APC UPS Daemon smart home integration, free and open source
APC UPSs monitored by apcupsd: power outages, battery, runtime, load, power and energy.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Follow your APC UPSs in Gladys through apcupsd, the daemon Unraid, many NAS and Linux servers use to watch their UPS: power outages, battery charge, runtime, load, voltages, an estimate of the power drawn by your equipment and its energy. Scenes can react to a power outage, to the power coming back, to a low battery and to a battery to replace.
Tested on real hardware: an APC Smart-UPS SRT connected over USB to an Unraid server running apcupsd 3.14. It was also built and tested against real apcupsd answers published by other projects. If something looks wrong with your model, open an issue on GitHub with the output of
apcaccess status(hide the serial number).
This integration is not affiliated with APC or Schneider Electric.
Requirements
- Gladys Assistant 5.1.0 or later.
- A UPS connected (USB or serial cable) to a computer running apcupsd: a Linux server, a NAS, an Unraid server, a Raspberry Pi…
- The network information server (NIS) of apcupsd turned on and listening
on the network, on port 3551 (the default). This is the read-only service
apcaccessand Home Assistant use.
apcupsd on Linux or Windows
In apcupsd.conf (usually /etc/apcupsd/apcupsd.conf), check these three
lines:
NETSERVER on
NISIP 0.0.0.0
NISPORT 3551
NISIP 127.0.0.1 (the default on some distributions) only answers the
computer itself: Gladys, in its container, is refused. Restart apcupsd after
the change (sudo systemctl restart apcupsd), then check from another computer
that port 3551 answers.
Unraid
Unraid runs apcupsd itself: open Settings → UPS Settings, turn on the
network server option ("Enable network server") and apply. If the integration
still gets "connection refused", the server listens on the Unraid computer
only: check the NISIP line of /etc/apcupsd/apcupsd.conf on Unraid.
Configuration
In Gladys, open Integrations → APC UPS Daemon → Configuration:
- apcupsd servers: the IP address of the computer running apcupsd, followed
by
:portif the port is not 3551. One apcupsd serves one UPS: for several UPSs, enter several servers separated by commas, for example192.0.2.10, 192.0.2.11:3552. Prefer IP addresses:.localnames do not resolve inside the integration container. - Refresh interval: 5, 10 (default), 30 seconds or 1 minute. A power outage is seen within this delay.
- Language of the device texts: the language of the feature names of new devices and of the texts the UPS shows (state, last transfer reason). French by default.
The Check the servers button reads every server and says which ones answer, with their model, or why they do not.
Then open the Discovery tab and add your UPS to Gladys.
The UPS device
Each UPS is a device. A feature only exists when your UPS reports the matching value (a Back-UPS has no internal temperature, an old Smart-UPS no nominal power). Everything is read-only: the network server of apcupsd cannot send commands, and no button switches a UPS off.
| Feature | What it shows |
|---|---|
| State | The state in words: On mains, On battery, Low battery, Replace battery, Overload… |
| Mains power | On (1) on mains, Off (0) during a power outage: the value to use in scene conditions |
| Low battery | Yes when the UPS says the battery is low: shutdown is near |
| Battery charge | Battery charge, in % |
| Runtime | Runtime left on battery, in minutes, as the UPS estimates it |
| Load | Load of the UPS, in % of its capacity |
| Power | Power drawn by your equipment, in W, estimated: load × nominal power |
| Energy | Cumulative energy, in kWh, computed from the power (see below) |
| Input / output / battery voltage | In volts |
| Internal temperature | In °C |
| Time on battery / Total time on battery | Current outage, and since apcupsd started, in seconds |
| Transfers | Number of transfers to battery since apcupsd started |
| Last transfer / Last transfer reason | Date and reason of the last transfer to battery (self-test, low mains voltage…) |
| Battery date, Model, Serial number | As the UPS reports them |
Energy tracking
apcupsd gives a load in percent, not an energy meter. When the UPS reports its nominal power, the integration estimates the power (load × nominal power) and adds it up over time into an Energy index, in kWh. Gladys turns this index into a consumption every 30 minutes and its cost, like a smart plug: the Energy screen of Gladys then shows what your server corner uses. The index is kept in the integration's data, so it never goes backwards when the integration restarts. It is an estimate: count on a few percent of error, and more at very low load.
Widget
The UPS widget shows, for the UPS chosen in its settings (the first one added by default), the state in words with a color (green on mains, orange on battery or battery to replace, red for a low battery, an overload or a lost UPS), the last transfer, and live tiles for the battery charge, the runtime, the load and the estimated power.
Scene triggers
Four triggers, in the scene editor under the integration's name. Each one can watch one UPS, or any UPS when the field is left empty.
| Trigger | When | Variables |
|---|---|---|
| UPS: power outage | the UPS switches to battery | UPS name, battery charge, runtime |
| UPS: power restored | the UPS is back on mains after an outage | UPS name, battery charge, outage duration |
| UPS: battery low | the UPS reports a low battery | UPS name, battery charge, runtime |
| UPS: replace the battery | the UPS asks for a new battery | UPS name, battery date |
A trigger fires once per change, never on the first reading after a start. A change that happens while the integration restarts still fires, as long as the restart takes less than 30 minutes.
Scene examples
Warn me of a power outage
Trigger UPS: power outage, action Send a message: "Power outage!
[UPS name] is on battery, [Battery charge] % left, about [Runtime] minutes."
The words in brackets are the trigger variables: type {{ in the message to
insert them.
Turn off what is not needed during an outage
Trigger UPS: power outage, actions: turn off the plugs of the screens, the printer and the lights the UPS feeds, to make the battery last.
Tell me when the power is back
Trigger UPS: power restored, action Send a message: "Power is back after [Outage duration] seconds."
Troubleshooting
- "connection refused": the network server of apcupsd is off, or listens on
the apcupsd computer only (
NISIP 127.0.0.1). See the requirements. - "no answer": wrong address or port, or a firewall between Gladys and the apcupsd computer. Port 3551 must be open in TCP.
- "unknown host name": enter the IP address instead of the name.
- The State says "UPS not responding": apcupsd answers, but lost the UPS itself (USB cable, driver). Look at the apcupsd computer.
- No Power nor Energy feature: your UPS does not report its nominal power
(
NOMPOWERinapcaccess status). - Logs: the integration only writes its start, the servers found, outages
and errors. Set
LOG_LEVEL=debugon the container to see every read.
Limits
- An outage shorter than the refresh interval can be missed (the Transfers counter still counts it).
- The power and the energy are estimates, not measurements.
- The Transfers counter and the times on battery start again from zero when apcupsd restarts.
- Read-only: no self-test, no shutdown, no setting changes from Gladys.
- Tested on one real UPS (Smart-UPS SRT over USB) and on real apcupsd statuses (Back-UPS ES 600, SMART-UPS 1400, an old apcupsd 3.8) and a simulated server.
- For a UPS watched by NUT instead of apcupsd, use a NUT integration.
Configuration settings
These are the settings APC UPS Daemon asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Before you start | section | No | Gladys reads your UPS through the network server (NIS) of apcupsd, on port 3551. It must listen on the network: set NISIP 0.0.0.0 in apcupsd.conf and restart apcupsd (on Unraid, enable the network server in the UPS settings). |
| apcupsd servers | string | Yes | IP address of the computer running apcupsd, with :port if it is not 3551. Several servers (one per UPS) are separated by commas. |
| Refresh interval | select | No | How often the UPS is read. A power outage is seen within this delay. |
| Language of the device texts | select | No | Names of the features of new devices, and the texts the UPS shows (state, last transfer reason). |
How to install APC UPS Daemon in Gladys
- In Gladys, open Integrations: APC UPS Daemon appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-apcupsd:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-apcupsd.
APC UPS Daemon requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
APC UPS Daemon is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
