FoxESS smart home integration, free and open source
FoxESS inverters and batteries through the FoxESS Cloud: solar, house, grid and battery.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
FoxESS inverters and batteries (H1, H3, KH, AIO, T and F series…) in Gladys, through the official FoxESS Cloud Open API: solar production, house consumption, grid import and export, battery charge, inverter status and faults, on your dashboard and in your scenes.
This integration was developed without the hardware, from the Open API document and the open source projects that use it: feedback welcome. It is not affiliated with FoxESS.
What you get
- One device per inverter of your FoxESS Cloud account, read every 5 minutes by default.
- The energy flows: solar power (total and per PV string), house consumption, grid import and export, battery charging and discharging.
- The meters: production of the day, total production (the index Gladys' energy tracking reads), grid import and export meters, battery charge and discharge meters.
- The battery: charge level and temperature.
- The inverter: status (on grid, off grid, fault…), current alarm, online or not, temperature.
- A dashboard widget with the flows of one inverter, its battery and its work mode.
- A scene trigger when the inverter reports a new fault.
- Optional control (off by default): work mode and minimum battery charge, from scenes and the widget.
Prerequisites
- Gladys Assistant 5.1.0 or later.
- A FoxESS Cloud account (foxesscloud.com) where your inverter shows up: the same account as the FoxESS app.
- An API key for that account: on foxesscloud.com, open your profile (top right), User Profile, API Management, then Generate API key. Copy the long key it shows.
- The Gladys server needs internet access and a clock on time (the requests are signed with the time: a clock more than a minute off is refused).
Configuration
Install the integration (Integrations → Install from GitHub, or from the store), then fill in its configuration:
| Field | What to put |
|---|---|
| API key | The key generated in API Management. |
| Inverter serial numbers | Empty to show every inverter of the account, or the serial numbers to keep, separated by commas (FoxESS Cloud, Device, Inverter). |
| Refresh interval | 5 minutes (default) to 1 hour. The FoxESS Cloud updates its values about every 5 minutes: reading faster would only spend the quota. |
| Number of PV strings | 0 (default): one feature per string the inverter reports. Some models report 4 or 6 strings when 2 are wired: type 2 to keep strings 1 and 2. |
| Language of the feature names | The language of the feature names when an inverter is added (Gladys keeps them afterwards), and of the status texts. |
| Allow inverter control | Off by default. See Scene actions. |
Test the connection lists the inverters of the account and, when the cloud gives it, the number of API calls left today. Then open the Discovery tab and add your inverters.
The inverter device
| Feature | Type in Gladys | Unit | Notes |
|---|---|---|---|
| Solar power | Production power | W | All the PV strings together. |
| PV string | Production power | W | One per string: "PV string 1", "PV string 2"… |
| Production today | Daily production | kWh | Back to 0 at midnight (time of the installation). |
| Total production | Production index | kWh | Lifetime meter, for the energy tracking. |
| House consumption | Power | W | What the house draws, whatever the source. |
| Grid import | Grid import power | W | |
| Grid export | Grid export power | W | |
| Grid import meter | Grid import index | kWh | Lifetime meter of the inverter's grid meter. |
| Grid export meter | Grid export index | kWh | |
| Battery level | Battery level | % | Inverters with a battery only, like the next five. |
| Battery charging | Charge power | W | |
| Battery discharging | Discharge power | W | |
| Battery charge meter | Charge index | kWh | |
| Battery discharge meter | Discharge index | kWh | |
| Battery temperature | Temperature | °C | |
| Inverter temperature | Temperature | °C | |
| Inverter status | Text | Online, On grid, Off grid (backup), Fault, Offline… | |
| Inverter alarm | Text | The fault FoxESS reports, "None" otherwise. | |
| Online | State of input | 1 when the inverter talks to the FoxESS Cloud. |
An inverter the FoxESS Cloud reports offline (at night for an inverter without battery, or when its Wi-Fi dongle is down) only updates its status and "Online": the cloud would otherwise serve its last values as if they were live.
The total production is a cumulative production index for Gladys' energy tracking; its history is kept. Whether Gladys draws a 30-minute production from it depends on your Gladys version: 5.2.1 derives it automatically for consumption indexes only.
Dashboard widget
FoxESS solar shows, for the inverter chosen in its settings (the first one added when none is chosen):
- tiles for solar power, house consumption, battery level, grid import and export, production of the day — live, they follow the states;
- the inverter status, its current alarm, what the battery does (charging, discharging, idle), its minimum charge, the work mode and the time of the last reading;
- with inverter control allowed and a battery: three buttons Self-use, Feed-in first and Backup, each one asking for a confirmation. The current mode has a check mark. With the buttons there is room for four tiles: grid export and production of the day become status rows.
Scene trigger
Inverter fault fires when the inverter reports a fault it did not report at the previous reading (a new fault, or another one replacing it). Filter on one inverter or leave it empty for all. The Fault variable holds the description FoxESS gives (for example "Grid Lost Fault"). A fault already present when the integration starts does not fire it, nor does a fault that clears: the "Inverter alarm" feature then goes back to "None".
Scene actions
Both actions are refused while "Allow inverter control" is off, the default: a scene that changes how the battery is used should never run by accident. Turn it on in the configuration to use them. They need an inverter with a battery.
- Set the inverter work mode: Self-use (the battery covers the house first), Feed-in first (the solar goes to the grid first) or Backup (the battery is kept full for a power cut). Output: the mode applied.
- Set the minimum battery charge: the charge the battery keeps off grid and on grid, 10 to 100 %, the on-grid one not below the other. Outputs: both values applied.
These settings go through the official Open API (setting/set with the WorkMode key, and
battery/soc/set). When a schedule (time segments) is active in the FoxESS app, the inverter
refuses them: the action fails with "a schedule is active in the FoxESS app". The forced charge and
discharge windows of the FoxESS scheduler are not offered.
Scene examples
- Fault alert: trigger "Inverter fault", action "Send a message": "FoxESS: {{triggerEvent.data.fault}}".
- Storm coming: when the weather forecasts a storm, "Set the inverter work mode" to Backup; the next morning, back to Self-use.
- Use the surplus: when "Grid export" stays above 2,000 W for 15 minutes and "Battery level" is above 90 %, turn on the water heater.
API quota
The FoxESS Cloud allows 1,440 Open API calls a day (one a minute on average) and refuses bursts. The integration spaces its calls by one second at least and reads, per cycle:
- the real-time values of every added inverter, in one call;
- every 15 minutes at most: the inverter list (online, alarm, offline) and the production of the day of each inverter;
- every hour, for an inverter with a battery: its minimum charge and its work mode.
Calls a day for one inverter with a battery:
| Refresh interval | Calls a day |
|---|---|
| 5 minutes | 528 |
| 10 minutes | 384 |
| 15 minutes | 336 |
| 30 minutes | 192 |
| 1 hour | 120 |
Without battery, 48 fewer. Each more inverter adds 96 calls (its production) plus 48 with a battery. The quota is shared with every other tool using the same API key (Home Assistant, a script…): give each its own key, or slow down the refresh. When the cloud refuses a call for quota or burst, the readings pause for 30 minutes and the Configuration screen says so.
Troubleshooting
- "The FoxESS Cloud refused the API key": the key is invalid, or was deleted or regenerated. Generate a new one in API Management and paste it again. The readings pause an hour after a refusal, or until the configuration changes.
- "The FoxESS Cloud refused the request signature": the clock of the Gladys server is off by more than a minute. Set it on time (NTP).
- "FoxESS Cloud call limit reached": another tool uses the same key, or the refresh is too fast. See API quota.
- "Serial number(s) not on this account": check the serial numbers of the configuration against FoxESS Cloud, Device, Inverter, or leave the field empty.
- No PV string, or too many: the strings come from what the inverter reports; set "Number of PV strings", then "Update" the inverter in the Discovery tab.
- "No recent value" on a stable value: values that do not change are sent again every 6 hours, which is enough; an offline inverter keeps its last values.
- More detail: set
LOG_LEVEL=debugon the integration and read its logs. The API key never appears in them.
Limits
- Cloud only: no local (Modbus) access. For a local link,
foxess_modbusexists for Home Assistant; it is not part of this integration. - Not real time: the FoxESS Cloud updates every 5 minutes or so, a reading can be that old.
- Developed without the hardware: the answers of the API come from its documentation and from the projects that use it. Fields named differently on some models may be missing: tell us.
- The minimum charge and work mode are read once an hour: a change made in the FoxESS app shows in the widget within the hour.
- The forced charge or discharge windows and the scheduler of the FoxESS app are not offered; nor are the export limit or the battery heating.
- The house consumption index is not published (only its power): priced by the energy tracking, it would count self-consumed solar as bought from the grid.
- Not affiliated with FoxESS. FoxESS is a trademark of its owner.
Configuration settings
These are the settings FoxESS asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your FoxESS Cloud account | section | No | On foxesscloud.com, open your profile (top right), User Profile, API Management, then Generate API key. The FoxESS Cloud allows 1,440 API calls a day per inverter: keep the refresh at 5 minutes or more. |
| API key | secret | Yes | The key generated in API Management of your FoxESS Cloud profile. |
| Inverter serial numbers | string | No | Empty: every inverter of the account. Otherwise the serial numbers to show, separated by commas (Device, Inverter in FoxESS Cloud). |
| Refresh interval | select | No | The FoxESS Cloud itself updates its values about every 5 minutes. |
| Number of PV strings | number | No | 0: every string the inverter reports. Otherwise only strings 1 to this number get a feature. |
| Language of the feature names | select | No | Used when an inverter is added to Gladys, and for the status texts. |
| Inverter control | section | No | Off by default. When on, scenes and the dashboard widget can change the work mode and the minimum battery charge. A wrong setting can leave the battery empty during a power cut. |
| Allow inverter control | boolean | No |
How to install FoxESS in Gladys
- In Gladys, open Integrations: FoxESS appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-foxess:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-foxess.
FoxESS requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
