every failed read and every switch to the fallback address. The API key never appears in them.
Security
- The API key is stored in a secret field, sent only to the addresses you configured, and never logged.
- Anyone who can press a switch or run a scene in Gladys can open or close your public resources: keep that in mind when you share Gladys.
- For the Internet address, use
https://.
Configuration settings
These are the settings Pangolin asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Getting started | section | No | Gladys reads your Pangolin organization through its Integration API: one device per site (online, traffic) and one per public resource (enabled, healthy). Create an organization API key in Pangolin (API Keys → Generate API Key) with the List Sites, List Resources, Update Resource and Get Organization permissions. A self-hosted server must have the Integration API enabled (flags: enable_integration_api: true). |
| Local API address | string | No | The Integration API of a self-hosted Pangolin, reached on your network (the Pangolin container listens on port 3003 or 3004 depending on the version). Leave empty if you only use the Internet address. |
| Internet API address | string | No | Pangolin Cloud: https://api.pangolin.net/v1. Self-hosted: the public address of your Integration API, e.g. https://api.example.com/v1. With both addresses filled in, the "Prefer the local connection" switch picks the one tried first; the other one takes over when it does not answer. |
| API key | secret | Yes | The organization API key, as Pangolin shows it once when you create it (it reads id.secret). |
| Organization ID | string | Yes | The ID of the organization, as in the Pangolin address bar: /my-org/settings → my-org. |
| Refresh interval (s) | number | No | How often Pangolin is read, in seconds. Each read is two requests, whatever the number of devices. |
How to install Pangolin in Gladys
- In Gladys, open Integrations: Pangolin appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/prohand/gladys-pangolin:0.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/prohand/gladys-pangolin.
Pangolin requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Pangolin is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by prohand, not by the Gladys core team.
- Browse all integrations, native and community
- Build and publish your own external integration
- Source code on GitHub — source of this documentation
