OpenSprinkler smart home integration, free and open source

OpenSprinkler integration for Gladys Assistant

OpenSprinkler watering: stations, programs, rain delay and sensors, on your local network.

View on GitHubAll integrations

Control your OpenSprinkler or OpenSprinkler Pi irrigation controller from Gladys, on your local network: see which stations water and for how long, water a bed now, start a program, hold the schedule with a rain delay, read the rain, soil and flow sensors.

Developed without the hardware: feedback welcome. This integration was written against the OpenSprinkler API documentation and answers recorded on the official firmware (Demo build), not on a physical controller. Please report what works and what does not on GitHub.

This integration is not affiliated with OpenSprinkler or OpenThings Inc.

Requirements​

  • An OpenSprinkler (2.x, 3.x, 4.x) or OpenSprinkler Pi controller with a 2.x firmware (2.1.9 or later recommended, tested against 2.2.1(6)).
  • The controller and Gladys on the same local network. The integration talks to the controller directly (no cloud, no OpenThings Cloud account).
  • The device password of the controller: the one you type in the OpenSprinkler app (factory default: opendoor).
  • Gladys 5.2.0 or later (the widget buttons open forms).

Configuration​

In Gladys, go to Integrations → OpenSprinkler → Configuration:

  • Address: the IP address or name of the controller, e.g. 192.168.1.20. Add :port if the web server does not listen on port 80 (an OpenSprinkler Pi often listens on :8080). Give the controller a fixed IP address in your router.
  • Device password: the password of the OpenSprinkler app. It is sent to the controller as its MD5 hash, as the official app does, and never written in the logs.
  • Name (optional): the name of the device in Gladys; empty, the device name set on the controller is used.
  • Up to three controllers (second and third sections).
  • Refresh interval: 30 seconds or 1 minute. The controller is also read right after every command.
  • Watering time of a station switch: how long a station waters when you turn its switch on in Gladys (10 minutes by default). The controller stops it by itself at the end.
  • Unit of the flow pulse rate: liters or US gallons, the unit of the volume per pulse you set in the OpenSprinkler options (only used with a flow sensor).
  • Language of the feature names: the names given to the features when the device is added, and the texts of the scene events.

Then use Test the connection: it reads every controller and reports its firmware, its stations and programs. Finally, open the Discovery tab and add the controller to Gladys.

Devices and features​

One device per controller, identified by its MAC address: changing its IP address or its slot in the configuration keeps the device and its history.

FeatureTypeWhat it does
Controller enabledswitchEnables or disables the controller operation (no program runs while it is off).
One switch per station, named after the stationswitchOn while the station waters. Turning it on waters the station for the configured time; turning it off stops it.
Program: …switchOn while the program is enabled. Turning it off disables the program (it no longer runs on its schedule).
Watering levellevel (%)The watering percentage applied to the programs (0 to 250 %), set by the weather adjustment or by hand.
Rain delayduration (hours)The hours left before the programs run again, 0 without a rain delay.
Rain sensorrain sensorOnly with a rain sensor on a sensor input: 1 when rain is detected.
Soil sensor (wet)inputOnly with a soil sensor: 1 when the soil is wet.
Water flowflow (m³/h)Only with a flow sensor: the current flow.
Water metervolume (liters)Only with a flow sensor: the water used since the device was added. The controller counts the pulses since it was powered on; the integration adds them up across its reboots and keeps the total in /data.

The names are fixed when the device is added. A station renamed, a program added or a sensor plugged in later: the Discovery tab offers Update for the device.

Master stations (pump, master valve) appear like the others and show when they run, but they cannot be started alone: the controller opens them with the stations they serve.

Dashboard widget​

Add the OpenSprinkler widget to a dashboard (choose the controller in its settings, or leave it empty for the first one). It shows:

  • the Watering level, the Rain delay and the Water flow (with a flow sensor) as tiles;
  • the controller state (Idle, Watering, Paused, Disabled, rain delay), the rain sensor when it detects rain, and each station watering with its time left or waiting in the queue;
  • four buttons: Water… (choose a station and a duration), Program… (choose a program, with or without the watering level), Stop all (asks for confirmation), and Rain delay… (a number of hours), which becomes Cancel rain delay while a rain delay runs.

Scene triggers​

  • OpenSprinkler station finished: a station stopped watering. Filters: the controller, and what started it (a manual run, a program schedule, or a program started by hand / a run-once program). Variables: the station number and name, the watering time in minutes, what started it, the controller name.
  • OpenSprinkler unreachable: the controller stopped answering on the network (two readings in a row). Variables: the controller name and the reason.

Scene actions​

  • Water an OpenSprinkler station: open one station (number 1 = the first) for a number of minutes (1 to 1080), queued behind the stations already watering.
  • Stop OpenSprinkler watering: stop every station watering or waiting.
  • Start an OpenSprinkler program: start a program now (number 1 = the first), with or without the watering level. What is watering stops and the program takes over.
  • Set the OpenSprinkler rain delay: hold the programs for a number of hours (0 to 720; 0 cancels the delay).

Scene examples​

  • Rain on the way: when your weather integration raises a rain alert, Set the OpenSprinkler rain delay to 24 hours.
  • Water the vegetable garden from the wall tablet: the Water… button of the widget, or a scene started by a button that runs Water an OpenSprinkler station for 15 minutes.
  • Watering report: on OpenSprinkler station finished, send a message "{{triggerEvent.data.station_name}} watered {{triggerEvent.data.duration_minutes}} min".
  • Kids in the garden: when a presence is detected in the garden, Stop OpenSprinkler watering.
  • Controller offline: on OpenSprinkler unreachable, send a notification.

Troubleshooting​

  • "does not answer": check the address and the port (open http://<address> in a browser: the OpenSprinkler page must show). The integration runs in a Docker container: the controller must be reachable from the Gladys server.
  • "password refused": type the password of the OpenSprinkler app again (case-sensitive). The factory default is opendoor.
  • "no OpenSprinkler at this address": something answers at this address, but not the OpenSprinkler API (another device, a web page).
  • A station switch turns itself back off: the controller refused the run. A station already watering or waiting, a master station or a disabled controller cannot be started; the error message says which.
  • More details: set the LOG_LEVEL environment variable to debug in the integration settings; the logs then show every reading. They never contain the password.

Limits​

  • Reading frequency and controller load: the controller (an ESP8266 on the OpenSprinkler 2.3 / 3.x) serves one request at a time. The integration reads it every 30 seconds or every minute with a single /ja request (five requests on firmwares older than 2.1.6, sent one after the other), plus one reading after each command. No cloud service is used, so there is no quota; please do not lower the interval below 30 seconds.
  • Stations and programs are identified by their number on the controller, the only identifier the API gives: deleting or reordering programs in the OpenSprinkler app shifts the program switches (the names stay those of the creation until Update).
  • A program started by hand runs as a "run-once" program on the controller: its switch only shows whether it is enabled, and the "station finished" trigger reports it as started by hand.
  • The station finished trigger reads the last completed run of the controller at each reading: when two stations finish between two readings, only the last one is reported.
  • The water meter starts at 0 when the device is added, and misses the water used while the integration is stopped across a controller reboot.
  • Expanded sensors (analog sensors of firmware 2.2.1), special stations and program editing are not handled: use the OpenSprinkler app.
  • The integration talks HTTP to the controller, as the official app does on the local network; the password hash travels unencrypted on the LAN.

Configuration settings​

These are the settings OpenSprinkler asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your OpenSprinklersectionNoOpenSprinkler or OpenSprinkler Pi with firmware 2.x, on your local network. Up to three controllers.
AddressstringYesIP address or name of the controller, with :port if not 80 (OpenSprinkler Pi: often :8080).
Device passwordsecretNoThe password of the OpenSprinkler app (factory default: opendoor). Sent to the controller as its MD5 hash.
NamestringNoName of the device in Gladys. Empty: the device name set on the controller.
Second OpenSprinkler (optional)sectionNoSame fields, for another controller of your network.
AddressstringNoIP address or name of the controller, with :port if not 80 (OpenSprinkler Pi: often :8080).
Device passwordsecretNoThe password of the OpenSprinkler app (factory default: opendoor). Sent to the controller as its MD5 hash.
NamestringNoName of the device in Gladys. Empty: the device name set on the controller.
Third OpenSprinkler (optional)sectionNoSame fields, for another controller of your network.
AddressstringNoIP address or name of the controller, with :port if not 80 (OpenSprinkler Pi: often :8080).
Device passwordsecretNoThe password of the OpenSprinkler app (factory default: opendoor). Sent to the controller as its MD5 hash.
NamestringNoName of the device in Gladys. Empty: the device name set on the controller.
OptionssectionNo
Refresh intervalselectNoHow often the controllers are read. They are read again right after each command.
Watering time of a station switchselectNoTurning a station on in Gladys waters it for this long, then the controller stops it.
Unit of the flow pulse rateselectNoOnly with a flow sensor: the unit of the volume per pulse set in the OpenSprinkler options.
Language of the feature namesselectNoNames given to the features when a device is added, and texts of the scene events.

How to install OpenSprinkler in Gladys​

  1. In Gladys, open Integrations: OpenSprinkler appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-opensprinkler:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-opensprinkler.

OpenSprinkler requires Gladys >=5.2.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

OpenSprinkler is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
