OCEA Smart Building smart home integration, free and open source
Cold water, hot water and heating readings of your OCEA resident portal.
Published by guim31
- Devices
- Version 1.0.2
- Requires Gladys >=5.1.0
- ★ 0
Reads the meters of your dwelling from the OCEA Smart Building resident portal (https://espace-resident.ocea-sb.com): cold water, hot water and heating, when your building's meters are read remotely by OCEA.
Not affiliated with OCEA Smart Building. OCEA publishes no public API: this integration reads the portal like your browser does, and can stop working if OCEA changes it.
Developed without an account: feedback welcome. Tell us on the Gladys forum what you see, especially if your heating is measured by heat cost allocators.
What you get
One device per dwelling of your account (several if you have several), with one feature per fluid the portal shows:
| Feature | Unit | Notes |
|---|---|---|
| Cold water | m³ | cumulative index |
| Hot water | m³ | cumulative index |
| Heating (energy) | kWh | when a thermal energy meter (CETC) is fitted |
| Heating (allocator units) | no unit | when heat cost allocators are fitted on the radiators |
Heat meter or heat cost allocators? A heat meter (CETC) measures the energy your dwelling received, in kWh. Heat cost allocators, one per radiator, measure no energy: they count units that only tell which share of the building's heating bill your dwelling pays. The integration therefore shows allocator units as a plain counter without a unit, never as kWh.
Configuration
- Open the Configuration tab of the integration.
- Enter the e-mail and password of your OCEA resident portal. Your dwellings are found from the account.
- Optionally set the reading interval (6 hours by default, 1 to 24) and the language used for the names of the meters.
- Save, then open the Discovery tab and add your dwelling.
The Test the connection and read now button signs in to OCEA right away and tells how many dwellings and meters it found.
How often the readings change
OCEA meters send their index once, or a few times, a day. The integration reads the portal every 6 hours by default, at most every hour: reading more often brings no fresher data and only loads the portal. The last reading is kept, so restarting Gladys does not read OCEA again before the interval is over. An unchanged value is still sent to Gladys at least every 12 hours, so "No recent value" never shows.
Charts and energy monitoring
- Water: the index of each meter is kept in the history of the feature, and drawn by the device chart.
- Heating in kWh (CETC): the index is an energy meter index, which the Gladys energy monitoring turns into a 30-minute consumption and a cost by itself. Gladys attaches a new energy index under your main electric meter (when one is set): in Integrations → Energy monitoring, set the heating index to No parent (root), or your heating counts as part of your electricity. As the index arrives every few hours, the consumption of those hours lands in one 30-minute slot.
- Heating in allocator units: a history chart of the counter only. These units are not energy and do not enter the energy monitoring.
Dashboard widget
The OCEA consumption widget shows, for the dwelling you pick, the consumption of the current month for each fluid. It is computed by the integration from the indexes it read: the first month only counts from the first reading, and the widget says since when it counts.
Limits
- Only what the portal's dashboard shows: one value per fluid, no detail per radiator or per meter, no alert.
- The readings are as late as OCEA's own (often the previous day).
- No account was available to build the integration: the heat cost allocator case in particular is based on assumptions. Your feedback helps.
Privacy
The e-mail and the password stay in the Gladys configuration. The
integration keeps the OCEA session token and the last readings in its own
/data volume, and never writes credentials or tokens to its logs.
Troubleshooting
- "OCEA rejected the e-mail or the password": check them on the portal, then save them again. The integration stops trying until you do, so it never locks your account.
- "The OCEA portal did not answer": OCEA may be under maintenance. The integration tries again in 30 minutes.
- Open the Logs tab of the integration to see what happened. A normal reading writes nothing there: only the start, the connection to OCEA, errors (one line when they start, one when everything works again) and your actions show.
Configuration settings
These are the settings OCEA Smart Building asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your OCEA resident account | section | No | Use the e-mail and password of the OCEA Smart Building resident portal. Your dwellings are detected from the account. The meters report a few times a day: the integration reads the portal every few hours. Not affiliated with OCEA Smart Building. |
string | Yes | ||
| Password | secret | Yes | |
| Reading interval (hours) | number | No | How often the OCEA portal is read, from 1 to 24 hours. The meters only report a few times a day. |
| Language of the device names | select | No | Used for the names of the meters when the device is added to Gladys. |
How to install OCEA Smart Building in Gladys
- In Gladys, open Integrations: OCEA Smart Building appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-ocea:1.0.2), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-ocea.
OCEA Smart Building requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
OCEA Smart Building is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
