Keenetic smart home integration, free and open source
Keenetic routers: presence of your devices, router health, Internet and 4G backup, guest Wi-Fi.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Follow your Keenetic router from Gladys Assistant: who is at home, the health of the router, the state of your Internet connection and of its 4G / 5G backup, the guest Wi-Fi. Everything stays on your local network: the integration talks to the router through RCI, the JSON interface of its web interface, without any cloud.
Developed without the hardware: feedback welcome, on the issues of the project. This integration is not affiliated with Keenetic Ltd.
Overview
- Presence: each device you choose (a phone, a laptop, a wired NAS) becomes a presence sensor, present while the router sees it online, on its Wi-Fi, on a cable or on a mesh extender.
- Router: CPU load, memory, uptime, KeeneticOS version, connected devices and Wi-Fi clients.
- Internet: whether the router reaches the Internet, the connection in use with its download and upload rates, and, if the router has several connections, whether the backup one (4G / 5G modem, second ISP) is up and in use.
- Scenes: an unknown device connected, Internet down and restored, a switch to the backup connection and the return to the main one.
- Commands, disabled by default: guest Wi-Fi on and off, blocking the Internet access of a device (parental control), rebooting the router.
- Widgets: the health of the router, and the devices at home.
Requirements
- A Keenetic router (Giga, Ultra, Hopper, Viva, Peak, Titan, Hero, Speedster…) with KeeneticOS 3 or later. The integration was written for KeeneticOS 4 and 5.
- Gladys Assistant 5.1 or later, on the same local network as the router.
- The local address of the router (e.g.
192.168.1.1). A KeenDNS address does not work: the remote access does not offer the login of the local web interface.
Create a dedicated user
Do not give Gladys the admin account. In the web interface of the router, open Users and
access (Management menu), add a user, e.g. gladys, with a strong password, and tick Web
interface only (no CLI, no FTP, no VPN).
-
Read only (recommended if you do not use the commands): on the command line of the router (Telnet / SSH, or the web CLI at
http://<router>/a), add the read-only tag:user gladys tag readonlysystem configuration saveThe presence, the measures and the scene triggers work; the commands are refused by the router.
-
With the commands: keep the user without
readonly, then tick Allow commands in the configuration of the integration.
Configuration
In Gladys: Integrations → Keenetic → Configuration.
| Field | What to enter |
|---|---|
| Router address | The local IP address of the router, with :port if its web interface does not use port 80. |
| User name | The dedicated user, e.g. gladys. |
| Password | Its password. It never leaves Gladys: only a one-time answer to the challenge of the router travels. |
| Refresh interval | 10 s, 15 s, 30 s (default) or 1 minute. The rates are averages over this interval. |
| Departure delay (minutes) | A device no longer seen counts as away after this delay (5 minutes by default, 0 to 60). |
| Guest segment | Empty (default): the guest network of the router, found automatically. Otherwise a segment id such as Bridge1. |
| Allow commands | Off by default. Lets the scenes and the widget switch the guest Wi-Fi, block a device and reboot the router. |
| Language of the names | The language of the device and feature names, set when a device is added (French by default). |
Then click Test the connection: the report gives the model, the KeeneticOS version, the Internet connections by priority, the segments with their id, the state of the guest Wi-Fi and what the user may not read.
Devices
Open the Discovery tab of the integration: the router comes first, then the devices of its host table (the registered ones first). Add the ones you want to follow.
The router
| Feature | Values |
|---|---|
| CPU load | % of the processor. |
| Memory used | %, as the web interface counts it. |
| Uptime | Hours since the last start. |
| KeeneticOS version | e.g. 4.1.7. |
| Internet available | 1 when the router reaches the Internet, 0 when it does not. |
| Connection in use | The name of the connection carrying the Internet (its description in the router), None if down. |
| Download rate | Mbit/s on the connection in use, averaged over the refresh interval. |
| Upload rate | Mbit/s on the connection in use. |
| Backup connection in use | 1 when the Internet goes through a backup connection (only with several connections). |
| Backup connection up | 1 when the first backup connection is established, ready to take over. |
| Wi-Fi clients | Stations on the Wi-Fi of the router itself (not on the mesh extenders). |
| Connected devices | Devices the router sees online. |
| Guest Wi-Fi enabled | 1 when the Wi-Fi of the guest segment is on (only with a guest segment). |
The Internet connections are the interfaces the router uses for the Internet, by their priority in Internet → Connection priorities. A VPN tunnel used for the Internet (WireGuard, OpenVPN, IPsec…) is no Internet connection of its own, and no backup.
Nothing is a switch: the guest Wi-Fi state is read only, so that a voice assistant or a mistaken dashboard tap never cuts a network. The commands go through the scene actions and the widget.
Network devices (presence)
Each device you add is a Presence sensor: 1 when present, 0 when away. It is present while the router sees it online (the "Online" of its device list), or while it is associated on an access point of the router. It becomes away once the departure delay has passed since it was last seen: a phone asleep leaves the Wi-Fi a few minutes without leaving home. When the router cannot be read, nobody is sent away.
Widgets
- Keenetic router: CPU, memory, download and upload rates, connected devices; Internet with the connection in use, the backup connection (ready, in use, down), the guest Wi-Fi, the uptime and the version. With Allow commands, a Guest Wi-Fi button (its icon shows the current state) and a Reboot button, both with a confirmation.
- Devices at home: the followed devices, present first, with the time since they left and the ones whose Internet access is blocked. Its setting shows all of them or the present ones only.
Scene triggers
| Trigger | When | Filters and variables |
|---|---|---|
| Unknown device connected | A MAC address never seen before is online. The first reading learns the network. | Filters: network (home, guest, other), connected by (Wi-Fi, cable). Variables: MAC address, IP address, host name, Wi-Fi network (SSID). |
| Internet down | The router no longer reaches the Internet, through any connection. | Last connection used. |
| Internet restored | The Internet is back. | Connection, outage length (minutes). |
| Switched to the backup connection | The main connection failed, the Internet goes through a backup one. | Backup connection, main connection. |
| Back on the main connection | The router uses its main connection again. | Main connection, time on the backup (minutes). |
A switch to the backup is not an Internet outage: "Internet down" fires only when no connection works.
Scene actions
All of them need Allow commands and a user without readonly.
- Turn on the guest Wi-Fi / Turn off the guest Wi-Fi: every access point of the guest segment (2.4 and 5 GHz). Output: guest Wi-Fi enabled.
- Block the Internet of a device / Allow the Internet of a device: choose a network device followed by the integration. The router can only block a device registered in its device list: register it first in Device lists of the web interface of the router. Output: Internet access blocked.
- Reboot the Keenetic router: the network is cut for two to three minutes.
Every command is read back from the router, and saved in its configuration so that it survives a restart.
Configuration actions
- Test the connection: logs in again and reads everything, then gives the report described in the Configuration section.
Scene examples
- Guests: when the "Guests" mode starts, turn on the guest Wi-Fi; at 23:00, turn it off.
- Homework: every school day at 21:00, block the Internet of the children's tablet; at 7:00, allow it again.
- Outage: on "Switched to the backup connection", send a message "Fibre down, on 4G for now" and pause the cloud backups of the NAS; on "Back on the main connection", resume them.
- Intruder: on "Unknown device connected" with the filter network = home, send a notification with the MAC address and the host name.
- Nobody home: when every followed phone is away, turn off the lights and arm the alarm with a scene of Gladys.
Network use
- One batch request to the router per refresh interval (the load, the interfaces, the host table, the Wi-Fi associations, the Internet status and the counters of the connections), on its local web interface. No quota, no cloud, no data sent outside your network.
- One login per session: the router ends a session after a few minutes without use, the integration logs in again by itself.
- The integration remembers under
/dataonly the MAC addresses already seen, for the "Unknown device connected" trigger.
Troubleshooting
- "the router does not answer at this address": check the local IP address, and that Gladys is on the same network.
- "no Keenetic web interface here": the address points to another device, or to KeenDNS: use the local address.
- "user name or password refused by the router": check them in Users and access; the integration tries again every five minutes so as not to fill the log of the router.
- "refused by the router: the user lacks this right": the user lacks the web interface right, or is read-only and a command was asked.
- Register this device first: to block a device, register it in Device lists of the router.
- A phone shows away while at home: raise the departure delay; some phones put their Wi-Fi to sleep for a long time.
- More details in the logs of the integration with
LOG_LEVEL=debug.
Limits
- Developed without the hardware: tested against real answers of a Keenetic Ultra (KeeneticOS 5.1) and answers rebuilt from the documentation of KeeneticOS, not on a real router yet.
- KeeneticOS 5.2 adds access tokens for scripts on the router; the integration uses the login of the web interface, not verified on KeeneticOS 5.2 yet.
- Plain HTTP on the local network (the web interface of the router has no local HTTPS); the password never travels, but the readings do.
- The Wi-Fi clients count only the stations of the router itself, not those of the mesh extenders (they are online in the connected devices).
- No per-device traffic, no signal of the 4G / 5G modem, no VPN control: the integration only changes the guest Wi-Fi, the Internet access of a chosen device, and reboots the router.
Feedback
Questions, a model that answers differently, an idea: github.com/guim31/gladys-keenetic/issues.
Configuration settings
These are the settings Keenetic asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your Keenetic router | section | No | Any Keenetic with KeeneticOS 3 or later, on its local address. Create a dedicated user with the web interface right only, read only if you do not use the commands (see the documentation). |
| Router address | string | Yes | Local IP address of the router, with :port if its web interface does not use port 80. Not a KeenDNS address. |
| User name | string | Yes | A user of Users and access, ideally a dedicated one (see the documentation). |
| Password | secret | No | |
| Refresh interval | select | No | How often the router is read (one request). The rates are averages over this interval. |
| Presence | section | No | Add the devices to follow from the Discovery tab: each one becomes a presence sensor, present while the router sees it online (Wi-Fi, cable or mesh extender). |
| Departure delay (minutes) | number | No | A device no longer seen counts as away only after this delay: a phone asleep leaves the Wi-Fi for a few minutes. |
| Commands | section | No | Read only by default. Commands turn the guest Wi-Fi on or off, block or allow the Internet access of a device and reboot the router, from a scene or a widget. Nothing else is ever changed. |
| Guest segment | string | No | Empty: the guest network of the router, found automatically. Else the id of a segment, as "Test the connection" lists them. |
| Allow commands | boolean | No | Lets scenes and widgets use the commands. The Keenetic user must not be read-only. |
| Language of the names | select | No | Language of the device and feature names, set when a device is added to Gladys. |
How to install Keenetic in Gladys
- In Gladys, open Integrations: Keenetic appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-keenetic:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-keenetic.
Keenetic requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Keenetic is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
