Bambu Lab smart home integration, free and open source

Bambu Lab integration for Gladys Assistant

Follow and control your Bambu Lab 3D printers locally: progress, temperatures, AMS, alerts.

View on GitHubAll external integrations

Follow and control your Bambu Lab 3D printers (X1, P1, A1, H2 and P2S series) from Gladys: state, progress, time left, layers, temperatures, AMS spools, HMS errors, chamber light, speed, pause and resume, camera image (P1 and A1). Everything stays on your local network: Gladys talks to the printer directly (encrypted MQTT on port 8883, like Bambu Studio in LAN mode), without the Bambu Lab cloud.

Developed without the hardware: the integration was tested against real printer reports (published by the ha-bambulab project) replayed by a real encrypted MQTT broker, but not on a physical printer yet. Feedback is welcome on the Gladys forum.

Requirements​

  • Gladys Assistant 5.1 or later.
  • A Bambu Lab printer on the same local network as Gladys.
  • Its serial number (printer settings, device information, or Bambu Handy / Bambu Studio) and its LAN access code (shown on the printer screen, in the network / WLAN settings).
  • To pause, resume, cancel or change the speed from Gladys with a recent firmware (X1 01.08.05, P1 01.08.02, A1 01.05 and later, the 2025 "Authorization Control"): turn on LAN only mode, then Developer mode on the printer. Without it, the printer refuses these commands; the state, the light and the camera work anyway. Note: in LAN only mode, Bambu Handy and remote printing through the cloud stop working. See the Bambu Lab wiki.

Configuration​

  1. Open the Configuration tab of the integration.
  2. Enter the Serial number (for example 01P00A000000000) and the Access code of the printer.
  3. IP address: optional. Left empty, Gladys listens to the printer's announcements on the network and finds it by itself (and follows it when its address changes). Enter it if the search does not find the printer. Save.
  4. The Find printers on the network button lists the printers that announce themselves: name, model, address, serial number, LAN mode.
  5. A second or third printer: fill in Printer 2 and Printer 3 the same way.
  6. Camera images (on by default): one image a minute during a print, and on demand, for the P1 and A1 series.
  7. Check the printer certificate (on by default): the connection is encrypted and the printer certificate is checked against the Bambu Lab authorities. Turn it off only if the connection fails with a certificate error (a very recent model).
  8. Language picks the language of the feature names and of the texts the integration creates (French by default). Feature names are set when the device is added to Gladys.

The Test the connection button gives, for each printer, its model, firmware and state, and whether the firmware refuses commands. Then add the printer from the Discover tab.

The printer device​

One device per printer, named after the name given to the printer (found by the network search) or after its model. The printer sends its state every second; the integration passes it on to Gladys at most every 5 seconds, and at once when the print state changes.

FeatureWhat it shows
StateReady, Preparing, Printing, Paused, Finished, Failed, Offline, Printer unreachable, Access code refused
FileThe name of the current print, or of the last one
ProgressPercentage of the print
Time leftEstimated by the printer, in minutes
Layer, Total layersLayer numbers (a scene can test "layer > 3")
Nozzle, BedTemperatures, in whole degrees, and their targets, read only
ChamberChamber temperature (X1, H2, P2S), and its target on the models with a heated chamber (X1E, H2)
Print speedList: Silent, Standard, Sport, Ludicrous (during a print)
Chamber lightSwitch
Pause, ResumePush buttons
HMS errors"No error", or the code and text of the first HMS error (and how many others)
CameraThe camera image (P1 and A1 series)

There is no cancel button on the device, on purpose: one tap without a confirmation would ruin a print. Cancelling is offered by the widget (with a confirmation) and by the scenes. The temperature targets are read only and the integration never heats: nothing can start heating from the dashboard, HomeKit, Alexa or Google. For Gladys they are "device temperatures": they never count in the room temperature. The light is a switch, not a lamp: a "turn off every light" scene does not plunge a print (and its timelapse) into the dark.

Dashboard widget​

Add the Bambu Lab 3D print widget to a dashboard and choose the printer in its settings. It shows:

  • the progress gauge, the time left, the nozzle and bed temperatures (live);
  • the last camera image (P1, A1);
  • the state, the file, the layer, the expected end time, the speed, the HMS errors;
  • the spools loaded in the AMS (AMS A1, AMS A2… AMS B1 for a second AMS): material, colour and estimated remainder, the one in use marked with a tick; otherwise the external spool;
  • the buttons that matter at the moment: Pause or Resume and Cancel (asks for a confirmation) during a print, Light on or Light off otherwise. When the firmware refuses commands, the widget says so ("Developer mode needed") instead of showing useless buttons.

Scene triggers​

In the Integrations category of the scene editor. Each can be limited to one printer.

  • Print started: variables printer name, file.
  • Print finished: variables printer name, file, print time (as text, like 1 h 05 min, and in minutes).
  • Print failed or cancelled: can be limited to a reason (cancelled, error). Variables printer name, file, print time, reason, error code and message.
  • Print paused: by someone or by the printer itself (filament runout, jam). Variables printer name, file, elapsed time, error code and message when there is one.
  • HMS error: a new alert of the printer's health monitoring. Can be limited to a severity (fatal, serious, common, information). Variables printer name, code (0300_0100_0001_0007), message (in the language of the integration), severity.

The variables are read in the following actions with, for example, {{triggerEvent.data.file}} and {{triggerEvent.data.message}}. The triggers follow the printer itself: a print started from Bambu Studio or paused on the screen fires them too.

Scene actions​

  • Pause, resume or cancel a print: returns Applied false when there was nothing to pause, resume or cancel (the scene goes on). Cancelling cannot be undone.
  • Turn the chamber light on or off: works without Developer mode too.
  • Change the print speed: Silent, Standard, Sport, Ludicrous; during a print only (Applied false otherwise).

Scene examples​

  • Print finished → notification: trigger Print finished, action "Send a message": {{triggerEvent.data.file}} done in {{triggerEvent.data.duration}}.
  • Smoke detected → stop everything: trigger on the smoke detector, actions Pause, resume or cancel a print (cancel), then turn off the smart plug of the printer.
  • Quiet at night: at 10 pm, Change the print speed (Silent); no effect when nothing prints.
  • Serious error → alert: trigger HMS error limited to the fatal and serious severities, action "Send a message": {{triggerEvent.data.printer}}: {{triggerEvent.data.message}}.

Troubleshooting​

  • Printer unreachable: check the IP address (printer screen, network settings), that the printer is on and on the same network as Gladys. Leave the address empty to let Gladys find it.
  • Access code or serial number refused: the access code may change (LAN mode turned off and on again, reset); enter it again. Check the serial number too (15 characters). After a refusal, the integration waits 5 minutes before trying again.
  • Unexpected certificate: a model more recent than the authorities the integration knows; turn off Check the printer certificate and report it on the forum. Without the check, Gladys no longer follows the printer when its address changes (a network announcement could be forged): enter its IP address.
  • "The printer firmware only accepts commands from Bambu Lab apps": turn on LAN only mode, then Developer mode on the printer (see Requirements).
  • The network search finds nothing: it listens to the printers' announcements for 10 seconds (UDP ports 1990 and 2021, through Gladys); a network that blocks broadcasts (VLAN, guest Wi-Fi) hides them. Enter the IP address then.
  • No camera image: only the P1 and A1 series have a camera reachable this way; Gladys refuses an image over 150 KB.
  • Logs: on the integration page in Gladys, or docker logs on the host. LOG_LEVEL=debug gives the details. The access code never appears in the logs.

Limits​

  • Three printers at most.
  • No file upload nor print start, no G-code commands, no temperature setting, no timelapse.
  • Camera: P1 and A1 series only (the X1, H2 and P2S series film over RTSPS, which the integration does not read), one image a minute during a print and on demand, no video stream.
  • H2D: the temperature shown is the one of the active nozzle.
  • The texts of the HMS errors come from the tables Bambu Lab publishes (as collected by ha-bambulab): a very recent code may show without text.
  • A print finished while the integration was disconnected fires no scene.
  • Developed without the hardware: feedback welcome.
  • Not affiliated with Bambu Lab.

Configuration settings​

These are the settings Bambu Lab asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Connect your Bambu Lab printersectionNoGladys talks to the printer on your local network, without the Bambu Lab cloud. On the printer screen, open the network settings: note the access code (and the IP address), and turn on LAN only mode with Developer mode if you want to pause, resume or cancel prints from Gladys (recent firmwares refuse these commands otherwise; reading always works). The serial number is in the device settings of the printer or in Bambu Handy. Up to three printers.
Serial numberstringYes
Access codesecretYesShown on the printer screen, in the network (WLAN) settings.
IP addressstringNoOptional: left empty, Gladys looks for the printer on the network.
Printer 2 (optional)sectionNoAnother Bambu Lab printer, connected the same way.
Serial number 2stringNo
Access code 2secretNoShown on the printer screen, in the network (WLAN) settings.
IP address 2stringNoOptional: left empty, Gladys looks for the printer on the network.
Printer 3 (optional)sectionNoAnother Bambu Lab printer, connected the same way.
Serial number 3stringNo
Access code 3secretNoShown on the printer screen, in the network (WLAN) settings.
IP address 3stringNoOptional: left empty, Gladys looks for the printer on the network.
OptionssectionNoLanguage of the names and texts the integration creates (feature names are set when a device is added).
Camera images (P1 and A1 series)booleanNoOne image a minute during a print, and on demand.
Check the printer certificatebooleanNoAgainst the Bambu Lab authorities. Turn it off only if the connection fails with a certificate error.
LanguageselectNo

How to install Bambu Lab in Gladys​

  1. In Gladys, open Integrations: Bambu Lab appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-bambulab:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-bambulab.

Bambu Lab requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Bambu Lab is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
