HomeWizard Energy integration for Gladys Assistant

HomeWizard P1 Meter, Energy Socket, kWh meters, Watermeter and battery, read on the local network.

View on GitHubAll external integrations

Read your HomeWizard Energy devices in Gladys, over your local network: the P1 Meter plugged into the P1 port of a smart electricity meter (DSMR, Netherlands, Belgium, Luxembourg…), the Energy Socket, the kWh meters (one and three phases, Eastron SDM230 and SDM630 included), the Watermeter and the Plug-In Battery. Power, meter indexes, voltages, gas and water, ready for the energy tab of Gladys, with a dashboard widget, two scene triggers and three scene actions. No account and no cloud: Gladys reads each device directly, through the official local API of HomeWizard.

Developed without the hardware: feedback welcome. This integration was built and tested against real answers of HomeWizard devices recorded by the python-homewizard-energy and Home Assistant projects, and against simulated devices (API v1 and v2), not against a real meter. If something does not work as described, please say so on the Gladys forum or in the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • HomeWizard devices set up in the HomeWizard Energy app, on the same network as Gladys.
  • For each device, the local API:
    • API v1 (every model except the Plug-In Battery): in the HomeWizard Energy app, Settings → Meters → your device → Local API, turned on.
    • API v2 (P1 Meter, kWh meters and Plug-In Battery with a recent firmware): secure (HTTPS), nothing to turn on in the app, but you pair each device once by pressing its button (see below). The Plug-In Battery only has this one.
  • Nothing else: no HomeWizard account, no key, no internet access.

Set up​

  1. Install the integration from the Gladys catalog.
  2. Open its Configuration. Nothing is required; the options are:
    • IP addresses of HomeWizard devices: only for the devices automatic discovery does not find, separated by commas (for example 192.168.1.40, 192.168.1.41). Your router lists the address of each device. Names ending in .local do not work here: use the address.
    • Refresh interval: how often each device is read, from 2 seconds to 1 minute (10 seconds by default). Powers follow this pace; indexes, voltages, currents, gas and water are sent to Gladys at most once a minute, which is plenty for the energy tab and keeps Gladys light.
    • Language of the feature names: English, French, German or Spanish (French by default). The names of the features are given when a device is added, and the messages of the scene actions use this language.
  3. Open the Discovery tab of the integration: the devices found are listed. Add the ones you want.
  4. To use the API v2 (recommended on the devices that offer it, and the only way for the Plug-In Battery): click Pair (API v2): press the device button, then, within the next 75 seconds, press the button of each device to pair (on a kWh meter, the Wi-Fi pairing button, 1 to 3 seconds, not longer). The message under the button lists the devices paired. A P1 Meter with its API v1 turned on is read through v1 until it is paired.

The Search for HomeWizard devices action runs a new search and lists what was found, the API used for each device and what blocks the others (local API off, pairing needed, device not answering). The Blink a device's light action makes the status light of a device blink for a few seconds, to find it among identical ones.

The Gladys devices​

One Gladys device per HomeWizard device, named after its model and the end of its serial number (HomeWizard P1 Meter aabbcc). Only what the device reports is published: a single-phase meter has no L2 and L3, a meter with one tariff no tariff index, a P1 Meter without gas meter no gas.

P1 Meter

  • Imported power and Exported power (W): what the house draws from the grid and sends back to it, never negative.
  • Import index (kWh): the total imported energy. This is the one the energy tab of Gladys turns into consumption and cost; the imported power is kept for the power peaks some contracts are billed on.
  • Export index (kWh): the total energy sent to the grid.
  • Import index T1… T4 and Export index T1… T4 (kWh): per tariff (day/night), when the meter has several.
  • Voltage L1… L3 (V) and Current L1… L3 (A), per phase, when the meter reports them. The current is given without sign: its size.
  • Gas and Water (m³): the gas and water meters connected to the smart meter, read every hour or so by the meter itself.
  • Wi-Fi signal (%).

Energy Socket

  • On/Off: the relay, controllable.
  • Power (W), Energy index (kWh: the consumption the energy tab uses), and on recent sockets Voltage (V) and Current (A).
  • Switch lock: on, the button of the socket and Gladys can no longer switch it off (a freezer, a router). Controllable.
  • LED brightness (0 to 100 %): the light ring of the socket.
  • Wi-Fi signal (%).

kWh meters (HWE-KWH1, HWE-KWH3, SDM230, SDM630)

  • Power (W, negative when the circuit sends energy back, a solar inverter for example) and, on three-phase meters, Power L1… L3.
  • Import index (kWh, consumption in the energy tab) and Export index (kWh, counted as production by Gladys: a kWh meter on a solar inverter).
  • Voltage and Current, or Voltage L1… L3 and Current L1… L3 on three-phase meters. Wi-Fi signal (%).

Watermeter

  • Water flow (m³/h: 1 L/min is 0.06 m³/h) and Water total (m³).
  • Wi-Fi signal (%). The Watermeter only answers on USB power: on batteries it sleeps and Gladys cannot read it.

Plug-In Battery (API v2 only)

  • Battery level (%), Charge power and Discharge power (W), Charged energy and Discharged energy (kWh), Cycles, Wi-Fi signal (%).

A device that does not answer three readings in a row shows the "unreachable" badge in Gladys; its last values stay.

Dashboard widget​

Live energy shows the grid exchange of a P1 Meter:

  • a Grid gauge, signed: to the right when the house draws power, to the left (green) when it sends power back;
  • Import and Export tiles, live;
  • with a solar kWh meter chosen in the widget settings: Solar (the production measured by that meter) and House (what the house consumes: import − export + production);
  • the current tariff, the gas index, and whether the meters answer.

Settings: the P1 Meter (empty: the first one found) and, optionally, the kWh meter (or Energy Socket) measuring your solar panels.

Scenes​

Triggers​

  • Home exports more than…: the power a P1 Meter sends to the grid rises above a threshold, chosen from 100 W to 8 kW. Typical use: the solar panels produce more than the house uses.
  • Home draws more than…: the power a P1 Meter draws from the grid rises above a threshold.

Each trigger fires once when the power goes above the threshold, and again only after it went back below it by 10 % (50 W at least), so a power wobbling around the threshold does not repeat it. Nothing fires right after Gladys or the integration starts. The scene can read the Power (W) and the threshold reached. To act when the power goes back down, use the Imported power or Exported power feature in a "device state" trigger.

Actions​

  • Turn on a HomeWizard socket and Turn off a HomeWizard socket: they return whether the socket is on. Refused, with a message, while its switch lock is on.
  • Blink a HomeWizard device: the status light blinks for a few seconds (not on kWh meters read through the API v1).

Scene ideas​

  • Solar surplus: "Home exports more than… 1.5 kW" → turn on the Energy Socket of the water heater or of the car charger; "Exported power" below 200 W for 10 minutes → turn it off.
  • Avoid a power peak: "Home draws more than… 5 kW" → turn off a non-essential socket and send a message.
  • Find a device: in a scene started from the dashboard, "Blink a HomeWizard device".

Troubleshooting​

  • A device is missing from the Discovery tab: run Search for HomeWizard devices and read the message. "Local API off in the app": turn it on in the HomeWizard Energy app. "Press its button after Pair": the device only offers the API v2, pair it. Not found at all: the devices are found through the Gladys core (mDNS), on the same network only; enter its IP address in the configuration.
  • "Token refused, pair it again": the token of the integration was removed (device reset, user list cleared in the app). Run the pairing again.
  • "Certificate refused": the device at this address does not prove it is the expected HomeWizard device; Gladys sends it nothing. Check the address (a DHCP change?) and run a search.
  • The Watermeter does not answer: it must be powered over USB.
  • The values seem late: indexes, voltages and gas are sent once a minute; the gas meter itself updates every hour or so.

Limits​

  • Polling only (no push): powers are as fresh as the refresh interval.
  • The battery modes (zero, to full, standby) and the cloud settings of the devices are not controlled; the Energy Display is not supported.
  • The Energy Socket and the Watermeter are read through the API v1 (their API v2 is still in development at HomeWizard).
  • The external meters of a P1 Meter: one gas meter and one water meter; heat meters are not read.
  • Developed without the hardware (see above).

HomeWizard is a trademark of HomeWizard B.V. This integration is not affiliated with HomeWizard.

Configuration settings​

These are the settings HomeWizard Energy asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Finding your HomeWizard devicessectionNoTurn on "Local API" for each device in the HomeWizard Energy app, then open the Discovery tab: devices on the same network as Gladys are found automatically. Newer devices (P1 Meter, kWh meters, battery) also offer the secure API v2: run Pair and press their button.
IP addresses of HomeWizard devicesstringNoOptional, separated by commas. Only needed for the devices automatic discovery does not find.
Refresh intervalselectNoHow often each device is read. Power values follow this pace; indexes, voltages and currents are sent to Gladys at most once a minute.
Language of the feature namesselectNoUsed for the names of new devices' features and for the messages of scene actions.

How to install HomeWizard Energy in Gladys​

  1. In Gladys, open Integrations: HomeWizard Energy appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-homewizard:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-homewizard.

HomeWizard Energy requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

HomeWizard Energy is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
