Healthchecks smart home integration, free and open source

Your cron jobs and backups watched by Healthchecks, in Gladys: react when one stops.

• Published by guim31
• Devices
• Version 1.0.0
• Requires Gladys >=5.1.0
• ★ 0

View on GitHubAll integrations

Healthchecks watches your scheduled jobs: a cron task, a backup, a certificate renewal or any script "pings" a URL when it runs, and Healthchecks raises the alarm when the ping does not come. This integration brings the checks of a Healthchecks project into Gladys, whether you use healthchecks.io or your own server: each check becomes a device with its state, its last ping and the next one expected. Scenes can react when any check goes down, is late or comes back, a dashboard widget lists the checks down first, and scenes can pause, resume or ping a check.

Tested against a real self-hosted Healthchecks v4.4 (Docker); not yet on healthchecks.io itself: feedback welcome on the issues.

What you need

• Gladys Assistant 5.1.0 or later.
• A Healthchecks project: on healthchecks.io (free plan included) or on your own Healthchecks server, reachable from the Gladys machine.
• An API key of the project. The read-only key is enough to follow the checks; the full key also allows pause, resume and "Send a ping".

The integration reads one request per refresh interval (one minute by default): far below what healthchecks.io accepts.

Getting started

1. Create an API key

In Healthchecks, open your project, then Settings → API Access → Create API Keys. Two keys appear: the full one ("API key") and the read-only one. Copy the one you want: Healthchecks shows it again later, but keep it private.

2. Configure the integration

In Gladys, open Integrations → Healthchecks → Configuration:

• Healthchecks address: https://healthchecks.io (default), or the address of your server, the one of its SITE_ROOT setting (for example http://192.168.1.2:8000).
• API key: the key copied above.
• Refresh interval: from 30 seconds to 5 minutes.
• Language of the names: language of the feature names, of the states and of the scene results (French by default).

Save, then click Test the connection: the result gives the number of checks, the ones down or late, and says when the key is read-only.

3. Add the checks

Open the Discover tab: a "Healthchecks" device sums up the project, and each check is proposed with its name. Add the ones you want to see in Gladys. The scene triggers work for every check, added or not.

The devices

Each check becomes a device with:

• State: On time, Late, Down, Running, Paused or New, as a text.
• Working: No (red) when the check is down, Yes (green) otherwise (on time, late, running, new or paused). Handy as a scene condition.
• Last ping: day/month and time of the last ping.
• Next ping expected: when the check turns late without a new ping; "-" when nothing is expected (down, paused or new check).
• Pings received: the counter of Healthchecks.
• Last run duration: in seconds, between the "start" and the "success" signals, for the checks that send a start signal (/start).

The Healthchecks device of the project counts the Checks down, the Checks late and the Checks in total.

Last ping, next ping, pings and duration are sent at most every 5 minutes per check (at once when the state changes), to stay within the limits of Gladys.

Dashboard

The Healthchecks widget shows three tiles (down, late, on time), then one row per check: down first, then late, then running, new, paused and on time, with the state and the last ping. Ten rows at most; the rest is counted. In the widget settings, choose some checks to show only them (devices added to Gladys). The Refresh button reads Healthchecks again.

Scenes

Triggers

• A check goes down: no ping before the end of its grace time, or a failure signal (/fail). Variables: check name, tags, last ping.
• A check is back up: a check that was down receives a ping again. Variables: the same, plus the outage length in minutes.
• A check is late: the expected ping did not come and the grace time starts: still time to act before the check goes down.

Each trigger can be limited to some checks (empty: any). The state is kept in the /data volume: a check that went down while Gladys or the integration restarted is announced once at the next read. Nothing is announced at the first read, nor for a check paused, resumed or running.

Actions

• State of a check: gives down (yes/no), the state in words, the name, the last_ping and a ready-made sentence, for example "Nightly backup: Down, last ping 14/10 03:12.".
• Count the checks down: down, late, in total, and the names of the checks down.
• Pause a check and Resume a check: for a planned maintenance (full API key). A resumed check waits for its next ping.
• Send a ping: sends the success signal of a check (full API key), so a Gladys scene reports by itself that it ran.

Scene ideas

• When A check goes down, limited to the backup checks in its Checks field, send a Telegram message "The backup did not run, last ping {{last_ping}}".
• Every morning at 8:00, Count the checks down and, if there is at least one, read the names on the speaker.
• In a nightly Gladys scene (watering, heating schedule…), end with Send a ping to a dedicated check: Healthchecks warns you if Gladys itself stopped running it.
• Before switching the NAS off for maintenance, Pause a check of the backup, and Resume a check when it is back.

Troubleshooting

• API key refused: copy the key again from Settings → API Access of the right project; each project has its own keys.
• No Healthchecks at this address: check the address; for your own server it is the one of SITE_ROOT, with a sub-path if it has one.
• The address redirects: enter the final address, usually in https://. The integration does not follow redirects, so that the key is never sent elsewhere.
• Certificate refused: a self-signed certificate is not accepted; use the http:// address on the local network, or a trusted certificate.
• This needs the full API key: pause, resume and ping need the full key, not the read-only one.
• Send a ping fails on a self-hosted server: the ping URL is built by Healthchecks from its PING_ENDPOINT (or SITE_ROOT) setting; Gladys must be able to reach that address.

Limits

• One project per configuration (one API key = one project).
• The integration reads Healthchecks: a check is not created or edited from Gladys.
• A short outage between two reads can go unseen in the device states; Healthchecks keeps the full history.
• "Running" (a start signal without its end) does not change the state used by the triggers.
• Developed without access to a healthchecks.io account: tested against the self-hosted server (same API). Feedback welcome.

Configuration settings

These are the settings Healthchecks asks for in its configuration screen in Gladys.

Setting	Type	Required	Description
Your Healthchecks project	section	No	In Healthchecks, open the project Settings → API Access, create an API key and paste it below. The full key also allows pause, resume and ping; the read-only key only reads. Then add the checks to follow from the Discover tab.
Healthchecks address	string	No	https://healthchecks.io, or the address of your own server (its SITE_ROOT).
API key	secret	No	The key of one project. Read-only is enough to follow the checks.
Options	section	No
Refresh interval	select	No	How often Healthchecks is read: one API request each time.
Language of the names	select	No	Language of the feature names (set when a device is added), of the states and of the scene results.

How to install Healthchecks in Gladys

1. In Gladys, open Integrations: Healthchecks appears in the catalog, next to the native integrations, with a community badge.
2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-healthchecks:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
3. Open the Configuration screen of the integration, fill in the settings, and save.
4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-healthchecks.

Healthchecks requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations

Healthchecks is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.

• Browse all integrations, native and community
• Build and publish your own external integration
• Source code on GitHub — source of this documentation
