ecojoko integration for Gladys Assistant

ecojoko integration for Gladys Assistant

Live power, daily consumption and ambient sensors from your ecojoko energy assistant.

View on GitHubAll external integrations

Bring the readings of your ecojoko energy assistant into Gladys: the live power draw, today's consumption and, when your display reports them, the temperature and humidity. The integration also builds a cumulative index from the daily totals, so Gladys can drive its energy dashboard (half-hour consumption and cost from your contract).

SensorUnitMeaning
Live powerWWhat the home draws from the grid right now
Consumption indexkWhCumulative counter since install (the base of the energy dashboard)
Today's consumptionkWhToday's total, reset every night
Period todaykWhSame per tariff period (off-peak/peak, Tempo colours…), optional
Solar surplus todaykWhEnergy exported to the grid, if ecojoko measures it at your place
Temperature / humidity°C, %Indoor (display) and outdoor, as a second device

Requirements​

  • An ecojoko sensor installed and linked to the ecojoko cloud.
  • The credentials of your ecojoko account (the mobile app's, or service.ecojoko.com).

Setup​

  1. Enter your ecojoko email and password, then save.
  2. Click Test the connection: the message confirms the gateway found, the current power and what your account exposes (tariff periods, solar surplus, ambient sensor).
  3. Open the integration's Devices tab and add the ecojoko device (and ecojoko (ambiance) if it shows up).
  4. For the energy dashboard, pick the Consumption index feature as the main meter in Gladys' energy settings and fill in your contract.

Both refresh rates are configurable: live power (30 s by default) and daily statistics (5 min by default). Every reading is a request to the ecojoko cloud: going below a few seconds is pointless, the display itself is not faster.

Showing the power as a gauge​

The power is published as a signed grid exchange: positive when you draw from the grid, negative when your panels export. The declared scale runs from −12,000 to +12,000 W, so 0 W sits in the middle.

On a Gladys dashboard, add a Gauge box, pick the Live power feature, then turn on custom colours:

  • low threshold at 0 with a green low colour: every negative value, so every surplus, shows green;
  • high threshold at whatever you consider heavy draw (3,000 W for example) with a red high colour;
  • the in-range colour applies between the two.

If you produce​

When your ecojoko account reports a solar surplus, two extra sensors show up: the surplus today, reset every night, and an exported energy index, cumulative and never reset. The latter is the shape Gladys tracks production from, as it already does for consumption.

The energy dashboard​

Half-hour consumption and its cost are not computed by the integration: Gladys derives them from the Consumption index. Two conditions must be met, or the tile reads "no recent value":

  1. an electricity contract filled in in Gladys' energy settings;
  2. at least 30 minutes of index history, so a first delta exists.

Good to know​

  • No official API. ecojoko publishes none; the integration uses the interface of its own web app, like the community integrations for Home Assistant do. It may stop working if ecojoko changes it. Nothing is ever written to your account.
  • The index starts at zero on install, not at your Linky's value: ecojoko does not expose the meter index. Only differences matter to Gladys. The state lives in the integration's volume: a restart does not reset it, and days missed while stopped are backfilled from ecojoko's weekly statistics.
  • Tariff periods come from the tariff you declared in the ecojoko app. If you change it, save the configuration again: the new sensors will show up in Devices.
  • One account, one gateway: when several gateways are attached to the account, only the first one is supported.
  • The "today" sensors reset at midnight (Paris time), like the ecojoko app. Only the cumulative index keeps growing.

Troubleshooting​

  • "ecojoko rejected the email or password": check them on service.ecojoko.com. The integration stops on purpose until the configuration is fixed, so your account never gets locked.
  • "ecojoko cloud not answering": outage on ecojoko's side or Internet down; retries resume by themselves, no action needed.
  • No "ambiance" device: your account reports no temperature/humidity sensor, or the option is disabled in the configuration.

Independent community project, not affiliated with the ecojoko company.

Configuration settings​

These are the settings ecojoko asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
How it workssectionNoYour ecojoko sensor sends its readings to the ecojoko cloud; this integration reads them back with your ecojoko account (the one of the mobile app). ecojoko publishes no official API: this is the interface its own web app uses, it may change without notice. Nothing is ever written to your account.
ecojoko emailstringYes
ecojoko passwordsecretYes
Live power refresh (s)numberNoSeconds between two readings of the instantaneous power. Keep it reasonable: every reading is a request to the ecojoko cloud.
Daily statistics refresh (s)numberNoSeconds between two refreshes of today's consumption, the cumulative index and the ambient sensors.
One sensor per tariff periodbooleanNoAdds today's kWh per period reported by ecojoko (off-peak/peak hours, Tempo colours) when your tariff declares them.
Ambient temperature and humiditybooleanNoPublishes the indoor/outdoor temperature and humidity of the ecojoko display as a second device.

How to install ecojoko in Gladys​

  1. In Gladys, open Integrations: ecojoko appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-ecojoko:1.0.2), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-ecojoko.

ecojoko requires Gladys >=4.86.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

ecojoko is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
