Growatt smart home integration, free and open source

Growatt integration for Gladys Assistant

Growatt solar inverters and batteries: production, battery, grid and home energy.

View on GitHubAll integrations

Follow your Growatt solar inverters and batteries in Gladys: solar production, energy of the day and production index, battery level and power, grid import and export, home consumption, inverter status. The data comes from the Growatt cloud (ShineServer, the ShinePhone app), read every 5 minutes: the pace at which the Growatt dataloggers upload. The integration only reads: it never changes a setting of the inverter.

Developed without the hardware: feedback welcome. This integration is not affiliated with Growatt.

Requirements​

  • A Growatt plant visible in the ShinePhone app or on server.growatt.com, its datalogger (ShineWiFi, ShineLAN, ShineLink) online.
  • One of the two ways in:
    • an OpenAPI token (recommended). Some accounts can create one in the account settings of server.growatt.com; otherwise ask the Growatt support or your installer;
    • the username and password of the ShinePhone app.
  • Gladys 5.1 or later, with internet access.

Configuration​

Open the Configuration tab of the integration.

Choose OpenAPI token as connection mode and paste the token. The OpenAPI is the interface Growatt documents for third-party software: no login, nothing stored by the integration. Detailed data exists for the MIN family (MIN, TL-X, TL-XH, MOD, MIC) and the SPH hybrids; the other devices are counted in the totals of the plant.

ShinePhone account​

Choose ShinePhone account and enter the username and password of the app. This access may be blocked by Growatt: the interface is not documented, its server only accepts the User-Agent of the Growatt app (the integration presents itself as the app, like the reference libraries), may refuse a login with HTTP 403, and locks an account that logs in too often (error 507, for about a day). Prefer a token when you can. The integration therefore logs in once, keeps the session in its /data volume (never the password) and reuses it, even after a restart; it logs in again only when the session expires, and never twice within 10 minutes. Detailed data exists for string inverters, TL-X / MIN and SPH (MIX).

Other settings​

  • Growatt server: the region where the account was created (Europe and other regions, North America, Australia and New Zealand, China).
  • Plants to follow: empty for every plant of the account, or plant ids separated by commas.
  • Refresh interval: 5 minutes by default, or 10, 15, 30. Reading faster than 5 minutes is refused by Growatt.
  • Language of the feature names: the names given to the features when a device is added, and the language of the inverter status (French by default).

Save, then click Test the connection: the message lists the plants and inverters found. The devices appear in the Discovery tab: add the ones you want.

Devices​

Plant​

One device per Growatt plant, with the totals Growatt computes for the whole plant:

FeatureUnitMeaning
Production powerWPower the plant produces now
Production todaykWhEnergy produced since midnight
Production indexkWhEnergy produced since the installation

Inverter​

One device per inverter the API reads in detail. The features follow what the inverter reports: a battery appears only on an installation that has one, the grid and home features only when a Growatt meter (or a CT clamp) is connected.

FeatureUnitMeaning
Inverter statustextNormal, Waiting, Fault, Offline
Solar powerWPower of the solar panels
PV1 voltage, PV1 current, PV2…V, AEach string of panels
Inverter output powerWAC power the inverter delivers
Production today, Production indexkWhSolar energy of the day, since the installation
Battery level%State of charge
Battery charge power, Battery discharge powerWPower into and out of the battery
Battery charge index, Battery discharge indexkWhEnergy charged and discharged since the start
Grid import power, Grid export powerWPower taken from and sent to the grid
Grid import index, Grid export indexkWhEnergy taken from and sent to the grid
Home consumption, Home consumption indexW, kWhConsumption of the home measured by the meter
Inverter temperature°CTemperature of the inverter

A feature seen for the first time (a battery that wakes up in the morning) is offered as an Update in the Discovery tab. A feature is never removed: a battery read empty at night keeps its features.

Energy monitoring​

The indexes (production, battery, grid, home) are counters in kWh that the energy monitoring of Gladys turns into energy per half hour. The plant and its inverters count the same production: for the production, add the plant or its inverters to the energy monitoring, not both, or it will be counted twice. The Growatt counters sometimes read 0 or go back a little around midnight: the integration filters these glitches.

Dashboard widget​

Solar overview: pick a plant or an inverter in its settings. It shows live tiles (production, energy of the day, battery, grid import and export, home), the production curve of the day and the status of the inverter with the time of its last data.

Scene trigger​

Inverter status changed: fires when an inverter goes into fault, stops reporting to the Growatt cloud (offline), waits (at night) or runs normally again. Filters: the inverter, the new status. Variables for the actions: the new status (code and text), the previous status, the inverter name. The first reading after a start never fires it.

Action​

Test the connection (Configuration tab): reads the account and tells the plants and inverters found, the devices counted in the plant totals only, or the reason of a failure. It reuses the data read less than 5 minutes ago: clicking it again does not multiply the requests to Growatt.

Scene examples​

  • Warn of a fault: trigger "Inverter status changed" with the status Fault and Offline → send a message "The inverter {{device_name}} is now {{status_label}}".
  • Use the surplus: every 5 minutes, if the grid export power is above 1500 W and the battery level above 90 % → turn on the water heater plug.
  • Evening summary: every day at 21:00 → send a message with the production of the day of the plant.

Troubleshooting​

  • "Growatt refused the token": check the token and the server region. The integration stops calling Growatt until the configuration changes.
  • "Growatt refused the username or password": check them in the ShinePhone app, and the region. No new attempt until the configuration changes, to protect the account.
  • "The Growatt server refused the ShinePhone login (HTTP 403)": the server refuses the login request itself, whatever the password. The integration waits 6 hours before trying again; use an OpenAPI token instead.
  • "Growatt locked the account": the ShinePhone server locked the account after too many connections (other apps logging in with the same account count too). The integration waits 6 hours before trying again, restart included. A token avoids the problem.
  • "The Growatt cloud does not answer": the readings resume on their own.
  • An inverter shows Offline: its datalogger no longer uploads (Wi-Fi, power).
  • For the details, set the variable LOG_LEVEL=debug on the integration and look at its logs: they never contain the token nor the password.

Limits​

  • Developed without the hardware nor a Growatt account: the field names come from the growattServer library and the Home Assistant integration. Feedback welcome, especially on the SPH (the unit of its grid powers) and on the statuses of the less common families.
  • Reading only: no setting of the inverter (charge, discharge, export limit) can be changed.
  • The data is the Growatt cloud's: at best 5 minutes old, and absent when the cloud is down.
  • Detailed data: MIN / TL-X / MOD / MIC and SPH with a token; string inverters, TL-X and SPH with an account. Other families (MAX, SPA, storage, NOAH…) are in the plant totals only.
  • Requests per refresh: with a token, 2 per plant, 1 per MIN, 2 per SPH, and the device list once an hour; with an account, 1 or 2 per plant, 1 per inverter, 2 per SPH.

Configuration settings​

These are the settings Growatt asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Connect your Growatt accountsectionNoAn OpenAPI token (recommended: ask Growatt support or your installer). The ShinePhone app account may be blocked by Growatt: its server refuses some logins and locks accounts that log in too often. Data is read every 5 minutes.
Connection modeselectYes
OpenAPI tokensecretNoToken mode only. Kept by Gladys, never written in the logs.
ShinePhone usernamestringNoShinePhone account mode only. Growatt may block this login: prefer a token.
ShinePhone passwordsecretNoShinePhone account mode only. Kept by Gladys, never written in the logs.
Growatt serverselectNoThe region where the account was created.
Plants to followstringNoEmpty: every plant of the account. Otherwise the plant ids, separated by commas.
Refresh intervalselectNoGrowatt receives new data every 5 minutes: reading faster brings nothing.
Language of the feature namesselectNoUsed when a device is added to Gladys, and for the inverter status.

How to install Growatt in Gladys​

  1. In Gladys, open Integrations: Growatt appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-growatt:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-growatt.

Growatt requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Growatt is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
