NIBE myUplink smart home integration, free and open source
NIBE heat pumps through myUplink: temperatures, compressor, hot water, heating offset, alarms.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Brings your NIBE heat pumps into Gladys through myUplink, NIBE's cloud: temperatures (outdoor, supply and return lines, hot water, indoor), compressor, operating mode, heating curve offset, hot water mode and boost, produced heat and active alarms. Heat pumps of the group sold under other brands on the same platform (CTC, Contura…) show up too, with what their points allow.
Developed without the hardware: feedback welcome. The integration was written and tested against real myUplink answers published by other projects, not against a heat pump. If something is missing or wrong with yours, open an issue on GitHub.
This integration is not affiliated with NIBE or myUplink.
Requirements
- A heat pump connected to myUplink (you see it in the myUplink app).
- The myUplink account that owns it (e-mail and password of the app).
- Gladys 5.1 or later.
- To change a setting from Gladys (heating offset, hot water mode, boost): the paid myUplink Premium Manage subscription for that heat pump, bought in the myUplink app. Reading works without it.
Configuration
Gladys talks to myUplink with an "application" that you create, free, on the myUplink developer site.
- Open dev.myuplink.com and sign in with the account of your heat pump (the same as in the myUplink app). Accept the terms of use of the API if asked.
- Open Applications, then Create new application.
- Fill in the form:
- Name:
Gladys(anything you like); - Description:
Gladys Assistant; - Callback URL: the form requires one but this integration never uses it; enter an https address
such as
https://localhost/.
- Name:
- Save. The application page shows an Identifier (the client ID) and a Secret.
- In Gladys, open Integrations → NIBE myUplink → Configuration and paste the Identifier in Client ID and the Secret in Client secret. Choose the language of the names, keep 5 minutes as the refresh interval, save.
- Click Test the connection: Gladys says how many heat pumps it found and whether the Premium Manage subscription is active.
- Open the Discover tab and add your heat pump.
The client ID and secret stay in the Gladys configuration. The access token myUplink gives in exchange is
kept in the /data volume of the integration and renewed about every hour; neither is ever written to the
logs.
Devices
One device per heat pump, named after the product and the myUplink system, e.g. "F730 CU 3x400V (Home)". The integration looks for the following values among the hundreds of points myUplink publishes, and only creates a feature when the heat pump has it:
| Feature | Type in Gladys | Notes |
|---|---|---|
| Outdoor temperature | Temperature | BT1 sensor |
| Supply line temperature | Temperature | BT2, or the external supply line on a SMO |
| Return line temperature | Temperature | BT3, or the external return line |
| Hot water temperature (top) | Temperature | BT7 |
| Hot water temperature (charging) | Temperature | BT6 |
| Indoor temperature | Temperature | BT50 room sensor, when installed |
| Compressor frequency | Text, e.g. "57 Hz" | Gladys has no hertz unit |
| Compressor | Text | Off, starting, running, stopping |
| Operating mode | Text | What the heat pump works for: heating, hot water, cooling… |
| Heating curve offset | Selection −10 … +10 | Command, when myUplink allows writing it |
| Hot water mode | Selection | Economy, normal, luxury, smart control (model dependent) |
| Hot water boost | On/off, or a selection | "Temporary lux"; a selection of durations on some models |
| Heat produced, heating (kWh) | Counter | Heat meter, when the heat pump has one |
| Heat produced, hot water (kWh) | Counter | Heat meter, when the heat pump has one |
| Active alarms | Counter | Number of alarms active on myUplink |
| Alarm | Text | Number and title of the latest alarm, or "No alarm" |
A setting is only offered as a command when myUplink marks it as writable on your heat pump; otherwise it stays read-only. The heating curve offset is deliberately a selection and not a thermostat: it is not a temperature, and a voice assistant asked for "21 degrees" must never reach it.
The heat produced is shown as a counter, not as an energy meter: Gladys would count an energy index as electricity drawn from your main meter, while this is heat delivered to the house.
The device card shows a cloud badge, or unreachable when the heat pump is no longer connected to myUplink (its last values then stay as they were).
Widget
The Heat pump widget sums one heat pump up on the dashboard: live tiles for the outdoor, supply line, hot water and indoor temperatures, a status list (myUplink connection, operating mode, compressor, curve offset, hot water mode, boost, alarms) and, when the heat pump accepts commands, buttons to start or cancel the hot water boost and to move the curve offset by one step. Choose the heat pump in the widget settings.
Scene trigger and actions
- Heat pump alarm (trigger): fires when a heat pump raises a new alarm on myUplink, once per alarm. You can restrict it to one heat pump. Variables: alarm number, title, description and severity, in the language of the integration. The alarms already active when you install the integration, or announced before a restart, are not fired again.
- Actions: the commands are device features, so a scene changes them with the standard Control a device action (boost on, offset to −2, hot water mode…). No extra action is needed.
- The Test the connection button of the Configuration tab checks the client ID and secret, counts the heat pumps and reads the Premium Manage subscription.
Scene examples
- Be warned of a fault: trigger "Heat pump alarm" → action "Send a message":
Heat pump alarm {{triggerEvent.data.alarm_number}}: {{triggerEvent.data.header}}. - Hot water when electricity is cheap: at 1:30 a.m. on off-peak days → control a device "Hot water boost" = on.
- Away for the weekend: when the house is empty → "Heating curve offset" = −2; when someone comes back → 0.
- Frost watch: when "Outdoor temperature" goes below −15 °C → send a message.
Troubleshooting
- "myUplink refused the client ID or secret": copy them again from dev.myuplink.com, without spaces; check the application still exists.
- "No heat pump on this myUplink account": the application was created with another account than the one of the heat pump. Create it again, signed in with the account used in the myUplink app.
- "Changing a setting requires the Premium Manage subscription": reading works, writing needs the paid subscription for this heat pump. Once subscribed, try again: the integration checks it again.
- "myUplink quota reached": another program uses the same application (Home Assistant, a script…). Give each one its own application, or raise the refresh interval.
- Values that do not move: the heat pump itself sends its data to myUplink every few minutes; check it is "connected" in the myUplink app.
- A feature is missing: your model names its points differently. Restart the integration with
LOG_LEVEL=debug: the logs list the roles found. Open an issue with the model and that line.
Limits
- Cloud only: no local access; without Internet, nothing is read nor written.
- Quota and terms: myUplink limits the number of requests (25 per minute and per application at the time of writing) and its API is offered for personal use under the terms of dev.myuplink.com. Each refresh costs 1 request plus 1 per heat pump added to Gladys (plus 1 when an alarm is active); the integration respects the quota headers and waits when told to. Every 5 minutes is the default, 1 minute the minimum.
- Delay: a change made in Gladys reaches the heat pump within a minute or two; the next reading confirms it.
- Writing requires the Premium Manage subscription.
- Points: only the values listed above, found by their NIBE register number, by myUplink's smart home category or by their English name. The ids of the F-series and of the indoor modules (VVM, SMO) are known; on the S-series and the other brands, the names are relied upon, which could not be checked on real hardware.
- The electricity consumed by the heat pump is not read: no myUplink point for it could be identified with certainty.
Configuration settings
These are the settings NIBE myUplink asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Connect your myUplink account | section | No | Sign in to dev.myuplink.com with the account of your heat pump, create an application (free) and copy its client ID and secret below. Changing a setting from Gladys also needs the myUplink Premium Manage subscription. The documentation explains every step. |
| Client ID | string | Yes | The "Identifier" of your application on dev.myuplink.com. |
| Client secret | secret | Yes | The "Secret" of the same application. Stored by Gladys, never written to the logs. |
| Refresh interval (minutes) | number | No | How often myUplink is read. 5 minutes is plenty for a heat pump and spares the quota. |
| Language of names and texts | select | No | Names of the features (fixed once the device is added), alarms, messages. |
How to install NIBE myUplink in Gladys
- In Gladys, open Integrations: NIBE myUplink appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-nibe:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-nibe.
NIBE myUplink requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
