Bosch Smart Home smart home integration, free and open source
Bosch Smart Home Controller, locally: heating, contacts, smoke, plugs, shutters, alarm status.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Connect your Bosch Smart Home Controller (first or second generation) to Gladys, over your local network, without any cloud: the heating of each room (temperature, setpoint, mode), the radiator and room thermostats, the door/window contacts, the motion detectors, the smoke detectors, the plugs, the switches, the shutters, the water leak detectors, the universal switches and the state of the intrusion alarm.
Developed without the hardware: feedback welcome. This integration was built from the public local API of the controller and from the work of the boschshcpy library, and tested against a simulated controller, not a real one. If something does not work as described, please say so on the Gladys forum or in the issues.
This integration is not affiliated with, nor endorsed by, Bosch.
What you need
- Gladys Assistant 5.1.0 or later.
- A Bosch Smart Home Controller (I or II), installed with the Bosch Smart Home app, on the same local network as Gladys.
- Its IP address. The app shows it under Settings → System → Smart Home Controller; your router shows it too. Give the controller a fixed address (DHCP reservation in your router): the integration reaches it by this address.
- Its system password, chosen when the controller was installed. It is only used once, for the pairing.
- Physical access to the controller, to press its button during the pairing.
Set up
The controller only talks to the clients it has paired. Pairing registers
Gladys as a client of the controller, with a certificate the integration
generates and keeps in its /data volume.
- In Gladys, open Integrations → Bosch Smart Home → Configuration.
- Enter the Controller IP address (e.g.
192.168.1.20) and the System password, then save. - Go to the controller and press its button (on the front) until its lights flash: the controller is now in pairing mode, for a short while.
- Back in Gladys, click Pair right away. After a few seconds the result shows under the button: Paired. N device(s) found.
- Open the Discovery tab and add the devices you want.
Once paired, the system password is erased from the Gladys configuration: it is not needed any more. The pairing appears in the Bosch app (as oss_Gladys_Assistant), where you can remove it at any time.
Test the connection reads the controller again and tells its software version and how many devices are supported.
The other settings:
- Language of the names: the language of the feature names given to the new devices and of the texts sent by the integration (French by default).
- Motion lasts: a motion detector only tells the time of each detection; this is how long its Motion feature then stays on (1 minute by default).
- Allow arming from Gladys: off by default, see Intrusion alarm below.
- Do not check the controller certificate: off. Only for a controller whose certificate expired because it stayed offline for years: the connection then fails with a certificate error.
Devices
Each supported device of the controller becomes a Gladys device, named as in the Bosch app. The states arrive in real time: the integration keeps an event subscription open on the controller (long polling, as Bosch recommends), and reads everything again every 15 minutes as a safety net. A device the controller reports as unavailable shows the unreachable badge.
Heating
Bosch handles the heating per room: for each room with radiator thermostats, the controller has a room climate control, which becomes the device Heating <room>:
| Feature | What it does |
|---|---|
| Temperature | Room temperature measured by the controller. |
| Setpoint | Target temperature, 5 to 30 °C by half degrees. Changing it in manual mode keeps it. |
| Heating mode | Off (summer), Manual (fixed setpoint) or Schedule (the weekly programme of the Bosch app). |
| Heating demand | Whether a radiator of the room is asking for heat. |
In Schedule mode, a new setpoint lasts until the next step of the programme, as in the Bosch app. When the room is in eco mode, a new setpoint leaves eco.
The radiator thermostats and the room thermostats are devices too: Temperature, Humidity (room thermostats that measure it) and Low battery.
Sensors
| Device | Features |
|---|---|
| Door/window contact | Opening, Low battery |
| Motion detector | Motion, Low battery |
| Smoke detector | Smoke, Low battery |
| Water leak detector | Water leak, Low battery |
| Universal switch | Low battery |
Smoke is on when the detector itself detects smoke. When another detector of the house does, every detector sounds, but only the one in the smoky room shows Smoke: the trigger Smoke detector in alarm tells both cases apart.
Plugs, switches and shutters
| Device | Features |
|---|---|
| Smart plug, compact plug | On/Off, Power (W), Energy (kWh) |
| Light switch, light and relay micromodules | On/Off (and Power, Energy if measured) |
| Shutter control, shutter and awning modules | Position (0 % closed, 100 % open), Open/Close (open, close, stop) |
Energy is the counter of the plug: Gladys adds the consumption and cost features to it in the energy screens.
Intrusion alarm
When the controller has the intrusion detection system, the device Intrusion alarm shows:
- Armed: on when the system is armed;
- Alarm triggered: on during a pre-alarm or an alarm;
- Alarm status: Disarmed, Arming, Armed, Pre-alarm, Alarm! or Alarm muted.
The alarm is read-only by default. With Allow arming from Gladys, the scene action Arm the intrusion alarm can arm it. Disarming and muting are never possible from Gladys: a scene, a voice assistant or a shared dashboard must not be able to switch the protection of the house off. Use the Bosch app for that.
Dashboard
The widget Bosch Smart Home (in the widget list of a dashboard) sums the house up: the state of the controller, of the intrusion alarm, how many doors and windows are open, how many batteries are low, how many devices do not answer, then the names. It is read-only.
The features themselves go on a dashboard as usual (Devices in room widget, thermostat widget…).
Scenes
Triggers
Smoke detector in alarm: a smoke detector detects smoke, or sounds
because another one does. Filters: the detector, the origin (Smoke detected
by this detector or Alarm relayed from another detector). Information
passed on to the scene: Detector name, Room, Origin (detected or
relayed).
Universal switch pressed: a short or long press on a button of a Bosch universal switch. Filters: the switch, the button (upper, lower, and the four of the four-button model), the press (Short press, Long press). Information passed on: Switch name, Room, Button, Press.
The other states (a window opened, a leak, the alarm armed) are device features: use the usual Device state trigger of Gladys.
Actions
Arm the intrusion alarm: arms the alarm system of the controller with a protection profile: Full protection, Partial protection or Individual protection (as set up in the Bosch app). It only works when Allow arming from Gladys is on; otherwise the action fails and the scene goes on.
Scene ideas
- Fire: trigger Smoke detector in alarm → turn every light on, open the shutters, send everyone a message with the Room of the detector (from the variable picker).
- Bedside button: trigger Universal switch pressed, lower button, long press → close every shutter and turn the lights off.
- Window open, heating off: trigger Device state on Opening of the living-room window = open for 2 minutes → set the Heating mode of the room to Off (summer); back to Schedule once closed.
- Leaving home: when the house becomes empty → Arm the intrusion alarm (Full protection), after allowing arming in the configuration.
Troubleshooting
- Not paired yet: follow Set up above; the pairing is kept in the
/datavolume of the integration, and survives updates. - the controller is not in pairing mode: the button was not pressed long enough, or the pairing mode ended before the click. Press until the lights flash, then click Pair within a few seconds.
- system password refused: check the password in the Bosch app (it can be changed there), type it again, save, and pair again.
- the controller does not answer at this address: check the IP address (it may have changed: give the controller a fixed one), and that Gladys can reach the controller on ports 8443 (pairing) and 8444 (API).
- the controller refuses Gladys (pair it again): the pairing was removed in the Bosch app, or the controller was reset. Pair again.
- the controller certificate is not a valid Bosch certificate: another device answers at this address, or the certificate of the controller expired. Check the address; if it is the right one, tick Do not check the controller certificate.
- A new device of the Bosch app appears in the Discovery tab by itself within seconds; a device removed there disappears from it.
- Detailed logs: set the
LOG_LEVEL=debugenvironment variable of the integration. The logs never contain the password, the key or the certificate.
Limits
- Developed without the hardware: tested against a simulated controller only. Feedback welcome.
- One controller per Gladys instance.
- Supported devices: radiator thermostats I and II, room thermostats, wall thermostats, door/window contacts I and II, motion detectors I and II, smoke detectors I and II, smart plugs and compact plugs, light switches, light and relay micromodules, shutter controls I and II, shutter and awning modules, water leak detectors, universal switches. Not supported (ignored): Twinguard, cameras, outdoor siren, dimmers and coloured lights, heating circuits and boilers, presence simulation, Bosch scenarios and automations.
- Not offered: the valve position of the radiator thermostats, the illuminance of motion detector II, the boost and eco presets, the child lock and the other settings of the devices.
- The intrusion alarm can only be armed (opt-in), never disarmed nor muted.
- Bosch asks local clients to use long polling and to keep the number of requests low: the integration keeps one event request open at a time (30 s each), reads everything again every 15 minutes (4 requests), and re-sends the unchanged values to Gladys every 6 hours.
- The local API of Bosch is for private, non-commercial use.
Configuration settings
These are the settings Bosch Smart Home asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your Smart Home Controller | section | No | Smart Home Controller I or II, on the same network as Gladys. 1. Enter its IP address and its system password, save. 2. Press the button of the controller until its lights flash. 3. Click "Pair" within a minute. |
| Controller IP address | string | Yes | Shown in the Bosch Smart Home app (Settings, System, Smart Home Controller) or in your router. Give it a fixed address. |
| System password | secret | No | The password chosen when the controller was installed. Used once, for the pairing, then erased from Gladys. |
| Language of the names | select | No | Language of the feature names given to new devices and of the texts sent by the integration. |
| Motion lasts | select | No | The controller only sends the time of each detection: how long a motion detector then shows "motion". |
| Security | section | No | The intrusion alarm is read-only by default. Disarming and muting it are never possible from Gladys. |
| Allow arming from Gladys | boolean | No | Lets the "Arm the intrusion alarm" scene action arm the alarm system of the controller. |
| Do not check the controller certificate | boolean | No | Only if the connection fails with a certificate error (a controller kept offline for years). Less secure. |
How to install Bosch Smart Home in Gladys
- In Gladys, open Integrations: Bosch Smart Home appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-bosch-shc:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-bosch-shc.
Bosch Smart Home requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
