MikroTik smart home integration, free and open source

MikroTik routers: presence of your devices, router health, WAN rates and outages.

• Published by guim31
• Devices
• Version 1.0.1
• Requires Gladys >=5.1.0
• ★ 0

View on GitHubAll integrations

Follow your MikroTik router from Gladys, over your local network: know who is home from the phones on your Wi-Fi, see the health of the router and the rates of your internet link, be told when the WAN drops or when an unknown device joins, and, if you allow it, cut the internet of the kids' tablet from a scene.

Developed without the hardware: feedback welcome. This integration was built and tested against the answers documented by MikroTik and the test data of the Home Assistant integration, not against a real router. If something does not work as described, please say so on the Gladys forum or in the issues.

This integration is not affiliated with MikroTik.

What you need

• Gladys Assistant 5.1.0 or later.
• A MikroTik router running RouterOS 7 (REST API) or RouterOS 6.43 or later (API), reachable from Gladys.
• One of these RouterOS services enabled (IP → Services): www-ssl (HTTPS, RouterOS 7), api-ssl, www (HTTP, RouterOS 7) or api. The default configuration of RouterOS has www and api enabled.
• A RouterOS user for Gladys (see below).

Set up

The RouterOS user

Create a dedicated user rather than using admin. A read-only account is enough for the presence sensors, the measurements, the triggers and the widgets. In a terminal (WinBox, WebFig or SSH):

/user add name=gladys group=read password=a-long-password

Check that the group has the api policy, and rest-api on RouterOS 7 (System → Users → Groups). The commands (firewall rules, reboot) need a group with the write and reboot policies, such as write.

To go further, allow the service only from the address of Gladys, e.g. /ip service set www address=192.168.88.10/32.

The configuration

Open Integrations → MikroTik → Configuration:

• Router address: its IP address (192.168.88.1 by default), with :port if the service does not use its default port.
• User name and Password of the RouterOS user.
• Protocol: Automatic tries REST over HTTPS, API-SSL, REST over HTTP, then API, and keeps the first that works; the encrypted ones first. Choose one to force it.
• Accept a self-signed certificate: for HTTPS and API-SSL. RouterOS uses a self-signed certificate unless you installed another one.
• Refresh interval: 10 seconds to 1 minute (30 seconds by default).
• WAN interfaces: empty, the integration takes the members of the WAN interface list of RouterOS (the default configuration puts ether1 in it), else ether1. Up to four names, separated by commas.
• Presence: the Departure delay (minutes) and the sources (see below).
• Firewall rules to follow and Allow commands (see below).
• Language of the names: the language of the device and feature names.

Then press Test the connection: the report says which protocol is used, which WAN interfaces are followed, how many clients are seen and whether the followed rules exist. Finally open the Discovery tab and add the devices you want.

The devices

The router

One device, named after the RouterOS identity:

Feature	What it shows
CPU load	in %
Memory used	in %
Temperature	in °C, when the router has a sensor
Uptime	in hours
RouterOS version	e.g. 7.18.2
RouterOS update available	On when RouterOS reports a newer version
Download / Upload	per WAN interface, in Mbit/s, averaged over a period
WAN link	per WAN interface: On when the link is up

The integration asks RouterOS to check for updates once a day (a read-only user cannot: then the last check made by RouterOS is shown).

Presence sensors

The Discovery tab lists the clients of the router: its DHCP leases, its Wi-Fi registration tables (wireless, wifiwave2, wifi and CAPsMAN) and, if enabled, its ARP table. Add the phones you want to follow: each becomes a Presence sensor, named after its comment in RouterOS, else its host name.

• A device is present as soon as the router sees it: associated to the Wi-Fi, or with a live ARP entry if Also use the ARP table is ticked, or with a bound DHCP lease if Count a DHCP lease as present is ticked.
• It becomes away only when it has not been seen for the Departure delay (5 minutes by default): a phone asleep leaves the Wi-Fi for a few minutes without leaving home.
• When the router cannot be read, nobody changes state.

A present device is published again every two minutes, so the Check user presence scene action of Gladys works too; with the departure delay, you rarely need it.

Phones use a private (random) Wi-Fi address per network. Keep it fixed for your home Wi-Fi (on iOS: Private Wi-Fi Address set to Fixed; on Android: per-network randomization, not per connection), or the device will look new after a change.

Firewall rules

To follow a rule, give it a comment in RouterOS (IP → Firewall → Filter Rules), then enter that comment in Firewall rules to follow (List the firewall rules shows the commented rules). Each one becomes a device with a Rule enabled feature (On when the rule is enabled). The IPv4 and IPv6 rules that share the comment count as one.

The state is read only. With Allow commands ticked, the scene actions and the widget can enable or disable the rule: the integration then changes only the disabled flag of these rules, and nothing else in the configuration.

Dashboard

Three widgets:

• MikroTik router: CPU, memory, temperature, download and upload rates of the first WAN interface, the state of every WAN link, the uptime, the RouterOS version or the update available, and a Reboot button (with confirmation) when the commands are allowed.
• Devices at home: the devices followed as presence sensors, present first, with how long the others have been away. Its setting Show keeps only the present ones.
• Firewall rules: the followed rules, and when the commands are allowed, one button per rule (four at most) to enable or disable it, with confirmation. A check mark shows the enabled rules.

Scenes

Triggers

• Unknown device connected: a MAC address never seen before joined the Wi-Fi or got a DHCP lease. The devices present when the integration starts for the first time are learnt without firing. Filter: Seen by (Wi-Fi or DHCP lease). Variables: MAC address, IP address, host name, seen by, interface.
• WAN link down: a WAN interface lost its link. Filter: Interface. Variable: interface.
• WAN link restored: the link is back. Filter: Interface. Variables: interface, outage in minutes.

Actions

They need Allow commands, and a RouterOS user with the write and reboot policies.

• Enable a firewall rule and Disable a firewall rule: choose a rule device. Output: Rule enabled.
• Reboot the MikroTik router: the network is cut for a minute or two.

Scene ideas

• Nobody home: when the presence of every phone is "No presence", set the alarm and lower the heating.
• Bedtime for the tablet: every evening at 21:00, Enable a firewall rule "Block kids tablet"; at 7:00, Disable a firewall rule.
• Internet outage: on WAN link down, send a message through a channel that does not need the internet (an SMS gateway on the LAN), and on WAN link restored, tell how long it lasted.
• Who is this?: on Unknown device connected, send yourself a message with its host name and IP address.

How often the router is read

The integration reads the router itself, at the refresh interval of the configuration (Gladys does not poll these devices). A reading is about ten small listings (resource, health, interfaces, Wi-Fi, ARP, DHCP leases, rules): negligible for the router. The update status is read every hour, and RouterOS is asked to check MikroTik's servers once a day. Only the values that change are sent to Gladys, plus a heartbeat every six hours.

Troubleshooting

• "user name or password refused": check them in WinBox. After a refusal, the integration tries again every five minutes (each try is a line in the RouterOS log).
• "the user group lacks a policy": give the group api (and rest-api on RouterOS 7).
• "certificate refused": tick Accept a self-signed certificate, or install a certificate trusted by Gladys.
• "does not answer": check the address, that the service is enabled in IP → Services, and that its address field allows Gladys.
• No WAN rate: the rates need two readings; check the names in WAN interfaces.
• A phone stays away: tick Also use the ARP table, raise the departure delay, and check its private Wi-Fi address is fixed.
• More details: start the integration with LOG_LEVEL=debug. At the default level the logs show only the start, the router lost and back, the problems (once each) and your commands. Passwords never appear in the logs.

Limits

• One router per integration. With several access points, follow the presence on the one that sees every client (the CAPsMAN controller, or the router with the ARP table).
• The WAN link state is the state of the interface: an internet outage behind a working link (the ISP side) is not seen.
• The rates are averages over the refresh interval, from the interface counters.
• The Wi-Fi tables of other brands of access points are not read: use the ARP table.
• Device and feature names are set when a device is added to Gladys.
• Firewall filter rules only (not NAT, mangle or Kid Control), found by their exact comment.
• Developed without the hardware: the answers of real routers may differ from the documented ones. Feedback welcome.

Configuration settings

These are the settings MikroTik asks for in its configuration screen in Gladys.

Setting	Type	Required	Description
Your MikroTik router	section	No	RouterOS 7 (REST API) or RouterOS 6.43+ (API). Create a dedicated user: the read group is enough for presence and measures. The protocol is detected automatically.
Router address	string	Yes	IP address or name of the router, with :port if the service does not use its default port.
User name	string	Yes	A RouterOS user, ideally in the read group.
Password	secret	No
Protocol	select	No	Automatic tries REST over HTTPS, API-SSL, REST over HTTP, then API, and keeps the first that works.
Accept a self-signed certificate	boolean	No	For HTTPS and API-SSL: RouterOS uses a self-signed certificate unless you installed another one. Tick only for your own router.
Refresh interval	select	No	How often the router is read. The rates are averages over this interval.
WAN interfaces	string	No	Names separated by commas, up to four. Empty: the members of the WAN interface list of RouterOS, else ether1.
Presence	section	No	Add the devices to follow from the Discovery tab: each one becomes a presence sensor, present when the router sees it.
Departure delay (minutes)	number	No	A device no longer seen counts as away only after this delay: a phone asleep leaves the Wi-Fi for a few minutes.
Also use the ARP table	boolean	No	Sees the wired devices and the Wi-Fi of other access points. The Wi-Fi registration tables of the router are always used.
Count a DHCP lease as present	boolean	No	A lease stays bound until it expires, long after the device left: tick it only for devices nothing else sees.
Firewall rules and commands	section	No	Read only by default. Commands enable or disable the rules listed below, or reboot the router, from a scene or a widget. Nothing else is ever changed.
Firewall rules to follow	string	No	The comments of the filter rules, separated by commas (up to ten). "List the firewall rules" shows them.
Allow commands	boolean	No	Lets scenes and widgets enable or disable the rules above and reboot the router. The user needs the write and reboot policies.
Language of the names	select	No	Language of the device and feature names, set when a device is added.

How to install MikroTik in Gladys

1. In Gladys, open Integrations: MikroTik appears in the catalog, next to the native integrations, with a community badge.
2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-mikrotik:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
3. Open the Configuration screen of the integration, fill in the settings, and save.
4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-mikrotik.

MikroTik requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
