Docker integration for Gladys Assistant

Docker integration for Gladys Assistant

Start, stop, restart and monitor the Docker containers of your server.

View on GitHubAll external integrations

Manage the Docker containers of your server from Gladys: see whether they run, start and stop them from a dashboard or a scene, restart them from the Configuration screen, and follow their CPU and memory usage.

How it connects to Docker​

Gladys runs every external integration in a sandboxed container that cannot mount a path of your host, and /var/run/docker.sock is a host path. So this integration does not use the Docker socket: it talks to the Docker Engine API over your network, at an address you provide.

You have two ways to expose that API. The first one is strongly recommended.

Option A — a socket proxy (recommended)​

A socket proxy sits in front of the Docker socket and only forwards the calls you allow. Even if something else on your network reached it, it could not create a privileged container on your host.

Add this to a docker-compose.yml on the machine that runs your containers:

services:
  docker-proxy:
    image: ghcr.io/tecnativa/docker-socket-proxy:0.3.0
    restart: unless-stopped
    ports:
      - '2375:2375'
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro
    environment:
      CONTAINERS: 1 # list the containers (required)
      POST: 1 # allow start / stop / restart

Then docker compose up -d, and use http://<ip-of-that-machine>:2375 as the address below.

Two notes on those permissions:

  • CONTAINERS: 1 alone gives a read-only integration: states, CPU and memory work, the On/Off switch and the restart button do not.
  • POST: 1 is what allows starting, stopping and restarting. It is scoped to the endpoints the proxy exposes, so it does not grant container creation.

The proxy has no authentication of its own: publish its port on a network you trust, and never on the public internet.

Option B — the Docker daemon itself​

If your daemon already listens on TCP (-H tcp://0.0.0.0:2375, or a hosts entry in /etc/docker/daemon.json), point the integration straight at it. Be aware that an unprotected Docker API grants full root-equivalent access to that machine: only do this on a trusted network, and prefer option A.

https:// addresses are supported. Client certificates (--tlsverify with a client key pair) are not: if your daemon requires them, put a socket proxy in front of it instead.

Configuration​

  1. Open the Configuration tab of the integration.
  2. Docker API address — for example http://192.168.1.10:2375. The tcp://host:port form the Docker CLI uses and a bare host:port are accepted too.
  3. Click Test the Docker connection. It answers with the Docker version and how many containers match your filters. Fix this before going further: nothing else works until it succeeds.
  4. Containers to include / to exclude — comma-separated names where * matches anything, for example media-*, nginx. Leaving the inclusion list empty exposes every container. The exclusion list is applied last and defaults to gladys*, so the containers running Gladys itself are kept out of reach — controlling them from Gladys would let you stop the very thing holding the switch.
  5. Click List the matching containers to check your filters before saving.
  6. Save: the containers appear in the Discovery tab, ready to be added.

The other settings:

SettingWhat it changes
Offer stopped containersWhether containers that are currently stopped are listed in Discovery.
Collect CPU and memoryAdds a CPU and a memory sensor to each container. Costs about a second of daemon time per refresh.
Refresh intervalHow often the state and the sensors of a container are refreshed. Gladys polls a device once a minute at the slowest, so the choices run from 10 seconds to 1 minute.
Discovery intervalHow often the container list is re-read, so containers created later appear on their own. This is the integration's own timer, unrelated to the refresh interval.
Stop timeoutThe grace period Docker gives a container to exit before killing it.

What each container looks like in Gladys​

FeatureWhat it does
RunningRead-only badge: on or off. Keeps its history, and works as a scene condition ("if the container is running").
Staterunning, exited, restarting, paused…
Start / Stop / RestartOne push button each. Always all three: Gladys cannot hide a feature depending on a state, but pressing Start on a running container does nothing (Docker answers "already started").
ActionA single control offering only what makes sense right now — Start when the container is stopped, Stop and Restart when it runs.
CPUPercentage, same scale as docker stats: 200% means two full cores.
MemoryMegabytes, page cache excluded.

Containers created by Docker Compose are named project · service; the others keep their container name. The device page also shows the image the container runs and, for a Compose container, its project and service.

Two labels come from Gladys, not from this integration. The CPU row reads "Temperature": Gladys has no CPU category, so the feature borrows the one whose icon is a processor chip — the value and its percent unit are correct, only the wording is not. The Running row reads "Switch" for the same reason. Both can be renamed for good in a dashboard, from the pencil icon of the "Devices in room" box.

A device carries a local badge, which turns orange when the container needs attention — restarting in a loop, paused, dead, or failing its own health check — and grey when the daemon can no longer be reached.

Actions​

  • Test the Docker connection — contacts the daemon and reports its version, its platform and how many containers your filters select.
  • List the matching containers — shows exactly what your inclusion and exclusion filters select right now. The fastest way to understand why a container does or does not show up.
  • Restart a container — pick one of your containers and restart it, without having to build a stop-then-start scene.

Good to know​

  • Containers are tracked by name, not by id. docker compose up after an image update recreates a container with a brand new id but the same name, so your devices, their history and the scenes using them survive the update.
  • A container renamed is a new device. Rename a container and Gladys sees the old device disappear and a new one show up in Discovery.
  • Stopped containers stay controllable. Hiding stopped containers only changes what Discovery offers; a device you already added keeps its switch and can be started again.
  • The state published is the daemon's, not the request's. Start a container that crashes on boot and the switch goes back to off, because that is what Docker reports.
  • Collecting CPU and memory is not free. Docker needs about a second to answer a stats request, per container. With twenty containers refreshed every 10 seconds, the daemon spends more time answering than idling: leave the refresh interval at one minute unless you have few containers, or turn the stats off.

Troubleshooting​

"Cannot reach the Docker API" — the address is wrong, the port is not published, or a firewall drops the connection. From another machine on the same network, curl http://<address>/version should answer some JSON.

"Docker API returned a non-JSON body" — something answered, but it was not a Docker API: usually a web server or a router page on that port.

"Docker API 403" — a socket proxy is refusing the call. Add the permission it needs: CONTAINERS: 1 to list, POST: 1 to start, stop and restart.

No container in Discovery — click List the matching containers. An empty answer means your filters exclude everything; remember the exclusion list defaults to gladys*.

The CPU is missing but the memory is there — a container needs two consecutive readings before a CPU percentage can be computed. One is missing just after a start; the next refresh has it.

The integration logs everything it does. Set LOG_LEVEL=debug to see every call it makes to the Docker API, then read the integration logs from the Gladys UI (or docker logs on the host).

Configuration settings​

These are the settings Docker asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Before you startsectionNoThis integration runs in a sandboxed container that cannot mount the Docker socket of your host. It talks to the Docker Engine API over the network instead: expose it with a read-limited socket proxy (recommended) and paste its address below. The full step-by-step is in the documentation.
Docker API addressstringYesAddress of the Docker Engine API, for example http://192.168.1.10:2375. https:// is supported.
Accept a self-signed certificatebooleanNohttps addresses only: skip the verification of the server certificate. Leave off unless your proxy uses a self-signed certificate.
Containers to includestringNoComma-separated container names, * allowed (e.g. media-*, nginx). Leave empty to expose every container.
Containers to excludestringNoComma-separated container names, * allowed. Applied after the inclusion list — keep your Gladys containers here.
Offer stopped containersbooleanNoAlso list the containers that are currently stopped in the Discovery tab.
Collect CPU and memorybooleanNoAdd a CPU and a memory sensor to each container. Costs about one second of daemon time per container and per refresh.
Refresh intervalselectNoHow often the state and the sensors of each container are refreshed. Gladys polls no slower than once a minute. With CPU and memory collection on, each refresh costs about a second of daemon time per container: keep it slow if you manage many.
Discovery interval (s)numberNoHow often the container list is re-read, so new containers show up on their own. Unrelated to the refresh interval above: this one is the integration’s own timer.
Stop timeout (s)numberNoGrace period Docker gives a container to exit before killing it.

How to install Docker in Gladys​

  1. In Gladys, open Integrations: Docker appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/philippema/gladys-docker:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/PhilippeMA/gladys-docker.

Docker requires Gladys >=4.86.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Docker is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by PhilippeMA, not by the Gladys core team.
