Flo by Moen smart home integration, free and open source

Flo by Moen integration for Gladys Assistant

Unofficial: Flo by Moen water shutoff and leak sensors, flow, pressure, alerts, Home/Away.

View on GitHubAll integrations

This integration brings the Flo by Moen Smart Water Shutoff and the Flo Water Sensors into Gladys, through the Flo cloud the Moen Smartwater app (formerly Flo) uses, with the e-mail and password of your account. These products are sold in the United States and Canada. Unofficial, not affiliated with Moen or Fortune Brands.

Development version (0.1). Written from the Python library aioflo (the one of the Home Assistant Flo integration). The integration has never been tested on a real device or a real account: only against simulated answers. Feedback is welcome on the GitHub repository.

What you get​

Flo deviceIn Gladys
Smart Water Shutoff (valve)valve open/closed and away mode (settable, see "Safety"), mode (text: home, away, sleep), flow m³/h, pressure psi, water temperature °C, today's use in litres, leak alert, pending alerts (text)
Water Sensor (leak sensor)water leak, temperature °C, humidity %, battery %

Other Flo devices (bridge…) are skipped: the Test the connection button counts them.

Units: the flow is converted from gallons per minute to m³/h, the use from gallons to litres, temperatures from °F to °C (Gladys shows them as you prefer). The pressure stays in psi. A shutoff without a water temperature probe sends a placeholder (225 °F): it is ignored.

Installation​

  1. Install the integration from the Gladys store.
  2. In the Configuration tab, enter the e-mail and password of your Flo or Moen Smartwater account, then save. The status reads "Connected to Flo: 2 devices."
  3. Open the Discovery tab and add the devices you want. Their values arrive as soon as they are added.

Sign-in: "Automatic" (default) tries the historical Flo sign-in, then the Moen one (newer Moen Smartwater accounts) when Flo refuses or no longer answers there. Once Flo refused, only Moen is tried until the configuration changes. You can force either.

Safety: commands off by default​

These commands are refused until you allow them in the configuration:

OptionDefaultOff: Gladys…
Allow closing the valvenonever shuts the water off
Allow opening the valvenonever turns the water on
Allow changing the Home/Away modenonever changes the Flo mode

To shut the water off from a scene when a leak is detected, turn on "Allow closing the valve". Even allowed, a valve command:

  • runs one at a time for a device (two "close" at once are never sent together);
  • reads the device from Flo just before acting: if that read fails, the device is offline, or the valve is moving the other way or in an unknown state, the command is refused; the state kept in memory never decides;
  • sends nothing when the valve is already where asked, or already moving there;
  • is refused rather than sent late when it could not leave in time (3.5 seconds after the request from the dashboard, 25 seconds for a scene action): Gladys would already have shown a failure;
  • reads the device again 15 seconds and 60 seconds later (even after a failure), to show the real position.

Warning: as soon as a valve option is on, the valve is a Gladys switch like any other. A voice assistant, a "turn everything off" command or a scene acting on every switch can then shut (or open) the water. Check your scenes and assistants before turning these options on.

Home / Away mode (the "Away mode" switch or a scene action): off by default. Switching to Home disarms the automatic shutoff Flo applies in Away: turn the option on knowingly. Sleep needs a duration: it is shown, but set in the Moen app. A mode Flo has locked is refused.

Scenes​

Triggers:

  • Flo: leak detected: a Water Sensor detects water, or Flo raises a new critical or warning leak alert (water detected, drip, failed health test); filtered by severity;
  • Flo: abnormal flow: a new critical or warning fast flow, long flow or high use alert;
  • Flo: new alert: any new alert, filtered by severity and family.

A trigger fires once per new alert, at the refresh that finds it (an alert still pending does not fire again). What the integration saw last is kept in /data: an alert raised during a restart fires at the next start. The alerts of a device never seen before do not fire (nothing says they are new).

The family of an alert (leak, flow, other) comes from its name in the Flo alarm catalog, read once a day, matched against a list of known names. When the catalog is unavailable (or an alert is not in it), the alert is "other": only "new alert" fires, and, by caution, an unknown critical alert turns "Leak alert" on. The "Pending alerts" feature always lists every alert.

Recommended to shut the water off: besides "leak detected", make a scene on the "device state changed" trigger of the Water leak feature of the Water Sensor (or Leak alert of the shutoff) going to 1. That state is read again at every refresh, even if a scene event was missed.

Actions: Flo: set Home or Away (one home or all) and Flo: open or close the valve, behind the options above.

Usage limits​

  • Flo publishes no API limit. The integration reads the account and each device every 2 minutes by default (1 to 60), today's use every 15 minutes and the alarm catalog once a day: Home Assistant's pace (1 minute) or slower.
  • When Flo answers "too many requests" (429), the integration pauses for the time asked (1 minute to 1 hour, 5 minutes when not given). After a network error or a Flo outage it tries again after 1, 2, 5, 10 then 15 minutes.
  • A refused e-mail or password is never retried by itself: the integration waits for a change or a click on Test the connection.
  • Values arrive at the refresh pace, not in real time.
  • Gladys accepts 300 states a minute: only the values that change are sent (and every value at least every 30 minutes).

Options​

OptionDefaultRole
E-mail, password—your Flo / Moen Smartwater account
Allow closing the valvenosee "Safety"
Allow opening the valvenosee "Safety"
Allow changing the Home/Away modenosee "Safety"
Sign-inAutomaticFlo then Moen, or either one
Refresh interval (min)2how often the devices are read
Language of the feature namesFrenchnames of the features of the devices added

Troubleshooting​

  • "Flo refused the e-mail or the password": check them in the Moen Smartwater app. Try the "Moen" sign-in if your account was made in the Moen app.
  • "Flo cannot be reached": a Flo outage or your connection; the integration tries again by itself.
  • unreachable badge with an orange dot: Flo reports the device offline (Wi-Fi, sensor batteries).
  • "The state of the Flo valve could not be confirmed": the valve was offline, moving or unreadable when the command came; try again later.
  • "The command waited too long for its turn": Flo answered slowly; try again.

Privacy​

The e-mail and password are kept by Gladys in its database (and so in its backups); the password is never shown again in the interface. They are only sent to the Flo sign-in (api.meetflo.com) and the Moen one (Amazon Cognito, execute-api.us-east-2.amazonaws.com), over HTTPS. The token stays in memory and never reaches a log. The only file written to /data (flo-seen.json) holds the alert counts and the "water detected" state of each device, no secret.

Flo by Moen and Moen are trademarks of Moen Incorporated (Fortune Brands); this integration is not affiliated with Moen.

Configuration settings​

These are the settings Flo by Moen asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Flo by Moen accountsectionNoBrings the Flo by Moen Smart Water Shutoff (flow, pressure, water temperature, today's use, valve, Home/Away mode, alerts) and the Flo Water Sensors (leak, temperature, humidity, battery) into Gladys, through the Flo cloud the Moen Smartwater app uses (US and Canada products). Enter the e-mail and password of your Flo or Moen account. Scene triggers fire on new leak and abnormal flow alerts. Opening or closing the valve and changing the mode stay off until you allow them below. Unofficial, not affiliated with Moen or Fortune Brands; never tested on a real device yet.
E-mail of the Flo accountstringYes
PasswordsecretYesKept by Gladys in its database, never shown again, sent only to Flo/Moen (HTTPS).
Allow closing the valve from GladysbooleanNoOff by default. Turn it on to shut the water off from a scene when a leak is detected.
Allow opening the valve from GladysbooleanNoOff by default: reopening the water after a leak should be done on site.
Allow changing the Home/Away mode from GladysbooleanNoOff by default. Warning: Home disarms the automatic shutoff Flo applies in Away.
Sign-inselectNoAutomatic tries the Flo sign-in, then the Moen one (the newer Moen Smartwater accounts).
Refresh interval (min)numberNoHow often every device is read, in minutes (1 to 60). Today's use is read every 15 minutes.
Language of the feature namesselectNoUsed for the names of the features of the devices added from now on.

How to install Flo by Moen in Gladys​

  1. In Gladys, open Integrations: Flo by Moen appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/lm1lc3n7/gladys-flo:0.1.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/LM1LC3N7/gladys-flo.

Flo by Moen requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Flo by Moen is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by LM1LC3N7, not by the Gladys core team.
