Honeywell Evohome smart home integration, free and open source
Honeywell / Resideo Evohome heating: zones, setpoints, system modes and hot water.
Published by LM1LC3N7
- Devices
- Version 0.1.1
- Requires Gladys >=5.1.0
- ★ 0
This integration brings a Honeywell / Resideo Evohome heating system into Gladys through the international Total Connect Comfort cloud, the one of the Evohome app (Europe, United Kingdom): the Evohome controller (Evotouch, Evohome Wi-Fi, Round Wireless with its RFG100 gateway), its heating zones and the hot water. It uses the account of the app. Unofficial, not affiliated with Honeywell or Resideo.
Development version (0.1). Built from the protocol of evohome-async (the library of the Home Assistant evohome integration) and tested with simulated answers, not with a real Evohome system yet. Feedback is welcome on the GitHub repository.
Which Honeywell integration?
| Your app or portal | Your devices | Integration |
|---|---|---|
| Evohome app, international.mytotalconnectcomfort.com (Europe, UK) | Evohome, Evotouch, Round Wireless + RFG100 | this one |
| Total Connect Comfort, mytotalconnectcomfort.com (US and Canada) | RTH6580WF, RTH8580WF, RTH9580WF, VisionPRO Wi-Fi… | guim31/gladys-honeywell-tcc |
| Honeywell Home / Resideo app (developer API) | Lyric Round, T5, T6, T9, T10 | guim31/gladys-honeywell-lyric |
What you get
| Device | In Gladys |
|---|---|
| The system | system mode (settable), end of a temporary mode, fault, active faults |
| Each zone | temperature, setpoint (settable), heating on/off, setpoint mode (settable), end of the override, low battery, fault, active faults |
| Hot water | tank temperature, on/off (settable), mode (schedule, on, boost, off), end of the override, low battery, fault, active faults |
- System modes: Auto (the schedule), Economy, Away, Day off, Custom, Heating off, and "Auto, zones reset" (Auto and every zone back to its schedule), as your controller offers them.
- Setpoint: a setpoint changed from Gladys holds for 60 minutes by default (then the zone goes back to its schedule), or until changed again: see the options. The zone setpoint mode tells whether the zone follows its schedule or holds an override, and until when.
- Heating off on a zone holds it at its minimum (5 °C, frost protection) until you choose Heating again, which puts it back on its schedule. A zone also reads "off" when the whole system is in Heating off.
- Hot water: on and off are permanent; Boost turns it on for the configured time (60 minutes by default); Schedule puts it back on its programme.
- Faults come from the Evohome cloud: low batteries, lost communication
with a sensor, an actuator, the boiler or the gateway… "Fault" is 1 while one
is active, "Active faults" lists them, "Battery low" is 1 when one of them is
a low battery. When the gateway loses its connection, the badges of the
devices turn
unreachablewith an orange dot. - The temperatures have the resolution the cloud gives (often 0.5 °C), and the cloud learns a change made on the controller within a few minutes.
Installation
- Install the integration from the Gladys store.
- In the Configuration tab, enter the e-mail and password of your Total Connect Comfort account (the ones of the Evohome app), then save.
- The status says "Connected to Evohome "My Home": 6 zones and hot water".
- Open the Discovery tab and add the devices you want. Their values arrive as soon as they are added.
The Test the connection button reads the cloud again and lists the locations of the account, the mode and the faults.
Several homes
An account can hold several locations. The integration follows one: the first by default, or the one whose name or number you type in Location. "Test the connection" lists the names and numbers.
Scenes
Four scene actions:
- Set the Evohome system mode: a mode, permanently or for a while: hours for Economy (until the end of the hour, 24 h at most), days for Away, Day off and Custom (until midnight, today counting as the first day).
- Set an Evohome zone setpoint: a zone and a temperature, for a number of minutes (empty: the default of the configuration; 0: permanently).
- Put an Evohome zone back on its schedule.
- Set the Evohome hot water: on, off or schedule, permanently or for a number of minutes.
They return until, the end of the override (UTC, empty when permanent).
Three scene triggers:
- Evohome system mode changed: the mode changed outside Gladys (on the
controller, in the app, at the end of a temporary mode). Variables:
system_name,mode,previous_mode,permanent,until. A mode set from Gladys does not fire it. - Evohome fault detected and Evohome fault cleared: for one device or
all; variables
device_name,fault_type(e.g.TempZoneActuatorLowBattery) andsince.
The faults already active when the integration starts fire nothing. The temperatures and setpoints work with the usual "Device state changed" trigger.
How often it reads
Honeywell limits the number of sign-ins and requests per account (a lockout of an hour has been reported). The integration:
- signs in once and keeps the session (about 30 minutes, renewed with its
refresh token) in its
/datafolder, so a restart does not sign in again; - reads the status of the location in one request, every 5 minutes by default (60 s minimum, like Home Assistant), plus one read 15 s after a command;
- reads the installation (zones, hot water, allowed modes) at start-up, once a day and on Scan in the Discovery tab (at most every 10 minutes);
- waits 1, 2, 5, 10 then 15 minutes after errors, and as long as Honeywell asks after a "too many requests" (30 minutes otherwise, an hour after too many sign-ins).
Options
| Option | Default | Purpose |
|---|---|---|
| E-mail, password | — | the Total Connect Comfort account of the Evohome app |
| Location | empty (the first one) | the location to follow when the account has several |
| Setpoint set from Gladys | for the duration | a zone setpoint holds for a while, or until changed again |
| Setpoint override duration (min) | 60 | how long a setpoint set from Gladys holds (10 to 1440) |
| Hot water boost duration (min) | 60 | how long Boost keeps the hot water on (10 to 1440) |
| Refresh interval (s) | 300 | how often the status is read (60 to 3600) |
| Language of the feature names | French | names of the features and modes of the devices added from now on |
Troubleshooting
- "Total Connect Comfort refused the e-mail or password": check them on international.mytotalconnectcomfort.com, then in the configuration. The integration does not retry by itself: it waits for a change or a click on Test the connection.
- "Too many sign-ins" or "asks to slow down": Honeywell blocks the account for a while. Do not lower the refresh interval; stop other tools that read the same account (Home Assistant, Homebridge…) if you can.
- "Total Connect Comfort cannot be reached": the cloud or your Internet access is down (service status: https://status.resideo.com).
- A zone has no temperature: its sensor does not answer the controller (see its faults).
- A US / Canada thermostat or a Lyric / T-series: this is not the right integration, see the table at the top.
Privacy
The e-mail and password are stored by Gladys as a secret (never sent back to
the browser). The integration only sends them to tccna.resideo.com, the
Total Connect Comfort cloud of the Evohome app, to open a session; it keeps
the access and refresh tokens and the user id in its /data folder (with a
hash of the e-mail, never the password). Honeywell, Evohome and Total Connect
Comfort are trademarks of their owners; this integration is not affiliated
with Honeywell or Resideo.
Configuration settings
These are the settings Honeywell Evohome asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your Total Connect Comfort account | section | No | Brings your Honeywell / Resideo Evohome system into Gladys through the international Total Connect Comfort cloud (the one of the Evohome app, Europe): each heating zone with its temperature and setpoint, the system mode (Auto, Economy, Away, Day off, Custom, Heating off), the hot water, the faults, plus scene actions and triggers. Enter the e-mail and password of the app, then add the devices from the Discovery tab. Read every 5 minutes by default: Honeywell limits sign-ins and requests. For the US and Canada portal (mytotalconnectcomfort.com) or the Honeywell Home app (Lyric, T-series), use the other Honeywell integrations of the store. Unofficial, not affiliated with Honeywell or Resideo. |
| Total Connect Comfort e-mail | string | Yes | |
| Total Connect Comfort password | secret | Yes | |
| Location (several homes only) | string | No | Name or number of the location to follow when the account has several. Empty: the first one. "Test the connection" lists them. |
| Setpoint set from Gladys | select | No | A zone setpoint changed from the dashboard holds for a while (then the schedule resumes), or until changed again. |
| Setpoint override duration (min) | number | No | How long a setpoint set from Gladys holds, in minutes (10 to 1440, by steps of 10). |
| Hot water boost duration (min) | number | No | How long the hot water stays on with the Boost mode, in minutes (10 to 1440). |
| Refresh interval (s) | number | No | How often the status is read, in seconds (60 to 3600). One request per read; Honeywell blocks accounts that read too often. |
| Language of the feature names | select | No | Used for the names of the features and of the modes of the devices added from now on. |
How to install Honeywell Evohome in Gladys
- In Gladys, open Integrations: Honeywell Evohome appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/lm1lc3n7/gladys-evohome:0.1.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/LM1LC3N7/gladys-evohome.
Honeywell Evohome requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Honeywell Evohome is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by LM1LC3N7, not by the Gladys core team.
