ecoNET300 integration for Gladys Assistant

Pellet boilers with a Plum ecoMAX via the local ecoNET300: temperatures, alarms, optional commands.

View on GitHubAll integrations

This integration shows in Gladys a pellet boiler run by a Plum ecoMAX controller (Kostrzewa, Hydro-Vacuum, Pereko and other makers), through the local API of its ecoNET300 network module, on your network, without econet24.com.

Never tested with a real module: Plum does not document the local API; the integration follows ecoNET-300-Home-Assistant-Integration (the project Home Assistant users run) and its captures of real modules. Not affiliated with Plum nor with the boiler makers. Your feedback is welcome.

What you get​

One Gladys device per ecoNET300 module, read every 60 s by default:

  • temperatures: boiler, hot water, outdoor, flue gas, feeder, return, buffer tank (top and bottom), mixing circuits 1 to 4;
  • boiler and hot water setpoints;
  • operating state (Off, Firing up, Operation, Supervision, Burning off, Alarm...) and the boiler on/off;
  • fuel level (%);
  • alarms running (the name of the best known ones, the code of the others);
  • link status ("OK", "ecoNET300 unreachable", a stop from Gladys under way...).

A feature appears as soon as the controller gives its value (a sensor not fitted creates none) and never disappears afterwards.

Setup​

  1. Find the address of the ecoNET300 on your network (in your router, or on the screen of the controller), for example 192.168.1.50. Reserve it if you can (DHCP reservation).
  2. In Gladys, open the configuration of the integration and enter the address (with :port if not 80), the local user name and password of the module (those of its local web interface, not those of your econet24.com account). A password without a user name is refused.
  3. Save, then add the device from the Discovery tab.

The password is kept by Gladys in its database, never shown again, and sent only to the ecoNET300 (HTTP Basic, plain http on your network; https is not supported in this version).

The Test the connection button reads the module once, but never sooner than the refresh interval after the previous read.

Commands​

By default Gladys only reads. The option Allow "On" and the setpoints (off by default) lets the dashboard, the scenes and the voice assistants:

  • switch the boiler On;
  • change the boiler setpoint, within the bounds the controller gives (those of the last read when less than two intervals old, else read again before the write) and between 20 and 90 °C;
  • change the hot water setpoint, in whole degrees, within the bounds of the controller, between 20 °C and the configured ceiling: 65 °C by default, 40 to 65 °C, never more than 65 °C whatever is typed or the controller allows (scalding risk).

They are neither switches nor binaries: a "turn everything off" of a scene or a voice assistant does not reach the boiler.

Each command first reads the module again (its identity and its values) and decides on that read, never on the values kept in memory; commands arriving together (a scene) share that read and the read that confirms them, then leave one by one. A command leaves 3.5 s after the click at the latest, else it is refused with nothing sent ("not sent in time" when the commands before it took the time). It is reported successful only when a read made after it, before 4.3 s, shows the value asked; otherwise Gladys shows "sent and accepted, not applied yet" (or "sent, without confirmation" when the module did not answer), and the follow-up reads, 5 s and 20 s later, publish the value as soon as it shows. Beyond 4 commands waiting, they are refused. An HTTP 401/403 refusing a command concerns it only: the reads go on.

A setpoint is refused while a stop sent from Gladys holds (see below): switch the boiler "On" first. When /data cannot be read, "On" and the setpoints are refused (a stop kept there would be unknown).

The stop​

"Off" (the boiler stopped, BOILER_CONTROL=0) needs no option. It leaves without waiting for a read, ahead of any other request: a read under way is cut, the commands not sent yet are cancelled (nothing asked before the stop leaves after it). Neither the option, nor the bounds, nor a pause asked by the module (HTTP 429/5xx), nor a password refused before (one try), nor an unreadable /data, nor a device not read yet holds it.

It is refused in these two cases only:

  • the configuration of the integration is not valid, or could not be read yet since the integration started (without an address and a password, nothing can leave);
  • the last read showed another ecoNET300 at this address (a different identifier).

When it cannot leave (module unreachable, an outage), it is tried again for 250 ms, then kept in /data and sent again first thing at each next read, without limit, until it leaves: it goes at the first read that reaches the module (after a pause asked by the module, or new credentials when they were refused, as the reads wait then), and as soon as the integration restarts or the configuration changes. It is never sent again to another ecoNET300 read at the address. When the module refuses it with HTTP 401/403 while it accepts the reads, it is sent again twice at most, then the status says so; a refusal due to the credentials (the reads refused too) does not count, and other credentials reset the count. When it leaves without an answer, Gladys shows "stop sent, without confirmation". When the module answers something other than "OK", Gladys shows it and it is not sent again.

It is reported successful when a read made after it shows the boiler off, or burning off while it was read running just before the stop left (a read less than two intervals old) or since: the stop is then taken. A pellet boiler takes several minutes to go out; the select shows "Off" while it burns off. Once the stop is taken, nothing is sent again. If a read made after the stop shows the boiler running while the stop has not been seen taken yet, the stop is sent again, 3 times at most.

When the state before is unknown (module unreachable, the integration restarted, credentials refused or the last read too old when the stop left) and the first read after it already shows burning off, nothing proves the stop was taken (it may be a normal extinction): if the boiler is then read running, that does not count as started elsewhere, and the stop is sent again. A start on the panel during that extinction may therefore be contradicted; once burning off follows a running state read, the stop is taken and a new start is not contradicted any more.

The stop from Gladys is kept in /data, with no time limit. It is lifted only by a click on "On" (with the option), or when, once the stop is taken, the boiler is read running (firing up, operation, supervision..., not an alarm nor a service mode) twice in a row (started again on the panel or from the app).

Status and errors​

  • User name or password refused (HTTP 401/403 of a read): the reads stop, no automatic retry; save other credentials or use "Test the connection".
  • The module asks to slow down (HTTP 429 or 5xx): a pause of 1 min to 6 h, kept in /data, for everything but the stop.
  • Module unreachable: tried again after 1, 2, 5 then 10 min, never sooner than the interval; the last values stay shown, the link status says so.
  • Another ecoNET300 answers at the address: its values never go to the created device; it shows as a new device in Discovery.
  • Bounds not read: some modules do not give the bounds of the setpoints (rmCurrentDataParamsEdits); the reads go on, the setpoints are refused.

The identity of the device is a print of the identifier (uid) of the module; the identifier itself, the econet24.com key and the Wi-Fi name the module gives are never published nor kept.

What /data keeps​

econet300-state.json: a pause under way, a refusal of the credentials (with 8 bits of a salted print, enough to tell whether they changed, not enough to find a password), the time of the last read (a restart never reads sooner than the interval), the stop sent from Gladys. No secret.

Known limits​

  • Only the controllers giving their values in regParams are read (in the captures of the reference: ecoMAX810P-L, ecoMAX850R2-X, ecoMAX860P2-N, ecoMAX860P3-V; other ecoMAX860 and 920, the ecoMAX360i, the ecoSOL give nothing there); the others only show their alarms: the link status says so.
  • Summer/winter mode, mixing circuit setpoints, burner output, pumps: not in this version.
  • Slow module, measured on a local server: a scene "On" + two setpoints is sent and confirmed up to 700 ms per request; at 900 ms the first two leave and are confirmed by the follow-up reads ("not applied yet" on screen), the third is refused with nothing sent ("not sent in time"). A setpoint alone is confirmed up to 900 ms.

Credits​

The local protocol is ported from ecoNET-300-Home-Assistant-Integration (jontofront and contributors, MIT License); see THIRD_PARTY_NOTICES.md.

Configuration settings​

These are the settings ecoNET300 asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your ecoNET300 modulesectionNoShows a pellet boiler run by a Plum ecoMAX controller (Kostrzewa, Hydro-Vacuum, Pereko and others) in Gladys, through the local API of its ecoNET300 network module: temperatures, setpoints, operating state, fuel level, alarms, and optionally the boiler on/off and the setpoints. Enter the address of the module on your network, its local user name and password (those of the module, not of econet24.com), save, then add the device from the Discovery tab. Never tested with a real module. Not affiliated with Plum.
Address of the ecoNET300stringYesIts IPv4 address or host name on your network, with a port if not 80 (plain http, as the module answers).
Local user name of the modulestringYes
Local password of the modulesecretYesKept by Gladys in its database, never shown again, sent only to the ecoNET300 at the address above (HTTP Basic, on your network).
CommandssectionNoBy default Gladys only reads. Once allowed, the dashboard, the scenes and the voice assistants can switch the boiler on and change the boiler and hot water setpoints, always within the bounds the controller gives and those below. "Off" needs no option: it stops the boiler; the guide lists the cases where it is still refused.
Allow "On" and the setpointsbooleanNoOff by default. Off: the boiler on and every setpoint change are refused. "Off" (boiler stopped) is never refused for this reason.
Hot water setpoint ceiling (°C)numberNoGladys never sets the hot water above this temperature (scalding risk). 65 °C by default, from 40 to 65 °C (never more than 65 °C, whatever is typed; the controller's own maximum applies when lower). The floor is 20 °C.
Refresh interval (s)numberNoHow often the ecoNET300 is read, in seconds.
Language of the feature namesselectNoUsed for the names of the device and features added from now on, for the status texts and for the command errors.

How to install ecoNET300 in Gladys​

  1. In Gladys, open Integrations: ecoNET300 appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/lm1lc3n7/gladys-econet300:0.1.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/LM1LC3N7/gladys-econet300.

ecoNET300 requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

ecoNET300 is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by LM1LC3N7, not by the Gladys core team.
