Bond Bridge integration for Gladys Assistant

Bond Bridge ceiling fans, shades and lights: local control, live state, fan widget.

View on GitHubAll integrations

Control from Gladys the ceiling fans, shades, lights and other remote-controlled devices of a Bond Bridge, a Bond Bridge Pro or a Smart by Bond device, over the local network: no cloud, no Bond account needed by Gladys.

Developed without the hardware: feedback welcome. This integration follows the official Bond Local API v2 and the behavior of the Home Assistant bond integration, and is tested against a simulated bridge. If your bridge behaves differently, open an issue on the GitHub repository. Not affiliated with Bond or Olibra.

Overview​

A Bond Bridge learns the RF (radio) remotes of your ceiling fans, shades, fireplaces and lights, and replays them on command. This integration talks to the bridge on your network and creates one Gladys device per Bond device:

  • ceiling fans: on/off, speed, direction, breeze mode, light and brightness, up and down lights;
  • shades, blinds, awnings: open, close, stop, position;
  • lights: on/off, brightness, color temperature;
  • generic devices: on/off;
  • fireplaces: hidden by default, read-only when shown (see below).

A dashboard widget drives a ceiling fan like its wall remote, two scene triggers tell when a bridge stops answering and comes back, and a scene action corrects what Bond believes about a device.

Requirements​

  • Gladys Assistant 5.1 or later.
  • A Bond Bridge, Bond Bridge Pro or Smart by Bond device, set up in the Bond app first (Wi-Fi, devices added).
  • The bridge and Gladys on the same local network. Give the bridge a fixed IP address in your router (DHCP reservation): Gladys reaches it by its address.
  • The local token of the bridge (16 characters), read once — see below.

Configuration​

In Gladys, open Integrations, install Bond Bridge, then its Configuration tab.

Find the bridge​

Press Find the bridges: Gladys looks for Bond bridges on your network (mDNS) and fills in the empty addresses. If nothing is found (another subnet, mDNS blocked), type the IP address of the bridge yourself, for example 192.168.1.20. You can configure up to three bridges.

Get the local token​

Every request to the bridge carries its local token. Two ways to get it:

  1. From Gladys: unplug the bridge, plug it back, wait for its light to come back, then within 10 minutes press Get the local token. The bridge gives its token during the 10 minutes after it starts; Gladys saves it in the configuration.
  2. From the Bond app: open the bridge (or the Smart by Bond device), Settings, Advanced, Local token, and copy it into the Local token field.

Then press Test the connection: each bridge answers with its firmware, the number of devices for Gladys and whether live updates work.

Options​

  • Fireplaces: Hidden (default) or Shown, read-only.
  • Language of the feature names: the names given to the features when a device is added to Gladys (French by default). They do not change afterwards.

Then go to the Discovery tab and add the devices you want.

Devices​

A device gets a feature only when its remote, as set up in the Bond app, has the matching action: a fan remote without a light button gets no light.

Ceiling fans​

FeatureGladys typeWhat it does
Powerswitchon / off
Speedfan speed1 to the number of speeds of the remote, 0 turns it off
Directionairflow directionforward (summer) / reverse (winter)
Breeze modeswitchBond's natural-breeze mode, when the fan has it
Lightlightthe light of the fan
Brightnesslight brightness1 to 100 %, 0 turns the light off
Up / Down lightswitchthe separate up and down lights of some fans

When the fan is off, its speed shows 0: the bridge keeps the last speed, used again at the next "on". A remote that only has toggle buttons (one button for on and off) is toggled only when the state Bond believes differs from the one asked for.

Shades​

Open / close (open, close, stop) and Position (0 % closed, 100 % open) when the motor supports a position. Bond counts the other way round (0 open, 100 closed): the integration converts.

Lights​

Light (on/off), Brightness (1 to 100 %) and Color temperature (in kelvin, within the range of the light), depending on the remote.

Fireplaces​

A fireplace is never controlled from Gladys. Lighting a gas flame by mistake — a scene, a voice assistant, a child on the dashboard — is not harmless. By default fireplaces are hidden; with Shown, read-only they appear with their Power and Flame as read-only values, for display and scene conditions. Keep using the Bond app or the fireplace remote to light it.

Generic devices​

A device of type "Generic" in the Bond app gets a Power switch. Do not use it for heating.

Not supported​

Garage doors (a door opened by mistake is a security problem), air conditioners and bidets are not published. Groups of the Bond app are not supported either: put the devices in a Gladys scene instead.

What Bond believes​

An RF remote sends, but never answers: Bond does not know the real state of a device, it remembers what it sent last. The state in Gladys is that belief. It becomes wrong when a device is used with its own remote (the Bond Bridge Pro hears some remotes and follows them), a wall switch, or a power cut.

To correct it without sending anything, use Correct the Bond state (in the Configuration tab, or as a scene action): choose the device and its real state (on, off, light on, light off, open, closed). Bond records it, no signal is sent, and the next command from Gladys starts from the right state. The Bond app offers the same correction for each device.

Widget​

The Ceiling fan widget shows one fan, chosen in its settings:

  • the speed (and the brightness of its light) as live tiles;
  • whether the fan and its light are on, its direction, the breeze mode;
  • four buttons: Slower, Faster, Light (on/off) and Turn on / Turn off.

"Slower" at speed 1 turns the fan off; "Faster" on a fan that is off starts it at speed 1. If the bridge stops answering, the widget says so.

Scene triggers and actions​

KindNameVariables
TriggerBond bridge unreachablebridge name, Bond ID
TriggerBond bridge backbridge name, Bond ID, minutes away
ActionCorrect the Bond statedevice, real state

A bridge counts as unreachable after two failed readings in a row (about one minute); a wrong token is no "unreachable", it shows in the connection status. The devices themselves have no trigger here: use the regular "device state changed" trigger of Gladys on their features.

Scene examples​

  • Summer night: at 11 pm, if the bedroom temperature is above 26 °C, set the bedroom fan to speed 2 and turn its light off.
  • Sunset: at sunset, close the patio shades (position 0 %), and open them at 8 am on weekdays.
  • Bridge watch: when a Bond bridge is unreachable, send a message "The Bond bridge {{bridge}} is not answering".
  • Wall switch: the bedroom fans are cut by a wall switch every night at 1 am: a scene at 1:05 runs "Correct the Bond state: off" on them, so that the next "on" from Gladys does not toggle them off.

Refresh and network​

  • Live updates: the bridge pushes every state change over UDP (BPUP, port 30007) to the clients that keep a subscription open; the integration renews it every 60 seconds. Changes made in the Bond app (and on a Bond Bridge Pro, with the remotes it hears) appear in Gladys within a second.
  • Reading: while the live updates are silent, each device added to Gladys is read every 30 seconds; while they work, every 10 minutes as a safety net. Only the devices added to Gladys are read.
  • Load on the bridge: two requests at a time at most, a fresh connection per request, a 5-second timeout. A command is followed by one reading of the device.
  • Everything stays on your network: no cloud, no Bond account, nothing stored in /data.

Troubleshooting​

  • "Local token refused": the token changed (a bridge reset changes it) or was mistyped. Get it again (see above).
  • "Local token missing": press Get the local token within 10 minutes of plugging the bridge back in.
  • "Locked" when getting the token: more than 10 minutes since the bridge started. Unplug it, plug it back, retry; or copy the token from the Bond app.
  • "Does not answer": check the IP address (fix it in your router), that the bridge is on (its light), and that Gladys and the bridge are on the same network.
  • "Find the bridges" finds nothing: mDNS does not cross routers or some mesh Wi-Fi settings. Type the address.
  • The state in Gladys is wrong: someone used the original remote. Use Correct the Bond state.
  • Test the connection says "no live updates": a firewall between Gladys and the bridge may block UDP port 30007. Everything works, a little slower (readings every 30 s).
  • More details in the logs of the integration (LOG_LEVEL=debug shows every reading).

Limits​

  • Developed without the hardware: the behavior follows the Bond documentation, the Home Assistant integration and the bond-async library; it was not tried on a real bridge. Feedback welcome.
  • The state is what Bond believes, never a measurement (see above).
  • Fireplaces are read-only, garage doors, air conditioners and bidets are left out.
  • No tilt control of shades, no timers, no Bond groups, no scenes of the Bond app.
  • Up to three bridges.
  • The live updates cross the Docker network of the Gladys sandbox in unicast (keep-alive every 60 s); this was not verified on real hardware. Without them, readings every 30 s take over.
  • Not affiliated with Bond or Olibra. Bond, Bond Bridge and Smart by Bond are trademarks of their owners.

Configuration settings​

These are the settings Bond Bridge asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Bond bridgesectionNoBond Bridge, Bond Bridge Pro or Smart by Bond device, set up in the Bond app first. Press "Find the bridges" below to fill in the address, then "Get the local token" within 10 minutes of plugging the bridge back in. Up to three bridges.
IP addressstringNoAddress of the Bond bridge on your network. Fix it in your router (DHCP reservation).
Local tokensecretNo16 characters. Bond app: the bridge, Settings, Advanced, Local token. Or the "Get the local token" button below.
Second bridge (optional)sectionNoSame fields, for another Bond bridge or Smart by Bond device.
IP addressstringNoAddress of the Bond bridge on your network. Fix it in your router (DHCP reservation).
Local tokensecretNo16 characters. Bond app: the bridge, Settings, Advanced, Local token. Or the "Get the local token" button below.
Third bridge (optional)sectionNoSame fields, for a third one.
IP addressstringNoAddress of the Bond bridge on your network. Fix it in your router (DHCP reservation).
Local tokensecretNo16 characters. Bond app: the bridge, Settings, Advanced, Local token. Or the "Get the local token" button below.
OptionssectionNoFireplaces are never controlled from Gladys: lighting a gas flame by mistake (a scene, a voice assistant) is not harmless. They can be shown, read-only.
FireplacesselectNo
Language of the feature namesselectNoUsed when a device is added to Gladys; the names do not change afterwards.

How to install Bond Bridge in Gladys​

  1. In Gladys, open Integrations: Bond Bridge appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-bond:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-bond.

Bond Bridge requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Bond Bridge is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
