Bosch HomeCom Easy smart home integration, free and open source

Bosch heat pumps, boilers and air conditioners of the HomeCom Easy app, through the Bosch cloud.

• Published by guim31
• Devices
• Version 1.0.1
• Requires Gladys >=5.1.0
• ★ 0

View on GitHubAll integrations

Overview

This integration brings the Bosch appliances of your HomeCom Easy account into Gladys, through the Bosch cloud (the same one the app uses):

• heat pumps and boilers connected to a Connect-Key K 30 RF / K 40 RF (Compress 5800i, 6800i, Condens boilers…) or to an ICOM module (Compress 7000i / 7001i AW): outdoor temperature, supply and return temperatures, system pressure, generator state, faults, and per heating circuit the room temperature, the room setpoint and the operating mode; the domestic hot water with its temperature, setpoint, mode and one-off charge;
• Climate air conditioners (3000i, 5000i, 6000i): on/off, mode, setpoint, fan speed, room temperature.

It reads the cloud every few minutes and sends your commands right away, within the limits the appliance announces.

Developed without the hardware: this integration was written from the public work of the community (see "Limits" and the README credits) and tested against recorded answers, not on a real appliance. Your feedback is welcome, on the Gladys forum or in the GitHub issues.

This integration is not affiliated with, nor endorsed by, Bosch. It is distinct from the Bosch Smart Home integration (Smart Home Controller), which covers other products.

Requirements

• Gladys 5.1.0 or later.
• A HomeCom Easy account (SingleKey ID) where your appliance is already set up and working in the app. Buderus appliances of the MyDevice app work the same way: choose "Buderus MyDevice" as app brand.
• A computer with a browser that has developer tools (Chrome, Edge, Firefox) for the one-time sign-in.
• Gladys must reach the Internet (singlekey-id.com and pointt-api.bosch-thermotechnology.com).

Configuration

Bosch gives no public sign-in for third-party software: the integration uses the sign-in of the app, which ends on an address only the app can open. You copy one code by hand, once.

1. In Integrations → Bosch HomeCom Easy → Configuration, choose the app brand and save.
2. Click Connect next to "Bosch account (SingleKey ID)": the Bosch sign-in page opens in a new tab.
3. In that tab, press F12 to open the developer tools and select the Network tab. Then sign in with your SingleKey ID email and password.
4. The last page does not open (the browser cannot open com.bosch.tt.dashtt.pointt://…): this is expected. In the Network tab, find the request whose address contains code= and copy the value after code= (it ends with -1). Copying the whole address also works.
5. Paste it in Authorization code and save within a minute: the code is short-lived and works once.

The status turns to "connected" and the appliances appear in the Discovery tab: add the ones you want.

Your password never reaches Gladys. The integration keeps a refresh token in its private volume (/data) and renews it on its own: you sign in again only if Bosch revokes it (password change, sign-out of all sessions…). The status then says so.

Other settings:

• Refresh interval: how often the cloud is read, 5 minutes by default, 2 minutes minimum.
• Language of the device names: the names written when you add a device (French by default).
• Test the connection: lists the appliances of the account, supported or not.

Devices

Each appliance gives several Gladys devices, so you can place each circuit in its room. Only the values your appliance reports are created.

Heat generator

The heat pump or the boiler: outdoor temperature, supply and return temperatures, system pressure (bar), generator state (heating, hot water, frost protection, idle), total consumption (kWh, ICOM only), and the active fault codes ("No fault" otherwise).

Heating circuit

One device per circuit (hc1, hc2…): room temperature (when a room sensor or thermostat is fitted), humidity (when available), room setpoint and operating mode (programme, manual, off — the modes the circuit offers). The setpoint is limited to the range the appliance announces (5–30 °C usually) and rounded to the half degree. In cooling, the cooling setpoint is changed.

Hot water

One device per hot water circuit: water temperature, setpoint, mode (off, eco, comfort, own programme…, as offered by the appliance) and extra hot water, a one-off charge you start or stop. The setpoint changes the temperature of the level in use (comfort, eco…); it cannot be changed when the hot water is off.

Air conditioner

On/off, mode (auto, cooling, heating, drying, fan), setpoint (16–30 °C usually), fan speed and room temperature.

Widget

Heating and hot water shows on the dashboard the room temperature and setpoint of the first circuit, the hot water and outdoor temperatures, the heating and hot water modes, what the generator is doing and the faults, with an Extra hot water button. In its settings, pick any device of a system to show that one (useful with several gateways); empty, the first one is shown.

Scene trigger

Bosch fault reported starts a scene when an appliance reports a new fault code. Choose the heat generator or the air conditioner, or leave empty for any. The variable Fault code holds the code (for example A01-5), to put in a notification. The faults already present when you sign in do not start the scene, and a fault starts it once, not at every reading.

The temperatures, modes and setpoints are device features: use them in the usual "device value" triggers and conditions of the scene editor.

Scene examples

• Fault alert: trigger "Bosch fault reported" → send the message "Heat pump fault {{triggerEvent.data.code}}" to the family.
• Hot water on solar surplus: when the solar production exceeds 2 kW, set "Extra hot water" of the hot water device to on.
• Away: when everybody leaves, set the room setpoint to 17 °C; when the first person comes back, to 20 °C.
• Summer evening: at 19:00, if the living room is above 27 °C, switch the air conditioner on in cooling mode at 25 °C.

Troubleshooting

• "This code does not come from the Connect button": the code was captured elsewhere (for example with another tool). Click Connect in this integration, sign in again, and paste the new code.
• "Bosch refused the code": the code was used already, has expired (it lives about a minute), or was copied incompletely. Click Connect again; paste the value right after code=, up to & if there is one.
• No request with code=: open the developer tools before signing in, in the tab of the sign-in page. With Chrome, tick "Preserve log" in the Network tab.
• "The Bosch sign-in has expired": Bosch revoked the refresh token. Sign in again as in Configuration.
• "The Bosch cloud does not answer": an Internet or Bosch outage; the integration retries at every refresh and says when it works again. The devices stay listed.
• A device is missing: run Test the connection. An appliance listed as "not supported" (water heater wddw2, thermostat rrc2, wallbox, Matter air conditioner…) is not covered yet.
• A command is refused: the value is outside the range the appliance announces, or the mode is not offered by this appliance. The integration logs say why (LOG_LEVEL=debug shows every reading).

Limits

• Cloud only: no local access. If the Bosch cloud or the Internet connection is down, nothing is read nor sent.
• Quotas: Bosch publishes no quota for this API. The integration stays sparing: two to three requests per gateway at each refresh (5 minutes by default, 2 minutes minimum), one request per command, and it stops as soon as Bosch answers "too many requests" or refuses the sign-in.
• Unofficial API: it is the one of the HomeCom Easy app, documented by the community. Bosch may change it without notice.
• Delay: a command is shown at once, but the cloud may take a minute to report the new value; the next reading confirms or corrects it.
• K30/K40 in programme mode: the room setpoint written is the one of the manual mode (as in the Home Assistant integration). To change the room temperature now, switch the circuit to manual.
• Not covered: holiday and away programmes, schedules, ventilation, solar circuits, pools, energy history (daily and monthly counters), water heaters wddw2, thermostats rrc2, wallboxes, and air conditioners commissioned over Matter.
• Values that could be dangerous (heat curves, maximum flow temperature, thermal disinfection) are not offered.

Data and privacy

The integration stores in its private volume (/data): the refresh token of your Bosch account, the PKCE secret of the last sign-in in progress, the list of your appliances and the fault codes already reported. It never stores nor logs your password, your tokens or the authorization code. It only talks to singlekey-id.com and pointt-api.bosch-thermotechnology.com.

Configuration settings

These are the settings Bosch HomeCom Easy asks for in its configuration screen in Gladys.

Setting	Type	Required	Description
Bosch HomeCom Easy	section	No	Reads and controls the Bosch appliances of your HomeCom Easy account through the Bosch cloud: heat pumps and boilers on a K 30 RF / K 40 RF or ICOM gateway, Climate air conditioners. Not affiliated with Bosch. Developed without the hardware: feedback welcome.
App brand	select	No	The app you use: Bosch HomeCom Easy, or Buderus MyDevice. Save before clicking "Connect".
Sign in to your Bosch account	section	No	1. Click "Connect": the Bosch sign-in page opens in a new tab. 2. In that tab, press F12 and open the Network tab, then sign in with your SingleKey ID. 3. The last page fails to open (normal): in the Network tab, copy the value after "code=" (it ends with "-1"). 4. Paste it below and save within a minute.
Bosch account (SingleKey ID)	account_link	No	Opens the Bosch sign-in page. Your password never reaches Gladys.
Authorization code	secret	No	The code copied after signing in, used once. The whole address with "code=" also works.
Refresh interval (minutes)	number	No	How often the Bosch cloud is read: 2 minutes minimum, so as not to overload it.
Language of the device names	select	No	Names of the devices and features, written when you add them.

How to install Bosch HomeCom Easy in Gladys

1. In Gladys, open Integrations: Bosch HomeCom Easy appears in the catalog, next to the native integrations, with a community badge.
2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-bosch-homecom:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
3. Open the Configuration screen of the integration, fill in the settings, and save.
4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-bosch-homecom.

Bosch HomeCom Easy requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations

Bosch HomeCom Easy is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
