Emporia Vue smart home integration, free and open source
Emporia Vue energy monitors, smart outlets and EV chargers: power and energy per circuit.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Overview
This integration brings the Emporia Vue energy monitors (Vue 2, Vue 3 and their circuit sensors), the Emporia smart outlets and the Emporia EV chargers into Gladys, through the Emporia cloud — the same account as the Emporia Energy app.
- Power of the whole home and of every circuit (up to 16 per Vue), refreshed every minute.
- Cumulative energy indexes (kWh), total and per circuit, which Gladys turns into 30-minute consumption and cost in its energy tracking.
- Solar production and grid export when the Vue is set up for solar.
- Outlets: on/off, power, energy. Chargers: connector and charging state, power, energy, and — only if you allow it — on/off and target current.
- A dashboard widget, a scene trigger and a scene action.
Developed without the hardware: feedback welcome. Not affiliated with Emporia Energy.
Requirements
- Gladys Assistant 5.1.0 or later (energy contracts and pricing come with Gladys 5.2).
- An Emporia account with an email and password, whose devices are set up in the Emporia Energy app. Accounts signed in with Google or Apple, and accounts with multi-factor authentication (MFA), are not supported.
- Internet access from Gladys: everything goes through the Emporia cloud, there is no local API.
Configuration
- In Gladys, open Integrations → Install from GitHub and install
https://github.com/guim31/gladys-emporia, or find Emporia Vue in the catalog. - Fill in the email and password of your Emporia account and save. The status turns to connected once Emporia accepts them.
- Language of the feature names: French by default; names are fixed when a device is added.
- Allow controlling the EV chargers: off by default (see below).
- Open the Discovery tab and add the devices you want. Nothing is read from Emporia for a device you have not added.
The password stays in the Gladys configuration; the sign-in tokens are kept in the integration's
/data volume so that a restart does not sign in again.
Devices
Emporia Vue
One Gladys device per Vue, named as in the Emporia app.
| Feature | Type | Unit |
|---|---|---|
| Total power | energy-sensor / power | W |
| Total index | energy-sensor / index | kWh |
| Circuit – power (one per circuit) | energy-sensor / power | W |
| Circuit – index (one per circuit) | energy-sensor / index | kWh |
| Unmonitored power | energy-sensor / power (signed) | W |
| Grid power (solar Vue) | grid-sensor / power (signed) | W |
| Grid import index (solar Vue) | energy-sensor / index | kWh |
| Grid export index (solar Vue) | grid-sensor / output-index | kWh |
| Circuit – production (solar) | energy-production-sensor / power | W |
| Circuit – production index | energy-production-sensor / index | kWh |
Circuits take the names given in the Emporia app; an unnamed circuit is called "Circuit n", and two circuits with the same name get their number. Unmonitored power is what the circuit sensors do not see (mains minus circuits).
Outlets
On/off (controllable), power (W) and energy index (kWh).
EV chargers
| Feature | Values |
|---|---|
| Connector | available, occupied (vehicle plugged in), unavailable, faulted |
| Charging state | charging, vehicle connected, paused by the vehicle or by the charger |
| Charger enabled | on/off |
| Target current | 6 A to the charger maximum |
| Charging power | W |
| Index | kWh |
Charger control is off by default: Charger enabled and Target current are read-only, and a command is refused. Turn on Allow controlling the EV chargers in the configuration, then use Update in the Discovery tab, to make them controllable. A wrong command could stop a charge you need in the morning: think twice before automating it.
Energy tracking and the sign of values
Emporia gives the energy of a period, not a meter index. The integration builds the index
itself: the sum of the completed days, read back from Emporia at the very end of each day, plus
the energy of today so far. The index therefore matches the Emporia app, never goes back, and
catches up the days missed while Gladys was stopped (31 days at most). It is updated every 5
minutes; it is kept in /data/energy.json.
Gladys derives the 30-minute consumption and the cost from every index (Gladys 5.x energy tracking). In the energy settings, choose the Total index (or the Grid import index of a solar Vue) as the main meter; the circuit, outlet and charger indexes become sub-meters. An outlet or a charger plugged on a monitored circuit is counted inside that circuit too: arrange the hierarchy to avoid counting it twice.
Sign conventions:
- Emporia reports generation as negative. A circuit of type Solar/Generation is published as a positive production (power and production index).
- On a solar Vue, the mains is the net exchange with the grid: Grid power is positive when importing and negative when exporting. The consumption index then comes from the grid import channel and the export from the grid export channel, when Emporia provides them.
- A bidirectional circuit (a battery…) keeps its sign and gets no index, since its daily total can be negative. So does Unmonitored power.
- Any other circuit is published as a positive value, as the Emporia app shows it.
Widget
Emporia power shows the total power of a Vue (live), its solar production when it has some, and the five circuits drawing the most right now, with their share of the total (not on a solar Vue, whose mains is a net exchange). Pick the Vue in the widget settings; empty, it shows the first Vue added to Gladys.
Scene trigger
Emporia device offline or back: a Vue, an outlet or a charger lost (or found back) its link to the Emporia cloud. While offline, its readings stop: nothing else in Gladys tells you. Filters: the device, and the change (goes offline / comes back online). Variables: device name, new status.
Scene action
Emporia energy of the day: for a chosen device, returns the energy taken from the grid today (kWh), the solar production today (kWh), the circuit that used the most today and its energy, and the current power (W). The values come from the latest readings (5 minutes at most).
The configuration also has a List my Emporia devices button, which shows what the account holds (Vues with their number of circuits, outlets, chargers).
Scene examples
- Evening report: every day at 21:00 → Emporia energy of the day on the Vue → send a message "Today: {{energy_today_kwh}} kWh from the grid, {{production_today_kwh}} kWh of solar; first: {{top_circuit}} ({{top_circuit_kwh}} kWh)".
- Forgotten appliance: when Oven – power stays above 1500 W and nobody is home → notify.
- Blind monitoring: when the Vue goes offline → send a message "The Emporia Vue no longer reports, check its Wi-Fi".
- Solar surplus: when Grid power goes below −1500 W (exporting) → turn on the water heater outlet.
Refresh and Emporia API usage
The Emporia API is not public and has no published quota; the integration stays close to what the Emporia app and the Home Assistant integration do:
- every minute, one request for the power of all the channels of all devices
(
getDeviceListUsages, 1-minute average) and one for the outlets, chargers and connectivity; - every 5 minutes, one request for the energy of the day (and one per completed day to close);
- every hour, the device list (names, circuits).
Nothing is read while no Emporia device is added to Gladys. Only changed values are sent to Gladys, plus an unchanged value every 6 hours so that it never looks stale. A refused password is never retried on its own, to avoid locking the account.
Troubleshooting
- "Emporia refused this email or password": check them in the Emporia app, then save the configuration again (that is what retries).
- "Your Emporia account asks for a step…": MFA or a forced password change. Sign in once in the Emporia app; MFA accounts cannot be used.
- "The Emporia cloud does not answer": the integration retries every minute and says when it works again; check Gladys's Internet access, and Emporia's status in its app.
- A circuit shows no value: Emporia sends no reading for an unused sensor. Name and set up the circuit in the Emporia app.
- Names in the wrong language: change the language, then delete and add the device again (names are fixed at creation).
- Logs: the integration page shows them; set
LOG_LEVEL=debugfor every cycle in detail.
Limitations
- Developed without the hardware nor an Emporia account: tested against the published API behaviour (PyEmVue and its simulator), not against real devices. Feedback welcome.
- Cloud only: no reading while Internet or the Emporia cloud is down. The minute power is a 1-minute average, not an instant value.
- The index is updated every 5 minutes, not read during the first 30 minutes after midnight (the Emporia API may still answer the previous day), and a stop of more than 31 days loses the days before.
- On a solar Vue whose grid import channel Emporia does not provide, there is no consumption index for the whole home (circuits keep theirs).
- Accounts using Google, Apple or MFA sign-in are not supported. Emporia batteries, thermostats and vehicles are not supported.
- Not affiliated with Emporia Energy; "Emporia" and "Vue" are their trademarks.
Configuration settings
These are the settings Emporia Vue asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your Emporia account | section | No | Use the email and password of the Emporia Energy app. The integration reads the Emporia cloud once a minute. Accounts signed in with Google or Apple, or protected by MFA, are not supported. Not affiliated with Emporia Energy. |
string | Yes | ||
| Password | secret | Yes | |
| Language of the feature names | select | No | Names are fixed when a device is added to Gladys. |
| Allow controlling the EV chargers | boolean | No | Off: chargers are read-only. On: Gladys can switch them and set the target current (6 A minimum). |
How to install Emporia Vue in Gladys
- In Gladys, open Integrations: Emporia Vue appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-emporia:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-emporia.
Emporia Vue requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
