Niko Home Control II smart home integration, free and open source
Niko Home Control II through its local Hobby API: lights, dimmers, shutters, thermostats, energy.
Published by LM1LC3N7
- Devices
- Version 0.1.1
- Requires Gladys >=5.1.0
- ★ 0
This integration connects Gladys to your Niko Home Control II installation through the Hobby API of its Connected Controller (or Wireless Smart Hub), on your local network: no cloud, and every change made in the house (a switch pressed, a mood started, a shutter moving) reaches Gladys at once. The lights, dimmers, shutters, thermostats and routines of your installation show up in the Discovery tab of Gladys, and Gladys controls them. Unofficial, not affiliated with Niko.
Development version (0.1). Tested against a controller simulated from Niko's Hobby API documentation, behind a real MQTT broker in TLS, not yet on a real installation. Your feedback is welcome on the GitHub repository.
What you get
| In Niko Home Control | In Gladys |
|---|---|
| Light (switched) | a light: on/off |
| Dimmer | a light: on/off, brightness |
| Socket, switched output, switched fan | a switch: on/off |
| Roll-down shutter, Venetian blind, gate | a shutter: open, close, stop, position (100 = open) |
| Sun blind | a curtain: open, close, stop, position |
| Garage door | a button to operate it, and a door sensor (closed or open) |
| Free function, mood, all-off, house mode | a switch (active or not) and a "Run" button |
| Presence simulation, condition, motion detection, peak/solar mode, alarm | a switch (active or not) |
| Bell button | a doorbell (every ring is an event for your scenes) and the door lock |
| Fan (speed action) | a list of its speeds (low, medium, high, boost) |
| Virtual flag | a switch |
| Thermostat, touch switch thermostat, virtual thermostat | temperature, setpoint, mode, program, activity, temporary setpoint, eco |
| HVAC thermostat | the same, plus heating or cooling and the fan speed |
| Electricity metering clamp, smart plug, Energy Home | power (W), production, power from and to the grid; the plug's on/off |
| Thermometer and other sensors | temperature, humidity |
| The controller itself | the days left before the Hobby API token expires |
Each item makes one Gladys device, named after it and its location ("Spots (Living room)"); its Niko identifier, model and location are kept in its parameters. The physical push buttons, modules and motion detectors are not visible through the Hobby API (Niko only exposes what they control): to react in Gladys to a push button, use the state of what it switches, of a free function or of a virtual flag that the button toggles.
Not supported yet: colour and tunable white lights, audio, video door station, access control calls, car chargers, partner heating and ventilation units, notifications. Niko Home Control I (the older system) is not supported.
Requirements
- A Niko Home Control II installation with a Connected Controller (550-00003) or a Wireless Smart Hub (552-00001), software 2.5.1 or later.
- The Gladys machine reaches the controller on the local network (port 8884). Give the controller a fixed IP address in your router.
- A Hobby API token (free, for private use, valid one year).
Get the Hobby API token
- Software 2.17 or later: open the Niko Home Control programming software, connect to your installation, then Dashboard → Manage connected services. Under Additional steps required, choose Manage next to Hobby API, sign in with your Niko Home Control account, accept the terms, and use Copy to get the token.
- Older software: on mynikohomecontrol.niko.eu, Connected services → Add a service → Hobby API, then copy the token.
The controller must be online (connected to the Internet) the first time the token is used. Afterwards, everything stays on your local network.
Installation
- In Gladys, open the integration, Configuration:
- IP address of the Connected Controller: for example
192.168.1.50. Not known? Leave it empty, save, and click Find the controller: Gladys looks for it on the network and saves its address. - Hobby API token: paste the whole token (a long text in three parts separated by dots).
- IP address of the Connected Controller: for example
- Click Test the connection: the Niko Home Control version, the number of devices offered and the expiry date of the token show up.
- Open the Discovery tab and add the devices you want. Their values are sent as soon as they are added, and every change follows at once.
Options
- Minimum interval between two readings of a measurement: 10 seconds by default (0 to 600). Powers and temperatures can change every few seconds: Gladys keeps the last reading at this pace. Lights, shutters, setpoints and switches are never delayed.
- Duration of a setpoint set from Gladys: 60 minutes by default (1 to 1439). On a Niko thermostat, a setpoint changed in Gladys is a temporary one (Niko calls it "overrule"); afterwards the thermostat follows its program again. To change the program, use the Program feature (Day, Night, Eco, Off, Prog1…).
- Language of the feature names: French, English or Dutch.
Thermostats
- Setpoint: a temporary setpoint for the configured duration. The Temporary setpoint switch shows when one is active; turn it off to go back to the program at once.
- Mode: Off (program Off), heating (Day, Night, Eco), cooling (program Cool, if your thermostat has it) or automatic (the weekly programs Prog1 to Prog3). Setting heating while already in Night or Eco keeps that program. HVAC thermostats: off, heating or cooling.
- Activity: heating, cooling or idle, as the thermostat reports its demand.
Meters
Niko sends the live power only for 30 seconds after it was asked: as long as a meter or a smart plug exists in Gladys, the integration asks again every 25 seconds. Remove the device from Gladys to stop it. The energy totals are not available through the Hobby API messages yet.
Token expiry
The token is valid one year. The controller device shows the days left; from 14 days before the expiry, the status of the integration, the badge of the controller device and the logs warn you, and the "Hobby API token about to expire" scene trigger fires once a day (with the days left and the expiry date): use it to send yourself a message. Niko lets you renew the token during the last month: paste the new one in the configuration. An expired token is not used; the status says so.
Troubleshooting
- "The controller is unreachable": check its IP address and that the Gladys machine is on the same network. The integration retries by itself (5 seconds, then up to 5 minutes).
- "The controller refused the Hobby API token": the token expired or was replaced; paste a new one. The integration only retries every 30 minutes, to spare the controller.
- "Its TLS certificate was not issued by Niko": the address is not the one of your controller. The integration only trusts Niko's own certificate authority.
- A command has no effect: the device may be offline for the controller (its badge says so). Niko accepts at most 5 applications at once on the Hobby API: close other ones (Home Assistant, Node-RED…) if the connection is refused.
- New devices or names changed: after you upload a new configuration to the controller, the integration reads the devices again; click Scan in the Discovery tab to force it.
Privacy
The integration only talks to your controller, on your local network, with the token you give it (kept by Gladys as a secret, never written in the logs). The Hobby API is offered by Niko for private, non-commercial use.
Configuration settings
These are the settings Niko Home Control II asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your Niko Home Control II installation in Gladys | section | No | Gladys talks to the Connected Controller (or the Wireless Smart Hub) on your local network, through the Hobby API that Niko offers for private use: no cloud, every change arrives at once. You need its IP address and a Hobby API token: with software 2.17 or later, create it in the Niko Home Control programming software (Dashboard, Manage connected services, Hobby API), before on mynikohomecontrol (Connected services). The token is valid one year: Gladys warns you 14 days before it expires. You get the lights, dimmers, sockets, shutters and sun blinds, gates, garage doors, free functions, moods and all-off, virtual flags, thermostats, meters and smart plugs. Unofficial, not affiliated with Niko. |
| IP address of the Connected Controller | string | No | Its IP address on your network (or its name, Niko1234.local). Give it a fixed address in your router. Empty: the "Find the controller" button looks for it. |
| Hobby API token | secret | No | The long text Niko gives when you add the Hobby API (three parts separated by dots). Paste the new one here every year. |
| In Gladys | section | No | How the values reach Gladys and how Gladys controls the thermostats. |
| Minimum interval between two readings of a measurement (s) | number | No | Powers and temperatures can change every few seconds: Gladys keeps the last reading at this pace. Lights, shutters, setpoints and switches are never delayed. |
| Duration of a setpoint set from Gladys (minutes) | number | No | A setpoint changed in Gladys is a temporary one on a Niko thermostat; after this time the thermostat follows its program again (at most 1439, almost a day). |
| Language of the feature names | select | No | Names given to the features in Discovery (Brightness, Setpoint…). The devices keep the names of your installation. |
How to install Niko Home Control II in Gladys
- In Gladys, open Integrations: Niko Home Control II appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/lm1lc3n7/gladys-niko-home-control:0.1.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/LM1LC3N7/gladys-niko-home-control.
Niko Home Control II requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Niko Home Control II is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by LM1LC3N7, not by the Gladys core team.
- Browse all integrations, native and community
- Build and publish your own external integration
- Source code on GitHub — source of this documentation
