AWTRIX 3 smart home integration, free and open source

AWTRIX 3 integration for Gladys Assistant

AWTRIX 3 pixel clocks (Ulanzi TC001): notifications, Gladys values on screen, sensors.

View on GitHubAll integrations

This integration connects AWTRIX 3 pixel clocks to Gladys: the Ulanzi TC001 "Smart Pixel Clock" and the DIY ESP32 builds running the free AWTRIX 3 firmware. Gladys reads them and controls them over the local network, through their HTTP API. No cloud, no account, no MQTT broker needed.

Developed without the hardware: feedback welcome. The integration is built and tested against the AWTRIX 3 API as its firmware and documentation describe it, not against a real clock. Please report what works and what does not in the issues.

AWTRIX and this integration are not affiliated with Ulanzi.

Overview​

  • One device per clock: display on/off, brightness, automatic brightness, a "next app" button, the app on screen, and the clock's sensors (temperature, humidity, ambient light, battery, Wi-Fi signal, uptime).
  • Scene actions: show a notification (text, color, icon, duration, sound, wait for the button), keep a Gladys value on screen, light the three colored indicators, change the app on screen.
  • A dashboard widget with the app on screen, the sensors and four buttons: Message…, Next app, Display off / Display on, Dismiss.
  • The clocks are found on their own on the network (mDNS), or by their addresses.

Requirements​

  • Gladys Assistant 5.2.0 or later.
  • A clock running the AWTRIX 3 firmware. The integration follows the API of 0.98, its last release; update an older clock from its web interface. See the AWTRIX 3 documentation to flash an Ulanzi TC001.
  • AWTRIX NG, the successor firmware (2026), has a different API and is not supported: the integration recognizes it and says so.
  • The clock and Gladys on the same local network.

Configuration​

  1. In Gladys, open Integrations → Install from GitHub and enter https://github.com/guim31/gladys-awtrix (or install AWTRIX 3 from the catalog).
  2. In Configuration:
    • Find the clocks on the network (on by default): Gladys looks for the clocks that announce themselves in mDNS, and follows a clock whose address changes.
    • Clock addresses: the IP addresses or host names of your clocks, separated by commas (192.168.1.50, 192.168.1.51). Useful when mDNS does not cross your network, or to keep a fixed address.
    • Username and Password: only if you set "Auth Username" and "Auth Password" in the web interface of the clocks. The same for all clocks.
    • Refresh interval: how often the clocks are read (30 seconds by default).
    • Language of the feature names: the names given to the features when you add a device, and the messages of the integration.
  3. Click Test the connection: each clock found is listed with its firmware and the app on screen.
  4. In the Discover tab, add the clocks to Gladys.

Each reading is two small HTTP requests per clock (/api/stats and /api/settings), sent one after the other: a clock is an ESP32 and serves one request at a time. There is no quota; keep the interval at 15 seconds or more.

Devices​

Each clock is a device named "AWTRIX" followed by the end of its identifier (for example AWTRIX 3c1a2b). Its identity is the clock's own identifier, not its address: a new IP address keeps the device and its history.

FeatureWhat it does
DisplayTurns the matrix on or off. The clock keeps running.
Brightness0 to 100 %. Setting it turns the automatic brightness off, or the clock would override it at once.
Automatic brightnessThe clock follows the ambient light.
Next appA button: shows the next app, like the right button of the clock.
Current appThe app on screen: Time, Date, Temperature, a custom app, Notification...
TemperatureIn °C. Only when the clock reports it (Ulanzi TC001, or a DIY build with a sensor).
HumidityIn %. Same condition.
Ambient lightIn lux, from the light sensor of the clock.
BatteryIn %. Ulanzi TC001 only.
Wi-Fi signal (dBm)The signal received by the clock, in dBm (−50: excellent, −80: weak).
UptimeHours since the last restart of the clock.

The names above are the English ones; the language chosen in the configuration gives "Écran", "Anzeige", "Pantalla"...

Widget​

Add the AWTRIX clock widget to a dashboard. It shows the app on screen, the display, the brightness and the Wi-Fi signal, with the temperature and the humidity when the clock has them. Choose one clock in its settings, or leave it empty for all of them (one line each).

Its four buttons act on the chosen clock, or on all of them:

  • Message…: opens a form (text, color, duration) and shows the text on the clock.
  • Next app: the next app of the rotation.
  • Display off / Display on: turns the matrix off or back on.
  • Dismiss: removes a notification that waits for the button.

Scene actions​

Every action targets one clock, or every clock when the clock field is left empty. Each one returns the number of clocks reached ("Clocks reached"), and fails when none accepted it.

  • Show a notification on AWTRIX: a text shown once over the apps. Options: text color (or rainbow), an icon, the duration, what a long text does (scrolls through once, scrolls for the duration, does not scroll), a sound, stay until the middle button is pressed, wake the display if it is off. Type {{ in the text to insert a value of the scene.
  • Dismiss the AWTRIX notification: removes a notification that waits for the button.
  • Show a value on AWTRIX: creates or updates a custom app that stays in the rotation of the clock. The same name updates the same app. Options: color, icon, a progress bar (0-100), and "Remove after (minutes)": the app disappears if the scene stops updating it, so an old value never stays on screen.
  • Remove a value from AWTRIX: removes that custom app.
  • Set an AWTRIX indicator: lights one of the three colored dots on the right of the screen (1 top right, 2 right, 3 bottom right), steady, blinking or fading, or turns it off.
  • Next AWTRIX app: the next app of the rotation.
  • Show an AWTRIX app: jumps to an app by its name (Time, Date, Temperature, Humidity, Battery or a custom app).

Icons are LaMetric icon ids that you first download on the clock: web interface of the clock, Icons tab, enter the id (for example 2422), download. Sounds are an RTTTL melody typed in the field (beep:d=16,o=6,b=120:c,e), or the name of a melody file of the clock (MELODIES folder), played by the buzzer of the Ulanzi TC001.

Scene triggers​

None. The buttons of the clock report their presses over MQTT, or by an HTTP call to an address the integration cannot offer from its container. Gladys still sees what the buttons change: the app on screen and the display are device states you can use in a scene.

Scene examples​

  • Outdoor temperature always on screen: trigger "a device value changes" on your outdoor sensor → action Show a value on AWTRIX, name outdoor, text {{trigger value}} °C (insert it with {{), icon of a thermometer, Remove after 60 minutes.
  • Washing machine done: trigger on the power of the machine plug falling below 5 W → Show a notification on AWTRIX "Laundry done", green, a sound, Stay until the button is pressed.
  • Night mode: at 23:00, set the Display of the clock to off; at 7:00, back on. Or keep it on with Brightness at 5 %.
  • Door left open: when the front door opens, Set an AWTRIX indicator 1 red, blinking; when it closes, indicator 1 off.

Troubleshooting​

  • No clock found: mDNS does not always cross Wi-Fi access points or VLANs. Enter the address of the clock in Clock addresses. The address is shown on the clock at startup, and in your router.
  • "does not answer": the clock is off, on another network, or its address changed. With discovery on, Gladys looks for it again every 10 minutes.
  • "username or password refused": the clock has "Auth Username" set; enter the same username and password in the configuration.
  • "AWTRIX NG firmware": the clock runs AWTRIX NG, not supported.
  • The temperature is too high: the sensor of the Ulanzi TC001 is heated by the clock itself. AWTRIX 3 offers a temperature offset in its dev.json file (temp_offset).
  • An icon does not show: download it on the clock first (web interface, Icons tab).
  • More details: set LOG_LEVEL=debug on the integration; the logs never contain the password.

Limits​

  • Developed without the hardware: tested against the documented API and a simulated clock only.
  • AWTRIX 3 only; AWTRIX NG is not supported.
  • No trigger for the buttons of the clock (MQTT only).
  • One username and password for all the clocks.
  • Plain HTTP only, as AWTRIX 3 serves it: keep the clocks on a trusted network.
  • The brightness of a clock with automatic brightness on moves with the light: Gladys shows the value read at each refresh.

Report a problem or an idea in the issues.

Configuration settings​

These are the settings AWTRIX 3 asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your AWTRIX 3 clockssectionNoClocks running the AWTRIX 3 firmware (Ulanzi TC001 or a DIY build), on the local network. Gladys finds them on its own (mDNS); otherwise enter their addresses. AWTRIX NG is not supported.
Clock addressesstringNoIP addresses or host names, separated by commas. Optional when Gladys finds your clocks.
Find the clocks on the networkbooleanNoGladys looks for the clocks announcing themselves in mDNS, and follows a clock whose address changes.
Password protectionsectionNoOnly if you set an "Auth Username" and "Auth Password" in the web interface of the clocks (the same for all of them). Leave empty otherwise.
UsernamestringNo
PasswordsecretNo
OptionssectionNoThe clocks are read over the local network only, one request at a time.
Refresh intervalselectNoHow often the clocks are read (sensors, display, current app).
Language of the feature namesselectNoNames given to the features when a device is added, and messages of the integration.

How to install AWTRIX 3 in Gladys​

  1. In Gladys, open Integrations: AWTRIX 3 appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-awtrix:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-awtrix.

AWTRIX 3 requires Gladys >=5.2.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

AWTRIX 3 is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
