LibreNMS integration for Gladys Assistant

Your LibreNMS devices, alerts and ports in Gladys, with scenes when something goes down.

View on GitHubAll integrations

Bring your LibreNMS network monitoring into Gladys: each device LibreNMS monitors becomes a Gladys device (online, uptime, active alerts, health sensors), the ports you choose get their own device (online, inbound and outbound rate), a "LibreNMS" device counts the devices down and the alerts, and your scenes react when a device or a port goes down, comes back, or when an alert is raised or cleared. A scene can also acknowledge the alerts of a device, and a dashboard widget shows what is wrong.

The integration reads the LibreNMS API on your local network, with an API token. Nothing goes through a cloud.

Tested against a real LibreNMS 26.9.1 (official Docker image), with an SNMP agent stopped and started again: device down and back, alert raised, acknowledged and cleared. Health sensors of real hardware and the link of a real switch port going down were checked only through the shape of the API answers. Feedback welcome: github.com/guim31/gladys-librenms/issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • LibreNMS with its API (any recent version), reachable from the Gladys machine (the address of its web interface).
  • A LibreNMS user for Gladys. The global-read role is enough to read; the acknowledgement scene action needs a role that may update alerts (admin).

Getting started​

1. Create an API token​

In LibreNMS, open the cog menu → API → API Settings, click Create API access token, choose the user, add a description and copy the token.

2. Configure the integration​

In Gladys, open the configuration of the integration:

  • LibreNMS address: the address you open LibreNMS with, e.g. http://192.168.1.2:8000 or https://librenms.example.com. A page copied from the browser (…/devices) works too.
  • API token: the token of step 1.
  • Device groups (optional): names of LibreNMS device groups, separated by commas. Empty: every device neither disabled nor ignored.
  • Ports to follow (optional): device:port pairs separated by commas, the device by its host name (or system name, or display name), the port by its name in LibreNMS, e.g. switch:ge-0/0/1, nas:eth0. device:* follows every port of the device that is administratively up. 20 ports at most.
  • Refresh interval: 30 seconds to 5 minutes (1 minute by default).
  • Allow acknowledging from scenes: untick to turn the acknowledgement action off.
  • Accept self-signed certificates: for an https:// address whose certificate your browser does not trust either.
  • Language of the names: language of the feature names and of the scene results.

Save, then click Test the connection: it shows the LibreNMS version, the number of devices, of devices down, of active alerts, and the followed ports that were not found.

3. Add the devices​

Open the Discover tab of the integration and add the devices and ports to follow, and the "LibreNMS" device for the totals. The scene triggers work for every device, added to Gladys or not.

The devices​

Each device of LibreNMS:

FeatureValue
Online1 up, 0 down, as LibreNMS sees it (ping, SNMP)
Uptimein days (SNMP devices only)
Active alertsnumber of active alerts, acknowledged ones included
Health sensorsup to 10: temperatures, fans (rpm), load, power, voltage, current, humidity

The health sensors are the ones LibreNMS discovered on the device, named as in LibreNMS; temperatures first.

Each followed port:

  • Online: 1 when the link is up
  • Inbound rate, in Mbit/s
  • Outbound rate, in Mbit/s

The LibreNMS device:

  • Devices down
  • Active alerts
  • Critical alerts

Values are sent to Gladys only when they change, and every 6 hours otherwise. While a device is down, its uptime and its ports keep their last values and its badge shows it unreachable.

Dashboard​

The LibreNMS overview widget shows three tiles — the devices down, the active alerts, the ones not acknowledged yet — and a list: the devices down first, then the alerts, the most severe first (rule, device, ✓ once acknowledged). Ten rows at most. Refresh reads LibreNMS again. In its settings, choose devices to show only theirs (empty: every device).

Scenes​

Triggers​

  • A device goes down: LibreNMS sees a device down. Filter: devices (empty: any). Variables: device name, host name, reason (icmp, snmp).
  • A device is back: a device seen down is up again, with the duration in minutes.
  • An alert is raised: a LibreNMS alert rule matches a device. Filters: devices, severities (Warning, Critical, OK). Variables: device name, alert rule, severity (in words and as a key), rule id, alert id.
  • An alert is cleared: an alert is over, with the same filters and variables, plus its duration in minutes.
  • A followed port goes down: a followed port loses its link (not when the administrator shuts it, nor while its device is down). Variables: device name, port, port description, status. Filter on the port devices.
  • A followed port is back: the link is up again, with the duration in minutes.
  • LibreNMS no longer answers: the API fails to answer twice in a row (variables: LibreNMS address, error).

What is already there when the integration starts is not announced. A change that happens while Gladys or the integration restarts is announced once at the next read. Acknowledging an alert neither clears nor raises it again.

Actions​

  • Acknowledge the alerts of a device: acknowledges the active alerts of the device in LibreNMS, with a note in their history (empty: "Acknowledged from Gladys"). LibreNMS notifies again if an alert gets worse. Returns the number acknowledged. Turn it off with "Allow acknowledging from scenes".
  • Read the network status: counts and lists the devices down and the active alerts, of one device or of all, for the next actions: devices down (number and names), alerts, not acknowledged, critical, highest severity, and the list "device: rule".

Scene ideas​

  • The router is down: trigger "A device goes down" on the router → turn the hallway lamp red and send {{triggerEvent.data.name}} is down.
  • Critical alerts only: trigger "An alert is raised", severity Critical → message {{triggerEvent.data.name}}: {{triggerEvent.data.rule}}.
  • The uplink of the switch: follow switch:ge-0/0/1, trigger "A followed port goes down" → message, and "A followed port is back" → "Back after {{triggerEvent.data.duration_minutes}} min".
  • Seen from the couch: a dashboard button runs "Acknowledge the alerts of a device" on the NAS.

Troubleshooting​

  • "API token refused": check the token in API Settings (not disabled) and that its user still exists.
  • "LibreNMS does not answer": check the address from the Gladys machine. localhost is the integration container itself: use the IP address of the LibreNMS machine.
  • "No LibreNMS API at this address" or "the address redirects": the address does not lead to LibreNMS; /api/v0 must answer at its root (or under its sub-path).
  • "Certificate refused": tick "Accept self-signed certificates", or use the http:// address on the local network.
  • "No device group with these names": the names must match LibreNMS.
  • A device is missing: it is disabled or ignored in LibreNMS, outside the device groups, or the user of the token cannot see it.
  • A port is not found: "Test the connection" lists the pairs it could not match; use the port name LibreNMS shows (ifName).
  • The acknowledgement is refused: the user of the token needs a role that may update alerts (admin). A global-read user gets an error.
  • A value lags behind: LibreNMS polls its devices every 5 minutes; a shorter refresh interval only catches changes sooner.

Limits​

  • One LibreNMS server per integration.
  • No processor and memory usage: the API gives them device by device, which would multiply the requests; the "load" sensors are kept when LibreNMS has them.
  • At most 10 health sensors per device, 20 followed ports, 30 scene events per read (an outage can bring dozens of devices down at once; the rest follows at the next reads).
  • Fan speeds have no unit in Gladys: "(rpm)" ends their name.
  • No quota on the LibreNMS API: each read sends four or five requests (one more per device group), whatever the number of devices.

Not affiliated with LibreNMS.

Configuration settings​

These are the settings LibreNMS asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your LibreNMS serversectionNoIn LibreNMS, open the cog menu → API → API Settings, create a token and paste it below with the address of LibreNMS. Then add the devices to follow from the Discover tab: the scene triggers work for every device, added or not.
LibreNMS addressstringYesThe address you open LibreNMS with in your browser.
API tokensecretYesA user with the global-read role is enough; acknowledging needs one that may update alerts (admin).
Device groups (optional)stringNoNames separated by commas. Empty: every device neither disabled nor ignored.
Ports to follow (optional)stringNodevice:port pairs separated by commas (device by host name, port by name), device:* for all its ports in use. Up to 20.
OptionssectionNo
Refresh intervalselectNoHow often LibreNMS is read (4 or 5 requests). LibreNMS itself polls the devices every 5 minutes.
Allow acknowledging from scenesbooleanNoUntick to turn off the "Acknowledge the alerts of a device" scene action.
Accept self-signed certificatesbooleanNoOnly for an https:// address whose certificate your browser does not trust either.
Language of the namesselectNoLanguage of the feature names (set when a device is added) and of the scene results.

How to install LibreNMS in Gladys​

  1. In Gladys, open Integrations: LibreNMS appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-librenms:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-librenms.

LibreNMS requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

LibreNMS is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
