Gatus smart home integration, free and open source

Gatus integration for Gladys Assistant

Your Gatus endpoints in Gladys: up or down, response time, uptime, and scenes when one goes down.

View on GitHubAll integrations

Gatus watches your services (websites, APIs, DNS, ports, certificates) and shows them on a status page. This integration brings its endpoints into Gladys: each endpoint becomes a device with its state, response time and uptime, scenes react when one goes down or comes back, and a dashboard widget shows them by group.

Gladys reads Gatus: it does not check your services itself. Everything stays on your network (no cloud).

Tested against a real Gatus in Docker (build of 16 October 2026): endpoints up, failing and stopped, groups, an external endpoint, basic login. Feedback welcome on the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • A Gatus reachable from Gladys, usually on port 8080.
  • If Gatus asks for a login: the user and password of its security.basic section. Gatus protected by OIDC is not supported.
  • To push results from Gladys (optional): an external endpoint in Gatus and its token.

Getting started​

1. Find the address of Gatus​

It is the address of its status page, for example http://192.168.1.2:8080. A URL copied from the browser works too (…/endpoints/core_api): the integration keeps the start of it.

2. Configure the integration​

In Gladys, open the integration and fill in:

  • Gatus address.
  • User and Password: only if Gatus asks for a login. The password in clear, not the bcrypt hash of the Gatus configuration.
  • External endpoints token: only for the action "Push a result to Gatus".
  • Refresh interval: 30 seconds to 5 minutes (1 minute by default). One request each time, plus two requests per endpoint for the uptimes every 5 minutes.
  • Failed checks before down: how many failed checks of Gatus in a row make an endpoint down (2 by default). 1 reacts at the first failure, as the Gatus page shows it; more avoids false alarms on a service that hiccups. Choose a refresh interval close to the interval of your Gatus endpoints, so that no result is missed.
  • Language of the names: language of the feature names and of the scene results (French by default).

Then click Test the connection: it reads Gatus and counts the endpoints.

3. Add the endpoints​

Open the Discover tab of the integration: one device per Gatus endpoint, and a "Gatus" device for the whole instance. Add the ones you want to follow. The scene triggers and the widget work for every endpoint, added or not.

An endpoint renamed or moved to another group in Gatus gets a new key, so a new device: delete the old one.

The devices​

Each endpoint:

  • Online: yes when the last check of Gatus succeeded, no when it is down (see "Failed checks before down"). Green or red badge, a Yes/No condition in scenes.
  • Response time: the duration of the last successful check, in milliseconds. Sent at most every 5 minutes, at once when the state changes.
  • Uptime 24 h and Uptime 7 days: the share of successful checks, as computed by Gatus, in percent.

The "Gatus" device:

  • Endpoints down and Endpoints in total.

Dashboard​

The Gatus widget shows three tiles (endpoints down, up, average uptime over 24 hours) and a list: with ten endpoints or fewer, one row per endpoint, the ones down first, with their group, response time and uptime; beyond, one row per Gatus group ("Down: 1 / 8"). In its settings, choose a group, or endpoints added to Gladys. The Refresh button reads Gatus at once.

Scenes​

Triggers​

  • An endpoint goes down: an endpoint fails its checks, as many times in a row as set in the configuration. Variables: endpoint name, group, what failed (the failed conditions, or the error).
  • An endpoint is back up: an endpoint that was down passes its check again. Variables: endpoint name, group, outage length in minutes.

Both can be limited to some endpoints. No event is sent at the first reading: only real changes. An endpoint that went down while Gladys was restarting is still announced, once.

Actions​

  • State of an endpoint: online or not, state in words, response time, uptime over 24 hours, what failed, and a ready-made sentence such as "NAS: Down, 97.5 % over 24 h. [STATUS] (502) == 200".
  • Count the endpoints down: how many are down and in total, in Gatus or in one group, and the names of the ones down.
  • Push a result to Gatus: reports a success or a failure (with its message) to an external endpoint of Gatus, given by its key (group_name, as in the address of its Gatus page) or its name. Gatus keeps the history and sends its own alerts. The external endpoint is declared in the Gatus configuration:
external-endpoints:
  - name: nightly-job
    group: backups
    token: 'a-long-random-token'

Put the same token in the integration configuration (several external endpoints can share it).

Scene ideas​

  • An endpoint goes down → send a message with the name of the endpoint and what failed.
  • Every evening, Count the endpoints down → if more than zero, a message with the names.
  • At the end of a Gladys scene that does a backup or a check of your own, Push a result to Gatus: Gatus shows it like any other service, and alerts when it stops running.

Troubleshooting​

  • "Gatus does not answer": check the address and the port from the machine of Gladys, and that a firewall does not block it.
  • "Gatus asks for a login": fill in the user and password of the security.basic section. With OIDC, the API cannot be read.
  • "The address redirects": enter the https:// address directly.
  • "Certificate refused": a self-signed certificate is not accepted; use the http:// address on your network.
  • An endpoint stays without value: it has no result yet (a new endpoint, or an external endpoint that never received one).
  • "No external endpoint with this key": the key is group_name, lower case, spaces and dots turned into dashes; an endpoint only appears in Gatus after its first result.

Limits​

  • Gladys reads Gatus at the chosen interval: an outage shorter than it, or than the threshold, may not be seen.
  • The uptimes come from Gatus, which counts them per hour.
  • Suites, announcements and the incidents of Gatus are not read.
  • Gatus protected by OIDC is not supported.
  • Not affiliated with Gatus or its author.

Configuration settings​

These are the settings Gatus asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your GatussectionNoEnter the address of your Gatus (the one of its status page). Then add the endpoints to follow from the Discover tab: Gladys reads Gatus, it does not check your services itself.
Gatus addressstringYesAddress and port of the Gatus web interface (8080 by default).
User (optional)stringNoOnly if Gatus is protected by a basic login (security.basic).
Password (optional)secretNoThe password of this user, in clear (not its bcrypt hash).
External endpoints token (optional)secretNoThe token of your Gatus external-endpoints, for the scene action that pushes a result.
OptionssectionNo
Refresh intervalselectNoHow often Gatus is read: one request each time, plus the uptimes every 5 minutes.
Failed checks before downselectNoHow many failed checks of Gatus in a row make an endpoint down: more avoids false alarms, at the cost of a later alert.
Language of the namesselectNoLanguage of the feature names (set when a device is added) and of the scene results.

How to install Gatus in Gladys​

  1. In Gladys, open Integrations: Gatus appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-gatus:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-gatus.

Gatus requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Gatus is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
