Midea integration for Gladys Assistant

Midea air conditioners and their rebrands on the local network: mode, setpoint, fan, energy.

View on GitHubAll external integrations

Control your Midea air conditioners from Gladys, on your local network: on/off, mode, setpoint, fan speed, swing, eco, turbo and sleep modes, indoor and outdoor temperature, and the energy consumption of the units that measure it.

Developed without the hardware: feedback welcome. This integration was written and tested against recorded frames of real units, not against a physical air conditioner. Please report what works and what does not on GitHub.

This integration is not affiliated with Midea.

Compatible hardware​

The criterion is the app, not the brand on the unit: an air conditioner (Midea appliance type 0xAC) with a Wi-Fi module that is set up in one of these apps works with this integration:

  • SmartHome / MSmartHome, NetHome Plus, Midea Air, Toshiba AC NA, Arctic King.

Midea builds units for many brands; units of related brands such as Comfee, Carrier or some Toshiba lines often use these apps. Split, window and portable units all speak the same protocol.

Not supported: other Midea appliances (dehumidifiers, water heaters...), which the search lists as "not supported", and the very first Wi-Fi modules (protocol V1, around 2015).

Requirements​

  • Gladys 5.2.0 or later.
  • The air conditioner on the same local network as Gladys, set up once in its app (the Wi-Fi module must be connected to your network).
  • For the units sold since about 2020 (protocol V3): an Internet access once, to fetch the unit's key from the Midea cloud. After that, everything is local.

Installation and configuration​

  1. In Gladys, open Integrations → Install from GitHub and enter https://github.com/guim31/gladys-midea.
  2. On the installation screen, accept the network discovery request: Gladys sends the Midea search request on your network (UDP ports 6445 and 20086) on behalf of the integration.
  3. Open the integration's Configuration tab. The settings:
    • IP addresses of the air conditioners: optional, only for the units the automatic search does not find (another subnet, a router that filters broadcasts). Give them a fixed address in your router.
    • Refresh interval: how often each unit is read (30 seconds by default).
    • Language of the device names: language of the names given to the new devices and their features (French by default).
    • Beep on each command: off by default, so that a scene at night stays silent.
    • Energy data format: leave "Standard (BCD)" unless the power or energy shown is absurd.
    • Keys of recent units (V3): the Cloud region of the public account used to fetch the keys (Europe by default), or your own account, in NetHome Plus account and NetHome Plus password (both optional).
  4. Open the Discovery tab: every unit found appears, named "Air conditioner" followed by the last four characters of its Wi-Fi name. Add the ones you want to Gladys.

The Search for air conditioners button (Configuration tab) runs a new search and lists every unit found, its address, its protocol and whether it answers.

About the keys of the V3 units​

A V3 unit only talks to a client that knows its token and key. These are stored by Midea in its cloud, filed under the unit itself, not under an account: the integration fetches them once, with public NetHome Plus accounts (the practice of the open-source libraries msmart-ng and midea-local), or with your own account if you enter it. They are then saved in Gladys' integration volume (/data) and never written in the logs. If the unit is reset or paired again in its app, the integration notices the refused key and fetches a new one.

Devices and features​

Each air conditioner is one Gladys device. Its features depend on what the unit announces:

FeatureWhat it does
On/offTurns the unit on or off.
ModeAuto, Cool, Heat, Dry, Fan only (only the modes the unit has).
Target temperatureThe setpoint, by half degrees when the unit takes them, within its range (16 to 30 °C usually).
Fan speedAuto, Silent, Low, Medium, High, Maximum (only the speeds the unit has).
Vertical swing, Horizontal swingSwing or fixed, when the unit has the louver.
Indoor temperatureThe temperature measured by the indoor unit.
Outdoor temperatureThe temperature measured by the outdoor unit, when it reports one.
Indoor humidityWhen the unit has a humidity sensor.
Eco mode, Turbo, Sleep modeThe unit's presets. Eco and Turbo exclude each other.
Power draw, Energy consumedInstant power (W) and total energy (kWh), for the units with an energy meter.

The changes made with the remote or the app are picked up at the next reading.

Widget​

The Air conditioner widget (choose the unit in its settings) shows the room temperature, the setpoint and the outdoor temperature (or the humidity), then the mode, the fan speed, the filter state and the error code of the unit. Its buttons:

  • Turn on / Turn off;
  • −0.5 °C and +0.5 °C (by 1 °C on the units that do not take half degrees);
  • Mode and fan: a small form to choose the mode and the fan speed together; the unit is switched on.

Scene triggers​

  • Filter needs cleaning: the unit asks for its filter to be cleaned. Useful to send yourself a message.
  • Unit error: the unit reports a new error code. The code is available to the scene as a variable (error_code), to put in a message.

Scene action​

  • Run the air conditioner: turns the unit on with its mode, setpoint and fan speed in one command (one beep, no intermediate state), where the standard Gladys actions would send one command per feature. An empty field keeps the current setting. The setpoint accepts half degrees (24,5 or 24.5). The setpoint applied is returned to the scene.

Turning the unit off, or changing a single setting, uses the standard "Control a device" action of Gladys.

Scene examples​

  • Cool the bedroom before bedtime: at 9:30 pm, if the bedroom temperature is above 26 °C, "Run the air conditioner" in Cool at 24 °C, fan Silent, then turn on the Sleep mode.
  • Nobody home: when the last person leaves, turn off every air conditioner.
  • Filter reminder: on "Filter needs cleaning", send a message "Clean the filter of the living room air conditioner".
  • Breakdown alert: on "Unit error", send a message with the error code (error_code).

Refresh and network​

  • The integration reads each unit itself every 30 seconds by default, through the local network (TCP port 6444). Gladys' own polling is only a fallback. Each reading is a few small frames: no Internet, no quota.
  • Only the values that changed are sent to Gladys, plus a reminder every 6 hours so that a stable value never looks stale.
  • A new search runs every 30 minutes, to follow a unit whose address changed.
  • The Midea cloud is only contacted to fetch the key of a V3 unit that has none yet.

Troubleshooting​

  • No unit found: check that the unit is connected in its app and on the same network as Gladys; enter its IP address in the configuration; run Search for air conditioners.
  • "A recent (V3) unit has no key": Gladys could not reach the Midea cloud, or the public account of the region does not know the unit. Try another Cloud region, or enter your own NetHome Plus account, then run Search for air conditioners again.
  • The unit does not answer: check that it is powered and that its address did not change; a module only accepts one connection at a time, so close other local tools that talk to it.
  • Absurd power or energy values: switch the Energy data format to "Binary".
  • More details: set the LOG_LEVEL environment variable of the container to debug.

Limits​

  • Developed without the hardware: feedback welcome on GitHub.
  • Air conditioners only: dehumidifiers and other Midea appliances are not supported yet.
  • The louver positions, the display (LED) and the advanced presets (breeze, iECO, fresh air...) are not handled.
  • The first-generation modules (V1) are not supported.
  • Gladys shows the setpoint by whole degrees on some screens; the unit itself takes half degrees.
  • The key of a V3 unit needs the Midea cloud once: if Midea closes this service, units already known keep working.

Configuration settings​

These are the settings Midea asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Finding your air conditionerssectionNoMidea units, and those of related brands using the same apps (Comfee, Carrier, some Toshiba...), on the same network as Gladys are found automatically: open the Discovery tab. Keep them set up in their mobile app. If one is missing, enter its IP address below.
IP addresses of the air conditionersstringNoOptional, separated by commas. Only needed for the units automatic discovery does not find.
Refresh intervalselectNoHow often each unit is read, to follow the changes made with its remote or its app.
Language of the device namesselectNoNames given to new devices and their features (Mode, Fan speed...).
Beep on each commandbooleanNoThe unit beeps when Gladys changes a setting, as with its remote.
Energy data formatselectNoUnits with an energy meter encode it in one of two ways. Change it only if the power or energy shown is absurd.
Keys of recent units (V3)sectionNoUnits sold since about 2020 need a key, fetched once from the Midea cloud, then kept in Gladys: everything else stays local. Public accounts are used by default; you may enter your own NetHome Plus account instead.
Cloud regionselectNoRegion of the public account. Try another one if the key cannot be fetched.
NetHome Plus account (optional)stringNo
NetHome Plus password (optional)secretNo

How to install Midea in Gladys​

  1. In Gladys, open Integrations: Midea appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-midea:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-midea.

Midea requires Gladys >=5.2.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Midea is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
