LaMetric smart home integration, free and open source

LaMetric integration for Gladys Assistant

LaMetric TIME and SKY clocks: messages from your scenes, brightness, volume, apps and timer.

View on GitHubAll integrations

This integration connects the LaMetric TIME and LaMetric SKY smart clocks to Gladys, over your local network, through the local device API of the clocks (API v2). No cloud, no LaMetric account in Gladys: only the API key of each clock.

  • Your scenes write on the clocks: a text, with an icon, a sound and a priority.
  • The brightness, the volume, the screen and Bluetooth are Gladys features you can show on a dashboard and drive from scenes.
  • Push buttons switch apps, clear the notifications, and drive the stopwatch, the timer and the radio.
  • A dashboard widget writes a message on the clock in two taps.

Developed without the hardware: feedback welcome. The integration is built and tested against answers of real clocks published by the python-demetriek library and Home Assistant, not against a clock. Please report what works and what does not in the issues.

This integration is not affiliated with LaMetric. LaMetric, LaMetric TIME and LaMetric SKY are trademarks of their owner.

What you need​

  • Gladys Assistant 5.2.0 or later.
  • A LaMetric TIME or LaMetric SKY, on the same local network as Gladys (up to three clocks).
  • The API key of each clock: sign in on developer.lametric.com with the account of the LaMetric app, open Devices, and copy the API key shown for the clock. Each clock has its own key.

Set up​

  1. In Gladys, open Integrations → Install from GitHub and enter https://github.com/guim31/gladys-lametric (or install LaMetric from the catalog).
  2. In Configuration, paste the API key of the first clock. Its Address (an IP address such as 192.168.1.20) is optional: left empty, Gladys looks for the clock on the network. Up to two more clocks below.
  3. Choose the Refresh interval (30 seconds by default) and the Language of the feature names, then save.
  4. Click Test the connection: each clock says OK, with its model and its firmware, or what is wrong.
  5. Open the Discover tab and add the clocks.

The clocks announce themselves on the network (SSDP). Gladys relays that search for the integration, which runs in its own container: it finds the address of a clock whose address is left empty (the clock that accepts the API key is the right one), and follows a clock whose address changed (a new IP given by the router), by its serial number. The search runs when a clock needs it, at most every 5 minutes, and at once from Scan in the Discover tab or the Test the connection button, which also lists the clocks found but not configured yet.

A clock that does not announce itself is reached at the address you enter. Give your clocks a fixed IP address in your router if you can.

The device of each clock​

One device per clock, named after the clock. Each feature appears only when the clock has it:

FeatureWhat it does
Brightnessslider 0-100; setting it turns the automatic brightness off. On a computer's USB port, the clock stops at 76.
Automatic brightnesson: the clock follows the light of the room
Screenturns the display on or off (firmware 3 and later)
Screensaverturns the screensaver of the LaMetric app on or off (TIME)
Volumeslider 0-100 (TIME: the SKY has no speaker)
Bluetoothturns Bluetooth on or off (TIME)
Wi-Fi signalthe Wi-Fi signal, in percent
App on screenthe name of the app shown on the clock
Next app, Previous apppush buttons: switch the app on screen
Clear notificationspush button: dismisses the notifications on screen and waiting
Start the stopwatch, Stop the stopwatch, Reset the stopwatchpush buttons, when the Stopwatch app is installed
Start the timer, Stop the timer, Reset the timerpush buttons, when the Timer app is installed (the duration set in the app)
Play the radio, Stop the radio, Next radio stationpush buttons, when the Radio app is installed

"Stop" pauses: "Start" goes on from there, "Reset" goes back to zero.

The clocks are read every refresh interval, by the integration itself: the values change in Gladys only when they change on the clock, and are sent again every 6 hours otherwise. A command is read back at once. The names of the features are given when the device is created; changing the language later does not rename them.

Dashboard widget​

Add the LaMetric widget to a dashboard. It shows the brightness, the volume and the Wi-Fi signal of a clock, its state, the app on screen and its firmware (and the update the clock offers, if any), with four buttons:

  • Previous and Next: switch the app on screen;
  • Message…: opens a form, with the text, an optional icon code and a sound, and shows it on the clock;
  • Clear: dismisses the notifications.

In the widget settings, choose the clock; left empty, the widget shows the first clock of the configuration.

Scenes​

The integration adds two actions to the scene editor, under the Integrations category. Both act on the chosen clock, or on every clock that answers when the LaMetric field is left empty, and return the number of clocks that did it (count).

Show on the LaMetric​

Shows a text. The text can hold scene variables (a temperature, a name…).

  • Icon: the code of an icon of the LaMetric gallery, i then the number for a still icon (i2867), a for an animated one (a7956). An unknown code is left out: the text still shows.
  • Sound: one of the notification sounds or alarms of the clock. A SKY has no speaker: the text shows without sound.
  • Priority: Information, Warning or Critical. Critical also shows over the screensaver and at night.
  • Number of times shown: 1 by default; 0 keeps it on screen until someone presses the button of the clock.
  • Duration of each pass (s): empty for the duration of the clock. A text longer than the screen scrolls anyway.

Start the LaMetric timer​

Starts the Timer app of the clock for the minutes and seconds you choose. The app must be installed on the clock (it is by default).

Scene ideas​

  • The washing machine is done: when the power of its plug drops below 5 W, Show on the LaMetric "Washing done", icon a7956, sound "Positive 1".
  • Someone at the door: when the doorbell rings, show "Door" with the sound "Knock knock", priority Critical, on every clock.
  • Tea time: from a button on the dashboard or a voice command, Start the LaMetric timer for 4 minutes.
  • Night: at 23:00, set the Brightness to 5, or turn the Screen off; at 7:00, turn Automatic brightness back on.

Troubleshooting​

  • "API key refused": copy the key again from developer.lametric.com → Devices; it belongs to one clock only. A clock reset to factory settings gets a new key.
  • "not found on the network: enter its address": the clock does not answer the network search (or Gladys cannot search): enter its IP address, shown in the LaMetric app (clock settings → Wi-Fi).
  • "does not answer": check that the clock is on, on the same network as Gladys, and that nothing blocks the TCP port 4343 between them.
  • "this address is not a LaMetric": another device answers at this address.
  • A command fails right after a firmware update: click Test the connection, then Scan in the Discover tab: a feature that appeared (the Screen switch after firmware 3) makes Gladys offer to update the device.
  • The integration logs only what matters (start, connection, loss and return of a clock, user actions). For every reading, set LOG_LEVEL=debug in the integration settings. The logs never show an API key.

Limits​

  • Local network only. The cloud features of LaMetric (apps of the store, account) are not used.
  • Up to three clocks.
  • The device API reports no battery level: there is no battery feature.
  • The stopwatch, the timer and the radio do not report their state to the integration: they are push buttons, without a state in Gladys.
  • The integration does not create apps on the clock (no "My Data DIY" frames): it shows notifications.
  • The clocks use a self-signed HTTPS certificate: the integration accepts it for their address. Keep the clocks on a network you trust.
  • The local API of LaMetric has no documented rate limit; the integration reads each clock twice per refresh interval (its state and its apps), and writes only on your commands.

Configuration settings​

These are the settings LaMetric asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your LaMetricsectionNoLaMetric TIME or SKY on your local network, up to three. Each clock has its own API key: sign in on developer.lametric.com, open Devices and copy the key of the clock.
AddressstringNoIP address of the clock. Empty: Gladys looks for it on the network.
API keysecretNoThe API key of this clock: developer.lametric.com, Devices.
Second LaMetric (optional)sectionNoSame fields, for another clock.
AddressstringNoIP address of the clock. Empty: Gladys looks for it on the network.
API keysecretNoThe API key of this clock: developer.lametric.com, Devices.
Third LaMetric (optional)sectionNoSame fields, for a third clock.
AddressstringNoIP address of the clock. Empty: Gladys looks for it on the network.
API keysecretNoThe API key of this clock: developer.lametric.com, Devices.
SettingssectionNoThe clocks are read on your local network only.
Refresh intervalselectNo
Language of the feature namesselectNoUsed when a device is created in Gladys, and for the messages of the integration.

How to install LaMetric in Gladys​

  1. In Gladys, open Integrations: LaMetric appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-lametric:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-lametric.

LaMetric requires Gladys >=5.2.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

LaMetric is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
