MinIO smart home integration, free and open source

MinIO integration for Gladys Assistant

Your MinIO storage in Gladys: free space, drives, buckets, and an alert when a drive is lost.

View on GitHubAll integrations

MinIO is a self-hosted object storage server, compatible with Amazon S3. This integration brings a MinIO server or cluster into Gladys: its free space, its drives and nodes online or offline, its objects, and one device per bucket with its size. Scenes can react when MinIO stops answering, when a drive or a node goes offline, or when the free space gets low; a dashboard widget shows the capacity and the largest buckets. The integration only reads: it never writes to MinIO.

Tested against a real MinIO RELEASE.2026-10-23 (built from the MinIO sources by Chainguard, a cluster of 4 nodes and a server with 4 drives, in Docker): a node stopped, a drive made unreadable, two drives lost (write quorum gone), the server stopped and started again. Also read a MinIO of May 2025. MinIO no longer publishes Docker images of its community edition since late 2025: the integration reads the metrics every MinIO version has offered for years, the way you install it does not matter. Not yet tested on a real Gladys: feedback welcome on the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • A MinIO server or cluster reachable from the Gladys machine, on its S3 API port (9000 by default), not on the port of its console (9001).
  • A MinIO user allowed to read the metrics (the admin:Prometheus permission), or metrics opened to everyone with MINIO_PROMETHEUS_AUTH_TYPE=public.

The integration reads two pages of metrics every minute by default: light requests on your own network.

Getting started​

1. Create a user that only reads the metrics​

With the mc client, create a policy that only allows the metrics, a user, and attach the policy to it:

cat > gladys-metrics.json <<'EOF'
{
  "Version": "2012-10-17",
  "Statement": [{ "Effect": "Allow", "Action": ["admin:Prometheus"], "Resource": ["arn:aws:s3:::*"] }]
}
EOF
mc admin policy create myminio gladys-metrics gladys-metrics.json
mc admin user add myminio gladys <a-long-secret-key>
mc admin policy attach myminio gladys-metrics --user gladys

This user can neither read nor write a single object. You do not need to generate a token with mc admin prometheus generate: the integration signs its own, with the secret key, for each request.

2. Configure the integration​

In Gladys, open the MinIO integration and enter:

  • MinIO address: e.g. http://192.168.1.2:9000, or https://s3.example.org behind a reverse proxy. A bare address uses port 9000.
  • Access key and Secret key of the user created above. Leave both empty if the metrics are public.
  • Accept a self-signed certificate only for an https:// address whose certificate is not signed by a known authority.
  • Refresh interval (1 minute by default), Low free space threshold (%) (10 % by default) and the Language of the names.

Test the connection reads MinIO at once and answers in one line: version, free space, drives, buckets.

On a cluster, any node will do, but the integration only sees what the node it reads sees: if that node stops, MinIO "no longer answers". Point it at a load balancer in front of the nodes when there is one.

3. Add the devices​

In the Discover tab, add the MinIO server and the buckets you want to follow. Nothing is created without you.

The devices​

The MinIO device:

  • Online: 1 while MinIO answers.
  • Healthy (write quorum): 1 while every erasure set has enough drives to accept writes. At 0, MinIO refuses new objects.
  • Version: the RELEASE date of MinIO (the most recent one when the nodes differ).
  • Data stored: the size of the objects (GB).
  • Free space and Usable capacity: after the erasure-coding parity (GB), the figures mc admin info shows.
  • Free space (%): free space out of the usable capacity.
  • Objects and Buckets.
  • Drives online, Drives offline, Nodes offline.
  • Drives healing: drives MinIO is rebuilding after a replacement.

One device per bucket: Size (MB) and Objects. A bucket deleted in MinIO shows as unreachable in Gladys.

MinIO computes the drives, the nodes and the capacity in the background: a lost drive shows within a minute or two. The objects and the sizes come from its scanner, which runs in the background too: on a fresh server they appear after its first pass, and they lag behind the uploads.

Dashboard​

The MinIO widget shows a gauge of the capacity used (green, orange near the threshold, red under it), the free space, the drives offline and the objects, then the buckets, the largest first, with their size and their objects (ten rows at most). Its settings choose the buckets to show (empty: all). The Refresh button reads MinIO again. When MinIO does not answer, or has lost its write quorum, the widget says so.

Scenes​

Triggers​

  • MinIO no longer answers: two reads in a row failed. Variables: server address, reason.
  • MinIO answers again: with the downtime in minutes.
  • MinIO drive offline: more drives are offline than at the previous read. When a whole node stops, its drives go with it: this trigger and the next one both fire.
  • MinIO drive back online: fewer drives are offline.
  • MinIO node offline and MinIO node back online: the same for the nodes of a cluster.
  • MinIO free space low: the free space went under the threshold of the configuration. It fires again only after the free space climbed back one point above the threshold.

The drive, node and threshold triggers carry the counts (drives offline and online, nodes offline and online, free space). What was seen is kept by the integration: a drive lost while Gladys was restarting is still announced, once.

Actions​

  • State of MinIO: reads MinIO for the next actions: online, healthy, version, free space, objects, buckets, drives, and a ready-made sentence ("MinIO: 400 GB free (40 %), 0 drive(s) offline."). When MinIO does not answer, it says so instead of failing.
  • State of a bucket: the size and the objects of a bucket, and a sentence.

Scene ideas​

  • A drive is lost: on "MinIO drive offline", send a message with the number of drives offline, a variable of the trigger.
  • Storage almost full: on "MinIO free space low", send a message with the free space and the threshold.
  • Every Sunday: at 10:00, "State of MinIO", then send its sentence.

Troubleshooting​

  • "Access refused": wrong access key or secret key, or the user lacks the admin:Prometheus permission. MinIO gives the same answer for both.
  • "No MinIO server at this address": the address is probably the one of the console (9001): use the API port (9000 by default).
  • "Certificate refused": tick "Accept a self-signed certificate", or use the http:// address.
  • No objects, no bucket: the scanner of MinIO has not finished its first pass yet: wait a few minutes.
  • Detailed logs: LOG_LEVEL=debug on the container of the integration.

Limits​

  • Reading only: no bucket is created, emptied or deleted from Gladys.
  • The counts of drives and nodes are those of the whole cluster: MinIO's metrics do not tell which drive was lost (mc admin info does).
  • Sizes come from the scanner of MinIO and lag behind.
  • The integration has not been tested with S3-compatible replacements (Garage, SeaweedFS): their metrics are different, they are not supported.
  • One MinIO server or cluster per installation of the integration.
  • Not affiliated with MinIO, Inc.

Configuration settings​

These are the settings MinIO asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your MinIO serversectionNoA MinIO server or cluster. Enter the address of its API and the keys of a user allowed to read its metrics, then add the server and the buckets to follow from the Discover tab.
MinIO addressstringYesThe address of the S3 API (port 9000 by default), not the one of the console. https:// if the server uses TLS.
Access keystringNoOf a user with the admin:Prometheus permission (see the guide). Empty if the metrics are public (MINIO_PROMETHEUS_AUTH_TYPE=public).
Secret keysecretNoThe secret key of this user. It never leaves the integration: it signs the metrics requests.
Accept a self-signed certificatebooleanNoOnly for an https:// address whose certificate is not signed by a known authority.
OptionssectionNo
Refresh intervalselectNoHow often the metrics are read. MinIO itself refreshes the drives and the capacity about once a minute.
Low free space threshold (%)numberNoThe scene trigger "MinIO free space low" fires when the free space goes under this percentage of the usable capacity.
Language of the namesselectNoLanguage of the feature names and of the texts sent by the integration (scene actions, triggers).

How to install MinIO in Gladys​

  1. In Gladys, open Integrations: MinIO appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-minio:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-minio.

MinIO requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

MinIO is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
