Moonraker (Klipper) smart home integration, free and open source

Moonraker (Klipper) integration for Gladys Assistant

Follow and control your Klipper 3D printers: progress, temperatures, alerts, macros.

View on GitHubAll external integrations

Follow and control your Klipper 3D printers from Gladys through Moonraker, the API server behind Mainsail and Fluidd: Voron, RatRig, Sovol, Elegoo, rooted Creality K1 or K2, and every printer running Klipper. Everything stays on your local network: Gladys talks directly to Moonraker, without any cloud account.

The integration was tested against a real Moonraker driving Klipper with a simulated micro-controller (simulavr): real prints, pause, resume, cancellation, a print error, an emergency stop, a webcam. Developed without a physical printer: feedback welcome on the Gladys forum.

Prerequisites​

  • Gladys Assistant 5.1 or later.
  • A printer running Klipper and Moonraker (installed with Mainsail or Fluidd, KIAUH, MainsailOS, FluiddPi...), reachable from the Gladys machine on port 7125 or through the address of Mainsail or Fluidd.
  • Either a Moonraker that trusts the network of Gladys (trusted_clients in moonraker.conf, the default of most installs for local networks), or a Moonraker API key.
  • For the webcam image: a webcam declared in Mainsail or Fluidd, with a snapshot address (the default with crowsnest or mjpg-streamer).

Configuration​

  1. Open the Configuration tab of the integration.
  2. In Moonraker address, enter the IP address of the printer, for example 192.168.1.50: the integration then uses port 7125, Moonraker's own. You may also enter the address you open Mainsail or Fluidd with, such as http://192.168.1.50 (its web server forwards the Moonraker API), or a port of your own (192.168.1.50:7126). Prefer an IP address: names like voron.local do not resolve inside the container of the integration.
  3. API key is only needed when Moonraker does not trust the network of Gladys. Mainsail: Settings → Authorization; Fluidd: Settings → Authentication; or http://<printer>:7125/access/api_key from a trusted machine.
  4. A second or third printer: fill in Printer 2 and Printer 3 the same way (one Moonraker each).
  5. Language picks the language of the feature names and of the texts the integration creates (French by default). Feature names are set when the device is added to Gladys.
  6. Save. Test the connection shows the state of each printer and the list of its macros.

Then add the printer from the Discovery tab.

The printer device​

One device per Moonraker, named after the host name of the printer (voron, mainsailos...), or "Klipper". Values arrive live from Moonraker (Klipper pushes its changes several times a second); the integration hands them to Gladys at most every 5 seconds, state changes at once.

FeatureWhat it shows
StateReady, Printing, Paused, Finished, Cancelled, Print error, Klipper stopped (shutdown), Klipper error, Klipper starting, Klipper disconnected, Moonraker unreachable, API key missing or refused
FileThe file being printed, or the last one
ProgressPrint progress, as on the screen of the printer (100 % kept after a finished print)
Elapsed timeSince the start of the print, in minutes
Time leftFrom the slicer estimate when the file has one, otherwise extrapolated from the progress, in minutes (0 at rest)
Layer, Total layersWhen the slicer sends them (SET_PRINT_STATS_INFO, as PrusaSlicer, OrcaSlicer and SuperSlicer setups for Klipper do); 0 otherwise
Nozzle, Nozzle 2, Bed...Temperatures, in whole degrees: every extruder, the heated bed, each heater_generic (a chamber...)
... (target)Targets, read only: heat through the widget or the scene actions
Temperature sensorsEach temperature_sensor and temperature_fan of Klipper (Raspberry Pi, MCU, chamber...), up to six
Part cooling fanSpeed of the [fan], in percent
Pause, ResumePush buttons
WebcamThe snapshot of the first webcam of Mainsail or Fluidd, refreshed every minute

There is deliberately no cancel button on the device: one tap without confirmation would ruin a print. Cancelling is offered by the widget (with a confirmation) and by the scenes. Temperatures and targets are read only too: a printer heater can never be started by mistake from the dashboard, nor by HomeKit, Alexa or Google. Heating goes through the widget (preheat, cool down) and the scene actions. They are "device temperatures" for Gladys: they never count in the temperature of the room. The bounds of each heater are Klipper's own max_temp.

What the printer has (heaters, sensors, fan, webcam) is read from Klipper at every connection. When it changes, Gladys offers to update the device in the Discovery tab.

Dashboard widget​

Add the Klipper 3D print widget to a dashboard and pick the printer in its settings. It shows:

  • the progress gauge, the time left, the nozzle and bed temperatures (live);
  • the state, the file, the layer, the elapsed time, the expected end time, the active targets;
  • the buttons that matter at the moment: Pause or Resume and Cancel (asks for a confirmation) during a print; Preheat and, when something heats, Cool down at rest; Restart Klipper (asks for a confirmation) after Klipper stopped on an error.

The preheat temperatures are widget settings (200 °C and 60 °C by default, PLA). There is no emergency stop button: Klipper's emergency stop is for someone standing next to the printer.

Scene triggers​

In the Integrations category of the scene editor. Each one can be limited to one printer.

  • Print started: variables printer name, file.
  • Print finished: variables printer name, file, print time (as text, like 1 h 05 min, and in minutes).
  • Print failed or cancelled: can be limited to one reason (cancelled, error). An error includes Klipper stopping during the print. Variables printer name, file, print time, reason.
  • Print paused: from Gladys, Mainsail, Fluidd, the screen of the printer or a filament sensor. Variables printer name, file, elapsed time.
  • Klipper stopped on an error: Klipper went into shutdown or error (heater fault, lost micro-controller, emergency stop). Variables printer name, Klipper's message (for example MCU 'mcu' shutdown: ADC out of range).

Variables are read in the next actions with, for example, {{triggerEvent.data.file}} and {{triggerEvent.data.duration}}.

Scene actions​

  • Pause, resume or cancel a print: returns Applied false when there was nothing to pause, resume or cancel (the scene goes on).
  • Preheat the printer: targets of every nozzle and of the bed, 200 °C and 60 °C by default, within the max_temp of each heater. Refused during a print (Applied: false): a scene preheating at a fixed time never touches a running print.
  • Turn the heaters off: TURN_OFF_HEATERS, also during a print (which then fails).
  • Run a Klipper macro: runs a G-code macro of the printer by its name, without parameters, for example LIGHTS_ON. Only the macros Klipper lists are accepted (see Test the connection); private macros (whose name starts with _) and free G-code are refused. Applied: false when Klipper is not ready.

A command Klipper takes long to acknowledge (a pause waits for the moves in its queue, a macro may heat for minutes) is taken as accepted after 15 seconds.

Scene examples​

  • Print finished → notification: trigger Print finished, action "Send a message": {{triggerEvent.data.file}} done in {{triggerEvent.data.duration}}.
  • Klipper stopped → alert: trigger Klipper stopped on an error, message Printer stopped: {{triggerEvent.data.message}}.
  • Smoke detected → stop everything: trigger on the smoke detector, actions Pause, resume or cancel a print (cancel), then Turn the heaters off, then switch the smart plug of the printer off.
  • Ready at breakfast: at 7 am on weekdays, Preheat the printer (no effect if a print is running).
  • Lights for the webcam: Print started → Run a Klipper macro LIGHTS_ON, or switch the workshop light on; Print finished or failed → off.

Troubleshooting​

  • Moonraker unreachable: check the address from the Gladys machine (curl http://192.168.1.50:7125/server/info). Use an IP address rather than voron.local. Behind Mainsail or Fluidd, enter their address without the port.
  • API key missing or refused: Moonraker does not trust the network of Gladys. Paste its API key, or add the network of Gladys to trusted_clients in moonraker.conf. A regenerated key stops the old one.
  • Klipper stopped (shutdown) or Klipper error: Klipper needs your attention (its message is in the trigger, and in Mainsail or Fluidd). Once the cause is fixed, Restart Klipper in the widget runs FIRMWARE_RESTART.
  • Layer stays at 0: the slicer does not send SET_PRINT_STATS_INFO; add it to the layer change G-code of the slicer (see the Klipper documentation).
  • Time left is off: without slicer metadata, it is extrapolated from the file progress, rough at the beginning of a print.
  • No webcam image: the image must be a JPEG of at most 150 KB (a limit of Gladys): lower the resolution of the webcam. A snapshot address relative to Mainsail (/webcam/?action=snapshot) is read on port 80 of the printer.
  • Logs: in the page of the integration in Gladys, or docker logs on the host. LOG_LEVEL=debug gives the details. The API key never appears in the logs.

Limits​

  • Three Moonraker instances at most.
  • No file upload, no print start from Gladys, no free G-code, no timelapse, no Spoolman, no power devices of Moonraker.
  • The webcam image is a snapshot refreshed every minute (and on demand), not a video stream; only the first webcam is used.
  • An event shorter than a quarter of a second may be merged with the next one by Klipper (a print failing at once is reported as failed, without "started").
  • Developed without a physical printer (Klipper with a simulated micro-controller was used): feedback welcome.
  • Not affiliated with the Klipper or Moonraker projects.

Configuration settings​

These are the settings Moonraker (Klipper) asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Connect your Klipper printersectionNoEnter the address of Moonraker: the IP address of the printer (port 7125 by default), or the address you open Mainsail or Fluidd with. An API key is only needed when Moonraker does not trust your network. Up to three printers.
Moonraker addressstringNo
API key (optional)secretNoMainsail: Settings, Authorization, API key. Fluidd: Settings, Authentication. Leave empty on a trusted network.
Printer 2 (optional)sectionNo
Moonraker address 2stringNo
API key 2 (optional)secretNo
Printer 3 (optional)sectionNo
Moonraker address 3stringNo
API key 3 (optional)secretNo
OptionssectionNoLanguage of the names and texts the integration creates (feature names are set when a device is added).
LanguageselectNo

How to install Moonraker (Klipper) in Gladys​

  1. In Gladys, open Integrations: Moonraker (Klipper) appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-moonraker:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-moonraker.

Moonraker (Klipper) requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Moonraker (Klipper) is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
