Mosquitto smart home integration, free and open source

The health of your Mosquitto MQTT broker in Gladys: clients, message rates, uptime, outages.

• Published by guim31
• Devices
• Version 1.0.0
• Requires Gladys >=5.1.0
• ★ 0

View on GitHubAll integrations

Watches the health of your Eclipse Mosquitto MQTT broker in Gladys: connected clients, message rates, traffic, subscriptions, uptime, version, and outages, from the statistics Mosquitto publishes on its $SYS topics.

This integration is not affiliated with the Eclipse Foundation or the Mosquitto project.

Overview

Gladys already speaks MQTT: its MQTT integration connects to a broker to drive your devices (including those announced in the Home Assistant format, such as Zigbee2MQTT). It shows no statistics of the broker itself. This integration does: it subscribes to $SYS/broker/#, read-only, and turns what Mosquitto says about itself into a Gladys device, five scene triggers, a scene action and a dashboard widget.

It never publishes a message and never subscribes to anything outside $SYS. Everything stays on your local network.

It can watch the broker Gladys installed for you (the credentials are on the MQTT page of Gladys) as well as any other Mosquitto on your network.

Requirements

• Gladys 5.1 or later.
• Mosquitto 1.6 or later (tested with 2.1 and 1.6), reachable from Gladys.
• A Mosquitto user allowed to read $SYS, or anonymous access if your broker allows it.
• sys_interval not set to 0 in mosquitto.conf (10 seconds by default).

Give the user read access to $SYS

If your broker uses an ACL file (acl_file in mosquitto.conf), add these two lines for the user of the integration, then restart Mosquitto:

user gladys
topic read $SYS/#

For anonymous access, put topic read $SYS/# at the top of the file, before any user line. Replace gladys with your user name. Without them, Mosquitto accepts the connection but sends no statistics: the integration page then shows the exact lines to add. Without an ACL file, every user can read $SYS.

Configuration

1. Open the Configuration tab of the integration.
2. Broker address: mqtt:// followed by the host, and the port if it is not 1883 (for example mqtt://mosquitto.local:1883). For TLS, use mqtts:// (port 8883). WebSocket addresses (ws://, wss://) work too.
3. User name and Password: leave empty for an anonymous broker.
4. Accept a self-signed certificate: only with mqtts://, when the certificate of the broker is not signed by a known authority.
5. Language of the texts: the names of the features when the broker is added, the sentence of the scene action and the messages of the action.
6. Save. The Mosquitto device appears in the Discovery tab once the first statistics arrived (within a second): add it.

The Check the connection button tells whether the broker answers, whether the user may read $SYS, and shows the version and the key numbers.

The integration connects with a client id drawn once and kept (gladys-mosquitto- followed by eight characters), and a clean session: it does not count among the disconnected persistent clients when Gladys restarts.

The broker device

Feature	Meaning
Reachable	1 while the broker answers (even if it refuses the login), 0 otherwise
Connected clients	Clients connected right now, this integration included
Disconnected persistent clients	Clients with a persistent session (clean session off) that are offline
Messages received (/min)	Messages published to the broker per minute (1-minute moving average)
Messages sent (/min)	Messages delivered by the broker to subscribers per minute
Incoming traffic	Bytes received per second (1-minute moving average)
Outgoing traffic	Bytes sent per second
Subscriptions	Active subscriptions
Retained messages	Retained messages kept by the broker
Uptime	Time since Mosquitto started, in days
Version	Version of Mosquitto, as text
Memory used	Memory used by Mosquitto, when it reports it (not the 1.6 Docker image)

A feature only exists if Mosquitto publishes its topic: some builds have no memory figure. Mosquitto 1.6 sends some figures only once they change: such a feature appears later, and the Discovery tab then offers to update the device. When the broker cannot be reached, Reachable goes to 0 and the other features keep their last value.

Mosquitto refreshes its statistics every sys_interval seconds; Gladys receives the changed values at most every 30 seconds, and Reachable at once.

Dashboard widget

The Mosquitto broker widget shows the state of the broker (online, unreachable, login refused, no $SYS statistics), its version and uptime, then four live tiles: connected clients, messages received and sent per minute, subscriptions. Pick the broker in the widget settings.

Scene triggers

• Broker unreachable: the broker has been unreachable for 1, 5, 15, 30 or 60 minutes (to choose). A restart of a few seconds fires nothing, nor does a refused login. Variable: the number of minutes.
• Broker back: the broker answers again after an outage of at least one minute. Variable: the duration of the outage.
• Broker restarted: the uptime of Mosquitto went back to zero. It restarted (update, reboot) or crashed, even if no outage was seen. Variable: the version.
• Fewer connected clients: fewer clients than the chosen number (2 to 100) for one minute: a sensor, a bridge or Zigbee2MQTT dropped. Fires once, and again only after the count came back. Remember that the integration counts as one client.
• Message spike: more messages published per minute than the chosen number (100 to 50,000): a device in a loop, a flood. At most once every 30 minutes per threshold; a flood still going on after 30 minutes is reported again.

Scene action

Broker summary gives a ready-made sentence, for example "Mosquitto 2.1.2 has been running for 3 days, 12 clients connected, 64 messages received and 87 sent per minute.", and its numbers: reachable, connected clients, messages received and sent per minute, uptime in hours, version.

Scene ideas

• Zigbee2MQTT dropped: trigger "Fewer connected clients" below 5, action "Send a message" with the number of clients, to check Zigbee2MQTT.
• Broker down: trigger "Broker unreachable" for 5 minutes, action "Send a message" — the lights and sensors driven over MQTT no longer answer.
• Weekly report: every Sunday at 9:00, action "Broker summary", then "Send a message" with its sentence.

Troubleshooting

• "Connected, but no $SYS statistics": the ACL does not let the user read $SYS. Add topic read $SYS/# under the user in the ACL file (see Requirements), or check that sys_interval is not 0, then restart Mosquitto.
• "Mosquitto refused the connection": wrong user name or password, or anonymous access disabled.
• "The Mosquitto broker cannot be reached": check the address and the port, that Mosquitto listens on the network (listener 1883 in Mosquitto 2, which only listens locally without it), and for mqtts:// the certificate (or tick "Accept a self-signed certificate").
• More details in the integration logs; LOG_LEVEL=debug shows every step.

Limits

• One broker per installation of the integration.
• Mosquitto only: other brokers (EMQX, VerneMQ, HiveMQ) publish different $SYS topics, or none.
• The rates are the moving averages computed by Mosquitto itself.
• A broker bridged to others shows its own figures only.

Configuration settings

These are the settings Mosquitto asks for in its configuration screen in Gladys.

Setting	Type	Required	Description
Connect Mosquitto	section	No	The integration reads the statistics Mosquitto publishes on $SYS/broker/#. It only subscribes, never publishes. The user needs read access to $SYS in the ACL file.
Broker address	string	Yes	mqtt:// (port 1883) or mqtts:// for TLS (port 8883). The broker installed by Gladys works too: its credentials are on the MQTT page of Gladys.
User name	string	No	Leave empty if the broker accepts anonymous clients.
Password	secret	No
Accept a self-signed certificate	boolean	No	mqtts:// only: the certificate of the broker is then not checked.
Language of the texts	select	No	Feature names of the broker when it is added, scene sentences and action messages.

How to install Mosquitto in Gladys

1. In Gladys, open Integrations: Mosquitto appears in the catalog, next to the native integrations, with a community badge.
2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-mosquitto:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
3. Open the Configuration screen of the integration, fill in the settings, and save.
4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-mosquitto.

Mosquitto requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations

Mosquitto is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.

• Browse all integrations, native and community
• Build and publish your own external integration
• Source code on GitHub — source of this documentation
