NextDNS smart home integration, free and open source

NextDNS integration for Gladys Assistant

Your NextDNS profiles: queries, blocked share, encrypted DNS, devices and filters.

View on GitHubAll integrations

Your NextDNS profiles in Gladys, through the official NextDNS API and the API key of your account. Each profile becomes a Gladys device:

  • Queries (24 h) and Blocked queries (24 h): the DNS queries and the blocked queries of the last 24 hours;
  • Blocked queries (%): the blocked share;
  • Encrypted queries (%): the share of the queries that came over an encrypted DNS transport (DNS-over-HTTPS, DNS-over-TLS, DNS-over-QUIC…);
  • Devices seen (24 h): the identified devices that made at least one query (unidentified queries do not count);
  • the state of each filter (1 on, 0 off): security protections, disguised trackers blocking, safe search, YouTube restricted mode, bypass blocking, categories (porn, gambling, dating, piracy, social networks, online gaming, video streaming) and the blocked services of your profile (TikTok, Fortnite…);
  • the Filter command select, to turn a filter on or off (off by default, see Commands).

This integration has never been tested against a real NextDNS account. This first version was written from the official documentation of the NextDNS API and the nextdns Python library 5.1.0, and tested only against a fake NextDNS. Tell on the Gladys forum what works and what does not.

Unofficial integration, not affiliated with NextDNS.

Configuration​

  • API key: on my.nextdns.io, Account, API section, at the bottom of the page. Kept by Gladys in its database, never shown again, sent only to api.nextdns.io, in the X-Api-Key header (never in an address, never in a log, never in the /data volume). Beware: the key gives access to the whole NextDNS account (NextDNS offers no read-only key).
  • Profiles: the ids of the profiles to follow (the 6 characters of my.nextdns.io/<id>), separated by commas; empty, every profile of the account, 10 at most.
  • Refresh: every 5 minutes (default) to every hour. Each reading makes 4 requests per profile, one after the other.
  • Allow the filter commands and Allow turning protections off: off by default (see Commands).

Then open the Discovery tab and create the profiles to follow.

NextDNS only has figures when the Logs are on in the profile: otherwise the queries stay at 0.

Commands​

  • By default Gladys only reads. A filter is never a switch: Gladys hands every switch to the voice assistants (Google Home, Alexa, HomeKit), MCP and the "turn off" scene actions, so "turn everything off" would remove your protections. Each filter is a reading, and commands go through the Filter command select of the profile (dashboard or the "Control a device" scene action).
  • Turn on: … (turning a filter on) needs Allow the filter commands.
  • Turn off: … (turning off a security protection, the tracker blocking or a parental control filter) also needs Allow turning protections off. Without it, Gladys refuses and sends nothing.
  • Just before acting, Gladys reads the profile from NextDNS again and decides on that reading only: a filter whose state is unknown is refused; a filter already in the state asked sends nothing. When the command cannot be checked within 3.5 s, nothing is sent and Gladys shows a failure (never an action after a failure shown). A command that left without an answer of NextDNS in time shows as a failure saying "sent, not confirmed yet" (never "not sent"); the state of the filter follows the answer, and the profile is read again a few seconds later.
  • Only the options of the select of the profile are accepted. The commands of a profile run one at a time (the next one waits for the answer to the previous one). The select goes back to "—" 1.5 s after each command.
  • Unticking an option takes effect at once, even while a reading runs.
  • The blocked services are those of your profile: a service added later in NextDNS shows in Discovery; press Update to add it to the device. A service removed keeps its feature (at 0), so that the history is never broken.
  • The parental control Recreation Time is not taken into account: the state shown is the setting of the filter, even during a recreation.

Connection problems​

  • Key refused (HTTP 401, or 403 from the API itself): Gladys does not try again by itself, not even after a restart. Copy the key, paste it and save, or press Test the connection.
  • NextDNS overloaded (HTTP 429, met by any request) or server error (HTTP 5xx on the list of the profiles): every request stops, for the chosen interval at least (429: 1 minute to 6 hours, as NextDNS asks), even after a restart; saving the configuration or pressing Test the connection lifts the pause.
  • NextDNS unreachable: retried at the chosen interval, then more and more spaced up to one hour. The devices show unreachable meanwhile.
  • A secondary request of a profile that fails (encrypted share, devices…) never blocks the other figures: the connection status says so.

Limits​

  • One NextDNS account per integration, 10 profiles at most (the profiles already created first; the connection status says how many are left out), 60 blocked services per profile.
  • Gladys accepts 300 states per minute: the first publication of many profiles (up to 10) may take several reading rounds.
  • Devices seen counts 500 devices at most.
  • The shares in % have no unit in Gladys (the core has no "share of queries" category): 75 means 75 %.
  • Blocklists, the allowlist, the denylist and the settings (logs, cache…) are not followed.

Configuration settings​

These are the settings NextDNS asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
How it workssectionNoGladys reads your NextDNS profiles through the official NextDNS API, with the API key of your account. Each profile becomes a Gladys device (Discovery tab): queries and blocked queries of the last 24 hours, the blocked share, the share of DNS-over-HTTPS, DNS-over-TLS and other DNS-over-encrypted-transport queries, the devices seen, and the state of each filter (security, privacy, parental control). Unofficial integration, not affiliated with NextDNS.
API keysecretYesOn my.nextdns.io: Account, API, at the bottom of the page. Kept by Gladys in its database, never shown again, sent only to api.nextdns.io, in the X-Api-Key header.
Profiles (optional)stringNoIds of the NextDNS profiles to follow (the 6 characters of my.nextdns.io/<id>), separated by commas. Empty: every profile of the account, 10 at most.
RefreshselectYesHow often Gladys reads NextDNS (4 requests per profile each time).
CommandssectionNoBy default Gladys only reads. The "Filter command" select of each profile turns a filter on or off only once you allow it below (a filter is never a switch: no voice assistant nor "turn everything off" can touch it). Turning a filter on needs the first option; turning one off (security, privacy or parental control) needs the second one too.
Allow the filter commandsbooleanNo
Allow turning protections offbooleanNoLets Gladys turn off a security protection, a privacy blocking (disguised trackers) or a parental control filter, category or service (with the option above). Off: only turning filters on is possible.

How to install NextDNS in Gladys​

  1. In Gladys, open Integrations: NextDNS appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/lm1lc3n7/gladys-nextdns:0.1.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/LM1LC3N7/gladys-nextdns.

NextDNS requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

NextDNS is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by LM1LC3N7, not by the Gladys core team.
