go-e Charger smart home integration, free and open source
go-e Charger EV wallboxes over the local API: charge state, power, energy, current and modes.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.2.0
- ★ 0
Follow and drive your go-e Charger EV charging stations (go-eCharger V3 and V4: HOME+ and HOMEfix V3, Gemini, Gemini flex) from Gladys, over their local HTTP API v2: no cloud needed. The go-e cloud API remains an option for a charger Gladys cannot reach on the local network.
Developed without the hardware: feedback welcome. This integration was written from the go-e API documentation and real answers published by other projects, without a charger at hand. If something looks wrong, open an issue on the GitHub repository with the integration logs.
This integration is not affiliated with go-e GmbH.
Requirements
- A go-e Charger with a firmware supporting the HTTP API v2 (V3 and later, firmware 051.4 or later). An old go-e Charger V2 (API v1 only) is not supported.
- The local HTTP API v2 turned on in the go-e app:
- older app: Internet → Advanced settings → Access to /api/status and /api/set API, then save;
- newer app: Settings → Connection → API settings → Allow local HTTP API v2.
- A fixed IP address for the charger, set in your router (DHCP reservation): the integration reaches it by its address.
- Gladys 5.2.0 or later.
When the API v2 is off, the charger answers but refuses the requests: the Configuration screen then says "the local HTTP API v2 is off" and where to turn it on.
Configuration
- Install the integration from Integrations → Install from GitHub (or the store), then open its Configuration tab.
- Charger IP addresses: the address of each charger, separated by commas
(for example
192.0.2.10, 192.0.2.11). - Refresh interval: how often the chargers are read (15 seconds by default).
- Language of the feature names: names given to the features of new devices and language of the error texts (French by default).
- Save: one device per charger appears in the Discovery tab. Add it.
- The Test the connection button reads every charger and says, for each one, whether it answers (name, serial number, firmware) or why not.
Optional, go-e cloud: only for a charger Gladys cannot reach locally. Turn on the cloud API in the go-e app (Internet → Advanced settings), then enter the charger's serial number and the API token the app shows. The data then goes through go-e's servers.
Refresh and API usage
The integration reads each charger itself, at the chosen interval, with one
filtered request (/api/status?filter=…, 16 keys) — go-e advises against
reading the full status, and against more than one request per second. Gladys
also polls the devices as a fallback; the integration then skips a charger it
has just read. Only the values that changed are sent to Gladys, plus every
value again every 6 hours so a stable one never shows "no recent value".
The go-e cloud has no documented quota; the same pace applies.
The charger device
| Feature | What it shows |
|---|---|
| Connector | Available (no car), Occupied (car plugged in), Unavailable (offline), Faulted (error) |
| Charging state | Charging, Vehicle connected (waiting), Paused (vehicle): charge complete, Paused (charger): not allowed, Idle |
| Car plugged in | 1 when a car is plugged in |
| Charging power | Total power, W |
| Power L1, L2, L3 | Power per phase, W |
| Current L1, L2, L3 | Current per phase, A |
| Session energy | Energy since the car was plugged in, kWh |
| Total energy | The charger's meter, kWh: Gladys' energy monitoring computes the consumption and its cost from it |
| Charging current | Command: the current offered to the car, from 6 A to 16 A (11 kW) or 32 A (22 kW) |
| Charging mode | Command: Automatic (app), Forced charge, Forced stop |
| Phases | Command, only on chargers able to switch: Automatic, One phase, Three phases |
| Temperature | The hottest sensor of the charger, °C |
| Error | The go-e error in words ("None" when all is well) |
| Online | 1 while the charger answers |
"Automatic (app)" is go-e's neutral mode: the charger follows what the app decides (schedule, solar "eco" mode, aWATTar prices). Solar charging stays in the go-e app or in evcc: this integration does not duplicate it.
Widget
Add the go-e Charger widget to a dashboard and pick a charger. It shows the live power, the session energy and the charging current, the state in go-e words (Ready, Charging, Waiting for the car, Charge complete, Error), the mode, the phases and the error if any. Four buttons: Charge (forced charge), Stop (forced stop), Auto (back to the app's mode) and Current…, which opens a form to set the current. The current mode carries a check icon.
Scene trigger
go-e charge finished: the car stopped drawing after a charge (it is full,
or reached the limit set in the car or the app). Optionally pick the charger.
The following actions can use energy_kwh (energy of the session) and
charger (its name). It fires once per charge, never at startup.
"Car plugged in" needs no trigger: use the Car plugged in feature (changes to 1) in a "device value" trigger.
Scene action
Set the go-e charging mode: forced charge, forced stop, or back to the automatic mode of the app. The charging current needs no action of its own: it is a feature, set with Gladys' usual "control a device" action.
Scene examples
- Charge during off-peak hours: at 22:00, "Set the go-e charging mode" to Forced charge; at 06:00, back to Automatic (app).
- Tell me when the car is full: trigger "go-e charge finished", then send a message "Charge finished: {{triggerEvent.data.energy_kwh}} kWh".
- Protect the main breaker: when the house power goes over a threshold, set the charging current to 6 A; when it goes down, back to 16 A.
Troubleshooting
- "No answer": check the address, that the charger is on the Wi-Fi, and that Gladys and the charger are on the same network.
- "The local HTTP API v2 is off": turn it on in the go-e app (see Requirements), save, then press Test the connection.
- Cloud: "the go-e cloud refused the token": check the serial number (6 digits) and the token; generating a new token in the app invalidates the old one.
- A command fails with "the charger refused the request": the current is probably above the maximum set in the go-e app.
- The integration logs say the rest: set
LOG_LEVEL=debugfor the detail of every read.
Limits
- One charger per address; the cloud access serves a single charger.
- The feature names and the maximum current are fixed when the device is added (a Gladys rule): to change the language, delete the device and add it again.
- The charger's firmware must be 051.4 or later (filtered reads).
- No access to the RFID cards, the schedules, the cable lock or the solar settings: they stay in the go-e app. The cable lock is deliberately not exposed.
- The local API v2 has no password: anyone on your network can use it, as with the go-e app.
- Tested against a fake charger and published answers only (see the note at the top).
Configuration settings
These are the settings go-e Charger asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Before you start | section | No | In the go-e app, turn on the local HTTP API v2 (Internet → Advanced settings, or Connection → API settings in the newer app). Give the charger a fixed IP address in your router, then enter it below. |
| Charger IP addresses | string | No | One or more addresses, separated by commas. |
| Refresh interval | select | No | How often the chargers are read. go-e advises against more than one read per second. |
| Language of the feature names | select | No | Names given to the features of new devices, and language of the error texts. |
| Optional: go-e cloud | section | No | Only for a charger Gladys cannot reach on the local network. Turn on the cloud API in the go-e app (Internet → Advanced settings): it shows the API token. The data then goes through go-e's servers. |
| Serial number | string | No | |
| Cloud API token | secret | No |
How to install go-e Charger in Gladys
- In Gladys, open Integrations: go-e Charger appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-goecharger:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-goecharger.
go-e Charger requires Gladys >=5.2.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
go-e Charger is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
