Matomo smart home integration, free and open source

Matomo integration for Gladys Assistant

Visitors right now, today's visits and goal conversions of your Matomo websites in Gladys.

View on GitHubAll integrations

Matomo is the open source (GPL-3.0) web analytics platform, self-hosted or on Matomo Cloud. This integration brings the figures of your Matomo websites into Gladys: each website becomes a device with its visitors right now and its unique visitors, visits, page views, goal conversions and bounce rate of the day. Scenes can react to a visitor spike, to the first visitor of the day, to a goal reached, or to a website that receives no visit any more (a broken tracking code); a dashboard widget shows the day at a glance, and a scene action puts the figures of a website in a message.

Tested against a real self-hosted Matomo 5.14.2 (Docker, MariaDB); not yet on Matomo Cloud: feedback welcome on the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • A Matomo 4 or 5, self-hosted or on Matomo Cloud, reachable from the Gladys machine.
  • An authentication token (token_auth) of a Matomo user with view access to the websites. A dedicated view-only user is best: the token gives the rights of its user.

At each refresh the integration sends one request to the Reporting API for up to 20 websites (a bulk request: visitors of the last 30 minutes, visits, page views and goals of the day), plus the website list every 10 minutes. The token is always sent in the body of a POST request, never in an address. Gladys accepts 300 states per minute: with the 30-second interval, add 25 websites at most to Gladys.

Getting started​

1. Create a token​

In Matomo, as a super user, create a user with the View access on the websites to follow (Administration → System → Users), or use your own account. Logged in as this user, open Personal → Security → Auth tokens, click Create new token, and copy the token (32 characters, shown only once).

2. Configure the integration​

In Gladys, open Integrations → Matomo → Configuration:

  • Matomo address: the address you open Matomo with, for example https://stats.example.org, http://192.168.1.10:8080 or https://example.matomo.cloud. An address copied from the browser is understood; a sub-folder (https://example.org/matomo) is kept.
  • Authentication token: the token of step 1.
  • Refresh interval: from 30 seconds to 5 minutes (1 minute by default).
  • Visitor spike from: the visitors at the same time that fire the "Visitor spike" trigger (10 by default).
  • No visit for (hours): the hours without any visit that fire the "No visit for a while" trigger (24 by default).
  • Language of the names: language of the feature names and of the scene results (French by default).

Save, then click Test the connection: the result gives the version of Matomo, the number of websites, the unique visitors of the day and the visitors right now.

3. Add the websites​

Open the Discover tab: each website is proposed with its name. Add the ones you want to see in Gladys. The scene triggers and the widget work for every website, added or not.

The devices​

Each website becomes a device with:

  • Visitors right now: the visitors of the last 30 minutes, as in the "Real-time visitors" widget of Matomo.
  • Unique visitors today: unique visitors of the day.
  • Visits today: visits of the day.
  • Page views today: page views of the day.
  • Goal conversions today: conversions of all the goals of the website.
  • Bounce rate today: the share of visits that saw a single page, in percent.

"Today" is the day of the website in Matomo (its time zone, in the website settings): the daily figures go back to 0 at its midnight. A value that does not change is sent again every 12 hours, so Gladys keeps it recent. The badge of the devices says "local" for your own server, "cloud" for Matomo Cloud, and "unreachable" when Matomo does not answer.

Dashboard​

The Matomo today widget shows five tiles (visitors right now, unique visitors, visits, page views and goals of the day), added up over the websites shown, then one row per website with its unique visitors of the day and its visitors right now, the busiest first. In the widget settings, choose some websites to show only them (devices added to Gladys). The Refresh button reads Matomo again.

Scenes​

Triggers​

  • Visitor spike: the visitors right now of a website reach the threshold of the configuration. Once per spike, and 30 minutes at least between two announcements for a website: a spike still under way at the end of the pause is announced then. Variables: website name, domain, visitors right now, threshold.
  • First visitor of the day: a website receives its first visitor of the day. Variables: website name, domain, unique visitors today.
  • Goal reached: a website records new goal conversions. Variables: website name, domain, new conversions, conversions today.
  • No visit for a while: a website that had visits receives none for the hours of the configuration: the tracking code may be broken, or the website down. Once, until a visit comes again. Variables: website name, domain, hours without a visit.

Each trigger can be limited to some websites (empty: any). What the triggers remember is kept in the /data volume: a restart of Gladys or of the integration does not announce a spike, a first visitor or a conversion twice. Nothing is announced at the first read of a website: a spike or a silence already under way is only recorded. If the integration was stopped, the conversions and the first visitor of the meantime are announced at the first read after it starts again.

Actions​

  • Read the figures of a website: gives the name, the visitors right now (active), the visitors, visits, pageviews, conversions and bounce_rate of the day, and a ready-made sentence, for example "Blog: 15 visit(s) and 41 page view(s) today, 2 right now, 1 goal conversion(s).".

Scene ideas​

  • When Goal reached fires for your shop, send a Telegram message "{{website}}: {{conversions}} new conversion(s), {{total}} today".
  • When No visit for a while fires, send a notification "No visit on {{website}} for {{hours}} h: check the tracking code".
  • Every evening at 21:00, Read the figures of a website and send the sentence by message.
  • With the device feature Visitors right now as a scene condition, light a lamp in green while someone is on the website.

Troubleshooting​

  • "token refused": the token is wrong, deleted or expired: create a new one in Personal → Security.
  • "no Matomo at this address": check the address and the port; it is the folder where index.php lives.
  • "the address redirects": enter the https:// address directly.
  • "certificate refused": the HTTPS certificate is self-signed or expired: use the http:// address in your network, or a trusted certificate.
  • "Matomo reports an error": the logs of the integration give the message of Matomo (a database error, a plugin disabled...).
  • A website is missing: the user of the token needs the View access to it. The list is read again every 10 minutes, or with Search in the Discover tab.
  • The figures of the day move by steps: Matomo computes them again at most every 15 minutes by default (Administration → System → General settings → Archive reports at most every X seconds), or at each archiving cron job if browser-triggered archiving is turned off. "Goal reached" follows them. The visitors right now are always live.
  • Goal conversions today stays empty: the Goals plugin is disabled. Visitors right now stays empty: the Live plugin, or the visits log, is disabled.
  • The logs of the integration (Integrations → Matomo) say more; nothing is written there during a normal reading cycle.

Limits​

  • Read-only: the integration does not change anything in Matomo.
  • The figures are those of Matomo at the time of the read, with the refresh interval as delay (and the archiving of Matomo for the figures of the day).
  • One Matomo server per integration, 200 websites at most.
  • The thresholds of "Visitor spike" and "No visit for a while" are the same for every website; "Goal reached" counts all the goals of a website together.
  • Matomo 3 and older are not supported.
  • Not tested on Matomo Cloud yet, and not affiliated with Matomo or InnoCraft.

Configuration settings​

These are the settings Matomo asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your MatomosectionNoThe address of your Matomo (self-hosted or Matomo Cloud) and an authentication token of a user with view access (Personal → Security → Auth tokens). Then add the websites from the Discover tab.
Matomo addressstringYesThe address you open Matomo with, e.g. https://stats.example.org or https://example.matomo.cloud.
Authentication tokensecretYestoken_auth of a user with view access only: 32 characters.
OptionssectionNo
Refresh intervalselectNoHow often Matomo is read: one API request for up to 20 websites each time.
Visitor spike fromnumberNoVisitors at the same time (last 30 minutes) that fire the scene trigger "Visitor spike".
No visit for (hours)numberNoHours without any visit that fire the scene trigger "No visit for a while".
Language of the namesselectNoLanguage of the feature names (set when a device is added) and of the scene results.

How to install Matomo in Gladys​

  1. In Gladys, open Integrations: Matomo appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-matomo:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-matomo.

Matomo requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Matomo is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
