This integration brings evcc into Gladys. evcc controls the charging of electric vehicles with solar surplus, dynamic tariffs or a charging plan. Gladys follows evcc live (solar production, home, grid, battery, loadpoints, vehicles), changes the charging mode and the limits, and runs scenes when a vehicle is plugged in or a charge finishes.
The integration talks to evcc on your local network, without any cloud. It was developed and tested against evcc's demo mode (versions 0.210 and 0.317), without a real charger: feedback welcome.
Requirements
- Gladys Assistant 5.1 or newer.
- evcc running on your network (Raspberry Pi, Docker, Home Assistant…), version 0.200 or newer recommended. Older versions are read as well as possible.
- The address of evcc, as you open it in your browser, for example
http://192.168.1.20:7070. Gladys must be able to reach it.
Configuration
- Integrations → evcc, then Configuration.
- evcc address: the address of its web interface. Without a port, 7070 is used. Behind a
reverse proxy, a path is allowed (
https://example.org/evcc). - Admin password: optional. Recent evcc versions change the mode and the limits without it. If your evcc (or your proxy) answers "unauthorized", enter it.
- Language of the feature names: French by default. The names are frozen when you add the device.
- Save, then click Test the connection: the evcc version and the number of loadpoints and vehicles are shown.
- In the Discover tab, add the devices you want.
The integration follows evcc through its websocket: values arrive at every evcc cycle (30 s by default). If the websocket drops, it reads the state every 30 s and reconnects by itself.
The devices
Site
One device named after your evcc site, with what evcc measures:
| Feature | Detail |
|---|---|
| Solar production | W, if evcc has a PV meter |
| Home consumption | W |
| Grid | W, positive when the house imports, negative when it exports |
| Home battery | level in %, charging and discharging power in W, if there is a battery |
| Grid price | current price of a kWh, if a tariff is configured in evcc |
Loadpoint
One device per evcc loadpoint:
| Feature | Detail |
|---|---|
| Mode | controllable: Off, Solar, Min + solar, Fast |
| Charging state | charging, plugged in, waiting (evcc waits for the sun or a slot), paused (vehicle full), idle |
| Vehicle plugged in | yes or no |
| Charging power | kW |
| Charging current | A |
| Session energy | kWh charged since plugging in |
| Time remaining | minutes, evcc's estimate while charging |
| Charge limit | controllable: battery level aimed at for this session, in % |
| Vehicle | name of the vehicle evcc identified |
| Cheap grid charging | evcc charges because the grid is cheap (dynamic tariff) |
| Charger meter | index in kWh, if the charger has a meter: Gladys derives its consumption and cost in the energy monitoring |
Since evcc 0.317, the "Solar" mode is called Smart in evcc, and "Min + solar" is Smart with the Always charge option. The integration keeps the four historical modes, understood by every evcc version.
An integrated device (heat pump, socket switched by evcc) only has the mode, the state, the power, the energy and the meter.
Vehicle
One device per vehicle configured in evcc:
| Feature | Detail |
|---|---|
| Battery level | %, known while the vehicle is plugged in (the last value stays) |
| Range | km, likewise |
| Charge limit | controllable: maximum battery level of the vehicle in evcc, in % |
| Plugged in | the vehicle is plugged into a loadpoint |
| Charging plan | the next plan (level and time), or "No plan" |
Dashboard widget
The evcc widget shows the energy flow (solar, home, grid in kW), the home battery, the grid price and one row per loadpoint (state, power, mode). Four buttons change the mode of a loadpoint: the one chosen in the widget settings, otherwise the first one. The current mode carries a check mark. If evcc stops answering, the widget shows the last known values, without buttons.
Scene triggers
| Trigger | When | Variables |
|---|---|---|
| Vehicle plugged in | a vehicle is plugged in, once evcc identified it (2 minutes at most) | loadpoint, vehicle |
| Vehicle unplugged | a vehicle is unplugged | loadpoint, vehicle, energy charged (kWh), time plugged in (minutes) |
| Charging started | a charge starts; a short pause (clouds) is not a new charge | loadpoint, vehicle, mode |
| Charging finished | the charge stopped for 10 minutes, or the vehicle was unplugged | loadpoint, vehicle, energy (kWh), charging time (minutes), solar share (%) |
| Charging mode changed | the mode of a loadpoint changes, in evcc or from Gladys | loadpoint, new mode, previous mode |
In a message, a variable is written {{triggerEvent.data.vehicle}}, {{triggerEvent.data.energy_kwh}}…
Each trigger can be limited to a loadpoint and, except the mode change, to a vehicle. The mode change can be limited to one mode.
Scene actions
| Action | Effect |
|---|---|
| Set the charging mode | Off, Solar, Min + solar or Fast on a loadpoint |
| Set a charge limit | battery level (%) of a loadpoint or a vehicle, or energy (kWh) of a loadpoint; 0 removes the limit |
A refused action (evcc unreachable, value out of range, a device that is not a loadpoint) fails with a clear message, and the scene goes on.
Scene examples
- Fast charge in the evening if the battery is low: at 9 pm, if the battery level of the vehicle is below 30 %, set the mode of the loadpoint to Fast, then set the limit to 60 %.
- Know when the car is full: trigger "Charging finished" on your vehicle, send "Charge
finished:
{{triggerEvent.data.energy_kwh}}kWh,{{triggerEvent.data.solar_percent}}% solar". - Back to solar when leaving: trigger "Vehicle unplugged", set the mode to Solar so that the next charge starts on the surplus again.
Troubleshooting
- "evcc does not answer at the configured address": open the address in a browser from the network of Gladys. Check the port (7070 by default) and that no firewall blocks Gladys.
- "The configured address does not answer like evcc": the address points to another service, or a proxy returns an error page.
- "evcc asks for its admin password": enter it in the configuration.
- The battery level of a vehicle does not move: evcc only reads the vehicle while it is plugged in (or if it has a car maker integration). The last value stays shown.
- "Vehicle plugged in" comes with an empty vehicle: evcc did not identify the vehicle within 2 minutes. Check the identification in evcc, or set a default vehicle on the loadpoint.
- Detailed logs: add the variable
LOG_LEVEL=debugto the container.
Limitations
- One evcc instance per installation of the integration.
- Charging plans are read but not created from Gladys (use evcc).
- Repeating plans (every weekday) are not shown.
- The number of phases, the minimum and maximum current, the home battery and the advanced settings stay in evcc.
- Developed without a real charger, against evcc's demo mode: feedback welcome on the Gladys forum.
- Independent project, not affiliated with evcc.
Configuration settings
These are the settings evcc asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Connect your evcc | section | No | Enter the address of evcc as you open it in your browser (port 7070 by default). The integration follows evcc live through its websocket. The admin password is only needed if your evcc asks for it to change a mode or a limit. |
| evcc address | string | Yes | Without a port, 7070 is used. A path is allowed behind a reverse proxy. |
| Admin password (optional) | secret | No | Recent evcc versions change modes and limits without it. |
| Language of the feature names | select | No |
How to install evcc in Gladys
- In Gladys, open Integrations: evcc appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-evcc:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-evcc.
evcc requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
