OpenWrt integration for Gladys Assistant

OpenWrt routers: presence of your devices, router health, WAN rates and outages, guest Wi-Fi.

View on GitHubAll integrations

Follow your OpenWrt router or access point from Gladys, over your local network: who is at home (the phones connected to the Wi-Fi), the health of the router, the state and the rates of the internet link, the guest Wi-Fi. No cloud, no account.

The integration talks to the router like LuCI, the web interface of OpenWrt, does: through ubus over HTTP (/ubus, rpcd sessions). A router without /ubus but with the LuCI RPC API (luci-mod-rpc) still gives the presence and the uptime.

Developed without the hardware: feedback welcome. The integration is built and tested against the answers of OpenWrt read in its source code (procd, netifd, hostapd, rpcd), not against a real router. Tell us what works and what does not in the issues.

This project is not affiliated with the OpenWrt project. OpenWrt is a trademark of its owner.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • A router or access point on OpenWrt 18.06 or later, with rpcd and uhttpd-mod-ubus. Both come with LuCI, so every standard image has them. Check on the router: ls /usr/lib/uhttpd_ubus.so must show the file. Without it: opkg install rpcd uhttpd-mod-ubus (apk add on OpenWrt 25), then /etc/init.d/uhttpd restart.
  • An rpcd user for Gladys (below). root works too, but a dedicated user only allowed to read is safer.

Set up​

The rpcd user and its ACL​

  1. Connect to the router with SSH and create the file /usr/share/rpcd/acl.d/gladys.json. The read part is what the integration reads; the write part is only used by the commands (guest Wi-Fi, reboot):

    {
      "gladys": {
        "description": "Gladys Assistant",
        "read": {
          "ubus": {
            "system": ["board", "info"],
            "network.interface": ["dump"],
            "network.device": ["status"],
            "network.wireless": ["status"],
            "hostapd.*": ["get_clients"],
            "iwinfo": ["assoclist"],
            "luci-rpc": ["getDHCPLeases"],
            "file": ["read"],
            "uci": ["get"]
          },
          "file": { "/tmp/dhcp.leases": ["read"] },
          "uci": ["wireless"]
        },
        "write": {
          "ubus": { "system": ["reboot"], "uci": ["set", "commit"] },
          "uci": ["wireless"]
        }
      }
    }

  2. Create the login, with a password of its own (uhttpd -m turns it into a hash, so it is not stored in clear):

    uci add rpcd login
    uci set rpcd.@login[-1].username='gladys'
    uci set rpcd.@login[-1].password="$(uhttpd -m 'choose-a-long-password')"
    uci add_list rpcd.@login[-1].read='gladys'
    uci commit rpcd
    /etc/init.d/rpcd restart

  3. Only if you want the commands: give the login the write part too, with list write 'gladys' in its section of /etc/config/rpcd, then /etc/init.d/rpcd restart.

Good to know: network.wireless status and uci get wireless can show the Wi-Fi keys to this user. The integration reads only the names, the SSIDs and the disabled option of the guest Wi-Fi, never stores a key and never writes one to its logs. The uci and file lines are optional: without them, the guest Wi-Fi and the leases of an old router without luci-rpc are not read.

The configuration​

In Gladys, open the integration, then Configuration:

  • Router address: the IP address of the router (192.168.1.1 by default), with :port when its web server uses another port.
  • Use HTTPS: encrypts the password on your network, when luci-ssl is installed. A router that sends HTTP to HTTPS is followed anyway.
  • Accept a self-signed certificate: OpenWrt makes its own certificate at first boot; tick it for your own router.
  • User name and Password: the rpcd login made above.
  • Interface: leave Automatic (ubus, and LuCI RPC only when the router has no /ubus).
  • Refresh interval: 10 s to 1 min (30 s by default).
  • WAN interfaces: empty, the integration takes wan and the interfaces that hold the default route. Otherwise, the names of Network → Interfaces (wan, wwan), up to four.
  • Departure delay (minutes) and Count a DHCP lease as present: see the presence sensors below.
  • Guest Wi-Fi network: the name of the wifi-iface section of the guest network (guest, wifinet2…). List the Wi-Fi networks shows them.
  • Allow commands: off by default (see the actions).
  • Language of the names: language of the device and feature names.

Save, then click Test the connection: the report says which interface answered, the WAN interfaces and the radios found, the clients seen, and what the ACL does not allow.

The devices​

Open the Discover tab: the router and the network clients it sees are listed. Add the ones you want.

The router​

  • System load (1 min): the load average in percent of one processor core (a router with 4 cores fully busy reads 400 %).
  • Memory used, in percent.
  • Uptime, in hours.
  • OpenWrt version (23.05.5).
  • Wi-Fi clients per radio (Wi-Fi clients 2.4 GHz, 5 GHz…): the stations connected and authorized.
  • Guest Wi-Fi enabled, when a guest network is chosen.
  • For each WAN interface: Download and Upload rates (Mbit/s, the average over the refresh interval) and WAN link (1 when up).

Nothing on these devices is a switch: a voice assistant cannot turn the guest Wi-Fi off or reboot the router by mistake.

Presence sensors​

Each client you add becomes a Presence sensor: present while it is connected (and authorized) on the Wi-Fi of the router, away once it has not been seen for the departure delay (5 minutes by default): a sleeping phone leaves the Wi-Fi for a few minutes.

  • A router that cannot be read changes nobody: an outage never sends the household away.
  • Wired devices are not on the Wi-Fi: tick Count a DHCP lease as present for them, knowing that a lease lasts until it expires (12 h by default).
  • Phones use a private (random) MAC address per Wi-Fi network: follow the address the phone uses on your network, and keep it fixed in its Wi-Fi settings.

Dashboard​

  • OpenWrt router: load, memory, the rates of the first WAN, the Wi-Fi clients, the state of each WAN link, each radio and the guest Wi-Fi, the uptime and the version. With the commands allowed: a Guest Wi-Fi button (its icon shows the current state) and a Reboot button, both with confirmation.
  • Devices at home: the followed devices, present first, with the time since a departure; a setting shows the present ones only.

Scenes​

Triggers​

  • Unknown device connected: a MAC address never seen before joined the Wi-Fi or got a DHCP lease. The first reading learns the network as it is; the addresses seen are kept in /data. Filters: Seen through (Wi-Fi or DHCP lease) and Wi-Fi network (SSID). Variables: MAC address, IP address, host name, SSID, Wi-Fi interface.
  • WAN link down: a WAN interface went down. Filter: WAN interface (e.g. wan).
  • WAN link restored: it is up again; the variable Outage length (minutes) gives the length of the outage.

Actions​

The actions do nothing until Allow commands is ticked, and the router refuses them when the ACL has no write part.

  • Turn on the guest Wi-Fi and Turn off the guest Wi-Fi: change the disabled option of the chosen section and commit it; OpenWrt reloads the Wi-Fi (the other networks blink for a few seconds). The output tells whether the guest Wi-Fi is enabled.
  • Reboot the OpenWrt router: the network is cut for one to three minutes.

Scene ideas​

  • Guests are coming: at 6 pm on Saturdays, Turn on the guest Wi-Fi; at 1 am, Turn off the guest Wi-Fi.
  • Nobody home: when the presence sensors of the phones are all away, arm the alarm and lower the heating.
  • Unknown device connected on your main SSID: send a message with the MAC address and the host name.
  • WAN link restored after more than 10 minutes: send yourself the length of the outage.

How often the router is read​

Every refresh interval, the integration calls system info, network.interface dump, network.device status, network.wireless status, the get_clients of each access point (or iwinfo assoclist) and the DHCP leases: about ten small requests, read-only, on your local network. Gladys does not poll these devices: the timer is the integration's own. Only the values that change are sent to Gladys, with a heartbeat every six hours.

Troubleshooting​

  • "no ubus nor LuCI RPC here": install uhttpd-mod-ubus (see above), or check the address and the port.
  • "user name or password refused by rpcd": check the login in /etc/config/rpcd and restart rpcd. After a refusal, the integration waits five minutes before trying again: click Test the connection to try now.
  • "refused by the rpcd ACL": the file of the ACL is missing or does not name the login (list read 'gladys'); the report lists what is not readable.
  • "certificate refused": tick Accept a self-signed certificate.
  • No Wi-Fi client: the access points need hostapd.* in the ACL; on a build of hostapd without ubus, rpcd-mod-iwinfo must be installed.
  • Logs: set LOG_LEVEL=debug on the container for the details of each reading (never a password nor a Wi-Fi key).

Limits​

  • One router per integration: the clients of other access points are not seen on their Wi-Fi (the DHCP lease option still sees them).
  • The WAN link is the state of the interface: an outage behind a working link (the ISP side) is not seen. The rates are averages over the interval.
  • The guest Wi-Fi is one wifi-iface section, named in the configuration; a disabled network is not listed by OpenWrt (type its name).
  • LuCI RPC fallback: presence from the neighbour table (less precise than the Wi-Fi), the uptime and the reboot only; no unknown-device trigger.
  • Developed without the hardware: the guest Wi-Fi commit, the reboot and the LuCI RPC fallback are untested on a real router.

Configuration settings​

These are the settings OpenWrt asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your OpenWrt routersectionNoOpenWrt 18.06 or later, with rpcd and uhttpd-mod-ubus (installed with LuCI). Create a dedicated rpcd user with the ACL of the documentation: read only is enough for presence and measures.
Router addressstringYesIP address or name of the router, with :port if its web server does not use the default port.
Use HTTPSbooleanNoEncrypts the password on your network. OpenWrt serves HTTPS when luci-ssl is installed. A router that redirects to HTTPS is followed anyway.
Accept a self-signed certificatebooleanNoOpenWrt makes a self-signed certificate at first boot. Tick it only for your own router.
User namestringYesA login of /etc/config/rpcd, ideally a dedicated read-only one (see the documentation).
PasswordsecretNo
InterfaceselectNoAutomatic uses ubus (/ubus) and falls back on the LuCI RPC API (luci-mod-rpc) only when the router has no /ubus.
Refresh intervalselectNoHow often the router is read. The rates are averages over this interval.
WAN interfacesstringNoNames of Network → Interfaces, separated by commas, up to four. Empty: wan and the interfaces holding the default route.
PresencesectionNoAdd the devices to follow from the Discovery tab: each one becomes a presence sensor, present while it is connected to the Wi-Fi of the router.
Departure delay (minutes)numberNoA device no longer seen counts as away only after this delay: a phone asleep leaves the Wi-Fi for a few minutes.
Count a DHCP lease as presentbooleanNoA lease lasts until it expires (12 h by default), long after the device left: tick it only for wired devices nothing else sees.
Guest Wi-Fi and commandssectionNoRead only by default. Commands turn the guest Wi-Fi on or off and reboot the router, from a scene or a widget. Nothing else is ever changed.
Guest Wi-Fi networkstringNoThe name of its wifi-iface section in /etc/config/wireless. "List the Wi-Fi networks" shows them. Empty: no guest Wi-Fi.
Allow commandsbooleanNoLets scenes and widgets turn the guest Wi-Fi on or off and reboot the router. The rpcd ACL needs the write part of the documentation.
Language of the namesselectNoLanguage of the device and feature names, set when a device is added to Gladys.

How to install OpenWrt in Gladys​

  1. In Gladys, open Integrations: OpenWrt appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-openwrt:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-openwrt.

OpenWrt requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

OpenWrt is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
