Huawei Solar smart home integration, free and open source

Huawei Solar integration for Gladys Assistant

Huawei SUN2000 inverters, LUNA2000 batteries and power meters, local or cloud.

View on GitHubAll integrations

Monitor and control your Huawei solar installation from Gladys: SUN2000 inverters, LUNA2000 batteries and the DTSU666-H / DDSU666-H power meter wired to the inverter.

Two connections are available, alone or together:

ConnectionHowRefreshCommands
LocalModbus TCP through the SDongle, an EMMA, or the inverter WLANevery 30 s or moreyes
CloudFusionSolar Northbound APIevery 5 min at mostno

With both, the Prefer the local connection toggle picks the preferred one; if it fails, the other one takes over and the device badge shows an orange dot.

Requires Gladys 5.1.0 or later.

  1. In the FusionSolar app, open Device commissioning on your inverter (installer login), then Settings > Communication configuration > Dongle parameter settings > Modbus TCP and choose Enable (unrestricted).
  2. Give the SDongle a fixed IP address in your router.
  3. In Gladys, fill in:
    • Inverter / SDongle address: the SDongle IP, e.g. 192.168.1.50;
    • Modbus port: 502 (SDongle / EMMA), 6607 (inverter WLAN);
    • Modbus unit id: usually 1 (SDongle), 0 (inverter WLAN).
  4. Click Test the connection.

Good to know:

  • the SDongle only accepts a few simultaneous Modbus clients: if another home automation system already reads it, keep the refresh interval at 60 s or more;
  • some commands (export limitation, inverter startup / shutdown) may require installer rights on some firmwares: the scene action then answers success: false with the inverter's message.

2. Cloud connection (FusionSolar)​

The cloud uses the FusionSolar Northbound API, which needs a dedicated API account: your usual app login does not work.

  1. Ask your installer to create an API account in FusionSolar (System > Company Management > Northbound Management), with access to your plant.
  2. In Gladys, fill in:
    • FusionSolar server: the address you use in a browser, e.g. https://eu5.fusionsolar.huawei.com;
    • API user name and API password (system code).
  3. Click Test the connection.

Huawei limits the number of API calls: the cloud is read every 5 minutes at most, whatever the refresh interval.

3. Create the devices​

Open the Discovery tab of the integration and create the devices found:

  • Huawei SUN2000… (inverter): solar production (W), total production (kWh), today's production (kWh), PV input power (W), internal temperature, status;
  • Huawei power meter: grid power (W, positive when drawing from the grid, negative when exporting), grid import / export power (W) and indexes (kWh), house consumption (W), voltage, current;
  • Huawei LUNA2000 battery: level (%), charge / discharge power (W), total charged / discharged (kWh, local), energy remaining (kWh, local), status, working mode (selectable from Gladys with the local connection: maximise self-consumption, time of use, fully fed to grid).

The production and grid indexes feed the Gladys energy monitoring.

4. Scenes​

Triggers (category Integrations):

  • Inverter status changed: production starts, stops, the inverter goes into fault… Variables: status, previous_status, production_power.
  • Grid exchange changed: the house starts exporting a surplus, drawing from the grid, or is balanced (dead band set in the configuration, 100 W by default). Ideal to start a water heater or a car charger on surplus. Variables: flow, previous_flow, grid_power.
  • Battery level crossed: the battery rises above or falls below a level, by steps of 10 %. Variables: direction, level, battery_level.

Actions (local connection, except the last one):

  • force the battery to charge or discharge (power, duration), stop forcing it;
  • set the battery working mode;
  • limit the grid export: no limit, zero export, or a limit in watts;
  • start or shut down the inverter;
  • read the solar installation: exposes production_power, daily_production, house_power, grid_power, battery_level, battery_power and inverter_status to the following actions.

Each command returns success and message: use a condition on success to react to a failure.

5. Dashboard widgets​

  • Solar overview: live production, house, grid and battery, the day chart, inverter status, today's production, grid exchange and connection.
  • Battery control: battery level, charge and discharge power, working mode, and buttons to force a charge or a discharge, stop it or change the mode.

Troubleshooting​

  • Cannot connect to …:502: Modbus TCP is not enabled on the dongle, the IP is wrong, or the dongle is busy with another client.
  • illegal data address: the register does not exist on your model (e.g. no battery): the integration ignores it when reading.
  • FusionSolar login refused: check the server address, the API user name and the system code; an ordinary account does not work.
  • rate limit reached: wait a few minutes, and keep a single integration using this API account.

Configuration settings​

These are the settings Huawei Solar asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Getting startedsectionNoConnect your Huawei installation locally (Modbus TCP through the SDongle, EMMA or the inverter WLAN) and/or through the FusionSolar cloud (Northbound API account). With both, the toggle below picks the preferred one and the other is used as a fallback. Commands (battery, export limit) need the local connection.
Local connection (Modbus TCP)sectionNoEnable Modbus TCP on the SDongle in the FusionSolar app (Device commissioning > Settings > Communication configuration > Dongle parameter settings > Modbus TCP: Enable (unrestricted)). Port 502 through the SDongle; port 6607 and unit id 0 through the inverter WLAN.
Inverter / SDongle addressstringNoIP address or host name on your local network. Leave empty to use the cloud only.
Modbus portnumberNo
Modbus unit idnumberNoUsually 1 through the SDongle, 0 through the inverter WLAN.
Cloud connection (FusionSolar)sectionNoUses the FusionSolar Northbound API: ask your installer for an API account (System > Company Management > Northbound Management). Your usual app login does not work here. Data is refreshed every 5 minutes at most.
FusionSolar serverstringNoThe address you use to log in to FusionSolar in a browser, e.g. https://eu5.fusionsolar.huawei.com or https://intl.fusionsolar.huawei.com.
API user namestringNo
API password (system code)secretNo
Advanced settingssectionNoRefresh interval of the readings and dead band of the "grid exchange changed" scene trigger.
Refresh interval (s)numberNoHow often the installation is read, in seconds (30 s minimum locally, 300 s minimum through the cloud).
Grid dead band (W)numberNoBelow this power, the grid exchange counts as balanced: avoids flapping triggers around zero.

How to install Huawei Solar in Gladys​

  1. In Gladys, open Integrations: Huawei Solar appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/gboulvin/gladys-huawei-solar:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/gboulvin/Gladys-Huawei-Solar.

Huawei Solar requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Huawei Solar is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by gboulvin, not by the Gladys core team.
