ntopng smart home integration, free and open source
ntopng in Gladys: network throughput, active hosts and flows, alerts and new hosts.
Published by guim31
- Devices
- Version 1.0.0
- Requires Gladys >=5.1.0
- ★ 0
ntopng watches the traffic of a network interface (a mirror port, the LAN side of a router, a home server) and tells who talks to whom, how much, and what looks suspicious. This integration brings it into Gladys: one device per interface ntopng monitors, with its download and upload rates, its active hosts and flows, and its alerts. Scenes can react to a new ntopng alert, to a local host never seen before, or to the throughput going above a threshold, and a dashboard widget shows the traffic and the alerts at a glance. Everything stays on your local network.
Tested against a real ntopng 7.0 Community (Docker), with traffic and a port scan between test containers. Not yet on a real home network: feedback welcome on the issues.
What you need
- Gladys Assistant 5.1.0 or later.
- ntopng 6 or 7 (the free Community edition is enough), reachable from the Gladys machine (port 3000 by default).
- An ntopng user allowed to read the alerts (an administrator, or a user with the "alerts" capability), and preferably its API token.
The integration only reads: it never changes anything in ntopng.
Getting started
1. Get an API token
Open ntopng in a browser (http://<machine>:3000). On a fresh installation,
ntopng first asks to change the default admin password: do it, the API stays
closed until then. Then open the user menu (top right) → your user name → the token tab →
Generate, and copy the token.
2. Configure the integration
In Gladys, Integrations → ntopng → Configuration:
- ntopng address:
192.168.1.20,ntop.lan, or the address shown in your browser, such ashttps://ntop.lan:3001(port 3000 when none is given). - API token: the token of step 1. Without a token, fill in User (without token) and Password (without token).
- Refresh interval: 1 minute by default (30 seconds to 5 minutes).
- Throughput threshold (Mbit/s): only for the trigger "Throughput above the threshold"; leave it empty otherwise.
- Accept self-signed certificates: only for an
https://address, since the certificate ntopng ships with is self-signed. - Language of the names: the language of the feature names and of the scene texts.
Then click Test the connection: it says the version of ntopng, the interfaces, the active hosts and the engaged alerts.
3. Add the interfaces
In the Discover tab, add the interfaces you want to follow. Only the added interfaces receive values; the scene triggers work for every interface.
The devices
One device per interface, named ntopng <interface>:
| Feature | What it shows |
|---|---|
| Reachable | ntopng answers and still monitors the interface |
| Download | traffic received, in Mbit/s |
| Upload | traffic sent, in Mbit/s |
| Active hosts | hosts seen on the interface right now |
| Local hosts | those of them in your local networks |
| Active flows | connections followed right now |
| Engaged alerts | alerts ntopng holds open on hosts or on the interface |
| Alerted flows | active flows with an alert (a port scan raises thousands) |
| Highest severity | the worst of them: None, Notice, Warning or Error |
Rates and flows are sent at most once a minute; the other values when they change.
Dashboard
The ntopng traffic widget shows, for one interface (the one chosen in its settings, or the only one), the download, the upload, the hosts, the flows and the engaged alerts, then the list of alerts: the engaged ones first, most severe first, then the flow alerts of the last 24 hours with their count. With several interfaces and none chosen, it shows the totals and one row per interface. The Refresh button reads ntopng again.
Scenes
Triggers
- New ntopng alert: ntopng raises an alert on a host, a flow or an
interface. Filters: interface, severity, alert type (the English name ntopng
shows, such as
Probing Attempt), host IP address. Variables: interface, alert type, severity, raised on, host IP address and name, description, occurrences. A port scan writes one flow alert per probe: they are grouped by type and host, and the same alert fires once an hour at most. - New local host: ntopng sees a local host never seen before, by its MAC address (else its IP address). Variables: interface, IP address, MAC address, host name. The hosts known when the integration starts are not announced.
- Throughput above the threshold: download plus upload of an interface goes above the threshold of the configuration for two reads in a row, or back below 90 % of it. Filter: the change. Variables: download, upload, total and threshold in Mbit/s.
To follow the presence of your devices, NetAlertX does it better (scans, presence per device); ntopng only sees the hosts that send traffic through the interface it monitors.
Actions
- State of an ntopng interface: reads an interface for the next actions:
download, upload, hosts, flows, alerts, highest severity, and a ready-made
summary such as
eth0: download 12.3 Mbit/s, upload 1.5 Mbit/s, 24 host(s), 310 flow(s), no alert. - Recent ntopng alerts: the engaged alerts and the flow alerts of the last 24 hours, on one interface or all of them, with their count and a summary.
Scene ideas
- New ntopng alert, severity Error → send the message
{{triggerEvent.data.alert_type}} on {{triggerEvent.data.host}} ({{triggerEvent.data.count}} times). - New local host → send
New device: {{triggerEvent.data.host_name}} {{triggerEvent.data.ip}} {{triggerEvent.data.mac}}. - Throughput above the threshold at night → pause the backups, and resume them on "Back below".
- Every evening at 21:00 → Recent ntopng alerts → if the count is above 0, send the summary.
Troubleshooting
- "does not answer": check the address and the port in a browser; a firewall may block port 3000.
- "log in to ntopng once and change the default admin password": ntopng
sends every request to the password page until the
adminpassword is changed. - "API token or password refused": generate a new token, or check the user and password.
- "this ntopng user may not read the alerts": the values still come, but no alert event: give the user the alerts capability, or use an administrator.
- "the address redirects": ntopng only serves HTTPS: enter the
https://address (port 3001 by default). - ntopng raises "Clear-Text Credentials" for Gladys: with a user and password over HTTP, ntopng sees the password pass in clear on the network it watches. Use an API token, or HTTPS.
- ntopng in Docker shows almost nothing: it monitors its own container;
start it with
--network host(on the machine that sees the traffic) or on a mirror port. - More details with the
LOG_LEVEL=debugenvironment variable on the integration.
Limits
- One ntopng instance, 8 interfaces at most.
- Engaged alerts (hosts, interface) and flow alerts are read; the other alert families of ntopng (networks, system, SNMP of the Enterprise edition) are not.
- Flow alert events need the SQLite alert store of the Community and Pro editions; with ClickHouse (Enterprise), the flow alert events are off.
- Built for the Community edition: the features of the paid editions (traffic policies, SNMP, nProbe) are not read.
- The integration reads the current values at every refresh: it does not import the history of ntopng.
- Not affiliated with ntop.
Configuration settings
These are the settings ntopng asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your ntopng | section | No | Enter the address of ntopng and an API token (or a user and password). Every interface ntopng monitors becomes a device: add the ones you want from the Discover tab. The Community edition is enough. |
| ntopng address | string | No | Port 3000 by default: 192.168.1.20, ntop.lan or https://ntop.lan:3001. |
| API token | secret | No | Recommended. In ntopng: user menu (top right) → your user → token tab → Generate. |
| User (without token) | string | No | Only without an API token: an ntopng user that may read the alerts. |
| Password (without token) | secret | No | |
| Options | section | No | Only the interfaces added to Gladys receive values; the scene triggers work for every interface. |
| Refresh interval | select | No | How often ntopng is read. |
| Throughput threshold (Mbit/s) | string | No | For the scene trigger "Throughput above the threshold": download plus upload of an interface, in Mbit/s. Empty: off. |
| Accept self-signed certificates | boolean | No | Only for an https:// address: the certificate ntopng ships with is self-signed. |
| Language of the names | select | No | Language of the feature names (set when a device is added), of the scene texts and of the connection test. |
How to install ntopng in Gladys
- In Gladys, open Integrations: ntopng appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-ntopng:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-ntopng.
ntopng requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
ntopng is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
