OctoPrint smart home integration, free and open source

OctoPrint integration for Gladys Assistant

Follow and control your 3D prints in OctoPrint: progress, temperatures, alerts.

View on GitHubAll external integrations

Follow and control your 3D printer from Gladys through OctoPrint, the open-source web interface for 3D printers (often installed on a Raspberry Pi with OctoPi). Everything stays on your local network: Gladys talks to OctoPrint directly, no cloud account.

The integration was tested against a real OctoPrint (1.11.8) driving its built-in virtual printer: real prints, pause, resume, cancellation, end of print. It has not been tried on a physical printer yet: feedback welcome on the Gladys forum.

Requirements​

  • Gladys Assistant 5.1 or later.
  • OctoPrint 1.5 or later, reachable from the Gladys machine. The approval page of the Connect button needs OctoPrint 1.10 or later; with an older version, the request pops up in the OctoPrint interface instead.
  • An OctoPrint user allowed to control the printer (the user who approves the request: its permissions are those of the key).
  • For the webcam image: OctoPrint 1.9 or later, with a webcam able to take snapshots (the default on OctoPi).

Configuration​

  1. Open the Configuration tab of the integration.
  2. In OctoPrint address, enter the address you open OctoPrint with in your browser, for instance http://192.168.1.50. A port or a path is allowed (http://192.168.1.50:5000, https://example.org/octoprint). Prefer an IP address: octopi.local names do not resolve inside the integration container. Save.
  3. Click Connect with OctoPrint. The approval page of OctoPrint opens: log in if asked, then allow Gladys Assistant. The integration receives its key by itself and saves it in API key (the field stays masked). The status of the Configuration screen turns to connected.
  4. Without the Connect button, create a key in OctoPrint (Settings → Application Keys, or your user's API key) and paste it in API key, then save.
  5. A second or third printer: fill Printer 2 and Printer 3 the same way (one OctoPrint instance each).
  6. Language sets the language of the feature names and texts the integration creates (French by default). Feature names are set when the device is added to Gladys.

Then add the printer from the Discover tab.

The printer device​

One device per OctoPrint instance, named after the instance name of OctoPrint (Settings → Appearance), or "OctoPrint". The values arrive in real time through the push connection of OctoPrint (every 5 seconds, events at once).

FeatureWhat it shows
StateOperational, Printing, Pausing, Paused, Resuming, Cancelling, Finishing, Error, Printer disconnected, OctoPrint unreachable, API key refused
FileThe file being printed, or the last one
ProgressPercentage of the print (kept at 100 % after a finished print, 0 after a cancellation)
Elapsed timeIn minutes
Time leftEstimated by OctoPrint, in minutes (0 when idle)
Nozzle, Bed, ChamberTemperatures, in whole degrees; one nozzle per extruder, the chamber only when the printer profile declares a heated chamber
… (target)Setpoints, read only: heat with the widget or the scene actions
Pause, ResumePush buttons
WebcamThe webcam image, through OctoPrint (when a webcam with snapshots is configured)

There is deliberately no cancel button on the device: one tap without confirmation would ruin a print. Cancelling is offered by the widget (with a confirmation) and by the scenes. The temperatures and setpoints are read only too: a printer heater cannot be turned on by mistake from the dashboard, nor by HomeKit, Alexa or Google. Heating goes through the widget (preheat, cool down) and the scene actions. They are "device temperatures" for Gladys, so they never count in the temperature of the room.

What the printer has (nozzles, heated bed and chamber, webcam) comes from the current printer profile of OctoPrint. When it changes, Gladys offers to update the device in the Discover tab.

Dashboard widget​

Add the 3D print widget to a dashboard and pick the printer in its settings. It shows:

  • the progress gauge, the time left, the nozzle and bed temperatures (live);
  • the state, the file, the elapsed time, the time the print should end, the active setpoints;
  • the buttons that fit the moment: Pause or Resume and Cancel (asks for confirmation) during a print; Preheat and, when something heats, Cool down when idle.

The preheat temperatures are settings of the widget (200 °C and 60 °C by default, PLA).

Scene triggers​

Under the Integrations category of the scene editor. Each can be limited to one printer.

  • Print started — variables: printer name, file.
  • Print finished — variables: printer name, file, print time (text, like 1 h 05 min, and in minutes).
  • Print failed or cancelled — can be limited to a reason (cancelled, error). Variables: printer name, file, print time, reason.
  • Print paused — by a user or by the printer itself (filament runout). Variables: printer name, file, elapsed time.

The variables are read in the following actions with, for instance, {{triggerEvent.data.file}} and {{triggerEvent.data.duration}}.

Scene actions​

  • Pause, resume or cancel a print — returns Applied: false when there was nothing to pause, resume or cancel (the scene goes on).
  • Preheat the printer — nozzle (every nozzle) and bed setpoints, 200 °C and 60 °C by default. Refused during a print (Applied: false): a scene preheating at a fixed time never touches a running print.
  • Turn the heaters off — every setpoint to 0, also during a print (which then fails).

Scene examples​

  • Print finished → notification: trigger Print finished, action "Send a message": {{triggerEvent.data.file}} done in {{triggerEvent.data.duration}}.
  • Smoke detected → stop everything: trigger on the smoke detector, actions Pause, resume or cancel a print (cancel), then Turn the heaters off, then turn the printer's smart plug off.
  • Ready when you get up: at 7:00 on weekdays, Preheat the printer (it does nothing if a print runs).
  • Light for the webcam: Print started → turn the workshop light on; Print finished or Print failed → turn it off.

Troubleshooting​

  • OctoPrint does not answer: check the address from the Gladys machine (curl http://192.168.1.50/api/version answers 403 without key: OctoPrint is reachable). Use an IP address rather than octopi.local.
  • API key missing or refused: click Connect again, or paste a new key. A key revoked in OctoPrint (Settings → Application Keys) stops working at once.
  • Connect does nothing / "denied or expired": the request must be approved within 10 minutes, by a user allowed to grant access. OctoPrint accepts 3 requests per minute at most: wait a minute before trying again. If the Application Keys plugin is disabled, paste a key instead.
  • The address redirects (http to https): enter the final address.
  • No webcam image: the image must be a JPEG of 150 KB at most (a Gladys limit): lower the webcam resolution in OctoPrint.
  • Values are 10 s late: the push connection is unavailable (a reverse proxy without WebSocket): the integration then reads the API every 10 seconds, and derives the print events from the state changes.
  • Logs: in the integration page of Gladys, or docker logs on the host. LOG_LEVEL=debug shows the detail. The API key never appears in the logs.

Limits​

  • Up to three OctoPrint instances.
  • No file upload, no print start from Gladys, no G-code commands, no time-lapse.
  • The webcam image is a snapshot refreshed every minute (and on demand), not a video stream.
  • When the integration cannot use the push connection, an event shorter than 10 seconds may be missed, and a print stopped by an error is reported as failed with the reason "error" only when OctoPrint shows the error state.
  • Developed without a physical printer (the OctoPrint virtual printer was used): feedback welcome.
  • Not affiliated with OctoPrint. OctoPrint is a project of Gina Häußge.

Configuration settings​

These are the settings OctoPrint asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Connect your OctoPrintsectionNoEnter the address of OctoPrint as you open it in your browser (an IP address works best), save, then click Connect and approve the request in OctoPrint. Or paste an API key from OctoPrint (Settings, Application Keys). Up to three printers.
OctoPrint addressstringYesA port or a path is allowed (http://192.168.1.50:5000, https://example.org/octoprint).
Connect with OctoPrintaccount_linkNoOpens the approval page of OctoPrint: log in there and allow Gladys Assistant. The key is then saved below.
API keysecretNoFilled in by Connect, or pasted from OctoPrint.
Printer 2 (optional)sectionNoAnother OctoPrint instance, connected the same way.
OctoPrint address 2stringNo
Connect with OctoPrint 2account_linkNoOpens the approval page of OctoPrint: log in there and allow Gladys Assistant. The key is then saved below.
API key 2secretNoFilled in by Connect, or pasted from OctoPrint.
Printer 3 (optional)sectionNoAnother OctoPrint instance, connected the same way.
OctoPrint address 3stringNo
Connect with OctoPrint 3account_linkNoOpens the approval page of OctoPrint: log in there and allow Gladys Assistant. The key is then saved below.
API key 3secretNoFilled in by Connect, or pasted from OctoPrint.
OptionssectionNoLanguage of the names and texts the integration creates (feature names are set when a device is added).
LanguageselectNo

How to install OctoPrint in Gladys​

  1. In Gladys, open Integrations: OctoPrint appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-octoprint:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-octoprint.

OctoPrint requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

OctoPrint is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
