Foscam smart home integration, free and open source
Foscam IP cameras on your network: images, motion alarms, PTZ and presets.
Published by prohand
- Devices
- Version 0.0.1
- Requires Gladys >=5.1.0
- ★ 0
This integration connects Gladys to your Foscam IP cameras, directly on your local network: camera images, motion / person / sound alarms, motion detection on or off, night vision, and for motorized models, pan / tilt and saved positions.
It talks to each camera through its built-in HTTP API (the Foscam "CGI"). No Foscam cloud, no Foscam account, no internet connection is involved: the transport badge of every camera reads local.
Compatible cameras
The Foscam HD cameras, which all share the same API: FI98xx and FI99xx, R2 / R4 / R5, C1 / C2 / C5, G2 / G4, SD2 / SD4, X1 / X2 / X5 and most of the current indoor and outdoor models.
Not supported:
- the old MJPEG models (FI8xxx, port 80): their API is a different one;
- the models that only work through the Foscam app and cloud (some battery cameras): they do not answer on the local network.
When in doubt, the Test the connection button tells you within seconds whether a camera answers.
Before you start
- Give each camera a fixed IP address, in your router (DHCP reservation) or in the camera (Settings → Network → IP configuration). The integration keys every camera on its MAC address, so a new address does not lose the camera, but it must be typed again in the configuration.
- Note the HTTP port of the camera: Settings → Network → Port, the HTTP port. It is 88 out of the box.
- Create a dedicated user on each camera (Settings → System → Account
management), with the same name and password on every camera if you can:
- role administrator if you want to arm or disarm the motion detection and change the night vision from Gladys;
- role operator otherwise (images, alarms, PTZ).
- Set up the detection in the camera: Settings → Alarm → Motion detection (and Sound detection, Human detection on the models that have it). The camera decides what is a detection — zones, sensitivity, schedule; the integration reads its alarms.
Configuration
| Field | What to put in it |
|---|---|
| Cameras | The address of every camera, see below |
| Username | The camera user (admin by default) |
| Password | Its password |
| Image refresh (s) | Seconds between two images sent to Gladys, 60 by default, 5 minimum. 0 sends none on its own |
| Alarm check (s) | Seconds between two reads of the camera alarms, 2 by default |
| PTZ step (ms) | How long a pan or tilt lasts before the integration stops it, 800 by default, 5000 at most |
The camera list
Type the IP addresses, separated by commas (or semicolons, or one per line):
192.168.1.20, 192.168.1.21
Add :port when the HTTP port is not 88, and Name= in front to choose the
name of the camera in Gladys (otherwise the name stored in the camera is
used):
Entrance=192.168.1.20, Garden=192.168.1.21:8080
A camera that needs its own username or password, or whose capabilities must be forced, goes in a JSON list instead (the whole field is then that list):
[
{ "host": "192.168.1.20", "name": "Entrance" },
{ "host": "192.168.1.22", "port": 88, "name": "Garage", "username": "gladys", "password": "…" },
{ "host": "192.168.1.23", "name": "Living room", "ptz": true, "zoom": true }
]
| Key | Meaning |
|---|---|
host | IP address or host name (required) |
port | HTTP port, 88 by default |
name | Name in Gladys |
username | User of this camera, instead of the one of the configuration |
password | Its password. Prefer the Password field: this one is not hidden in the form |
ptz | true / false to force the pan and tilt controls (detected otherwise) |
zoom | true for the rare models with a motorized zoom: adds Zoom in / Zoom out to the controls |
An entry that cannot be read (a typo in the address, a port out of range, the same camera twice) is ignored, and Test the connection says which one and why.
In Gladys
A camera shows up in Discovery as soon as it has answered once. Its features (you can rename them in Gladys):
| Feature | What it does |
|---|---|
| Image | The camera image, refreshed every Image refresh seconds and whenever Gladys asks for one |
| Enabled in Gladys | Off: Gladys stops showing the camera, and the integration stops sending its images and detections |
| Motion | 1 while the camera reports motion (or a person), 0 otherwise |
| Motion detection | The motion detection of the camera, armed (1) or not (0). It can be switched from Gladys |
| Night vision | The infrared LEDs, on or off. Switching it from Gladys forces them; set_night_vision puts them back on auto |
| Move (motorized cameras) | Pan left / right, tilt up / down (and zoom, when declared) |
| Preset (motorized) | The positions saved in the camera, by name |
Enabled in Gladys is a Gladys-side privacy switch: the camera itself keeps running, recording to its SD card and sending its own notifications.
Images
Gladys takes images of 150 KB at most. A Foscam snapshot is a frame of the main stream (often 200 to 400 KB in 1080p): the integration scales it down before sending it, keeping the ratio.
Every detection also sends a fresh image right away, so that a scene sending the camera image on a detection sends the frame of that detection.
Motorized cameras
The Foscam API has no "one step" movement: a move runs until it is stopped. The integration therefore stops every move after PTZ step milliseconds (5 s at most), so that a lost stop never leaves the camera grinding against its end stop. Lengthen the step for a bigger movement.
The presets are read when the camera is discovered. After adding or renaming one in the camera, run a new scan in Discovery: the list is updated without re-creating the camera.
Test the connection
The Test the connection button of the Configuration screen asks every camera, right now, who it is. For each camera you get the model, the firmware and whether it is motorized — or the exact reason why it does not answer:
| Message | What to do |
|---|---|
| nothing answers at this address | Check the IP address and the HTTP port; the camera must be on the same network as Gladys |
| no answer in time | The camera is off, rebooting, or its Wi-Fi is too weak |
| wrong username or password | Check them on the camera. After a few failures the camera locks the account for a few minutes |
| this account is not allowed | Give the user the administrator or operator role |
| not a Foscam camera API | Something else answers on that port: check the HTTP port |
After a wrong password, the integration stops asking that camera for five minutes: insisting would get the account locked.
Scenes and dashboard (Gladys 5.1+)
Scene triggers
- Camera detection (
detection): a camera raised an alarm. Filter on the camera and on what was detected:motion,person,sound,io(the alarm input of the camera). The scene reads{{triggerEvent.data.kind}}and{{triggerEvent.data.camera_name}}. One event per alarm, never one per read. - Camera offline or back (
camera_connection): a camera stopped answering (three reads in a row, or a wrong password), or answers again. The scene reads{{triggerEvent.data.state}}(offline/online),{{triggerEvent.data.camera_name}}and{{triggerEvent.data.reason}}.
The Motion feature also drives the standard "device state" trigger of Gladys.
Scene actions
Each action answers an output the next actions can test; a camera that
cannot carry it out answers false instead of stopping the scene.
| Action | Fields | Output |
|---|---|---|
Take a camera snapshot (take_snapshot) | camera | captured |
Move camera to a preset (goto_preset) | camera, preset name | moved |
Arm or disarm motion detection (set_motion_detection) | camera, armed | applied |
Set night vision (set_night_vision) | camera, automatic / on / off | applied |
Reboot a camera (reboot_camera) | camera | rebooted |
take_snapshot followed by the Gladys action Send camera image sends a
picture taken at that very moment. Typical scenes: arm the motion detection
of every camera when the house is empty, send the camera to its door preset
when the doorbell rings.
Widgets
- Foscam camera: one camera, chosen in the widget settings: its last image, the live motion tile, connection, motion detection, night vision, last detection, and buttons to refresh the image and to arm or disarm the detection.
- Foscam cameras: every camera at a glance (online, offline, in alarm), with a button that refreshes every image.
Security
- The Foscam API takes the username and password in the address of every request, over plain HTTP: they cross your local network in clear. Use a dedicated user, not the camera's main account, and keep the cameras on a network you trust.
- Do not expose the cameras to the internet (port forwarding, UPnP): the integration does not need it. Turn UPnP and P2P off in the camera if you do not use the Foscam app.
- Keep the camera firmware up to date.
- The password is stored by Gladys in a secret field; the integration never writes it to its logs nor to its own files.
Troubleshooting
- The camera does not show up in Discovery: it has never answered. Run Test the connection.
- Motion stays at 0: the motion detection must be armed and configured in the camera (zones, schedule). The Motion detection feature tells whether it is armed.
- "Motion detection" cannot be switched: the user needs the administrator role.
- The image is late: lower Image refresh; Gladys takes 12 images a minute per camera at most, so 5 s is the floor.
- Detailed logs: they are in the integration logs (Gladys, Integrations, Foscam, logs).
Configuration settings
These are the settings Foscam asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Getting started | section | No | The integration talks to your Foscam cameras directly on your local network, through their HTTP API (CGI): no Foscam cloud, no account, no internet. Give each camera a fixed IP address in your router, then type those addresses below. Create a dedicated user on each camera (operator role) rather than using the admin account. |
| Cameras | string | Yes | IP addresses of your cameras, separated by commas. Add :port when it is not 88, and Name= in front to name a camera, e.g. Entrance=192.168.1.20, Garden=192.168.1.21:8080. A JSON array is accepted too, for a camera with its own credentials (see the documentation). |
| Username | string | Yes | User of the cameras (the same on every camera, unless set per camera in a JSON list). |
| Password | secret | No | Password of that user. Careful: after a few wrong passwords, a Foscam camera locks the account for a while. |
| Image refresh (s) | number | No | Seconds between two images sent to Gladys (5 minimum). 0 sends none: Gladys then asks for an image only when you open the camera. |
| Alarm check (s) | number | No | Seconds between two reads of the camera alarms (motion, person, sound). 2 catches every alarm. |
| PTZ step (ms) | number | No | Motorized cameras: how long a move lasts before the integration stops it, in milliseconds (5000 at most). |
How to install Foscam in Gladys
- In Gladys, open Integrations: Foscam appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/prohand/gladys-foscam:0.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/prohand/gladys-foscam.
Foscam requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
