Bose SoundTouch smart home integration, free and open source
Bose SoundTouch speakers on the local network: power, volume, sources, presets, now playing.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.2.0
- ★ 0
Control your Bose SoundTouch speakers (SoundTouch 10, 20, 30, 300, Wave, Lifestyle and the other SoundTouch systems) from Gladys, over the local network: power, volume, mute, play and pause, previous and next track, source, the six presets, what is playing and the multi-room group.
Developed without the hardware: feedback welcome. This integration was written from the Bose SoundTouch Web API documentation and from the recorded answers of other open-source projects, without a speaker at hand. Tell us on the Gladys forum what works and what does not.
This integration is not affiliated with Bose. Bose and SoundTouch are trademarks of Bose Corporation.
Overview
Each speaker becomes one Gladys device, a music player: the Gladys Music dashboard box drives it (play, pause, previous, next, volume slider), and the device box shows the rest. Changes made from the speaker, its remote or the SoundTouch app reach Gladys within a second, through the speaker's own notifications.
Everything stays on your network: the integration talks to the speakers directly, with no account and no cloud. Bose has announced the end of the SoundTouch cloud service; the local API this integration uses keeps working without it.
Requirements
- Gladys 5.2.0 or later.
- SoundTouch speakers on the same network as Gladys, already set up with the SoundTouch app (they must be on your Wi-Fi or Ethernet network).
- Gladys must reach the speakers on TCP ports 8090 (API), 8080 (notifications) and, for the "Play an audio address" action, 8091 (UPnP).
Configuration
- Install the integration (Integrations → Install from GitHub while it is not in the store), then open its Configuration tab.
- Speakers on the same network are found automatically (mDNS, relayed by Gladys). If one is missing, type its IP address in Speaker IP addresses (several addresses: separate them with commas). The SoundTouch app shows it under Settings, Speaker Settings, Speaker Info. Give your speakers a fixed address in your router if you can.
- Choose the Language of the texts: the feature names (set when you add a speaker) and the texts the integration writes (source, group, standby). French by default.
- Save, then open the Discovery tab and add your speakers.
The Search for speakers button looks for the speakers again and lists the ones found, with their model, their address and whether their notifications are live.
The speaker device
| Feature | What it does |
|---|---|
| Power | Turns the speaker on (it resumes what it last played) or puts it in standby |
| Volume | 0 to 100, follows the volume knob and the remote |
| Mute | Mutes or unmutes |
| Play, Pause | Buttons of the Music box |
| Previous, Next | Previous or next track (on the sources that allow it) |
| Playback state | Playing or paused, read only (standby counts as paused) |
| Source | AUX, Bluetooth or one of the stored presets; "Other" for any other source |
| Now playing | The track, else the station, else the source; "Standby" when off |
| Artist | The artist, or the station of a radio playing a song; "—" when there is none |
| Multi-room group | "Not grouped", "Leads Kitchen, Bedroom" or "Follows Living room", read only |
The Source list shows the presets stored on the speaker with their names ("Preset 2 · FIP"); it follows the presets you store or change in the SoundTouch app. Picking "Other" does nothing: it only means the speaker plays a source Gladys cannot choose itself (Spotify, a radio outside the presets, standby). AUX is only offered on the speakers that have an AUX input.
Multi-room groups are shown, not created: create them in the SoundTouch app.
Dashboard widget
The SoundTouch player widget shows one speaker (chosen in its settings):
- the title and the artist, with the source or the preset;
- the volume, live;
- the state (playing, paused, standby, unreachable), the source and the multi-room group;
- four buttons: previous, play/pause (turn on when the speaker is in standby), next, and Presets, which opens the list of the six presets to start one.
The Gladys Music box works too: choose the speaker in it.
Scenes
Trigger: SoundTouch preset started
SoundTouch preset started fires when one of the six presets starts outside Gladys: from the buttons of the speaker, its remote or the SoundTouch app. It also fires when the speaker wakes up on a preset. It does not fire when Gladys starts the preset itself (a scene, the widget, the Source list), so a scene cannot loop on it.
Filters: the speaker, and the presets (leave empty for any). Variables: the preset number and the preset name.
Action: Play a SoundTouch preset
Play a SoundTouch preset starts preset 1 to 6 of a speaker, turning it on if needed. Its output is the name of the preset, for the next actions of the scene. An empty preset fails the action (the rest of the scene goes on).
Action: Play an audio address
Play an audio address sends an http:// address (a radio stream, a sound
file served on your network) to the speaker's UPnP renderer, at an optional
volume. The speakers do not play https:// addresses. Not every model has the
UPnP renderer: on those, the action fails.
Power, volume and source need no dedicated action: use the core's "Control a device" action on the speaker's features.
Scene examples
- Wake up with the radio: at 7:00 on weekdays, "Play a SoundTouch preset" (preset 1, your morning radio) in the bedroom, then set its volume to 15.
- A preset button as a switch: when "SoundTouch preset started" fires for preset 6 on the living room speaker, turn on the living room lamps and close the shutters: the speaker's button becomes a "movie night" button.
- Quiet when leaving: when the last person leaves home, set the power of every speaker to off.
Refresh and network
- The speakers push every change (volume, track, source, presets, group) over their notification WebSocket: Gladys follows them in real time.
- The integration also reads each speaker over HTTP every 2 minutes (every 30 seconds while its notifications are down), to catch a lost notification and notice a speaker that was unplugged. That is six small requests per speaker, on your local network only.
- Unchanged values are sent to Gladys again every 6 hours, so the device never shows "no recent value".
- A new search runs every 15 minutes, to follow a speaker whose address changed (DHCP).
- The SoundTouch web API has no account, no quota and no key. It is open to any device of your network: that is how the speakers are built.
Troubleshooting
- No speaker found: check that the speaker plays from the SoundTouch app, then type its IP address in the configuration. Automatic discovery needs a Gladys that relays mDNS (5.2.0 or later) and a network that lets mDNS through (some mesh Wi-Fi and guest networks do not).
- The speaker shows as unreachable: it may be unplugged or in a deep sleep (some models leave the network after a long standby). Press a button on the speaker, then Search for speakers.
- States arrive late: the notifications may be blocked between Gladys and the speaker (port 8080); the integration then reads the speaker every 30 seconds. Search for speakers shows "polled" instead of "live".
- A preset is not in the Source list: store it on the speaker first (SoundTouch app or a long press on the preset button).
- Set
LOG_LEVEL=debugon the integration to see every notification and refresh in its logs.
Limitations
- Developed without the hardware: the behaviour on a real speaker is not verified yet.
- Gladys announcements (the "Broadcast a notification" scene action) are not
offered: Gladys Plus serves them from an
https://address, and the speakers only playhttp://ones. - Multi-room groups are read, not created or changed.
- Only AUX and Bluetooth can be selected as inputs: the HDMI and TV inputs of the Lifestyle and SoundTouch 300 systems, and the streaming services, are shown as "Other".
- Previous and next only work on the sources that allow skipping (not on a radio).
- Bass, tone and the alarms of some models are not supported.
Configuration settings
These are the settings Bose SoundTouch asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Finding your speakers | section | No | SoundTouch speakers on the same network as Gladys are found automatically (mDNS): open the Discovery tab. If one is missing, enter its IP address below (shown in the SoundTouch app, under Settings, Speaker Settings, Speaker Info). Not affiliated with Bose. |
| Speaker IP addresses | string | No | Optional, separated by commas. Only needed for the speakers automatic discovery does not find. |
| Language of the texts | select | No | Language of the feature names (set when a speaker is added) and of the texts the integration writes: source, group, standby. |
How to install Bose SoundTouch in Gladys
- In Gladys, open Integrations: Bose SoundTouch appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-soundtouch:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-soundtouch.
Bose SoundTouch requires Gladys >=5.2.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Bose SoundTouch is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
