Fronius smart home integration, free and open source
Fronius solar inverters on the local network: production, grid, house consumption and battery.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Follow your Fronius solar installation in Gladys: solar production, house consumption, grid import and export, battery, inverters and meters — read on your local network, through the Fronius Solar API, with no cloud account.
Developed without the hardware: feedback welcome. This integration was written and tested against real answers of Fronius systems (Symo, Primo, GEN24 with and without battery) published by the Home Assistant project, but not on a real installation yet. If something looks wrong, open an issue on GitHub with the logs (
LOG_LEVEL=debug).Not affiliated with Fronius International GmbH. Fronius, Symo, Primo, Eco, GEN24 and Tauro are trademarks of their owners.
Overview
The integration reads the Fronius Solar API v1 (local JSON, no authentication) of a Fronius Datamanager (card or box, in a Symo, Primo, Eco, Galvo or IG Plus) or of a GEN24 / GEN24 Plus / Tauro inverter, which answers by itself. It creates:
- one system device: the power flows of the whole site and the energy produced;
- one device per inverter: AC power, voltages and currents, energy of the day, state and error code;
- one device per meter (Fronius Smart Meter, S0 meter): power per phase, voltages, grid import and export counters;
- one device per battery (BYD Battery-Box, Fronius Solar Battery, Reserva…): charge level, stored energy, temperature.
It also adds a dashboard widget, three scene triggers (inverter in fault, battery full, battery empty) and feeds the energy tracking of Gladys with the grid import counter of the meter.
Requirements
- Gladys 5.1.0 or later.
- A Fronius Datamanager 1.0 / 2.0 (card or box), or a GEN24, GEN24 Plus or Tauro inverter, connected to the same network as Gladys (Ethernet or Wi-Fi).
- Its IP address, ideally fixed: give it a DHCP reservation in your router, otherwise the integration loses it when it changes.
- On a GEN24 / Tauro: the Solar API is off by default. Open the web interface of the inverter, go to Communication > Solar API and turn on Activate communication via Solar API. On a Datamanager the Solar API is on by default; if it was turned off, turn it back on in its web interface.
The old Fronius Datalogger Web (API v0) is not supported.
Configuration
Open Integrations > Fronius > Configuration:
| Field | What to enter |
|---|---|
| IP address | The IP address (or host name) of the Datamanager or of the GEN24 / Tauro inverter, e.g. 192.0.2.10. http:// is added for you; https:// works too (a GEN24 may redirect to it). |
| Refresh interval | How often the power flows are read: 10, 15 (default), 20, 30 or 60 seconds. Inverters, meters and batteries are read once a minute. |
| Language | Language of the names of new devices and features, and of the inverter state texts (French by default). |
| Battery full at (%) | Charge level of the Battery full trigger (100 by default). |
| Battery empty at (%) | Charge level of the Battery empty trigger (5 by default): usually the minimum reserve set on your inverter. |
Save: the connection status shows whether the system answers. Then open the Discovery tab and add the devices you want. Only the devices you add are refreshed.
Pace and load. Fronius sets no quota on its local API, but the Datamanager (2.0 especially) is slow: the integration sends one request at a time, reads the power flow (one light request) at the chosen interval, and inverters, meters and batteries once a minute, like Home Assistant. Nothing is read while no device is added (except, at most once per interval, for the widget).
Devices
Device names come from the system (inverter custom names, meter and battery models) and can be renamed in Gladys. The names of the features are given once, when the device is created, in the language of the configuration.
System
From GetPowerFlowRealtimeData. Every flow is positive, one feature per
direction, so a scene never has to deal with a sign:
| Feature | Meaning |
|---|---|
| Solar production | Power produced by the panels (W). |
| House consumption | Power consumed by the house (W). Needs a meter. |
| Grid import | Power taken from the grid (W). Needs a meter. |
| Grid export | Power fed into the grid, your surplus (W). Needs a meter. |
| Battery charging | Power going into the battery (W). With a battery only. |
| Battery discharging | Power coming out of the battery (W). With a battery only. |
| Production today | Energy produced since midnight (kWh). On a GEN24, which does not count it, see below. |
| Total production | Lifetime production counter (kWh). |
A GEN24 / Tauro only gives a lifetime counter: the integration counts the
production of the day from it, using a reading taken while the panels produce
nothing (before sunrise, or the evening before). The day the integration is
installed during the day, "Production today" stays empty until the next
morning: a partial count would be wrong. The count survives restarts (kept
in /data).
Inverters
From GetInverterRealtimeData: AC power (W), AC voltage (V), AC current (A),
DC voltage and current of each input in use (MPPT 1, 2…), production of the
day (kWh), State (Producing, Standby, Starting, Sleeping, Error…) and
Error code ("No error" or "Code 307"…). At night a Symo or a Primo sleeps:
its AC power is 0 W, the other values keep their last reading. The codes 306 and
307 shown at dusk (PV voltage too low) are normal.
Meters
From GetMeterRealtimeData. What a meter gives depends on where it sits:
- at the feed-in point (the usual Smart Meter): the grid exchange (positive when importing, negative when exporting), the power of each phase, the voltage of each phase, and two counters: Energy imported (meter) and Energy exported (meter), in kWh;
- on the consumption path: the house consumption (positive) and, for a three-phase meter, phases and voltages;
- elsewhere (sub-load, external generator): its power, as the meter signs it.
Batteries
From GetStorageRealtimeData: Charge level (%), Stored energy (kWh,
from the charge level and the usable capacity) and Cell temperature (°C).
The charge and discharge powers are on the system device; the usable capacity
shows in the widget.
Energy tracking
The Energy imported (meter) counter of the feed-in meter is published as an energy index: when you add the meter device, Gladys creates its "consumption" and "cost" features and computes the energy taken from the grid every half hour, with the cost of your contract (Energy settings of Gladys: choose this meter as the main electric meter if it is the one of your supply). It is what your supplier bills: the solar energy you consume yourself is free and is not in it.
The other counters never count as consumption: Energy exported is a grid export index, Total production a production index. Gladys 5.2.1 keeps their history but does not yet compute a production per half hour for an external integration: the graphs of the Energy screens show the consumption.
Widget
Edit a dashboard and add the Fronius widget. It shows, in one card:
- tiles Solar, House, From the grid, To the grid, Battery (charge level) and Today (production of the day), live;
- a graph of the production and consumption of the last 24 hours;
- a list: self-consumption and self-sufficiency (%), battery state and mode, state of each inverter, production of the year (Datamanager) and lifetime, time of the last reading.
The widget never makes the Datamanager work more: it shows the last reading. Tiles a system cannot measure (no meter, no battery) are left out.
Scene triggers
Under Integrations in the scene editor:
- Fronius inverter in fault: an inverter switched to the error state. Pick
an inverter or leave empty for any. Variables:
{{triggerEvent.data.inverter}}(name) and{{triggerEvent.data.error_code}}. Fires once per fault, at most every 10 minutes per inverter; the dusk codes (306, 307) are not faults. - Fronius battery full: the charge level reached the "full" level of the configuration. Fires again only after the level dropped 5 points.
- Fronius battery empty: the charge level fell to the "empty" level.
Fires again only after the level rose 5 points. Variables of both:
{{triggerEvent.data.battery}}and{{triggerEvent.data.level}}.
No trigger fires on the first reading after a start: only changes count.
A solar surplus needs no trigger of its own: use the trigger Device state change on the Grid export feature of the system device, with the threshold ("above 1500 W") and, if you want, a duration.
Action
Test the connection (Configuration tab) reads the whole system and lists what it found: Datamanager or GEN24, number of inverters, meters and batteries. The devices found are published in the Discovery tab.
Scene examples
- Use the surplus: Device state change — "Grid export" of the Fronius system above 1500 W for 10 minutes → turn on the water heater plug. A second scene turns it off when "Grid import" goes above 500 W.
- Be warned of a fault: Fronius inverter in fault → send a message "Inverter {{triggerEvent.data.inverter}} in fault, code {{triggerEvent.data.error_code}}".
- Battery full at noon: Fronius battery full → start the dishwasher plug, or the car charging station.
- Battery empty in the evening: Fronius battery empty → send a message, or lower the heating setpoint by one degree.
Troubleshooting
- "The Fronius system does not answer": check the IP address (it may have
changed: reserve it in your router), that Gladys and the Fronius system are
on the same network, and on a GEN24 that the Solar API is on
(Communication > Solar API). Test in a browser:
http://<ip>/solar_api/v1/GetPowerFlowRealtimeData.fcgimust show JSON. - A GEN24 redirects to https: since firmware 1.35.4-1. The integration follows the redirect and accepts the self-signed certificate of the inverter.
- No device in the Discovery tab: press Test the connection; its message says what the system answered.
- The values do not change: only the devices added to Gladys are
refreshed. Check the logs of the integration (Supervision), and set
LOG_LEVEL=debugto see each reading. - "Production today" is empty on a GEN24: normal the day of the installation (see System above); it starts the next morning.
- At night: inverters sleep (state Sleeping or Starting, 0 W); a Datamanager switched off at night is reported once in the logs and the devices show as unreachable until the morning.
- A device has new features after an update: Gladys proposes Update in the Discovery tab; the history is kept.
Limits
- Developed without the hardware (see the top of this page): real-life feedback is welcome.
- Read only: nothing is driven (no battery control, no power limit, no Modbus). An inverter or a battery is not something a scene should switch by mistake.
- One Fronius system per integration (one IP address). A Datamanager sees all the inverters of its Solar Net.
- No automatic discovery: the Datamanager and the GEN24 do not announce themselves in mDNS or SSDP (Home Assistant finds them by their MAC address in DHCP, which Gladys does not relay to an integration).
- No AC frequency (Gladys has no unit for hertz), no Ohmpilot, no reactive or apparent power.
- Self-consumption and self-sufficiency are shown in the widget only: Gladys has no feature type for an energy ratio.
- The counters of a meter on the consumption path are not published (their direction is not documented well enough to feed the energy tracking).
- The triggers fire on changes only, never on the first reading after a start.
Data and network
- The integration only talks to the address you entered, on your local network, over HTTP (or HTTPS for a GEN24 that redirects). No cloud, no account, no data sent outside.
- The Solar API has no password: the integration stores no secret. If an address with a user name and password is typed, they are dropped.
- It keeps two small files in its
/datavolume: the list of devices of your system (serial numbers, so the devices stay after a restart, even when the Datamanager is off) and, for a GEN24, the baseline of the production of the day.
Configuration settings
These are the settings Fronius asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Connect your Fronius system | section | No | Enter the IP address of the Fronius Datamanager (Symo, Primo, Eco, IG Plus) or of the GEN24 / Tauro inverter, as shown in your router or in the Fronius web interface. On a GEN24, enable the Solar API first: web interface, Communication > Solar API. Then open the Discovery tab. |
| IP address | string | Yes | Of the Datamanager, or of the GEN24 / Tauro inverter. A host name works too. |
| Refresh interval | select | No | How often the power flows are read. Inverters, meters and batteries are read once a minute. |
| Language of the device texts | select | No | Names given to new devices and features, and the inverter state texts. |
| Battery full at (%) | number | No | Charge level that fires the "Battery full" scene trigger. |
| Battery empty at (%) | number | No | Charge level that fires the "Battery empty" scene trigger: the reserve set on your inverter, usually. |
How to install Fronius in Gladys
- In Gladys, open Integrations: Fronius appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-fronius:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-fronius.
Fronius requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Fronius is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
