Awair smart home integration, free and open source
Awair air quality monitors over their Local API: score, CO2, VOC, PM2.5, temperature, humidity.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Overview
This integration brings the Awair air quality monitors into Gladys: Awair Element, Awair Omni, Awair 2nd Edition, Awair Mint and Awair Glow C, read on your own network through their Local API. Each sensor becomes a Gladys device with its Awair score, temperature, humidity, CO2, VOC, fine particles and, depending on the model, light and noise.
Sensors without a Local API (first-generation Awair, Awair Glow) can be read through the Awair cloud with a developer token, as an option.
Everything is read only: the integration never changes a setting of your sensors.
Developed without the hardware: feedback welcome. The integration was built from the Awair API documentation and from real answers of the sensors recorded by other open-source projects. If something looks wrong with your model, open an issue on the GitHub repository.
This integration is not affiliated with Awair.
Requirements
- Gladys Assistant 5.1.0 or later.
- For each sensor, the Local API enabled in the Awair Home app: open the sensor, then Awair+ → Awair APIs → Local API, and enable it.
- The sensors on the same network as Gladys. A fixed IP address (DHCP reservation in your router) is recommended but not required.
- Optional: an Awair developer token, only for the sensors without a Local API.
Configuration
Open Integrations → Awair → Configuration.
- Click Search for sensors. The integration asks Gladys to browse the network (mDNS) and reads every Awair sensor it finds. The report under the button lists them, with their address.
- Open the Discovery tab and add the sensors you want in Gladys.
| Setting | Use |
|---|---|
| Sensor IP addresses | Only for a sensor the search does not find. Several addresses separated by commas. |
| Local refresh interval | 10 s, 30 s (default), 1 min or 5 min. The sensor itself updates its values every 10 seconds. |
| Awair access token | Optional. Token of the Awair developer console, for the sensors without a Local API. |
| Cloud refresh interval | 5 min (default), 10, 15 or 30 min. |
| Language of the integration | Names of the features of the devices added afterwards, and texts of the scene action. French by default. |
Awair cloud quota
The Awair developer API counts the calls per day. The Hobbyist tier, the free one, allows 300 "latest" calls a day: 5 minutes between two readings of a sensor is the fastest pace that stays within it. The integration reads the quota of your account and never goes faster than it allows, spread over all your cloud sensors. If the API still answers "quota exceeded", the sensor is left alone for an hour. A sensor reachable through the Local API is always read locally, and costs no quota.
Devices
One device per sensor, named after its model until you rename it. Its features are the measurements the sensor actually reports; as a guide:
| Feature | Unit | Models |
|---|---|---|
| Awair score | 0-100 | all |
| Air quality | band | all: good (80+), fair (60-79), poor (below 60) |
| Temperature | °C | all |
| Humidity | % | all |
| CO2 | ppm | Element, Omni, 2nd Edition, Glow, first generation |
| VOC | ppb | all |
| PM2.5 | µg/m³ | Element, Omni, 2nd Edition, Mint |
| PM10 | µg/m³ | Element and 2nd Edition (value estimated by the sensor) |
| Dust | µg/m³ | first generation (one sensor for PM2.5 and PM10) |
| Light | lux | Omni, Mint |
| Noise | dBA | Omni |
| Dew point | °C | Element (Local API) |
| Battery | % | Omni (Local API) |
| Plugged in | yes/no | Omni (Local API) |
When the sensor gives both a measured and an estimated value (CO2, PM10), the measured one is used. The Air quality band is shown in color on the dashboard: green, yellow, orange.
The values only changing are sent to Gladys, plus every value at least every 6 hours so that none looks old.
Dashboard widget
Air quality: choose a sensor in the widget settings. The widget shows the Awair score as a gauge, CO2, PM2.5 (or dust), temperature and humidity as live tiles, then the air quality band and the connection (local, cloud or unreachable).
Scene triggers
- Awair sensor lost: the sensor stopped answering, three failed readings in a row (unplugged, out of Wi-Fi, Local API disabled). Choose one sensor or leave the field empty for all. The scene receives the sensor name.
- Awair sensor back: a sensor counted as lost answers again.
The values themselves (score, CO2...) need no trigger: use the standard "device value" trigger of Gladys on the device features.
Scene action
Read the air quality: reads the sensor at once and gives the next actions of the scene:
summary: a ready-made sentence, for example "Office: air quality good (score 92/100), CO2 650 ppm, PM2.5 3 µg/m³, 21.5 °C, 45 % humidity.";score,co2,pm25,temperature,humidity: the values;level:good,fairorpoor, to compare in a condition.
The sentence follows the language of the integration configuration.
Scene examples
- Open the windows: trigger "device value" on CO2 above 1200 ppm → send a message "Time to air the room".
- Morning report: every day at 7:30 → action "Read the air quality" →
send a message with
summary. - Ventilation: when the Air quality band becomes "poor" → turn on the ventilation plug; when it is back to "good" → turn it off.
- Watch the sensor: trigger "Awair sensor lost" → send a message with the sensor name.
Troubleshooting
- No sensor found: check that the Local API is enabled in the Awair Home app, then enter the IP address of the sensor in the configuration. The address is shown in the Awair Home app, or in your router.
- "Automatic discovery (mDNS) through Gladys is unavailable": your Gladys does not relay mDNS. Enter the IP addresses.
- A sensor changed address: the integration searches again by itself when a sensor stops answering, at most every 10 minutes. You can also click Search for sensors.
- "The Awair cloud refused the token": copy the token again from the Awair developer console.
- Logs: the integration only writes what matters. For every reading, set
the environment variable
LOG_LEVEL=debug.
Limits
- Read only: the display, the LED and the other settings of the sensor stay in the Awair Home app.
- The Wi-Fi signal of the sensor is not available: the Local API does not give it.
- The first-generation Awair and the Awair Glow have no Local API: they need the cloud token, and are read every 5 minutes at best.
- Only the Local API answers of the Element and of the Omni could be checked against real recordings; the other models are expected to answer the same way.
- Feature names are set when the device is added: changing the language later does not rename them.
Configuration settings
These are the settings Awair asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Finding your sensors | section | No | First enable the Local API of each sensor in the Awair Home app (Awair+, Awair APIs, Local API). Sensors on the same network as Gladys are then found automatically (mDNS): open the Discovery tab. If one is missing, enter its IP address below. |
| Sensor IP addresses | string | No | Optional, separated by commas. Only needed for the sensors automatic discovery does not find. |
| Local refresh interval | select | No | How often the sensors are read over the network. The sensor itself updates every 10 seconds. |
| Awair cloud (optional) | section | No | Only for the sensors without a Local API (first-generation Awair, Glow): paste the token of the Awair developer console. Its daily quota limits the pace: 5 minutes at best. Sensors reachable locally are always read locally. |
| Awair access token | secret | No | |
| Cloud refresh interval | select | No | |
| Language of the integration | select | No | Names of the features of a newly added device, and texts of the scene action. |
How to install Awair in Gladys
- In Gladys, open Integrations: Awair appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-awair:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-awair.
Awair requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Awair is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
- Browse all integrations, native and community
- Build and publish your own external integration
- Source code on GitHub — source of this documentation
