GeoJSON & GeoRSS feeds smart home integration, free and open source

Located events (earthquakes, fires, alerts) from GeoJSON or GeoRSS feeds, near your home.

• Published by guim31
• Devices
• Version 1.0.0
• Requires Gladys >=5.1.0
• ★ 0

View on GitHubAll integrations

A generic reader of located event feeds for Gladys Assistant: paste the address of up to five feeds (USGS earthquakes, GDACS alerts, NSW Rural Fire Service fires, the feed of a local authority…), and Gladys follows the events within a radius of your house, shows them on the dashboard and starts a scene when one appears or disappears.

Formats read: GeoJSON (FeatureCollection), GeoRSS (Simple and GML), W3C geo (geo:lat / geo:long), RSS 2.0, RSS 1.0 and Atom.

For worldwide disasters or European earthquakes, the dedicated integrations GDACS and EMSC know their sources better (alert levels, magnitude revisions): this one is for any other feed.

A complement, not a safety alert system: follow the instructions of your local authorities.

What you get

• One device per feed: the number of events in the area, the distance and title of the nearest one, the latest event in words, and a badge telling whether the feed can be read.
• A dashboard widget: the current events of each feed, then the nearest ones.
• Two scene triggers: a new event in the area, an event removed.
• A scene action that reads the events of your area as one sentence.

Requirements

• Gladys Assistant 5.1.0 or later.
• Internet access from Gladys (the feeds are read by the integration container).
• The location of your house in Gladys (Settings → Houses), or coordinates typed in the configuration. Without either, only feeds with the radius "Whole feed" work.
• The address of a public feed. A few that work:
  • USGS earthquakes of the last day: https://earthquake.usgs.gov/earthquakes/feed/v1.0/summary/2.5_day.geojson
  • GDACS disaster alerts: https://www.gdacs.org/xml/rss.xml
  • NSW Rural Fire Service major incidents: https://www.rfs.nsw.gov.au/feeds/majorIncidents.json

Configuration

Settings

For each of the five feeds:

Setting	Use
Feed address	http or https, 5 MB at most. Empty: the slot is not used.
Name	Shown in the widget and the scenes. Empty: "Geo feed 1 (host)".
Radius	Distance from the centre to the event. "Whole feed": every event, for a local feed.
Categories (optional)	Keep only the events whose category contains one of these words (commas between words).
Numeric property (optional)	A numeric property of the events, mag for the USGS: sent to the scenes as value.
Minimum value (optional)	Events whose property is lower, or missing, are ignored.

Then, for every feed:

• Centre latitude / longitude: empty, the location of your house.
• Refresh interval: 5 to 60 minutes.
• Maximum age of the events: older events are ignored; events without a readable date are kept.
• Language of the texts: names of the devices and features at their creation, texts sent to the scenes.

Save, then open the Discover tab and create the devices.

Reading a feed

• GeoJSON: a Point is used as it is; for a Polygon, MultiPolygon or line, the centre of its points; for a GeometryCollection, its first Point (NSW RFS sends the fire point and its area).
• The identifier is id or guid; without one, a digest of the title, link and position.
• Title: title, name, headline or place. Date: time, date, pubDate, published, updated. Category: category or type. Link: url or link.
• RSS and Atom: georss:point, georss:polygon, georss:box, gml:pos or geo:lat / geo:long; title, link, guid or id, pubDate or updated, category. Items without a position are skipped.
• Nothing of a feed is ever run: it is only read. The XML DOCTYPE is ignored.

Device

One device per feed, refreshed by the integration itself (no Gladys polling):

Feature	Type	Value
Events in the area	counter	Followed events of the feed.
Nearest event distance	distance, km	The nearest followed event; 20,038 km (the farthest possible) when none.
Nearest event	text	Its title.
Latest event	text	The newest followed event, with its distance.

The device badge shows "Cloud" when the last reading worked, "Unreachable" otherwise; the reason (no answer, HTTP error, not a feed…) is in the integration status and the widget.

Dashboard widget

Geo feed events: a heading with the number of events, one row per feed (its count, or why it cannot be read), the nearest events (8 at most) with their feed and distance, and the time of the last reading. Tap an event: its summary, its date and a link to it. The settings choose the feeds to show (empty: all).

Scene triggers

Geo feed: new event in the area: an event enters the followed set of a feed (radius, age, categories and minimum value). Geo feed: event removed: a followed event leaves the feed, or no longer matches (too old, moved away).

The first reading of a feed, and the first one after a configuration change, fire nothing: what is there is the starting point. A restart fires nothing either (the followed events are kept in /data). At most 20 events per feed and per reading.

Filter: the feed (empty: any). Variables:

Variable	Content
feed_name	The name of the feed.
title	The title of the event.
category	Its categories, separated by commas.
distance_km	Distance from the centre, empty without a centre.
value	The numeric property chosen for the feed, empty without one.
time	The date of the event (ISO 8601), empty if unknown.
url	The link of the event.
summary	Title and distance, ready for a message.
latitude	Latitude of the event.
longitude	Longitude of the event.
properties	The simple properties of the event, as JSON.

Scene action

Geo feed: read the events reads the feeds again if needed and answers with text (the events as one sentence, nearest first), count and nearest_km (20038 when there is none). The feed filter limits it to one feed. The Read the feeds now button of the configuration tells, feed by feed, what was read.

Scene examples

• Earthquake nearby: trigger "new event in the area" on the USGS feed (radius 250 km, property mag, minimum 4) → send a message "{{summary}}, magnitude {{value}}".
• Bushfire warning: NSW RFS feed, categories Watch and Act, Emergency, radius 50 km → turn on a light in red and send the link {{url}}.
• Morning briefing: every day at 7:30, action "read the events" → read text aloud.

Data sources, terms and quotas

The data belong to the publisher of each feed: read and respect its terms of use, and credit it when you share them. The USGS feeds are in the public domain (earthquake.usgs.gov), GDACS asks to be cited. The integration reads each feed at most every 5 minutes, with its own User-Agent, and reads 5 MB at most: enough for public feeds, which are mostly refreshed every 5 to 15 minutes.

Troubleshooting

• "not a GeoJSON, RSS or Atom feed": the address gives a web page. Look for the feed link (GeoJSON, RSS, Atom) on the site of the publisher.
• No event while the feed has some: check the radius and the location of your house, the categories and the minimum value; a property that the events do not have excludes them all.
• "No centre": give your house a location in Gladys or type coordinates.
• The dates are missing (NSW RFS): the feed gives local dates without a time zone; they are not guessed. The maximum age keeps these events.
• Logs: docker logs of the integration container; LOG_LEVEL=debug shows each reading.

Limits

• Five feeds at most; one radius and filters per feed.
• The distance is measured to the centre of an area, not to its edge: a large area around your house can be farther than the radius.
• No authentication: public feeds only (a token in the query string works, and is never logged).
• Not affiliated with the USGS, GDACS, NSW RFS nor any feed publisher.

Configuration settings

These are the settings GeoJSON & GeoRSS feeds asks for in its configuration screen in Gladys.

Setting	Type	Required	Description
Your feeds	section	No	Paste the address of up to five feeds of located events: GeoJSON, GeoRSS, RSS or Atom (earthquakes, fires, alerts of a local service…). Each feed becomes a device: save, then create it in the Discover tab.
Feed 1	section	No	Example: the earthquakes of the last day from the USGS, https://earthquake.usgs.gov/earthquakes/feed/v1.0/summary/2.5_day.geojson
Feed address	string	No	http or https. GeoJSON, GeoRSS, RSS 2.0 or Atom, 5 MB at most.
Name	string	No	Shown in the widget and the scenes. Empty: the host of the address.
Radius	select	No	Distance from the centre to the event (the centre of an area). Whole feed: every event, for a local feed.
Categories (optional)	string	No	Keep only the events whose category contains one of these words, separated by commas.
Numeric property (optional)	string	No	Name of a numeric property of the events (mag for the USGS): sent to the scenes as value, and filtered by the minimum below.
Minimum value (optional)	string	No	Events whose property is lower, or missing, are ignored.
Feed 2	section	No	Optional: leave the address empty if not used.
Feed address	string	No	http or https. GeoJSON, GeoRSS, RSS 2.0 or Atom, 5 MB at most.
Name	string	No	Shown in the widget and the scenes. Empty: the host of the address.
Radius	select	No	Distance from the centre to the event (the centre of an area). Whole feed: every event, for a local feed.
Categories (optional)	string	No	Keep only the events whose category contains one of these words, separated by commas.
Numeric property (optional)	string	No	Name of a numeric property of the events (mag for the USGS): sent to the scenes as value, and filtered by the minimum below.
Minimum value (optional)	string	No	Events whose property is lower, or missing, are ignored.
Feed 3	section	No	Optional: leave the address empty if not used.
Feed address	string	No	http or https. GeoJSON, GeoRSS, RSS 2.0 or Atom, 5 MB at most.
Name	string	No	Shown in the widget and the scenes. Empty: the host of the address.
Radius	select	No	Distance from the centre to the event (the centre of an area). Whole feed: every event, for a local feed.
Categories (optional)	string	No	Keep only the events whose category contains one of these words, separated by commas.
Numeric property (optional)	string	No	Name of a numeric property of the events (mag for the USGS): sent to the scenes as value, and filtered by the minimum below.
Minimum value (optional)	string	No	Events whose property is lower, or missing, are ignored.
Feed 4	section	No	Optional: leave the address empty if not used.
Feed address	string	No	http or https. GeoJSON, GeoRSS, RSS 2.0 or Atom, 5 MB at most.
Name	string	No	Shown in the widget and the scenes. Empty: the host of the address.
Radius	select	No	Distance from the centre to the event (the centre of an area). Whole feed: every event, for a local feed.
Categories (optional)	string	No	Keep only the events whose category contains one of these words, separated by commas.
Numeric property (optional)	string	No	Name of a numeric property of the events (mag for the USGS): sent to the scenes as value, and filtered by the minimum below.
Minimum value (optional)	string	No	Events whose property is lower, or missing, are ignored.
Feed 5	section	No	Optional: leave the address empty if not used.
Feed address	string	No	http or https. GeoJSON, GeoRSS, RSS 2.0 or Atom, 5 MB at most.
Name	string	No	Shown in the widget and the scenes. Empty: the host of the address.
Radius	select	No	Distance from the centre to the event (the centre of an area). Whole feed: every event, for a local feed.
Categories (optional)	string	No	Keep only the events whose category contains one of these words, separated by commas.
Numeric property (optional)	string	No	Name of a numeric property of the events (mag for the USGS): sent to the scenes as value, and filtered by the minimum below.
Minimum value (optional)	string	No	Events whose property is lower, or missing, are ignored.
Options	section	No
Centre latitude	string	No	Leave both coordinates empty to use the location of your house in Gladys.
Centre longitude	string	No	Decimal degrees, east positive.
Refresh interval	select	No	Every feed is read this often. 5 minutes at least: the feeds are public services.
Maximum age of the events	select	No	Older events are ignored. Events without a readable date are kept.
Language of the texts	select	No	Names of the devices and features (at their creation) and texts sent to the scenes.
Sources and limits	section	No	The data belong to the publisher of each feed: respect its terms of use. A complement, not a safety alert system: follow the instructions of your local authorities.

How to install GeoJSON & GeoRSS feeds in Gladys

1. In Gladys, open Integrations: GeoJSON & GeoRSS feeds appears in the catalog, next to the native integrations, with a community badge.
2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-geofeeds:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
3. Open the Configuration screen of the integration, fill in the settings, and save.
4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-geofeeds.

GeoJSON & GeoRSS feeds requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations

GeoJSON & GeoRSS feeds is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
