Mailcow smart home integration, free and open source
Watch your mailcow mail server: containers, queue, quarantine, storage and mailboxes.
Published by prohand
- Devices
- Version 2.0.0
- Requires Gladys >=5.3.0
- ★ 0
Watch your mailcow: dockerized mail server from Gladys: containers, mail queue, quarantine, banned IPs, storage, domains and mailboxes — with scene triggers, scene actions and dashboard widgets.
Requires Gladys 5.3 or later and a mailcow API key.
1. Create an API key in mailcow
- Log in to the mailcow web interface as an administrator.
- Open System → Configuration → Access → Administrators, then unfold API.
- Choose the key:
- Read-only: enough to watch the server (recommended);
- Read-write: needed only if you want Gladys to flush the queue or turn domains and mailboxes on and off.
- In Allow API access from these IPs/CIDR, add the IP address Gladys reaches mailcow from (the IP of the Gladys host, or its public IP if mailcow is on the internet).
- Tick Activate API and save. Copy the key.
If the IP is missing, mailcow answers "api access denied for ip …": Test the connection shows that IP, add it to the list.
2. Configure the integration
| Field | What to put |
|---|---|
| LAN address | mailcow on your network, e.g. https://192.168.1.20. Empty if mailcow is elsewhere. |
| Public address | mailcow on the internet, e.g. https://mail.example.com. |
| API key | The key copied above. |
| Check the certificate of the LAN address | Untick it when the LAN address is an IP (the certificate names the domain). |
| Refresh interval (s) | How often the server is read: 60 s to 1 h, 300 s by default. |
| One device per domain | On by default. |
| One device per mailbox | Off by default; for a server with a few mailboxes (200 at most). |
| Allow changes | Off by default. On (with a read-write key): flush the queue, turn domains/mailboxes on and off. |
| Thresholds | Queue (20 mails), storage (85 %), mailbox quota (90 %): used by the scene triggers. |
| Detailed logs | Logs every read. The API key is never logged. |
Then click Test the connection: it reads the server and sums it up (version, containers, queue, quarantine, storage, domains, mailboxes), or says what is wrong.
3. Local and cloud
The integration knows two ways to reach mailcow:
- the LAN address is the
localtransport; - the public address is the
cloudtransport (a server at a hosting provider, or your own server reached over the internet).
Give one or both. With both, the Prefer the local connection switch (shown by Gladys) chooses which one is tried first; the other one is the fallback. Every device shows a badge with the address that answered. When the fallback is used, the badge is degraded (orange dot): it works, but not through the preferred address.
The certificate of the public address is always checked. Only the LAN address can skip the check.
4. Devices
Open Integrations → Mailcow → Discovery to create them.
mailcow server (always): containers running, containers down, mail queue, quarantine, banned IPs, mail storage used (GB and %), domains, mailboxes, mailcow version.
mailcow <domain> (one per domain): active (switch), mailboxes, aliases, messages, storage used.
<mailbox address> (one per mailbox, if enabled): active (switch), quota used (%), storage used, messages.
The active switches can be used from Gladys only when Allow changes is on; otherwise they are read-only.
5. Scene triggers
In a scene, pick Integrations → Mailcow. A trigger fires when something changes between two reads: the first read after a start never fires anything.
| Trigger | Key | Filters | Variables |
|---|---|---|---|
| A mailcow container stopped | container_down | container | container, state |
| A mailcow container is running again | container_up | container | container |
| Mail queue too long | queue_high | – | queue_size, threshold |
| Mail storage almost full | storage_high | – | used_percent, threshold |
| Mailbox almost full | quota_high | domain, mailbox | mailbox, domain, percent, threshold |
| A mail was quarantined | quarantine_new | recipient | sender, recipient, subject, score, virus |
| An IP was banned | ip_banned | – | ip |
| mailcow server unreachable | connection_lost | – | reason, message |
| mailcow server reachable again | connection_restored | – | transport |
The thresholds fire once, when the value goes over them. Use the variables in the next actions,
e.g. a message {{triggerEvent.data.container}} is down. At most 10 events of one kind are sent
per read (a spam wave does not flood your scenes).
6. Scene actions
| Action | Key | Fields | Outputs |
|---|---|---|---|
| Read the mailcow server now | refresh | – | reachable, queue_size, quarantine, containers_down, storage_percent |
| Flush the mail queue | flush_queue | – | queued_before |
| Turn a mailbox on or off | set_mailbox_active | mailbox address, active | changed |
flush_queue and set_mailbox_active need Allow changes and a read-write key.
7. Dashboard widgets
- mailcow server: address used, version, containers, stopped containers, queue, storage gauge, quarantine and banned IPs, a Refresh button, a Flush queue button (when changes are allowed, with a confirmation) and a link to mailcow.
- mailcow quarantine: the last quarantined mails (subject, sender, recipient, score or virus). Setting: number of mails (1 to 8).
- mailcow mailboxes: the mailboxes closest to their quota. Settings: number (1 to 10) and an optional domain.
8. Troubleshooting
| Message | What to do |
|---|---|
| The mailcow server does not answer | Check the address and that Gladys can reach it (firewall, DNS). |
| The HTTPS certificate is refused | For a LAN address written as an IP, untick "Check the certificate of the LAN address". |
| The API key is refused | Copy the key again; check that the API is activated. |
| mailcow refuses the API to the IP … | Add that IP to "Allow API access from these IPs/CIDR". |
| Something answered, but not the API | Give the address of the mailcow web interface, without any path. |
| Changes are turned off | Tick "Allow changes" and use the read-write key. |
| This API key is read-only | Use the read-write key for changes. |
A section mailcow does not answer (an older version, for instance) is simply left out: the rest is still read, and Test the connection lists what was not read.
Configuration settings
These are the settings Mailcow asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Getting started | section | No | The integration reads your mailcow server through its API. In mailcow, open System → Configuration → Access → Administrators, unfold API, create a read-only key (or a read-write one to act from Gladys) and add the IP Gladys reaches mailcow from to the allowed addresses. Give the LAN address, the public one, or both: the "Prefer the local connection" switch chooses which one is tried first, the other one is the fallback. |
| LAN address | string | No | The address of mailcow on your network (the "local" transport). Leave empty if mailcow is not on your network. |
| Public address | string | No | The address of mailcow on the internet (the "cloud" transport), e.g. a server at a hosting provider. Its certificate is always checked. |
| API key | secret | Yes | The read-only key is enough to watch the server. The read-write key also lets Gladys flush the queue and turn domains and mailboxes on or off, when "Allow changes" is ticked. |
| Check the certificate of the LAN address | boolean | No | Reached by its IP, mailcow shows a certificate made for its domain name, which does not match: untick this for a LAN address written as an IP. The public address is always checked. |
| Refresh interval (s) | number | No | How often the server is read, in seconds (one minute minimum). Every read is one request per section of the API. |
| Devices | section | No | The server is always a device. Each domain and each mailbox can be one too, to follow it, chart it, or turn it on and off from Gladys. |
| One device per domain | boolean | No | |
| One device per mailbox | boolean | No | For a server with a few mailboxes (200 at most are published). |
| Allow changes | boolean | No | Let Gladys flush the mail queue and turn domains and mailboxes on or off (needs the read-write API key). Off, everything stays read-only. |
| Alert thresholds | section | No | The scene triggers "Mail queue too long", "Mail storage almost full" and "Mailbox almost full" fire when a value goes over its threshold. |
| Mail queue threshold | number | No | |
| Mail storage threshold (%) | number | No | |
| Mailbox quota threshold (%) | number | No | |
| Detailed logs (debug) | boolean | No | Log every read of the server. The API key is never logged. |
How to install Mailcow in Gladys
- In Gladys, open Integrations: Mailcow appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/prohand/gladys-mailcow:2.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/prohand/gladys-mailcow.
Mailcow requires Gladys >=5.3.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
