Beszel smart home integration, free and open source

Beszel integration for Gladys Assistant

Your Beszel systems in Gladys: online, CPU, memory, disk, temperature and alerts.

View on GitHubAll integrations

Beszel is a lightweight server monitoring tool: a small agent on each machine reports to a hub, which keeps the history, shows the dashboard and raises alerts. This integration reads your Beszel hub and brings your systems into Gladys: one device per system, with whether it is online, its CPU, memory, disk, highest temperature, network traffic, load, uptime, failed services and the Beszel alerts triggered. Scenes can react when a system goes offline or comes back, and when a Beszel alert is triggered or resolved; a dashboard widget shows your systems at a glance. Everything stays on your local network.

Tested against a real Beszel 0.21.0 hub and agent (Docker), with a system stopped and started again and alerts triggered and resolved. Not yet on every installation: feedback welcome on the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • A Beszel hub (0.12 or later, 0.21 tested) reachable from the Gladys machine (port 8090 by default), with its agents already added.
  • The email and password of a Beszel user. Best: a user created for Gladys, with the read-only role.

The integration only reads: it never changes anything in Beszel nor on your machines.

Getting started​

1. Create a Beszel user for Gladys​

The integration sees exactly what its user sees: the systems shared with it, and its own alerts.

  1. Open the admin panel of PocketBase, at http://<hub>:8090/_/ (Beszel menu → Users in recent versions), and create a user in the users collection: an email, a password, the role readonly, verified ticked.
  2. Share the systems with it: either start the hub with the environment variable SHARE_ALL_SYSTEMS=true (every user sees every system), or, in the same admin panel, add the user to the users field of each system.
  3. Beszel alerts belong to a user: log into Beszel as this user and set the alerts the scenes should know (bell icon of a system). A read-only user may manage its own alerts.

You can also use your own Beszel account: the integration then sees your systems and your alerts.

2. Configure the integration​

In the Configuration tab of the integration:

  • Beszel address: the address of the hub, as you open it in a browser: 192.168.1.20 (port 8090 added), nas.lan:8090 or https://beszel.example.com.
  • Email of the Beszel user and Password.
  • Refresh interval: 30 seconds by default. The hub itself reads its agents once a minute: a shorter interval brings nothing.
  • Accept self-signed certificates: only for an https:// address whose certificate your browser does not trust either.
  • Language of the names: language of the feature names, set when a device is added, and of the texts sent to scenes.

Save, then click Test the connection: it says the version of Beszel, how many systems are online and how many alerts are triggered.

3. Add the systems​

Open the Discover tab: every system of the user is listed. Add the ones you want to follow. The scene triggers work for every system, added or not.

The devices​

Each system is one device, named as in Beszel. Its features:

  • Online: 1 while Beszel marks the system up, 0 when it marks it down. A paused system sends nothing.
  • CPU, Memory and Disk: the use, in %, of the processor, the memory and the root disk.
  • Highest temperature: the temperature Beszel shows on its dashboard (the hottest sensor), in °C, when the system has sensors.
  • Network traffic: sent and received together, in Mbit/s.
  • Load (1 min), Load (5 min), Load (15 min): the load averages.
  • Uptime: in days.
  • Failed services: the systemd services in failure, when the agent watches them.
  • Triggered alerts: how many Beszel alerts of the user are triggered on this system.

The values that move all the time (CPU, memory, load, network, temperature) are sent to Gladys at most once a minute, the others when they change. While a system is down, only Online and Triggered alerts are updated: the last figures stay.

Dashboard​

Add the Beszel systems widget to a dashboard:

  • with no system chosen in its settings, it shows how many systems are online and offline and how many alerts are triggered, then one line per system, red when it is offline, orange with a triggered alert;
  • with a system chosen, it shows its CPU, memory and disk gauges, its temperature, its triggered alerts, its load and its uptime.

The Refresh button reads Beszel again at once.

Scenes​

Triggers​

  • Beszel system offline or back: Beszel marks a system down (its agent no longer answers) or up again. Filters: the system and the new state (Offline, Back online). The actions can use the system name and the new state. Beszel decides when a system is down; a paused system fires nothing.
  • Beszel alert: a Beszel alert of the user is triggered or resolved. Filters: the system, the alert (CPU, Memory, Disk, Temperature, Status…) and the new state (Triggered, Resolved). The actions can use the system name, the alert, the alert with its threshold (CPU > 80%), the new state and the threshold.

The thresholds and durations of the alerts are set in Beszel, not in Gladys. The states found when the integration starts are its starting point: only the changes after that fire a scene, also across a restart of Gladys.

Actions​

  • State of a Beszel system: reads a system and gives the next actions its figures (online, CPU, memory, disk, temperature, network, load, uptime, triggered alerts) and a ready-made summary, for example nas: CPU 12%, memory 45%, disk 78%, 48 °C, no alert triggered.
  • State of every Beszel system: counts the systems online and offline and the triggered alerts, with a summary to send, for example Offline: pi then nas: 1 alert(s) triggered (Disk > 90%).

Scene ideas​

  • Beszel system offline or back, state Offline → send the message {{triggerEvent.data.system_name}} is offline.
  • Beszel alert, alert Temperature, state Triggered → switch on the fan of the server room.
  • Every morning at 8:00 → State of every Beszel system → send the summary.

Troubleshooting​

  • "does not answer": check the address and the port in a browser; a firewall may block port 8090.
  • "email or password refused": log into Beszel with them to check. A PocketBase superuser (the /_/ admin account) is not a Beszel user: use an account of the users collection.
  • "Connected, but this Beszel user sees no system": share the systems with the user (step 1) or set SHARE_ALL_SYSTEMS=true.
  • No alert ever fires: the alerts belong to the user the integration logs in with: set them in Beszel as this user.
  • "no Beszel hub at this address": another service answers there (another application, a reverse proxy without Beszel behind it).
  • No temperature: the agent reads no sensor (a VM, or an agent in Docker without access to the sensors).
  • More details with the LOG_LEVEL=debug environment variable on the integration.

Limits​

  • One Beszel hub per installation, 100 systems at most.
  • The summary of each system only: the containers, the extra disks, the GPU and the history of Beszel are not read.
  • Only the alerts of the configured user are seen.
  • Read every 30 seconds to 5 minutes, not in real time: the hub itself refreshes a system once a minute.
  • Not affiliated with Beszel or its authors.

Configuration settings​

These are the settings Beszel asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Beszel hubsectionNoEnter the address of your Beszel hub and the email and password of a Beszel user: every system this user sees becomes a device. A read-only user is enough. Then add the systems you want from the Discover tab.
Beszel addressstringNoAddress of the Beszel hub, the one of its web page (port 8090 by default): 192.168.1.20, nas.lan or https://beszel.example.com.
Email of the Beszel userstringNoBest: a user created for Gladys, with the read-only role, with whom the systems are shared.
PasswordsecretNoKept by Gladys, sent only to the Beszel hub.
OptionssectionNo
Refresh intervalselectNoHow often the Beszel hub is read. The hub itself refreshes each system once a minute.
Accept self-signed certificatesbooleanNoOnly for an https:// address (Beszel behind a reverse proxy) whose certificate your browser does not trust either.
Language of the namesselectNoLanguage of the feature names (set when a device is added), of the scene results and of the connection test.

How to install Beszel in Gladys​

  1. In Gladys, open Integrations: Beszel appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-beszel:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-beszel.

Beszel requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Beszel is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
