iRobot Roomba smart home integration, free and open source
iRobot Roomba and Braava robots on the local network: state, battery, bin, start and dock.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.2.0
- ★ 0
Presentation
This integration drives iRobot Roomba and Braava robots on your local network, without going through the iRobot cloud: it talks directly to each robot, over the encrypted MQTT connection the iRobot app uses at home (port 8883). You get one Gladys device per robot, with its state, its battery, its bin, the duration and area of the mission, and the commands Start, Pause, Stop, Return to dock and Locate. Three scene triggers (mission finished, robot stuck or in error, bin full) and a dashboard widget complete it.
The iRobot cloud is only used once, if you choose so, to read the password of your robots.
Developed without the hardware: feedback welcome. The author has no iRobot robot. The integration follows the local protocol as documented by the open-source projects dorita980 and roombapy (the library of Home Assistant), and is tested against a simulated robot. Please share your experience, and the output of the Diagnostic action, on the Gladys forum.
This integration is not affiliated with iRobot.
Supported robots
The robots with Wi-Fi that the iRobot app controls locally (the "v2" and "v3" local protocol):
- Roomba 600 series with Wi-Fi (675, 690, 694…), 800 series, 900 series (960, 980…);
- Roomba e series (e5, e6), i series (i3, i4, i7, i7+, i8…), s series (s9, s9+), j series (j7, j7+, j9…) and Combo models of the same generations;
- Braava jet m6.
The most recent "Matter-first" models (for example Combo Max 705) use a new protocol that neither dorita980 nor roombapy support yet: they are not supported here either. Robots without Wi-Fi are not supported.
Prerequisites
- Gladys 5.2.0 or later.
- The robot set up with the iRobot app and connected to your Wi-Fi.
- Gladys and the robot on the same local network, and the robot's IP address (in your router, or in the iRobot app: robot settings, Wi-Fi). Give the robot a fixed address in your router (DHCP reservation): the integration looks for a robot that changed address, but a fixed address is more reliable.
- The robot password, obtained by the integration in one of two ways (see Configuration):
- your iRobot account email and password, used once;
- or a press on the HOME button of the robot (DOCK + SPOT on some 600 series).
Installation
In Gladys, open Integrations → Install from GitHub and enter
https://github.com/guim31/gladys-roomba. Gladys shows what the integration asks for before
installing: network discovery on UDP port 5678 (the iRobot discovery port), through Gladys.
Configuration
Open the integration's Configuration page. Add your robots with one of the two actions below, then open the Discovery tab and add the robots to Gladys. Only the robots added to Gladys are connected.
Language of the names
Language of the feature names, the error texts and the texts of the scene events (French by default). Feature names are set when a device is created: to rename them after a change, delete the device and add it again.
Get the passwords from the iRobot cloud
Enter the email and password of your iRobot app account, and the two-letter country of the account (FR, BE, DE, ES…). The integration logs in once, reads the identifier (BLID) and the local password of each robot of the account, then looks for the robots on your network. The account password is never stored; the robot passwords are kept in the integration's private storage.
If a robot is not found on the network, run Add a robot with its IP address: its password is already known, no button to press.
Add a robot
Enter the robot's IP address. Three cases:
- the password was obtained from the cloud: nothing else to do;
- you know the password: enter it in the optional password field;
- otherwise, the HOME button method: close the iRobot app, put the robot on its base, hold HOME (DOCK + SPOT on some 600 series) for about two seconds until it plays a tune, then start the action within a few seconds. The integration keeps asking the robot for up to 45 seconds. The most recent firmware no longer answers: then use the cloud method.
The integration asks the robot who it is (its BLID) on UDP port 5678; if the robot does not answer, enter its BLID in the optional field. The password is then checked with a connection to the robot.
Forget a robot
Deletes the password of the chosen robot and closes its connection. Delete the device in Gladys too if you no longer want it.
Diagnostic
A summary to paste on the forum when something goes wrong: model, firmware, connection state, mission, capabilities. It contains no identifier, address or password.
The robot device
| Feature | Gladys type | Content |
|---|---|---|
| State | Vacuum cleaner, state | Stopped, running, paused, error, returning, charging, docked |
| Cleaning | Vacuum cleaner, run mode | Clean: starts, or resumes a paused mission. Idle: stops |
| Return to dock | Vacuum cleaner, dock | Sends the robot to its base (paused first if it is cleaning) |
| Pause | Push button | Pauses the mission |
| Locate | Push button | The robot plays a sound |
| Battery | Battery (%) | Charge level |
| Charging | Battery charging | 1 while charging on the base |
| Bin full | Input (yes/no) | 1 when the bin is full (robots with a bin sensor) |
| Mission duration | Duration (minutes) | Of the current mission, or of the last one |
| Mission area | Surface (m²) | Of the current mission, or of the last one (when reported) |
| Error | Text | "No error", or the error text and its code |
A robot stopped by the user in the middle of a mission shows Paused; a robot on its base shows Charging until its battery is full, then Docked.
Widget
The Roomba widget shows one robot: a live battery tile, then its state, its bin, the current or last mission, the error when there is one and the connection when it is lost. Its buttons follow the situation: Start (and Dock when the robot is not on its base) at rest, Pause and Dock while cleaning, Resume, Stop and Dock when paused. No button while the robot is not connected.
Scene triggers
- Roomba: mission finished — a cleaning mission ended, not because of a fault. Filters: robot, end ("completed, back home" when the robot went home by itself, "stopped or sent home" otherwise). Variables: robot, end, duration in minutes, area in m².
- Roomba: stuck or in error — the robot is stuck or reports a fault (once per fault). Filter: robot. Variables: robot, error text, error code.
- Roomba: bin full — the bin is full. It fires once, and again only after the bin was seen not full on the base (the sensor may flicker while cleaning). Filter: robot. Variable: robot.
The robot's state, battery and bin are also device features: a scene can use them with the usual "device state" trigger and conditions, and start or dock the robot with the "control a device" action.
Scene examples
- Clean when everybody is out: trigger "the house is empty", action: set Cleaning of the robot to Clean. A second scene sends it back to its base (Return to dock) when someone comes home.
- Warn me when the robot is stuck: trigger Roomba: stuck or in error, action: send a message "{{triggerEvent.data.robot}}: {{triggerEvent.data.error}}".
- Mission report: trigger Roomba: mission finished, end "completed, back home", action: send "Cleaning done in {{triggerEvent.data.duration_minutes}} min". With Roomba: bin full, a reminder to empty the bin.
Refresh and network use
- The robot sends every change itself, as soon as it happens; the integration forwards to Gladys only the values that changed.
- An internal timer re-checks every minute, and re-sends the unchanged values every 6 hours so that Gladys always has a recent value. It does not depend on Gladys polling the device.
- Everything stays on your local network. The iRobot cloud is only called by the "Get the passwords from the iRobot cloud" action, three requests, when you start it.
- A robot that does not answer is retried every 10 seconds to 2 minutes; a robot held by another client every 30 seconds to 2 minutes; a refused password every 15 minutes.
Troubleshooting
- "Busy (iRobot app?)": a robot accepts a single local connection. While the iRobot app (or Home Assistant, or another tool) holds it, the robot turns Gladys away. Close the app, or wait: the integration keeps trying and connects when the robot is free. Conversely, while Gladys holds the connection, the iRobot app still works, through the cloud.
- "Not answering": check that the robot is on, on the Wi-Fi, and that its IP address has not changed (run Add a robot again with the new address).
- "Password refused": run Add a robot again, or the cloud action.
- The HOME button method gives nothing: close the iRobot app, put the robot on its base, hold HOME until the tune, start the action right away; several tries may be needed. Recent firmware only gives the password through the cloud.
- The cloud refuses the login: check the email and password in the iRobot app; an account created with Google or Apple sign-in may have no password.
- Old firmware and TLS: the robots use old TLS settings (TLS 1.2, AES128-SHA256, legacy renegotiation). The integration enables them for the robot connection only.
For any problem, run Diagnostic and paste the result on the forum, with the integration logs
(Integrations → iRobot Roomba → Supervision). More detail with the LOG_LEVEL=debug environment
variable.
Limits
- Rooms: cleaning chosen rooms is not supported. The room names and maps live in the iRobot cloud; the local protocol only knows map and region identifiers, which change when the map is edited in the app. A whole-house cleaning is always available.
- No map, no position, no schedule, no suction or mopping settings in this version.
- Mission duration and area are those the robot reports: some recent models report no area.
- The bin sensor exists on most Roomba models, not on the Braava (no "Bin full" value then).
- One connection per robot: while Gladys is connected, the iRobot app goes through the cloud.
- Developed without the hardware: the reaction of each model to a second local client, and some states, are taken from the open-source projects, not observed.
Data and privacy
The integration stores, in its private volume (/data/robots.json, readable by the integration
only): each robot's name, model, firmware, IP and MAC address, BLID and local password. The iRobot
account password is never stored. No password, identifier or address is written in the logs.
Configuration settings
These are the settings iRobot Roomba asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Adding a robot | section | No | The integration talks to each robot on your local network and needs its password. Two ways, in the Actions box below: “Get the passwords from the iRobot cloud” (your iRobot app email and password, used once and never stored), or “Add a robot” with its IP address while you hold the HOME button of the robot on its base. Then add the robot to Gladys from the Discovery tab. A robot accepts a single local connection: while Gladys holds it, the iRobot app goes through the cloud. |
| Language of the names | select | No | Language of the feature names, error texts and scene event texts. Feature names are set when a device is created: to rename them after a change, delete and add the device again. |
