Huginn smart home integration, free and open source

Huginn integration for Gladys Assistant

Your Huginn agents in Gladys: their events start scenes, Gladys feeds or runs them.

View on GitHubAll integrations

Huginn is a free, self-hosted system of agents that watch the web for you and act on what they find: a page that changes, an RSS feed, a price, the weather, an email, a webhook. Each agent creates events that other agents pass on. This integration brings your agents into Gladys: each one becomes a device (working, last event, events kept, error message), scenes react when any agent creates an event or falls in error, Gladys can send an event to a Webhook Agent or run an agent, and a dashboard widget lists the latest events.

Tested against a real Huginn (Docker image ghcr.io/huginn/huginn); not yet on every setup: feedback welcome on the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • Huginn, reachable from the Gladys machine (on the local network, or on the Internet in HTTPS).
  • A Huginn account: its username (or email) and password.

Huginn has no API key: the integration signs in with the account, like your browser, and reads the pages of the interface in JSON. It sees the agents of this account only. A dedicated account works, as long as the agents to follow belong to it.

Getting started​

1. Choose the account​

Use your own Huginn account, or create one for Gladys (its agents are the ones Gladys sees). The integration never changes an agent, except running it when a scene asks for it.

2. Configure the integration​

In Gladys, open the integration, then its Configuration tab:

  • Huginn address: the address you open Huginn with, port included, for example http://192.168.1.2:3000. An address copied from the browser works too.
  • Username or email and Password: the account above.
  • Refresh interval: how often Gladys reads Huginn (1 minute by default). Three requests per read when nothing happened, a few more after new events.
  • Accept self-signed certificates: only for an https:// address whose certificate your browser does not trust either.
  • Language of the names: the language of the feature names, of the dates and of the scene results (French by default).

Save, then click Test the connection: it shows the number of agents, those in error and the events of the last 24 hours.

A refused password is tried once: Huginn locks an account after 10 failed sign-ins. The integration tries again when you save the configuration or click Test the connection.

3. Add the agents​

The Discover tab lists a Huginn device and one device per agent. Add the ones you want to see in Gladys. The scene triggers work for every agent, added or not.

The devices​

Each agent has:

  • Working: on while the agent has no recent error (an error logged after its last event, or less than 2 minutes before it, as Huginn counts it).
  • Last event: a short excerpt of its last event (its title, message or text, otherwise its content in JSON).
  • Last event date: the date and time of its last event.
  • Events kept: the events Huginn keeps for this agent (they expire after the time set on the agent).
  • Error message: the first line of its newest error log while it is in error, "None" otherwise.

The Huginn device counts the Agents, the Agents in error, the Disabled agents, the Events in 24 h and the Failed jobs (5 days) (the background jobs of Huginn that failed, every account included).

Dashboard​

The Huginn events widget shows the events of the last 24 hours and the agents in error, then one row per agent, newest event first: name, excerpt of its last event (or its error), date, and an "Error" badge. The agents in error come first. A tap on a row opens the detail.

In its settings, Agents narrows it to the devices you choose (only devices added to Gladys can be chosen); the 24-hour tile then disappears, it counts the whole instance.

Scenes​

Triggers​

They fire for every agent, added to Gladys or not. Leave Agents empty to react to any of them, or choose some.

  • An agent creates an event: a Huginn agent created an event. Variables: agent name, excerpt (500 characters at most), content (the event in JSON, 1000 characters at most), event number. 20 events per read at most, the newest: an agent that creates hundreds at once does not flood Gladys.
  • An agent falls in error: an agent logged an error and created no event since. Once, until it works again. Variables: agent name, error message.
  • Huginn is unreachable: Huginn stops answering (two failed reads in a row). Variable: the reason.
  • Huginn answers again: Huginn answers again, with the length of the outage in minutes.

An event created while Gladys or the integration restarts is still announced, once. Nothing is announced at the very first read.

Actions​

  • Send an event to Huginn: posts a text to a Webhook Agent, which creates a Huginn event from it. A JSON object is sent as is ({"room": "living room"}), any other text as {"text": "…"}. Scene values can be inserted. Outputs: accepted, HTTP status, answer of Huginn. The agent must accept post in its verbs (the default). The address of the webhook, with its secret, is read from the agent: nothing to copy.
  • Run a Huginn agent: Huginn checks the agent now (a page, a feed, a digest) instead of waiting for its schedule. Its events then fire the triggers above, at the next read.
  • Last event of an agent: reads the last event of an agent for the next actions. Outputs: excerpt, content (JSON), date (ISO 8601), working, error message, and a ready-made sentence ("Agent: excerpt").

Scene ideas​

  • Price watch: trigger "An agent creates an event" on a Website Agent that follows a price → send a message "💶 …" with the "Excerpt".
  • Gladys feeds Huginn: when the alarm turns on → "Send an event to Huginn" with {"alarm": "on", "at": "…"}; a Huginn scenario logs it or adds it to the evening digest.
  • Broken agent: trigger "An agent falls in error" → send a message "⚠️ Huginn: … (…)" with "Agent name" and "Error message".
  • Morning briefing: every day at 7:30 → "Run a Huginn agent" on the weather agent, then a minute later "Last event of an agent" → say the "Sentence".

Troubleshooting​

  • "Sign-in refused": check the username (or email) and the password, then save. "Your account is locked" in the logs of the integration: Huginn locked the account after too many failures; unlock it (by email, or wait an hour), then save.
  • "Huginn does not answer": check the address and the port (3000 by default) from the Gladys machine. localhost is the integration container itself: use the IP address of the machine running Huginn.
  • "Certificate refused": the HTTPS certificate is self-signed or expired; tick "Accept self-signed certificates", or use the http:// address on the local network.
  • "No Huginn at this address": the address points at another service, or at a sub-path that is not the one of Huginn.
  • "The address redirects": enter the https:// address.
  • "This agent is not a Webhook Agent": "Send an event to Huginn" needs a Webhook Agent (an agent with a secret option written as plain text, not a Liquid credential).
  • "Huginn refused the event (HTTP 401)": the secret of the Webhook Agent changed; the integration reads it again at the next read, try again.
  • "Working" stays off: the agent logged an error after its last event. Open its logs in Huginn; it turns on again at its next event.

Limits​

  • Huginn has no REST API: the integration reads the JSON pages of the web interface with a session. A future version of Huginn could change them.
  • An agent of another account is not seen; the failed jobs are counted for the whole instance.
  • "Working" follows the error logs only; the "Working?" column of Huginn also checks, for some agent types, that events arrive often enough.
  • At most 8 pages of 25 new events are read per refresh: beyond, the events are counted but neither announced nor excerpted.
  • The events of the last 24 hours are counted by hour (the oldest hour counts whole).
  • Agents are created, edited and deleted in Huginn; Gladys only sends events to Webhook Agents and runs agents.

Configuration settings​

These are the settings Huginn asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your HuginnsectionNoHuginn has no API key: the integration signs in like your browser. Enter its address and an account, then add the agents to follow from the Discover tab.
Huginn addressstringNoThe address you open Huginn with.
Username or emailstringNoThe account whose agents are read. A dedicated account only sees its own agents.
PasswordsecretNoA refused password is not tried again until you save the configuration: Huginn locks an account after 10 failures.
OptionssectionNo
Refresh intervalselectNoHow often Huginn is read: three requests or more each time.
Accept self-signed certificatesbooleanNoOnly for an https:// address whose certificate your browser does not trust either.
Language of the namesselectNoLanguage of the feature names (set when a device is added), of the states and of the scene results.

How to install Huginn in Gladys​

  1. In Gladys, open Integrations: Huginn appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-huginn:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-huginn.

Huginn requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Huginn is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
