DoorBird smart home integration, free and open source
DoorBird door stations, locally: image, rings, motion, infrared light, door opening in scenes.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Brings your DoorBird video door stations (D10x, D11x, D21x, D2101V…) into Gladys, locally, through their official LAN API: the camera image, the doorbell rings, the motion sensor, the infrared light, and — only if you allow it — opening the door from a scene. Nothing goes through a cloud.
Developed without the hardware: feedback welcome. Tell what works and what does not on GitHub.
This integration is not affiliated with Bird Home Automation (DoorBird).
Prerequisites
- Gladys 5.1.0 or later.
- A DoorBird door station on the same network as Gladys, with a fixed address (set it in your router).
- The DoorBird App, with the administrator credentials of the station (on the "Digital Passport" delivered with it), to create a user for Gladys.
Create a dedicated DoorBird user
Gladys must not use the administrator account. In the DoorBird App: Settings → Administration, log in
with the administrator credentials, then User → +. The App gives the new user a name like
abcdef0001 and a password: write both down. Give it only what Gladys needs:
- Watch always (live view at any time): the image of the camera at any time and the infrared light. Without it, the DoorBird only opens its image for 5 minutes after a ring.
- The relays the door opening may use, and only if you will allow it in Gladys (see below).
- Nothing else: Gladys needs neither "API-Operator", nor the history, nor the favorites.
Check also that the motion sensor is enabled on the DoorBird (Administration → Motion sensor), otherwise no motion is reported. The names of the permissions may differ slightly with the version and the language of the App.
Configuration
In Gladys: Integrations → DoorBird → Configuration.
- DoorBird address: the IP address of the door station, e.g.
192.168.1.50(with:portif not 80,https://for HTTPS). - DoorBird user and Password: the user created above. The password is only sent to the DoorBird. After a refused password, the integration stops asking (it never insists) until you fix it or press "Test the connection".
- Second DoorBird (optional): Its address, Its user and Its password, for a gate or a back door.
- DoorBird image: how often the image of each DoorBird is refreshed (only on events, every minute, 5 minutes — the default —, 15 minutes or every hour). A ring or a motion always takes a fresh one.
- Allow opening the door: off by default. See "Open the door (DoorBird relay)" below.
- Language of the names: language of the feature names (French by default) and of the texts sent to scenes. The names are set when you add the device: change the language before adding it.
Then open the Discover tab and add the DoorBird to Gladys.
The DoorBird device
One device per DoorBird, named after its model (for example "DoorBird D2101V"), with these features:
| Feature | Type | What it does |
|---|---|---|
| Image | camera | The camera image, refreshed at the chosen interval, at each ring and each motion. |
| Online | input | 1 while the DoorBird answers, 0 when it is unreachable. |
| Doorbell ring | doorbell | 1 when someone rings, back to 0 ten seconds later. |
| Motion | motion sensor | 1 while the motion sensor of the DoorBird reports motion. |
| Infrared light | light | Switches the infrared light on. It goes off by itself after about 3 minutes. |
The infrared light cannot be switched off on command: the DoorBird does not offer it, and the integration says so rather than pretending. The door is never a feature of the device: no switch, no voice assistant, no dashboard button can open it.
Dashboard widget
The DoorBird widget shows, for every DoorBird or the one chosen in its settings ("DoorBird (empty: all)"):
- the number of rings and of motions over the last 24 hours;
- the last rings and motions, newest first, each with the image taken at that moment;
- whether each DoorBird is online;
- with a single DoorBird added to Gladys, an Infrared light button.
The list is kept in memory: it starts empty when the integration restarts.
Scene triggers
- Someone rang the DoorBird: a ring. Filter: the DoorBird (empty: any). Variable: DoorBird name.
- Motion in front of the DoorBird: the start of a motion. Filter: the DoorBird. Variable: DoorBird name.
The image of the DoorBird is refreshed before the trigger fires: a "send the camera image" action in the same scene sends the visitor. One trigger per DoorBird every 15 seconds at most (a long press, a person lingering in front of the camera count once).
Scene actions
- Refresh the DoorBird image: takes a fresh image now, to send it in a message right after.
- Open the door (DoorBird relay): energizes a Relay of the DoorBird (door strike, gate):
1or2for the relays of the DoorBird,abcdef@1for a relay of a paired door controller ("Test the connection" lists them). It only works once Allow opening the door is checked. Only a relay the DoorBird lists is accepted, and the command is sent once, never retried.
Warning. A scene that opens a door opens it for whoever stands there. Never bind it to a trigger anyone outside can cause (a ring, a motion): use it with a condition only you control (a confirmation, your presence at home). Give the Gladys user only the relays it needs.
Configuration actions
- Test the connection: reads each DoorBird again and reports its model, firmware and relays, and whether its user may take an image. It also resumes a DoorBird stopped after a refused password.
- Show the video stream address: the RTSP address of a DoorBird
(
rtsp://user:PASSWORD@address:554/mpeg/media.amp), to add the live video to the "RTSP camera" integration of Gladys. ReplacePASSWORDyourself: the integration never shows it.
Scene examples
- Someone rings → photo on the phone: trigger "Someone rang the DoorBird", action "send a message with the camera image" (the DoorBird image).
- Motion at night → porch light: trigger "Motion in front of the DoorBird", condition "after sunset", action "turn on the porch light for 5 minutes".
- Motion while away → alert: trigger "Motion in front of the DoorBird", condition "nobody at home", actions "Refresh the DoorBird image" then "send a message with the camera image".
How it works
- Events: the integration keeps one connection open to the event stream of the DoorBird
(
monitor.cgi): rings and motions arrive within a second. The DoorBird repeats its state about every 20 seconds; a connection silent for a minute is reopened. - Why not the DoorBird favorites: a DoorBird can also call an HTTP address on each event, but the sandbox of Gladys accepts no incoming connection. The event stream is an outgoing connection, the reliable way here. The cloud history of the DoorBird is not used.
- Load on the DoorBird (its LAN API has no published quota, the integration stays light): the event
connection,
info.cgievery 5 minutes (every minute while the event stream is down), an image at the chosen interval and at each event (12 images a minute per DoorBird at most, the Gladys limit), two requests at once at most. States are sent to Gladys only when they change, and every 6 hours otherwise.
Troubleshooting
- "User name or password refused": check the user (not the administrator) and its password, then press Test the connection. The integration stops after a single refusal and never insists.
- "This DoorBird user lacks the permission": give the user "Watch always" (image, infrared light) or the relay (door) in the DoorBird App.
- No image between rings: same cause, "Watch always" is missing.
- No motion: enable the motion sensor of the DoorBird, and check its detection area.
- "No DoorBird LAN API at this address": wrong address, or a device without the LAN API.
- Details: the logs of the integration (Integrations → DoorBird) say when a DoorBird is lost and back.
For everything else, set
LOG_LEVEL=debug.
Limitations
- Developed without the hardware: the answers were taken from the published code of DoorBirdPy, Home Assistant, Homebridge and openHAB. Feedback welcome.
- RFID badges and keypad codes are not reported: the event stream of the LAN API only carries the doorbell and the motion sensor; the other events need the DoorBird favorites (an incoming connection, impossible in the sandbox).
- The live video is not in this integration: use the RTSP address in the "RTSP camera" integration.
- No two-way audio, no SIP, no DoorBird history (cloud).
- Two DoorBirds at most. An I/O door controller (A1081) is reached through the relays of its paired DoorBird.
- The infrared light cannot be switched off on command; its 3 minutes are the DoorBird's.
- A ring or a motion that happens while the integration is stopped is not caught up.
Configuration settings
These are the settings DoorBird asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your DoorBird | section | No | DoorBird video door stations on your network, through their official LAN API. Create a dedicated user in the DoorBird App, with only the permissions it needs (see the documentation). Nothing goes through a cloud. |
| DoorBird address | string | Yes | IP address or name of the door station, with :port if not 80, https:// for HTTPS. Give it a fixed address in your router. |
| DoorBird user | string | Yes | A user created in the DoorBird App (Administration, User), not the administrator. |
| Password | secret | Yes | Sent to the DoorBird only, never to a cloud. After a refused password, the integration stops asking until you fix it. |
| Second DoorBird | section | No | Optional: a second door station (a gate, a back door), with its own user. |
| Its address | string | No | |
| Its user | string | No | |
| Its password | secret | No | |
| DoorBird image | select | No | How often the image of each DoorBird added to Gladys is refreshed. A ring or a motion always sends a fresh one. |
| Allow opening the door | boolean | No | Lets scenes energize a relay of the DoorBird (door strike, gate): scene action only, never a switch. Off by default. |
| Language of the names | select | No | Language of the feature names and of the texts sent to scenes. Names are set when a device is added. |
How to install DoorBird in Gladys
- In Gladys, open Integrations: DoorBird appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-doorbird:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-doorbird.
DoorBird requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
DoorBird is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
